Page 1 COLOR VIDEO CAMERA BVP-9500WS BVP-9500WSP MAINTENANCE MANUAL 1st Edition (Revised 1) Serial No. 10001 and Higher: BVP-9500WS (UC) Serial No. 30001 and Higher: BVP-9500WS (J) Serial No. 40001 and Higher: BVP-9500WSP (CE)
Page 2 électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. BVP-9500WS/9500WSP MM...
Page 3: Table Of Contents
RET/MIC INCOM Switches ..........1-32 (E) 1-6-4. TALLY Switch..............1-33 (E) 1-6-5. FILTER LOCAL/ND/CC Switches ........1-34 (E) 1-6-6. RET 1 Switch ..............1-35 (E) 1-6-7. MIC POWER Switch ............1-35 (E) 1-7. Replacement of Filter Disk Unit ............1-36 (E) 1 (E) BVP-9500WS/9500WSP MM...
Page 4 Lens File Setup page ............2-6 (E) 2-2-5. OHB File Setup page ............2-7 (E) 2-2-6. Auto Iris Setup page ............. 2-8 (E) 2-2-7. Super Motion Setup page ............. 2-8 (E) 2-2-8. OHB Trimming page ............2-9 (E) 2 (E) BVP-9500WS/9500WSP MM...
Page 5 AD Gain Adjustment............3-37 (E) 3-4-3. V Modulation Balance Adjustment ........3-38 (E) 3-4-4. AD PHASE Adjustment ............. 3-40 (E) 3-5. Filter Positioning Adjustment ............. 3-41 (E) 3-6. Adjustment After Replacement of ND Filter ........3-42 (E) 3 (E) BVP-9500WS/9500WSP MM...
Page 6 PA-226 ......................6-7 SH-69 ......................6-8 VA-189 ......................6-8 TG-194 ......................6-9 VA-200 ...................... 6-10 AD-157 ...................... 6-11 MEM-98 ....................6-12 DA-143 ...................... 6-13 PR-248 ....................... 6-15 PR-249 ....................... 6-17 EN-141 ...................... 6-18 AT-128 ...................... 6-20 4 (E) BVP-9500WS/9500WSP MM...
Page 7 CN-1928 ....................7-80 CN-1929 ....................7-80 CN-1930 ....................7-81 CN-2045 ....................7-81 SW-1008 ....................7-81 SW-1009 ....................7-81 Frame Wiring .................... 7-82 SW-936 ....................7-82 SW-1010 ..................... 7-82 SW-1011 ..................... 7-82 SW-937 ....................7-83 CN-2095 ..................... 7-84 5 (E) BVP-9500WS/9500WSP MM...
Page 8 PS-554 ....................... 8-29 SH-69 ......................8-31 SW-936 ..................... 8-33 SW-937 ..................... 8-33 SW-1008 ....................8-33 SW-1009 ....................8-33 SW-1010 ....................8-33 SW-1011 ....................8-33 TG-194 ...................... 8-35 TG-203 ...................... 8-37 VA-189 ...................... 8-39 VA-200 ...................... 8-41 6 (E) BVP-9500WS/9500WSP MM...
Page 9: Manual Structure
Relative manuals Besides this “maintenance manual” the following manuals are available for this unit..BVP-9500WS/9500WSP Operation Manual (Supplied with this unit) This manual is necessary for application and operation of this unit..BVP-9500WS/9500WSP Installation and Maintenance Manual...
Page 10: Contents
Describes overall block diagram and the block diagrams for every circuit board. Section 7 Schematic Diagrams Describes schematic diagrams for every circuit board and frame wiring. Section 8 Board Layouts Describes board layouts for every circuit board. 8 (E) BVP-9500WS/9500WSP MM...
Page 11: Service Overview
Section 1 Service Overview 1-1. Circuit Description The electrical circuit of the BVP-9500WS/9500WSP consists of the following blocks. This section describes each block separately. . CCD drive block . Power supply block . Video signal processing block . System control block...
Page 12 The x3 speed signals above are input to the memory and then output from the memory as follows. x1 speed signal after conversion Line 1 output 1 field 4 field Line 2 output 2 field 5 field Line 3 output 3 field 6 field 1-2 (E) BVP-9500WS/9500WSP MM...
Page 13 Digital signals input to the DA-143 board are x1 speed signals. They are therefore converted from x1 speed to x3 speed in the memory circuit. Signals converted to x3 speed are DA-converted and output to the VA-200 board. 1-3 (E) BVP-9500WS/9500WSP MM...
Page 14 . Transmits camera head information such as self-diagnosis results and iris position to the CCU . Control of various files . Transmission and reception of OHB files with the microprocessor in the CCD unit . Auto setup . Generation of characters for the viewfinder 1-4 (E) BVP-9500WS/9500WSP MM...
Page 15: Function Of Internal Switches
Never change the settings of the “Factory use” switches. Ref. No. Switch name Description Factory setting — Factory use Momentary BLM CORRECT OFF Press this switch to check for RPN Momentary correction points. — Factory use Fully clockwise 1-5 (E) BVP-9500WS/9500WSP MM...
Page 16: Tg-203A Board
TG-203A BOARD (B SIDE) Ref. No. Switch name Description Factory setting S1-1 To be fixed according to model N (BVP-9500WS) N: NTSC model (BVP-9500WS) P (BVP-9500WSP) P: PAL model (BVP-9500WSP) S1-2 to 4 — Not used 1-6 (E) BVP-9500WS/9500WSP MM...
Page 17: Board
1-2. Function of Internal Switches 1-2-3. DA-143 board DA-143 BOARD (B SIDE) Ref. No. Switch name Description Factory setting — Factory use (for programming FPGA) Don’t care. For detail contact Sony Sales Office/Service Center. 1-7 (E) BVP-9500WS/9500WSP MM...
Page 18: Board
Q/U signal ON/OFF switch Use when adjusting VBS Q/U signals. S600-2 I/V signal ON/OFF switch Use when adjusting VBS I/V signals. S601-1 Chroma signal ON/OFF switch Use when setting chroma signals to OFF. S601-2 — Not used 1-8 (E) BVP-9500WS/9500WSP MM...
Page 19: Board
S3-4 ON/OFF Set to ON when the OHB Trimming page of the maintenance menu is displayed. (Refer to Section 2.) Be sure to reset this switch to OFF after using the OHB trimming page during adjustment. 1-9 (E) BVP-9500WS/9500WSP MM...
Page 20: Notes On Service
If the flash memory requires replacing, be sure to replace it with written one. For details, contact your local Sony Sales Office/Service Center. 1-3-2. Note on Replacement of EEPROM The stored data of EEPROM on the AT-128 board is as shown below.
Page 21: Note In Replacing The Tg-194 Board
To remove a PROM, remove its socket frame. This socket frame is so fragile. When removing the socket frame, therefore, it is recommended to use a special removing tool listed below. IC socket removing tool: Sony part No. J-6394-110-A Socket frame: Sony part No. 1-540-194-12 If it is not available, use a small slotted screwdriver or similar item as a substitute for it.
Page 22: Precautions On Heat Radiation Spring
PS-553 and/or PS-554 board, be very careful not to distort the spring. Also when installing the board, make sure that the heat radiation spring is touching the chassis. Heat radiation spring Heat radiation spring PS-553 board PS-554 board 1-12 (E) BVP-9500WS/9500WSP MM...
Page 23: Replacing The Fan
This unit is provided with the five fans. They are recommended to be replaced every two years. Sony part No. : 1-698-236-3X 1-4-1. Replacing the Fans of the Left Panel 1. Remove the left panel, and remove the CN-2045 board and two fan assemblies. (Refer to Section 2-1 in the Installation and Maintenance Manual.)
Page 24 Fan holder 5. Install the new fan in the reverse order of removal. [Note|at|installation] Install the fan to the fan holder with care so that the label faces the bracket as shown in the figure for step 1-14 (E) BVP-9500WS/9500WSP MM...
Page 25: Replacing The Front Fan
1. Remove the CCD unit. (Refer to Section 1-9-3.) 2. Lift up the spring of the fan assembly, and remove the fan assembly. Fan assembly Spring 3. Disconnect the harness connector from the CN3 connector on the CN-1930 board. CN-1930 board Fan assembly 1-15 (E) BVP-9500WS/9500WSP MM...
Page 26 Fan bracket 6. Install the new fan in the reverse order of removal. [Note|at|installation] Install the fan to the fan holder with care so that the label faces the bracket as shown in the figure for step 1-16 (E) BVP-9500WS/9500WSP MM...
Page 27: Replacing The Top Fan
1. Remove the both side panels. (Refer to Section 1-4 in the Installation and Maintenance Manual.) 2. Disconnect the harness connector from the CN13 connector of the MB-830 board. MB-830 board CN13 3. Loosen one screw, and pull out the fan assembly. Fan assembly Screw 1-17 (E) BVP-9500WS/9500WSP MM...
Page 28 Fan bracket 6. Install the new fan in the reverse order of removal. [Note|at|installation] Install the fan to the fan holder with care so that the label faces the bracket as shown in the figure for step 1-18 (E) BVP-9500WS/9500WSP MM...
Page 29: Replacing External Connectors
1. Remove the CCD unit. (Refer to Section 1-9-3.) 2. Remove the front fan assembly. (Refer to Section 1-4-2.) 3. Loosen the three screws to remove the shoulder pad assembly. B3 x 8 (With stopper) B4 x 12 (With stopper) Shoulder pad assembly 1-19 (E) BVP-9500WS/9500WSP MM...
Page 30 5. Remove the two screws and pull out the CN-1928 board. 6. Disconnect the harness from the CN2 connector on the CN-1928 board. OHB connector CN-1928 board B2 x 6 7. Install a new CN-1928 board in the reverse order of removal. 1-20 (E) BVP-9500WS/9500WSP MM...
Page 31: Analog/Digital Ca Connectors
4. Remove the four screws, and remove the board bracket. Precision P2.6 x 5 Precision P2.6 x 5 Board bracket Precision P2.6 x 5 5. Remove the five screws securing the ANALOG/DIGITAL CA connectors. Precision P2 x 4.5 Precision P2 x 4.5 ANALOG/DIGITAL CA connectors 1-21 (E) BVP-9500WS/9500WSP MM...
Page 32 1-5. Replacing External Connectors 6. Disconnect the harness connector from the CN6 connector on the CN-1787 board and pull out the CN-1787 board. CN-1787 board 7. Install a new CN-1787 board in the reverse order of removal. 1-22 (E) BVP-9500WS/9500WSP MM...
Page 33: Vf Connector
1. Remove the board bracket. (Refer to steps 1 to 5 of Section 1-5-2.) 2. Remove the two screws (Precision P2.6 x 10) and pull out the VF connector with harness. VF connector Precision P2.6 x 10 3. Install a new VF connector in the reverse order of removal. 1-23 (E) BVP-9500WS/9500WSP MM...
Page 34: Remote Connector
4. Remove the two screws securing the REMOTE connector, and remove the REMOTE connector. 5. Desolder the REMOTE connector. REMOTE connector CN-1930 board Connector cap Precision P2.6 x 8 6. Install a new REMOTE connector in the reverse order of removal. 1-24 (E) BVP-9500WS/9500WSP MM...
Page 35: Test Out Connector
Precision P2.6 x 8 9. Desolder the TEST OUT connector. 10. Remove the nut to remove the TEST OUT connector. TEST OUT connector 11. Install a new TEST OUT connector in the reverse order of removal. 1-25 (E) BVP-9500WS/9500WSP MM...
Page 36: Mic 1 Connector
Pin 1 : MIC (G) shielding Pin 2 : MIC (X) red RK3 x 6 Pin 3 : MIC (Y) white RK3 x 6 4. Install a new MIC 1 connector in the reverse order of removal. 1-26 (E) BVP-9500WS/9500WSP MM...
Page 37: Lens Connector
P2.6 x 5 CN-1927 board LENS connector 6. Install a new LENS connector in the reverse order of removal. [Note|at|installation] When installing the LENS connector, check that pin 1 is on the upper side of connector. 1-27 (E) BVP-9500WS/9500WSP MM...
Page 38: Replacing Function Switches
3. Open the lid. Remove the four screws, and remove the side switch panel. 4. Remove the seven cushions. 5. Remove the shield spring (SW). (For BVP-9500WSP only.) Cushions Side switch panel Shield spring (SW) Precision For BVP-9500 WSP only P2.6 x 8 Knob Precision P2.6 x 8 1-28 (E) BVP-9500WS/9500WSP MM...
Page 39 8. Remove the seven nuts, seven washers, one spacer and one nut, and remove the SW-1008 board from the switch bracket. 9. Desolder a switch or control that needs to be replaced. SW-1008 board Switch bracket Washers Nuts Washers Nuts Spacer 1-29 (E) BVP-9500WS/9500WSP MM...
Page 40 Fit the screw hole of the side switch panel to the screw hole of the lid as the figure, and attach a side switch panel. Side switch panel Precision P2.6 x 8 Precision P2.6 x 8 1-30 (E) BVP-9500WS/9500WSP MM...
Page 41: Front Switch Panel Block
3. Remove the two screws, and remove the SW-1009 board. 4. Desolder a switch that needs to be replaced. SW-1009 board PTP2.6 x 8 Front switch panel 5. Install a new switch in the reverse order of removal. 1-31 (E) BVP-9500WS/9500WSP MM...
Page 42: Ret/Mic Incom Switches
2. Disconnect the harness connectors from the CN1 and CN2 connectors on the SW-936 board. 3. Remove the two screws to remove the SW-936 board. 4. Desolder a switch that needs to be replaced. PTP2.6 x 6 SW-936 board 5. Install a new switch in the reverse order of removal. 1-32 (E) BVP-9500WS/9500WSP MM...
Page 43: Tally Switch
2. Remove the two screws, and remove the SW-937 board. 3. Disconnect the harness connector from the CN1 connector on the SW-937 board. 4. Desolder the TALLY switch. PTP2.6 x 6 SW-937 board 5. Install a new TALLY switch in the reverse order of removal. 1-33 (E) BVP-9500WS/9500WSP MM...
Page 44: Filter Local/Nd/Cc Switches
3. Disconnect the harness connector from the CN1 connector on the SW-1011 board. 4. Desolder a switch that needs to be replaced. SW-1011 board PS2.6 x 8 5. Install a new switch in the reverse order of removal. 1-34 (E) BVP-9500WS/9500WSP MM...
Page 45: Ret 1 Switch
1. Remove the CN-1927 board. (Refer to steps 1 to 4 Section 1-5-7.) 2. Desolder the MIC POWER switch. Precision P2.6 x 5 CN-1927 board MIC POWER switch 3. Install a new MIC POWER switch in the reverse order of removal. 1-35 (E) BVP-9500WS/9500WSP MM...
Page 46: Replacement Of Filter Disk Unit
. At installation, do not touch the surfaces of filters. . Confirm that the MOTOR switch of the filter disk unit is on. 4. After replacement, white balance adjustment is required. Refer to Section 3-6 for details on adjust- ment. 1-36 (E) BVP-9500WS/9500WSP MM...
Page 47: Description On Flexible Card Wire
1. Slide portion B in the direction of the arrow and insert the flexible card wire as far as it will go into connector with the conductive surface of the wire put down. 2. Slide portion B in the opposite direction of the arrow and lock. 1-37 (E) BVP-9500WS/9500WSP MM...
Page 48: Forming Before Installation
. MB-830 board CN17 ↔ PR-248 board CN4 Insulating surface (blue) MB-830 (CN17) Insulating surface (blue) PR-248 (CN4) Unit : mm . CN-1787 board CN5 ↔ PR-249 board CN2 Conducting surface (silver) CN-1787 (CN5) Conducting surface (silver) PR-249 (CN2) Unit : mm 1-38 (E) BVP-9500WS/9500WSP MM...
Page 49: Ccd Unit
1-9. CCD Unit 1-9. CCD Unit 1-9-1. Precautions on Replacing the CCD Unit When replacing the CCD unit, be sure to replace with the CCD unit designated for BVP-9500WS/ 9500WSP. The OHB-730/750A, etc. cannot be used with this unit even if attached.
Page 50: Replacing The Ccd Unit
4. Remove the four screws (B3 x 6), and remove the front panel. For BVP-9500WSP only PS2.6 x 5 PS2.6 x 5 (For BVP-9500WSP only) Screws B3 x 8 CCD unit B3 x 8 Screws Front panel 1-40 (E) BVP-9500WS/9500WSP MM...
Page 51 5. Remove the filter disk unit. (Refer to Section 1-7.) CCD unit Filter disk unit Screws 6. Remove the two screws of new CCD unit, and remove the blind plate. 7. Install the new CCD unit in the reverse order of removal. 1-41 (E) BVP-9500WS/9500WSP MM...
Page 52: Replacing Boards
Precision P2.6 x 8 P2.6 x 8 3. Remove the four screws, and remove the PS-554 board. Precision Precision 2.6 x 5 2.6 x 5 PS-554 board 4. Install the new board in the reverse order of removal. 1-42 (E) BVP-9500WS/9500WSP MM...
Page 53: Replacing The Pr-249, Pr-248 And Da-143 Boards
9. Install the new board in the reverse order of removal. [Note|at|installation] for BVP-9500WSP When replacing the PR-249 board, put off the shield sheet (PR) from the PR-249 board and then put it on the new PR-249 board. 1-43 (E) BVP-9500WS/9500WSP MM...
Page 54: Replacing The Mb-830 Board
MB-839 board. CN12 MB-830 board CN13 CN14 CN20 P2.6 x 8 CN18 CN17 CN15 CN16 CN19 CN10 CN11 P2.6 x 8 PS2.6 x 8 6. Install a new board in the reverse order of removal. 1-44 (E) BVP-9500WS/9500WSP MM...
Page 55: Driver Board
2. Remove the three screws and disconnect the connector. Connector Precision P2.6 x 4 Driver board 3. Install a new board in the reverse order of removal. 4. After replacement, be sure to perform the filter positioning adjustment referring to Section 3-5. 1-45 (E) BVP-9500WS/9500WSP MM...
Page 56: Boards Inside Ccd Unit
. When attaching the SH-69 board, fit the protrusions on the NR-65 board to the notch and hole on the SH-69 board. . When replacing the TG-194 board, put off two shield sheets (TG) from the PR-249 board and then put it on the new TG-194 board. (for BVP-9500WSP only.) 1-46 (E) BVP-9500WS/9500WSP MM...
Page 57 BVP-9500WSP only BVP-9500WS Supports Protrusion Notch Protrusion Support BVP-9500WSP Hole Sub harness (EMI-A) Sub harness (EMI-C) Shield sheet (TG) harness (EMI-B) Connector plate Screws (a) to (g) P2.6 x 4 Shield sheet (TG) Sub harness (EMI-A) 1-47 (E) BVP-9500WS/9500WSP MM...
Page 58: Setting/Adjusting Items After Replacing The Boards And Parts
Commercially available (Refer to Section 3-1-5) IC socket removing tool J-6394-110-A Replacing a PROM *1: When extending the MEM-98 or VA-200 board, both EX-762 and EX-819 are required. For details on usage, refer to Section 1-13. 1-48 (E) BVP-9500WS/9500WSP MM...
Page 59: Extension Board Usage
3. Insert the EX-762 extension board assembly into the slot for the VA-200 board. 4. Connect the MEM-98 and VA-200 boards to the EX-819 and EX-762 extension boards respectively. EX-762 board assembly VA-200 board MEM-98 board AD-157 board EX-819 board 1-49 (E) BVP-9500WS/9500WSP MM...
Page 60: Self-Diagnosis
3. To decide the menu page selection, press the MIC LEVEL control or set the ENTER/CANCEL switch to ENTER. 4. The menu page is returned to the previous page every time the ENTER/CANCEL switch is set to CANCEL. 5. To cancel the menu operation, set the DISPLAY switch to OFF. 1-50 (E) BVP-9500WS/9500WSP MM...
Page 61 *1: When the CCU is not connected to the camera, this item 8 is not displayed. *2: When the RM is not connected to the camera, “NC” is displayed in the column. For details on [CA-950] items (DA, IF, AU, SDI, DPR, TX), refer to CA-950/950P Maintenance Manual. 1-51 (E) BVP-9500WS/9500WSP MM...
Page 63: Maintenance Menu
* : The connection of the CCU-900/900P is available to only CA-950/950P. Switches and Knobs Used MIC1 LEVEL control GAIN OUTPUT AUTO WHITE STBY KNEE SAVE BARS DISPLAY TESTOUT ENTER CANCEL MENU ENTER/CANCEL switch DISPLAY switch 2-1 (E) BVP-9500WS/9500WSP MM...
Page 64 2. While pushing the ENTER/CANCEL switch to the “ENTER” side, set the DISPLAY switch from “OFF” to “MENU.” The OHB trimming page will be displayed on the maintenance menu. Be sure to reset S3-4 switch on the AT-128 board to OFF after using the OHB Trimming page during adjustment. 2-2 (E) BVP-9500WS/9500WSP MM...
Page 65: Details Of Maintenance Menu
To avoid incorrect operation, this item is not displayed at factory setting state. To display this item because of performing adjustment, refer to “Section 2-1 Entering the OHB Trimming Page”. After adjustment, be sure to reset the switch to the factory setting state (not to be displayed state). 2-3 (E) BVP-9500WS/9500WSP MM...
Page 66: System Setup Page
ON/OFF Sets the aspect ratio of the screen. ON : 4 : 3 OFF : 16 : 9 Field Rate 60/180 (for BVP-9500WS) Sets the field rate. 50/150 (for BVP-9500WSP) 60/50: x1 speed 180/150: x3 speed Digital Out ON/OFF Sets ON/OFF the digital signal output to CA.
Page 67: Reference Store Page
When the data reading is finished: Registers the data that was read as the reference file and saves it in the camera. When the registration is completed, the message “Complete” is displayed. 2-5 (E) BVP-9500WS/9500WSP MM...
Page 68: Lens File Setup Page
To reset the setting to the factory setting state: Rotates the MIC 1 LEVEL knob so that the arrow is positioned to “Reset ALL Lens”, and then press it. Then all lens files are reset to the factory setting state. 2-6 (E) BVP-9500WS/9500WSP MM...
Page 69: Ohb File Setup Page
For details on how to register the OHB file, refer to the BVP-900 System Manual. When the adjustment is completed, the message “Complete” will be displayed. When the MIC 1 LEVEL knob is pressed again during the automatic adjustment, cancels the adjustment and returns to the previous state. 2-7 (E) BVP-9500WS/9500WSP MM...
Page 70: Auto Iris Setup Page
This cannot be set when DA Sel is set to OFF. Monitor Sel ON/OFF Sets ON/OFF the function to output the monitor output signal from the TEST OUT terminal. This cannot be set when DA Sel is set to OFF. 2-8 (E) BVP-9500WS/9500WSP MM...
Page 71: Ohb Trimming Page
–99 to 99 Adjusts the Clamp offset. ON/OFF Sets ON/OFF the black shading correction function. Off 60/On 180 Sets the field rate. (for BVP-9500WS) Off 60/50 : x1 speed Off 50/On 150 On 180/150 : x3 speed (for BVP-9500WSP) Gain _3, 0, 3, 6, 9, 12 Sets the master gain.
Page 73: Electrical Alignment
. Extension board EX-464 (Sony part No. : A-8318-864-A) . Multi-burst chart (Sony part No. : J-6026-110-A) . Pattern box (PTB-500, 90-240 Vac) (Sony part No. : J-6029-140-B) . Grayscale chart (4:3, transparent) (Sony part No. : J-6026-130-B) . Grayscale chart (16:9, transparent) (Sony part No. : J-6394-080-A) .
Page 74: Notes On Adjustment
MASTER SETUP UNIT MASTER SETUP UNIT MSU-700 MSU-700 MSU-700A/750 *1: Represented as “CCU” simply for convenience in wirting in this section. *2: When CA-950/950P and CCU-900/900P are used. *3: When CA-570/570P, CA-550/550P and CCU-550/550P, CCU-700/700P/700A/700AP are used respectively. 3-2 (E) BVP-9500WS/9500WSP MM...
Page 75: Initial Settings
3-1-4. Initial Settings BVP-9500WS/9500WSP Set the Maintenance Menu as follows: (Refer to Section 2.) [Maintenance|Menu] → [System|Setup] → [Field|Rate] → [60] (for BVP-9500WS) → [50] (for BVP-9500WSP) When switching the following switches from a customer-set position, it is recommended to record the setting state of the customer in the table below.
Page 76 3. Turn the MIC 1 LEVEL control and set the arrow to the “All Preset” line and slide the ENTER/CANCEL switch upwards to ENTER once. When presetting is completed, a message “Completed” is displayed. 4. Set the DISPLAY switch to OFF. 3-4 (E) BVP-9500WS/9500WSP MM...
Page 77: Maintaining The Grayscale Chart
Adjust the position and angle of the light source so that the whole surface of the chart is evenly 2000 lx. Light the chart from almost the same direction and height as the camera to shoot the chart. 3-5 (E) BVP-9500WS/9500WSP MM...
Page 78 4. Adjust the luminance control of the pattern box so that the white portion in the center of the chart is 573 ± 6 cd/m This corresponds to the luminous intensity on the 89.9 %-reflective chart at 2000 lx. Chart Luminance meter 3-6 (E) BVP-9500WS/9500WSP MM...
Page 79: Video Adjustment
Adjustment procedures 1. Set the OHB Trimming page from Maintenance Menu as follows: [OHB|Trimming] → [SPM] → [OFF|60] (for BVP-9500WS) → [OFF|50] (for BVP-9500WSP) 2. Open the lens iris. Adjust the zoom control so that the pattern box is shot in the following condition.
Page 80 However, the video level specification should be 2.0 V p-p. [OHB|Trimming] → [SPM] → [ON|180] (for BVP-9500WS) → [ON|150] (for BVP-9500WSP) Setting after adjustment . [OHB|Trimming] → [SPM] → [OFF|60] (for BVP-9500WS) → [OFF|50] (for BVP-9500WSP) . S3-4/AT-128 board → OFF 3-8 (E)
Page 81: Rpn Correction Adjustment
. This adjustment is required when replacing the TG-194 board, or replacing adjustment controls 1RV1 or 1RV2 on the TG-194 board. . This adjustment must be done at Field Rate 60 (for BVP-9500WS) or 50 (for BVP-9500WSP) : x1 speed. (Refer to Section 3-1-4.) Preparations .
Page 82 If no RPN-corrected pixel is monitored in all channels, set 1RV1 and 1RV2 to their mechanical center. Corrected pixel Scanning line (Monitor screen) 6. Ensure that all the pixels are corrected properly in the other channels. Setting after adjustment TEST OUT switch (side panel) → ENC TG-194 BOARD (B SIDE) 3-10 (E) BVP-9500WS/9500WSP MM...
Page 83: Offset Adjustment
. Turn on the S3-4/AT-128 to display Maintenance Menu. Adjustment procedures 1. Set the OHB Trimming page from Maintenance Menu as follows: [OHB|Trimming] → [SPM] → [OFF|60] (for BVP-9500WS) → [OFF|50] (for BVP-9500WSP) → [SH] → [OFF] → [GB] → [ON] 2.
Page 84 5. Execute the File Store by selecting the OHB Trimming page from Maintenance Menu. [OHB|Trimming] → [File|Store] 6. Set the OHB Trimming page from Maintenance Menu as follows and repeat steps from 2 to 5. [OHB|Trimming] → [SPM] → [ON|180] (for BVP-9500WS) → [ON|150] (for BVP-9500WSP) Setting after adjustment .
Page 85: Test Signal Level Adjustment
A = 508 ± 5 mV Specification: 4. B-ch adjustment Test Point: TP6 (GND:E1)/VA-189 board Adj. point: 1RV6/VA-189 board A = 508 ± 5 mV Specification: Setting after adjustment TEST 2 button (MSU-700A) → OFF (unlit) VA-189 BOARD (B SIDE) 3-13 (E) BVP-9500WS/9500WSP MM...
Page 86: Va Gain Adjustment
. Make sure that presetting all the compensation data is completed before beginning adjustment. (Refer to Section 3-1-4.) . This adjustment must be done at Field Rate 60 (for BVP-9500WS) or 50 (for BVP-9500WSP) : x1 speed. (Refer to Section 3-1-4.) Preparations .
Page 87 Select B signal by pushing down the TEST OUT switch (side panel) from the RGB position towards the SEL position. 1RV3 (B)/VA-189 board Adj. point: Specification: The same as for G GAIN adjustment. Setting after adjustment TEST OUT switch (side panel) → ENC VA-189 BOARD RV3 (B) RV2 (G) RV1 (R) 3-15 (E) BVP-9500WS/9500WSP MM...
Page 88: Nr Gain Adjustment
. Shoot the grayscale chart so that its frame is aligned with the underscanned monitor frame. . S3-4/AT-128 board → ON . Set the Maintenance Menu as follows: (Refer to Section 2.) [Maintenance|Menu] → [System|Setup] → [Field|Rate] → [180] (for BVP-9500WS) → [150] (for BVP-9500WSP) [Maintenance|Menu] → [Supermotion|Setup] → [DA|Sel] → [ON] →...
Page 89 1RV3 (B3)/NR-65 board Adj. point: Specification: The same as for G GAIN adjustment. Setting after adjustment . TEST OUT switch (side panel) → ENC . S3-4/AT-128 board → OFF NR-65 BOARD RV3 (B3) RV2 (G3) RV1 (R3) 3-17 (E) BVP-9500WS/9500WSP MM...
Page 90: Encoder System Adjustment
Oscilloscope Notes . Perform this adjustment only when PR-248 board adjustment is not completed. . This adjustment must be done at Field Rate 60 (for BVP-9500WS) or 50 (for BVP-9500WSP) : x1 speed. (Refer to Section 3-1-4.) Preparations . Remove the PR-249 board. (Refer to Section 1-5-7.) .
Page 91 Pin 73 (73)/EX-762 (EX-464) board 1RV3 (B GAIN) /PR-248 board Adj. point: Specification: D = 700 ± 5 mV [NTSC] [PAL] Setting after adjustment Installation the PR-249 board. (Refer to Section 1-5-7.) PR-248 BOARD (A SIDE) 3-19 (E) BVP-9500WS/9500WSP MM...
Page 92: R Level Adjustment
RV406 RV104 RV407 RV401 RV201 RV202 RV100 RV608 RV203 RV304 RV301 RV200 RV302 RV605 RV300 RV303 RV204 RV601 RV600 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-20 (E) BVP-9500WS/9500WSP MM...
Page 93: G Level Adjustment
1RV204 (G BL) /EN-141 board Specification: A = 0 ± 5 mV [NTSC] [PAL] 2. Test point: TP2/EN-141 board GND: E1/EN-141 board 1RV200 (G LEV) /EN-141 board Adj. point: Specification: B = 1200 ± 10 mV 3-21 (E) BVP-9500WS/9500WSP MM...
Page 94: B Level Adjustment
RV406 RV104 RV407 RV401 RV201 RV202 RV100 RV608 RV203 RV304 RV301 RV200 RV302 RV605 RV300 RV303 RV204 RV601 RV600 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-22 (E) BVP-9500WS/9500WSP MM...
Page 95: Y Level Adjustment
. Supply power from the AC adaptor (AC-550/550CE). . OUTPUT switch/side panel → BARS Adjustment procedure 1. Test point: TP4/EN-141 board GND: E1/EN-141 board Adj. point: 1RV407 (Y BL) /EN-141 board Specification: A = 0 ± 5 mV [NTSC] [PAL] 3-23 (E) BVP-9500WS/9500WSP MM...
Page 96: Vtr Y/R-Y/B-Y Level Adjustment
RV604 RV602 S601 Adj. point: 1RV203 (VTR R-Y) /EN-141 board S800 Specification: D = 700 ± 5 mV [UC model] D = 525 ± 5 mV [PAL] S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-24 (E) BVP-9500WS/9500WSP MM...
Page 97 5. Test point: Pin 44/EX-762 or EX-464 board GND: Pin 43/EX-762 or EX-464 board Adj. point: 1RV303 (VTR B-Y) /EN-141 board Specification: E = 700 ± 5 mV [UC model] E = 525 ± 5 mV [PAL] 3-25 (E) BVP-9500WS/9500WSP MM...
Page 98: Ccu Y Level Adjustment
RV304 RV301 RV200 RV302 Specification: C = 700 ± 5 mV RV605 RV300 RV303 RV204 RV601 RV600 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 V rate S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-26 (E) BVP-9500WS/9500WSP MM...
Page 99: Ccu R-Y/B-Y Level Adjustment
Specification: C = 525 ± 5 mV 4. Test point: Pin 44/EX-762 or EX-464 board GND: Pin 43/EX-762 or EX-464 board Adj. point: 1RV301 (CCU B-Y SAMPLE) /EN-141 board Specification: D = 350 ± 5 mV V rate 3-27 (E) BVP-9500WS/9500WSP MM...
Page 100: Ret Level Adjustment
RV406 RV104 RV407 RV401 RV201 RV202 RV100 RV608 RV203 RV304 RV301 RV200 RV302 RV605 RV300 RV303 RV204 RV601 RV600 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-28 (E) BVP-9500WS/9500WSP MM...
Page 101: Vbs Y Level Adjustment
3. Test point: Pin 50/EX-762 or EX-464 board GND: Pin 49/EX-762 or EX-464 board 1RV605 (VBS Y) /EN-141 board Adj. point: Specification: C = 100 ± 1 IRE [NTSC] C = 700 ± 5 mV [PAL] 3-29 (E) BVP-9500WS/9500WSP MM...
Page 102: I (V) Level Adjustment
RV401 RV201 RV202 RV100 RV608 RV203 RV304 RV301 RV200 S600-2 S600-1 RV302 RV605 RV300 RV303 RV204 S600 RV600 RV601 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 S801 RV802 RV801 RV609 RV800 EN-141 BOARD (A SIDE) 3-30 (E) BVP-9500WS/9500WSP MM...
Page 103: Q (U) Level Adjustment
Adjustment procedure 1. Adj. point: 1RV600 (Q/U LEV) /EN-141 board Specification: The beam spot of Q (U) signal fit the scale [NTSC] : Q [PAL] : U Setting after adjustment S600-1 (Q/U ON/OFF) /EN-141 board → ON 3-31 (E) BVP-9500WS/9500WSP MM...
Page 104: I/Q (V/U) Phase Adjustment
RV202 RV100 RV608 RV203 RV304 RV301 RV200 RV302 RV605 RV300 RV303 RV204 BLACK DL605 BALANCE RV600 RV601 RV601 RV607 RV603 RV606 RV602 S600 RV604 RV602 S601 S800 S801 RV802 RV801 RV609 RV800 EN-141 BOARD (A SIDE) 3-32 (E) BVP-9500WS/9500WSP MM...
Page 105: Burst Adjustment
Q axis. [NTSC] The beam spot of bust signals match the each burst axis. [PAL] [NTSC] [PAL] 2. Adj. point: 1RV603 (BST LEV) /EN-141 board Specification: A = 40 IRE [NTSC] A = 300 mV [PAL] [PAL] [NTSC] 3-33 (E) BVP-9500WS/9500WSP MM...
Page 106: Int Sc Phase Adjustment
RV406 RV104 RV407 RV401 RV201 RV202 RV100 RV608 RV203 RV304 RV301 RV200 RV302 RV605 RV300 RV303 RV204 RV601 RV600 RV607 RV603 RV606 S600 RV604 RV602 S601 S800 S801 RV802 RV609 RV801 RV800 EN-141 BOARD (A SIDE) 3-34 (E) BVP-9500WS/9500WSP MM...
Page 107: Monitor Gain Adjustment
Specification: B = 100 ± 1 IRE [NTSC] B = 700 ± 5 mV [PAL] [NTSC] [PAL] Setting after adjustment . Connect the CCU with a triax cable or optical fiber cable. . Power off and return EN-141 board to its normal position. 3-35 (E) BVP-9500WS/9500WSP MM...
Page 108: Ad, Da System Adjustment
6. Adj. point: 1RV3 (B GAIN) /PR-248 board Specification: A = 109.5 ± 0.5 IRE [NTSC] A = 766 ± 3 mV [PAL] Setting after adjustment Installation the PR-249 board. (Refer to Section 1-5-7.) PR-248 BOARD (A SIDE) 3-36 (E) BVP-9500WS/9500WSP MM...
Page 109: Ad Gain Adjustment
(side panel) from the RGB position towards TP201 RV202 E701 the SEL position. 6. Adj. point: 1RV201 (B GAIN) /VA-200 board RV201 Specification: A = 100.0 ± 0.5 IRE [NTSC] A = 700 ± 3 mV [PAL] VA-200 BOARD (A SIDE) 3-37 (E) BVP-9500WS/9500WSP MM...
Page 110: Modulation Balance Adjustment
1RV102 (G MOD BAL) /VA-200 board 4. Adj. point: Specification: Adjust that the waveform does not change even if V MOD SAW switch/MSU-700A (PAINT menu) is turned to OFF or ON. For reference: 3 mV (0.5 IRE) or less 3-38 (E) BVP-9500WS/9500WSP MM...
Page 111 . V MOD adjustment control (R)/MSU-700A → 0 . V MOD adjustment control (G)/MSU-700A → 0 . V MOD adjustment control (B)/MSU-700A → 0 TP704 TP705 TP702 TP701 TP703 RV102 TP101 RV101 TP201 RV202 E701 RV201 VA-200 BOARD (A SIDE) 3-39 (E) BVP-9500WS/9500WSP MM...
Page 112: Ad Phase Adjustment
. Shoot a multi-burst chart. . S3-4/AT-128 board → ON Adjustment procedures 1. Set the Maintenance Menu as follows: [Maintenance|Menu] → [System|Setup] → [Field|Rate] → [180] (for BVP-9500WS) → [150] (for BVP-9500WSP) Adj. point: 1RV1 (x3 OHB PHASE) /AD-157 board panel...
Page 113: Filter Positioning Adjustment
1RV8 1VR8 CC 4 (5600 K) 1RV9 1VR9 RV8 RV9 VR3 VR5 CC 5 (8000 K) 1RV10 1VR10 RV10 Servo driver board (A) Servo driver board (B) * Servo driver boards (A) and (B) are compatible. 3-41 (E) BVP-9500WS/9500WSP MM...
Page 114: Adjustment After Replacement Of Nd Filter
OHB File Store 1. MSU menu operation: . FILE button → ON (lit) . Touch panel operation [OHB|File] → [OHB|Store] → [Store] 2. When the store operation is complete, the message “OHB File Stored” is displayed. 3-42 (E) BVP-9500WS/9500WSP MM...
Page 115: Spare Parts
Therefore, specified parts should be used in the case of replacement. 2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts common- ality and improvement. Parts list has the present standardized repair parts.
Page 116: Exploded Views
P2.6 x 4 Only for BVP-9500WSP P2.6 x 4 P2.6 x 4 P2.6 x 4 B3 x 6 P2 x 4 BVP-9500WS BVP-9500WSP P2.6 x 4 P2.6 x 4 P2.6 x 4 B3 x 8 B3 x 8 BVP-9500WS/9500WSP MM...
Page 117 A-8325-951-A o MOUNTED CIRCUIT BOARD,SH-69 *1 A-8327-404-A o MOUNTED CIRCUIT BOARD,TG-203A A-8325-953-A o MOUNTED CIRCUIT BOARD,VA-189 A-8327-354-A s OHB UNIT ASSY (for BVP-9500WS) A-8327-355-A s OHB UNIT ASSY (for BVP-9500WSP) X-3168-024-3 o PANEL ASSY, FRONT 1-475-772-11 o FILTER UNIT, OPTICAL (for BVP-9500WS)
Page 118 W2.6, W2.6, W2.6, SMALL SMALL P2.6 x 6 SMALL PRECISION W2.6, SMALL PTP2.6 x 6 PTP2.6 x 6 B3 x 6 *a : Former type P4 x 10 SCREW, HEXAGON 3 x 10 SCREW, HEXAGON 3 x 10 BVP-9500WS/9500WSP MM...
Page 119 7-623-208-22 s SPRING WASHER (3MM) 7-627-556-78 s SCREW,PRECISION +P2.6X6 7-682-162-09 s SCREW +P4X10 7-682-547-09 s SCREW +B3X6 7-683-404-04 s BOLT,HEXAGON SOCKET 3X8 7-683-405-04 s BOLT,HEXAGON SOCKET3X10 7-685-133-19 s SCREW +PTP2.6X6 7-688-002-02 s WASHER (2.6) 7-688-003-02 s WASHER (3) BVP-9500WS/9500WSP MM...
Page 120 Right Panel and Plug-in Boards W2.0 W2.0 W2.0 W2.0 W2.0 W2.0 W2.0 B4 x 12 W2.0 B4 x 12 B4 x 12 B4 x 12 BVP-9500WS/9500WSP MM...
Page 121 A-8325-958-A o MOUNTED CIRCUIT BOARD,AD-157 A-8325-959-A o MOUNTED CIRCUIT BOARD,VA-200 A-8325-960-A o MOUNTED CIRCUIT BOARD,PS-553 A-8327-156-A o MOUNTED CIRCUIT BOARD,EN-141 (for BVP-9500WS:S/N 10001-) A-8327-202-A o MOUNTED CIRCUIT BOARD,EN-141A (for BVP-9500WS:S/N 30001-) A-8327-214-A o MOUNTED CIRCUIT BOARD,EN-141B (for BVP-9500WSP) X-3604-503-5 o PANEL ASSY,RIGHT 3-165-162-01 s SCREW(+P2.6X5)(TYPE 1)(ST)
Page 122 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 5 PS2.6 x 8 PS2.6 x 5 2.6 x 8 2.6 x 8 Only for BVP-9500WSP BVP-9500WS/9500WSP MM...
Page 123 3-629-603-01 s SUPPORT(L8) 3-701-822-00 s HOLDER, WIRE 3-710-024-01 o PACKING,VF 4-963-924-01 s SCREW (DAMPER) 3-846-067-21 o SPACER, C Screws 7-627-553-47 s SCREW,PRECISION +P2X4 7-627-556-98 s SCREW,PRECISION +P 2.6X8 TYPE1 7-628-254-00 s SCREW +PS 2.6X5 7-628-254-20 s SCREW +PS 2.6X8 BVP-9500WS/9500WSP MM...
Page 124 Chassis Block PS2.6 x 8 PS2.6 x 8 P2.6 x 8 PRECISION P2.6 x 10 Only for PRECISION BVP-9500WSP Only for BVP-9500WSP PTP2.6 x 8 P2.6 x 8 PRECISION B2 x 6 4-10 BVP-9500WS/9500WSP MM...
Page 125 3-692-113-12 o WEDGE,HANGER 3-692-114-03 o PLATE,CONNECTOR(136P) 3-729-061-01 s SCREW (M2X4.5) (TYPE 1)(STEEL) 4-864-521-00 s SPRING,COMPRESSION 4-963-924-01 s SCREW (DAMPER) 1-958-342-11 o HARNESS (VF) (for BVP-9500WS) 1-961-057-12 o HARNESS (VF) (for BVP-9500WSP) Screws 7-621-772-38 s SCREW +B2X6 7-627-556-98 s SCREW,PRECISION +P 2.6X8 TYPE1 7-627-557-47 s SCREW,PRECISION +P 2.6X10 TYPE1...
Page 126 Shoulder Pad Block P2.6 x 8 PRECISION P2.6 x 8 PRECISION P2.6 x 8 PRECISION 2.6 x 6 2.6 x 6 B3 x 8 W4, MIDDLE 4-12 BVP-9500WS/9500WSP MM...
Page 127 3-659-365-00 s SPACER,4-3 3-687-116-01 o WASHER(4),STOPPER (PLA) 3-701-438-21 s WASHER PLASTIC (2.6X0.5) 3-901-261-01 s WASHER (ST) Screws/Washer 7-627-556-98 s SCREW,PRECISION +P 2.6X8 TYPE1 7-682-548-09 s SCREW +B 3X8 7-682-902-21 s SCREW +PWH 2.6X6 7-688-004-12 s WASHER W4 (M) 4-13 BVP-9500WS/9500WSP MM...
Page 128 P2.6 x 8 PRECISION P2.6 x 8 PRECISION P2.6 x 8 PRECISION RK3 x 6 PS2.6 x 8 PTP2.6 x 8 B3 x 6 P2.6 x 8 PRECISION P2.6 x 8 PRECISION P4 x 6 P4 x 6 4-14 BVP-9500WS/9500WSP MM...
Page 129 3-729-072-01 s SCREW +K4X8 (STEEL) 3-742-015-02 o WEDGE (B), MOUNTING Screws 7-627-556-98 s SCREW,PRECISION +P 2.6X8 TYPE1 7-628-254-20 s SCREW +PS 2.6X8 7-682-160-09 s SCREW +P4X6 7-682-347-04 s SCREW +RK 3X6 7-682-547-09 s SCREW +B3X6 7-685-134-19 s SCREW +PTP2.6X8 4-15 BVP-9500WS/9500WSP MM...
Page 130: Electrical Parts List
1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C255 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C256 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C112 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C257 1-162-925-11 s CAPACITOR,CERAMIC 68PF/50V CH C113 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C258 1-162-925-11 s CAPACITOR,CERAMIC 68PF/50V CH 4-16 BVP-9500WS/9500WSP MM...
Page 131 1-218-644-11 s RESISTOR,CHIP 10 1/16W 1-218-680-11 s RESISTOR,CHIP 330 1/16W(1608) JC155 1-218-644-11 s RESISTOR,CHIP 10 1/16W 1-218-688-11 s RESISTOR,CHIP 680 1/16W(1608) JC260 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) 4-17 BVP-9500WS/9500WSP MM...
Page 132 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R252 1-218-682-11 s RESISTOR,CHIP 390 1/16W (1608) R123 1-218-696-11 s RESISTOR,CHIP 1.5K 1/16W(1608) R253 1-218-695-11 s RESISTOR,CHIP 1.3K 1/16W(1608) R130 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R254 1-218-705-11 s RESISTOR,CHIP 3.6K 1/16W(1608) 4-18 BVP-9500WS/9500WSP MM...
Page 133 1-162-921-11 s CAPACITOR,CERAMIC 33PF/50V CH *c 1-241-261-41 s RESISTOR, ADJ, CERMET 1K 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F *d 1-241-266-11 s RESISTOR, ADJ, CERMET 50K *c 1-241-261-41 s RESISTOR, ADJ, CERMET 1K 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 1-162-920-11 s CAPACITOR,CERAMIC 27PF/50V CH 4-19 BVP-9500WS/9500WSP MM...
Page 134 8-759-472-31 s IC 74VHC163MTCX C113 1-162-919-11 s CAPACITOR,CERAMIC 22PF/50V CH IC16 8-759-472-31 s IC 74VHC163MTCX C114 1-162-919-11 s CAPACITOR,CERAMIC 22PF/50V CH IC18 8-759-182-95 s IC HD151015T C115 1-162-919-11 s CAPACITOR,CERAMIC 22PF/50V CH IC19 8-759-182-95 s IC HD151015T 4-20 BVP-9500WS/9500WSP MM...
Page 135 1-218-690-11 s RESISTOR,CHIP 820 1/16W (1608) 8-749-014-35 s IC HCPL-0630-500 1-218-722-11 s RESISTOR, CHIP 18K 1/16W 1608 1-216-855-11 s RESISTOR, CHIP 680K 1/16W 1608 8-729-101-07 s TRANSISTOR 2SB798 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) 8-729-807-51 s TRANSISTOR 2SD1623-S 4-21 BVP-9500WS/9500WSP MM...
Page 136 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R111 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R112 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R113 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R114 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R117 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 4-22 BVP-9500WS/9500WSP MM...
Page 137 1-239-898-22 s FILTER, EMI (SMD) FL139 1-239-895-11 s FILTER, EMI (SMD) FL20 1-239-898-22 s FILTER, EMI (SMD) FL140 1-239-895-11 s FILTER, EMI (SMD) FL141 1-239-895-11 s FILTER, EMI (SMD) FL21 1-239-898-22 s FILTER, EMI (SMD) FL142 1-239-895-11 s FILTER, EMI (SMD) 4-23 BVP-9500WS/9500WSP MM...
Page 138 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 1-239-308-11 s RESISTOR ARRAY,CHIP 47K 1-239-308-11 s RESISTOR ARRAY,CHIP 47K 4-24 BVP-9500WS/9500WSP MM...
Page 139 *a 1-543-775-11 s BEAD, FERRITE *a 1-543-775-11 s BEAD, FERRITE *a 1-543-775-11 s BEAD, FERRITE *a 1-543-775-11 s BEAD, FERRITE *a 1-543-775-11 s BEAD, FERRITE *a 1-412-364-11 s MICRO INDUCTOR *a 1-412-364-11 s MICRO INDUCTOR THP1 1-762-254-21 s SWITCH, POLY 4-25 BVP-9500WS/9500WSP MM...
Page 140 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C365 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C366 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C306 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C367 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C307 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C368 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 4-26 BVP-9500WS/9500WSP MM...
Page 141 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) R245 1-216-824-11 s RESISTOR, CHIP 1.8K 1/16W 1608 L304 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) R246 1-216-824-11 s RESISTOR, CHIP 1.8K 1/16W 1608 L305 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) R247 1-216-824-11 s RESISTOR, CHIP 1.8K 1/16W 1608 4-27 BVP-9500WS/9500WSP MM...
Page 142 8-759-599-93 s IC NC7SZO8P5 8-759-599-93 s IC NC7SZO8P5 1-795-081-11 s OSCILLATOR, CRYSTAL IC11 8-759-599-93 s IC NC7SZO8P5 8-729-143-14 s TRANSISTOR 2SC4176-B35 8-729-820-86 s TRANSISTOR 2SB1121-ST 8-729-143-07 s TRANSISTOR 2SA1610-Y33 *1:Refer to Section 4-1 "Note on Repair Parts". 4-28 BVP-9500WS/9500WSP MM...
Page 143 1-216-845-11 s RESISTOR,CHIP 100K 1/16W(1608) 1-216-845-11 s RESISTOR,CHIP 100K 1/16W(1608) 1-216-845-11 s RESISTOR,CHIP 100K 1/16W(1608) 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 4-29 BVP-9500WS/9500WSP MM...
Page 144 1-162-905-11 s CAPACITOR,CERAMIC 1PF/50V (CK) C505 1-164-505-11 s CAPACITOR,CHIP CERAMIC 2.2MF 1-162-908-11 s CAPACITOR,CERAMIC 3PF/50V 1608 C506 1-162-915-11 s CAPACITOR,CERAMIC 10PF/50V CH [for BVP-9500WS(J), BVP-9500WS(UC)] C507 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V 1-162-905-11 s CAPACITOR,CERAMIC 1PF/50V (CK) C508 1-164-505-11 s CAPACITOR,CHIP CERAMIC 2.2MF...
Page 145 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C662 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C605 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C663 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F [for BVP-9500WS(J), BVP-9500WS(UC)] C664 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C606 1-162-907-11 s CAPACITOR,CERAMIC 2PF/50V(CK) C665 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V...
Page 146 8-759-082-60 s IC TC7S66FU IC507 8-759-196-93 s IC TC7SH00FU-TE85R DL600 1-415-710-11 s DELAY LINE, Y (NTSC) IC508 8-759-082-61 s IC TC4W53FU [for BVP-9500WS(J), BVP-9500WS(UC)] 1-415-711-11 s DELAY LINE (Y) IC509 8-759-083-94 s IC TC7W74FU [for BVP-9500WSP(CE)] IC600 8-752-090-56 s IC CXA3178M-T4...
Page 147 Q'ty Part No. SP Description or Q'ty Part No. SP Description L500 1-410-656-11 s INDUCTOR,CHIP 150UH (3225) Q216 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL L501 1-410-385-11 s INDUCTOR,CHIP 22UH (3225) Q300 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL L502 1-412-029-11 s CHIP INDUCTOR 10UH (3225)
Page 148 Ref. No. or Q'ty Part No. SP Description or Q'ty Part No. SP Description Q623 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL 1-218-718-11 s RESISTOR CHIP 12K 1/16W (1608) Q624 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) Q625 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL...
Page 149 R112 1-218-720-11 s RESISTOR,CHIP 15K 1/16W(1608) R241 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) R113 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) [for BVP-9500WS(J), BVP-9500WS(UC)] R114 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-218-703-11 s RESISTOR,CHIP 3.0K 1/16(1608) R116 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608)
Page 150 Q'ty Part No. SP Description R341 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) R505 1-218-724-11 s RESISTOR,CHIP 22K 1/16W(1608) [for BVP-9500WS(J), BVP-9500WS(UC)] R506 1-218-724-11 s RESISTOR,CHIP 22K 1/16W(1608) 1-218-703-11 s RESISTOR,CHIP 3.0K 1/16(1608) R507 1-218-703-11 s RESISTOR,CHIP 3.0K 1/16(1608) [for BVP-9500WSP(CE)] R508 1-218-695-11 s RESISTOR,CHIP 1.3K 1/16W(1608)
Page 151 R562 1-218-732-11 s RESISTOR,CHIP 47K 1/16W(1608) R630 1-218-709-11 s RESISTOR,CHIP 5.1K 1/16W R563 1-218-732-11 s RESISTOR,CHIP 47K 1/16W(1608) [for BVP-9500WS(J), BVP-9500WS(UC)] R564 1-218-732-11 s RESISTOR,CHIP 47K 1/16W(1608) 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) R565 1-218-723-11 s RESISTOR,CHIP 20K 1/16W(1608) [for BVP-9500WSP(CE)]...
Page 152 1-218-691-11 s RESISTOR,CHIP 910 1/16W (1608) R813 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) R752 1-218-712-11 s RESISTOR,METAL 6.8K 1/16W R814 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) R753 1-218-710-11 s RESISTOR,CHIP 5.6K 1/16W(1608) R815 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) 4-38 BVP-9500WS/9500WSP MM...
Page 153 R944 1-218-712-11 s RESISTOR,METAL 6.8K 1/16W R872 1-218-701-11 s RESISTOR,CHIP 2.4K 1/16W(1608) R945 1-218-717-11 s RESISTOR,CHIP 11K 1/16W (1608) [for BVP-9500WS(J), BVP-9500WS(UC)] 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) R946 1-218-708-11 s RESISTOR,CHIP 4.7K 1/16W(1608) [for BVP-9500WSP(CE)] R947 1-218-664-11 s RESISTOR,CHIP 68 1/16W (1608)
Page 154 *a 1-236-904-11 s RESISTOR NETWORK 1K (1608) 1-239-309-11 s RESISTOR ARRAY,CHIP 100K 1-579-713-11 s OSCILLATOR,CRYSTAL 1-239-309-11 s RESISTOR ARRAY,CHIP 100K [for BVP-9500WS(J), BVP-9500WS(UC)] *b 1-239-430-11 s NETWORK RESISTOR 4.7K (1608) 1-579-718-11 s OSCILLATOR,CRYSTAL *a 1-236-904-11 s RESISTOR NETWORK 1K (1608)
Page 155 1-414-398-11 s INDUCTOR (SMD) 10UH 1-414-398-11 s INDUCTOR (SMD) 10UH 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) 1-412-026-11 s INDUCTOR,CHIP 1UH (3225) 8-729-117-32 s TRANSISTOR 2SC4177 8-729-117-32 s TRANSISTOR 2SC4177 8-729-140-63 s TRANSISTOR 2SA1611-M5M6 8-729-117-32 s TRANSISTOR 2SC4177 8-729-117-32 s TRANSISTOR 2SC4177 4-41 BVP-9500WS/9500WSP MM...
Page 156 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C291 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C164 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C292 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C293 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C165 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C300 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 4-42 BVP-9500WS/9500WSP MM...
Page 157 IC256 8-759-651-59 s IC SN74CBTLV3245APWR C603 1-104-852-11 s CAPACITOR,TANTALUM 22MF/10V IC257 8-759-651-59 s IC SN74CBTLV3245APWR C606 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC258 8-759-651-59 s IC SN74CBTLV3245APWR C608 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC260 8-759-595-53 s IC MB81F643242B-10 4-43 BVP-9500WS/9500WSP MM...
Page 158 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 R611 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 R612 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) 1-216-823-11 s RESISTOR, CHIP 1.5K 1/16W R613 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) 4-44 BVP-9500WS/9500WSP MM...
Page 159 1-236-907-11 s RESISTOR BLOCK 100K (1608) RB352 1-236-907-11 s RESISTOR BLOCK 100K (1608) RB353 1-236-907-11 s RESISTOR BLOCK 100K (1608) RB354 1-236-907-11 s RESISTOR BLOCK 100K (1608) RB355 1-236-907-11 s RESISTOR BLOCK 100K (1608) RB356 1-236-907-11 s RESISTOR BLOCK 100K (1608) 4-45 BVP-9500WS/9500WSP MM...
Page 160 *a 1-216-816-11 s RESISTOR, CHIP 390 1/16W 1608 1-162-915-11 s CAPACITOR,CERAMIC 10PF/50V CH *c 1-216-819-11 s RESISTOR,CHIP 680 1/16W (1608) 1-162-915-11 s CAPACITOR,CERAMIC 10PF/50V CH *b 1-216-817-11 s RESISTOR,CHIP 470 1/16W 1608 *a 1-216-816-11 s RESISTOR, CHIP 390 1/16W 1608 4-46 BVP-9500WS/9500WSP MM...
Page 161 1-216-827-11 s RESISTOR, CHIP 3.3K 1/16W 1608 1-216-827-11 s RESISTOR, CHIP 3.3K 1/16W 1608 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) 4-47 BVP-9500WS/9500WSP MM...
Page 162 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 IC10 8-759-564-49 s IC TC7W53FU-TE12R IC11 8-759-075-53 s IC LM35DM [for PA-226A board] 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 1-410-369-11 s INDUCTOR,CHIP 1UH (3225) 1-216-829-11 s RESISTOR,CHIP 4.7K 1/16W(1608) 4-48 BVP-9500WS/9500WSP MM...
Page 163 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C114 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C115 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C116 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C117 1-128-390-11 s CAPACITOR ELECT 220MF/6.3V C118 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C119 1-113-682-11 s CAPACITOR,TANTALUM 33MF/10V 4-49 BVP-9500WS/9500WSP MM...
Page 164 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C409 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C530 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C410 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C531 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C411 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C532 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 4-50 BVP-9500WS/9500WSP MM...
Page 165 8-759-575-66 s IC NC7SZ86P5 8-759-182-95 s IC HD151015T 8-759-532-02 s IC CY62256LL-70ZC-T2 IC601 8-759-575-66 s IC NC7SZ86P5 *b 8-759-660-22 s IC SN74HCT04APW (R) IC602 8-759-553-53 s IC NC7SZ125P5 *a 8-759-050-51 s IC SN74HCT04APW (E2) IC603 8-759-553-53 s IC NC7SZ125P5 4-51 BVP-9500WS/9500WSP MM...
Page 166 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) Q401 8-729-117-32 s TRANSISTOR 2SC4177 R126 1-218-718-11 s RESISTOR CHIP 12K 1/16W (1608) Q500 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL R128 1-218-724-11 s RESISTOR,CHIP 22K 1/16W(1608) Q501 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL R129 1-218-704-11 s RESISTOR,CHIP 3.3K 1/16W(1608)
Page 167 1-218-680-11 s RESISTOR,CHIP 330 1/16W(1608) R528 1-218-680-11 s RESISTOR,CHIP 330 1/16W(1608) 1-237-034-11 s RESISTOR,ADJ,CERMET 2K R529 1-218-680-11 s RESISTOR,CHIP 330 1/16W(1608) 1-237-034-11 s RESISTOR,ADJ,CERMET 2K R530 1-218-712-11 s RESISTOR,METAL 6.8K 1/16W 1-237-034-11 s RESISTOR,ADJ,CERMET 2K 1-237-034-11 s RESISTOR,ADJ,CERMET 2K 4-53 BVP-9500WS/9500WSP MM...
Page 168 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C613 1-128-390-11 s CAPACITOR ELECT 220MF/6.3V C614 1-113-682-11 s CAPACITOR,TANTALUM 33MF/10V C408 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C615 1-127-676-11 s CAPACITOR,CHIP CERAMIC 100MF F C409 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C616 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 4-54 BVP-9500WS/9500WSP MM...
Page 169 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 *a 8-759-569-91 s IC TLC7733IPWR R406 1-216-841-11 s RESISTOR, CHIP 47K 1/16W 1608 IC409 8-759-553-53 s IC NC7SZ125P5 R409 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) IC410 8-759-553-53 s IC NC7SZ125P5 R412 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) 4-55 BVP-9500WS/9500WSP MM...
Page 170 *e 1-137-688-91 s CAP, CHIP CERAMIC 47MF B 5750 C116 1-126-391-11 s CAPACITOR ELECT 47MF/6.3V(105) C117 *f 1-137-757-21 s CAP, ALMINIUM SOLID ELECT *e 1-137-688-91 s CAP, CHIP CERAMIC 47MF B 5750 C118 1-125-837-11 s CAPACITOR,CHIP CERAMIC1MF/6.3V C119 1-125-837-11 s CAPACITOR,CHIP CERAMIC1MF/6.3V 4-56 BVP-9500WS/9500WSP MM...
Page 171 1-127-820-11 s CAPACITOR, SQUARE CHIP 4.7MF FB155 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) C318 1-127-820-11 s CAPACITOR, SQUARE CHIP 4.7MF FB156 *a 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) C319 1-128-401-11 s CAPACITOR,ELECT100MF/25V(CHIP) FB157 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) 4-57 BVP-9500WS/9500WSP MM...
Page 172 1-218-729-11 s RESISTOR,CHIP 36K 1/16W(1608) Q103 8-729-045-16 s TRANSISTOR SI4410DY-T1-REVA R111 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) Q104 8-729-140-63 s TRANSISTOR 2SA1611-M5M6 R112 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R113 1-216-839-11 s RESISTOR,CHIP 33K 1/16W 1608 Q151 8-729-029-14 s TRANSISTOR DTC144EUA-T106 4-58 BVP-9500WS/9500WSP MM...
Page 173 1-216-843-11 s RESISTOR,CHIP 68K 1/16W (1608) R317 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R318 1-216-831-11 s RESISTOR,CHIP 6.8K 1/16W(1608) R319 1-216-828-11 s RESISTOR, CHIP 3.9K 1/16W 1608 R320 1-216-828-11 s RESISTOR, CHIP 3.9K 1/16W 1608 R321 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) 4-59 BVP-9500WS/9500WSP MM...
Page 174 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) C111 1-125-988-11 s CAPACITOR, ELECT 330MF/25V FB101 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) C112 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C113 1-128-399-11 s CAPACITOR ELECT 330MF/16V(CHIP FB102 1-414-864-11 s INDUCTOR, MICRO (CHIP TYPE) 4-60 BVP-9500WS/9500WSP MM...
Page 175 1-216-857-11 s RESISTOR,CHIP 1M 1/16W(1608) 1-218-728-11 s RESISTOR,CHIP 33K 1/16W 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) 1-218-718-11 s RESISTOR CHIP 12K 1/16W (1608) 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) 4-61 BVP-9500WS/9500WSP MM...
Page 176 1-793-066-21 o CONNECTOR, BOARD TO BOARD 10P 1-216-843-11 s RESISTOR,CHIP 68K 1/16W (1608) 1-695-443-21 o PIN, CONNECTOR (PC BOARD) 11P 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) *a 1-414-760-21 s INDUCTOR, MICRO (CHIP TYPE) 1-216-831-11 s RESISTOR,CHIP 6.8K 1/16W(1608) 4-62 BVP-9500WS/9500WSP MM...
Page 177 1-216-845-11 s RESISTOR,CHIP 100K 1/16W(1608) 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 1-216-831-11 s RESISTOR,CHIP 6.8K 1/16W(1608) 1-216-833-11 s RESISTOR,CHIP 10K 1/16W (1608) 1-216-825-11 s RESISTOR,CHIP 2.2K 1/16W 1608 4-63 BVP-9500WS/9500WSP MM...
Page 178 1-216-073-00 s RESISTOR,CHIP 10K 1/10W(2012) 1-771-313-11 s SWITCH, TOGGLE 1-762-241-11 s SWITCH, TOGGLE 1-762-241-11 s SWITCH, TOGGLE 1-762-241-11 s SWITCH, TOGGLE 1-762-241-11 s SWITCH, TOGGLE 1-762-491-11 s SWITCH, TOGGLE 1-473-315-11 s ENCODER, ROTARY (SWITCH) 1-762-242-12 s SWITCH, TOGGLE 4-64 BVP-9500WS/9500WSP MM...
Page 179 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC40 8-759-659-85 s IC SN74HC32APWR 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC41 8-759-523-02 s IC TC74HC4053AFT(EL) 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC42 8-759-487-51 s IC HN58C257AT10 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F IC44 8-759-050-06 s IC SN74HC157APW 4-65 BVP-9500WS/9500WSP MM...
Page 180 1-239-419-11 s NETWORK RESISTOR 470 (1608) 1-218-696-11 s RESISTOR,CHIP 1.5K 1/16W(1608) 1-239-419-11 s NETWORK RESISTOR 470 (1608) 1-218-721-11 s RESISTOR,CHIP 16K 1/16W(1608) 1-239-419-11 s NETWORK RESISTOR 470 (1608) 1-218-706-11 s RESISTOR,CHIP 3.9K 1/16W(1608) 1-239-419-11 s NETWORK RESISTOR 470 (1608) 4-66 BVP-9500WS/9500WSP MM...
Page 181 1-135-177-21 s CAPACITOR TANTALUM 1MF/25V 1-126-396-11 s CAPACITOR,ELECT 47MF/16V(CHIP) 1-127-518-11 s CAPACITOR,ELECT 100MF/16V 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 1-107-690-11 s CAPACITOR TANTALUM 6.8MF/35V 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 1-135-212-21 s CAPACITOR TANTALUM 2.2MF/35V *1:Refer to Section 4-1 "Note on Repair Parts". 4-67 BVP-9500WS/9500WSP MM...
Page 182 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C105 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B FB16 1-414-656-11 s INDUCTOR, MICRO (CHIP TYPE) C106 *b 1-115-156-11 s CAPACITOR CERAMIC 1MF/10V (1608) FB17 1-414-656-11 s INDUCTOR, MICRO (CHIP TYPE) *a 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 4-68 BVP-9500WS/9500WSP MM...
Page 183 8-729-421-71 s TRANSISTOR 2SK620 R103 1-216-834-11 s RESISTOR,CHIP 12K 1/16W 1608 8-729-143-07 s TRANSISTOR 2SA1610-Y33 R110 1-218-723-11 s RESISTOR,CHIP 20K 1/16W(1608) R111 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R112 1-218-723-11 s RESISTOR,CHIP 20K 1/16W(1608) 4-69 BVP-9500WS/9500WSP MM...
Page 184 1-218-710-11 s RESISTOR,CHIP 5.6K 1/16W(1608) R198 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R200 1-216-831-11 s RESISTOR,CHIP 6.8K 1/16W(1608) R201 1-216-797-11 s RESISTOR,CHIP 10 1/16W 1608 R203 1-216-845-11 s RESISTOR,CHIP 100K 1/16W(1608) R205 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 4-70 BVP-9500WS/9500WSP MM...
Page 185 *a 1-162-905-11 s CAPACITOR,CERAMIC 1PF/50V (CK) 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C142 *b 1-162-907-11 s CAPACITOR,CERAMIC 2PF/50V (CK) *a 1-162-905-11 s CAPACITOR,CERAMIC 1PF/50V (CK) 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 1-119-751-11 s CAPACITOR,TANTALUM 22MF/16V C338 *b 1-164-217-11 s CAPACITOR,CERAMIC 150PF/50V CH 4-71 BVP-9500WS/9500WSP MM...
Page 186 8-759-523-02 s IC TC74HC4053AFT(EL) 1-216-819-11 s RESISTOR,CHIP 680 1/16W 1608 IC51 8-759-547-54 s IC TC7SET00FU(TE85R) 1-216-843-11 s RESISTOR,CHIP 68K 1/16W (1608) 1-216-819-11 s RESISTOR,CHIP 680 1/16W 1608 1-411-755-11 s COIL, CHOKE 47UH 1-216-850-11 s RESISTOR,CHIP 270K 1/16W 1608 4-72 BVP-9500WS/9500WSP MM...
Page 187 1-218-689-11 s RESISTOR CHIP 750 1/16W (1608) R164 1-218-672-11 s RESISTOR,CHIP 150 1/16W(1608) 1-218-692-11 s RESISTOR,CHIP 1.0K 1/16W(1608) R165 1-218-672-11 s RESISTOR,CHIP 150 1/16W(1608) 1-218-690-11 s RESISTOR,CHIP 820 1/16W (1608) 1-216-857-11 s RESISTOR,CHIP 1M 1/16W(1608) R166 1-218-687-11 s RESISTOR CHIP 620 1/16W (1608) 4-73 BVP-9500WS/9500WSP MM...
Page 188 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R253 1-216-815-11 s RESISTOR,CHIP 330 1/16W 1608 R254 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) R321 1-216-818-11 s RESISTOR, CHIP 560 1/16W 1608 R256 1-216-821-11 s RESISTOR,CHIP 1.0K 1/16W(1608) R322 1-216-818-11 s RESISTOR, CHIP 560 1/16W 1608 4-74 BVP-9500WS/9500WSP MM...
Page 189 1-104-915-11 s CAPACITOR,CHIP 2.2MF/20V C113 1-127-954-11 s CAPACITOR,CHIP FILM 0.047MF C114 1-162-908-11 s CAPACITOR,CERAMIC 3PF/50V 1608 C115 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F C117 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C118 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C119 1-164-156-11 s CAPACITOR,CERAMIC 0.1MF/25V F 4-75 BVP-9500WS/9500WSP MM...
Page 190 1-234-589-21 s FILTER, LOW PASS C243 1-104-919-11 s CAPACITOR,TANTALUM 10MF/25V FL101 1-234-589-21 s FILTER, LOW PASS C244 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V FL201 1-234-589-21 s FILTER, LOW PASS C245 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V C248 1-104-851-11 s CAPACITOR,TANTALUM 10MF/10V 8-759-054-61 s IC CLC505AJE 4-76 BVP-9500WS/9500WSP MM...
Page 191 8-729-117-32 s TRANSISTOR 2SC4177 IC101 8-759-054-61 s IC CLC505AJE Q100 8-729-117-32 s TRANSISTOR 2SC4177 IC102 8-759-173-16 s IC TL062CPW Q101 8-729-040-48 s TRANSISTOR 2SA1688-4-SONY-TL IC103 8-759-271-18 s IC NJM1496V Q102 8-729-024-56 s TRANSISTOR 2SA1808 IC104 8-759-271-18 s IC NJM1496V Q103...
Page 192 1-218-732-11 s RESISTOR,CHIP 47K 1/16W(1608) R165 1-218-708-11 s RESISTOR,CHIP 4.7K 1/16W(1608) R100 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) R166 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R101 1-218-702-11 s RESISTOR CHIP 2.7K 1/16W(1608) R167 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) 4-78 BVP-9500WS/9500WSP MM...
Page 193 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R252 1-218-720-11 s RESISTOR,CHIP 15K 1/16W(1608) R513 1-216-864-11 s RESISTOR,CHIP 0 1/16W (1608) R253 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) R254 1-218-728-11 s RESISTOR,CHIP 33K 1/16W R514 1-218-652-11 s RESISTOR,CHIP 22 1/16W (1608) 4-79 BVP-9500WS/9500WSP MM...
Page 194 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) R705 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) R706 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) R707 1-218-716-11 s RESISTOR,CHIP 10K 1/16W(1608) R708 1-218-723-11 s RESISTOR,CHIP 20K 1/16W(1608) R709 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) 4-80 BVP-9500WS/9500WSP MM...
Page 195 1-698-236-31 s FAN,MOTOR 2pcs 1-580-580-11 o HOUSING, CONNECTOR 8P 16pcs 1-580-599-11 o TERMINAL,SOLDERLESS HN001 1-960-933-12 o HARNESS (OHB) (for BVP-9500WS) 1-960-056-12 s HARNESS (OHB) (for BVP-9500WSP) HN011 - - - HARNESS (TALLY) (TO CN2/CN-1918 BOARD) (FROM CN3/SW-936 BOARD TO CN1/SW-937 BOARD)
Page 196: Supplied Accessories
A-8318-864-A o EXTENSION BOARD, EX-464 A-8327-478-A o EXTENSION BOARD ASSEMBLY, EX-762 A-8327-481-A o EXTENSION BOARD, EX-819 J-6026-130-B o GRAY SCALE CHART J-6029-140-B o PATTERN BOX J-6394-110-A o IC SOCKET FRAME REMOVING TOOL J-6394-290-A o OHB EXTENSION HARNESS 4-82 BVP-9500WS/9500WSP MM...
Page 197 In addition, for semiconductors with ID Nos., refer to the separate CD-ROM titled “Semiconductor Pin Assignments” (Sony Part No. 9-968-546-xx) that allows searching for parts by semiconductor type or ID No. The semiconductors in the manual or on the CD-ROM are listed by equivalent types.
Page 198 EL4581CS-TE2 ............... EL4581CS EPC2LC20 ..............EPC2LC20 EPF10K50SFC256-3 ..............5-7 EPM7128AETC100-10 ........EPM7128STC100-7 FA7610CN-TE2 ................5-5 HD151015T ..............HD151015T HD151015TEL .............. HD151015T HD6417032VF12 ............ HD6417032F20 HD6475328F10 ............HD6475328F10 HN58C257AT-10 ............HN58C257T HN58C257AT10 ............HN58C257T LC35256DT-70-TLM ..........CXK58257ATM LC361000ATLL-10-TLM ......CXK581000ATM-70LL BVP-9500WS/9500WSP MM...
Page 199 SN74HC32APWR ............TC74HC32P TLC274CPW ............... TLC27M4CN SN74HC541APWR ........... MC74HC541N TLC274CPWR-12 ............TLC27M4CN SN74HC574APW-E20 ..........TC74HC574P SN74HC574APWR ............ TC74HC574P TLC27L4CPW ............. TLC27M4CN SN74HCT04APW-E20 ..........TC74HC04P TLC27L4CPW-E05 ............. TLC27M4CN TLC2932IPW-E20 ............TLC2932IPW SN74HCT541APWR ..........MC74HC541N TLC7733IPWR ............TLC7733IPWR SN74LVC00APW-E05 ..........TC74HC00P BVP-9500WS/9500WSP MM...
Page 200 UPC812G2 ................RC4558 UPC812G2-E2 ..............RC4558 UPD16502GS(1) ........... UPD16502GS(1) UPD16502GS(1)-E2 ..........UPD16502GS(1) UPD6466GS-515 ..........UPD6466GS-502-E2 XC18V02VQ44C ................. 5-5 XC4013XLA-09PQ208C ......XC4013XLA-09PQ208C XCV50-4TQ144C ................ 5-8 XRD7523AID-JTR ............... MP7523 XRD7523AIK-JTR ............... MP7523 OTHER Page or ID No. HCPL-0630-500 ............... MA009-01 BVP-9500WS/9500WSP MM...
Page 201 — — — — 1.5 V UNDER VOLTAGE RESET — — — LOCKOUT — — — — IN (_) — — ERROR — — — — 0.52 V — — — — — — — — — — BVP-9500WS/9500WSP MM...
Page 202 BI08 — YO00 BI09 — YO01 BO09 YO02 — YO03 CLKI2 — COM1 YO04 — CLKI1 COM2 YO05 CLKO2 — CMOD — — CLKO1 — PRST CLK1R — CLK2M — — CLK1M — CLK2R — — — — BVP-9500WS/9500WSP MM...
Page 203 — — GCLK1/CLK DEV OE/I/O — — — — — — — /I/O RDY/ /I/O CONF DONE INIT DONE/I/O TRST DATA6/I/O — — — — DEV CLR /I/O — — — — — — — — CLKUSR/I/O STATUS BVP-9500WS/9500WSP MM...
Page 204 : CONFIGURATION CLOCK D0 - D7 : CONFIGURATION DATA DONE : CONFIGURATION LOADING COMPLETE : INPUT AND/OR OUTPUT INIT : CONFIGURATION MEMORY CLEAR OTHERS : TEST CLOCK : TEST DATA INPUT : TEST DATA OUTPUT : TEST MODE SELECT BVP-9500WS/9500WSP MM...
Page 205: Block Diagram Index
E. EN-141 ..............6-18 M. MEM-98 ............. 6-12 O. Overall ..............6-3 P. PA-226 ..............6-7 PR-248 ..............6-15 PR-249 ..............6-17 S. SH-69 ..............6-8 T. TG-194 ..............6-9 TG-203 ..............6-6 V. VA-189 ............... 6-8 VA-200 ............... 6-10 BVP-9500WS/9500WSP MM...
Page 207: Overall
Overall (1/2) Overall (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher PA-226B(R) CN-2095 OHB BLOCK SUPER MOTION R_VA SMP_X3 SAMPLING EMPHASIS VIDEO_OUT R_VIDEO_OUT & & R CCD &...
Page 208 Overall (2/2) Overall (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN-1928 MB-830 MEM-98 DA-143 LINE1 VA-200 AD-157 SEL-1A-IN SEL-1A-OUT (1/2) R_OHB_VIDEO R GAIN R PRE...
Page 209 VD REF CURSOR 18CLK REF(X) L2/L3 ZEBRA 36CLK(X) CLOCK VF SKIN GATE GEN. Y OUT (VF) IIC_SPM_SDA X3/X1 CHARACTER X3/X1 MATRIX IIC_SPM_SCL IIC I/F BUFFER CHARACTER BACK R-Y OUT (VF) IIC_SW SDA IIC_SW_SCL B-Y OUT (VF) MATRIX Overall (2/2) BVP-9500WS/9500WSP MM...
Page 210 DR-377, PA-226, TG-203 DR-377, PA-226, TG-203 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 9-16 BLM_(R)_IN BLM_R_OUT 7-49 7-39 1-49 1-39 BLM_R_IN TG-194 9-13 BLM_(G)_IN BLM_G_OUT 7-46...
Page 211 IC10 1-21 H1_IN BUFF PA_VIDEO_OUT_X1 2-6 X3,X1 1-22 H2_IN SHP_X3_OUT 3-16 SELECT 1-14 SHP_X3_IN SHP_X3_IN X1_IN SHP_X1_OUT 4-16 1-16 SHP_X1_IN X1_IN X3_IN SHP_X1_OUT 3-16 PA-226 (B) BLM_IN SHP_X1_OUT 2-16 TEMP_IN 3-23 NOTE DR-377 SUFFIX NO. PA-226 TG-203 DR-377 BVP-9500WS/9500WSP MM...
Page 212 SH-69, VA-189 SH-69, VA-189 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC18 IC16 IC13,14,15 Q1,4 INV. TG-203 7-7 HD_IN HD_OUT 1-6 HD_IN BUFF IC18 Q12,15,16 BUFF...
Page 213 TG-194 TG-194 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher TG-194 TXD OUT 2-15 TG-203A, 8-15 IC26 IC38, 39 P95/TXD IC39-7 TG LD TG LD2 OUT 2-10...
Page 214 VA-200 VA-200 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher R LEVEL Q12,13 R_OBH_VIDEO_IN R_AD(X) R WHITE R PRE CN-1928,1-2 1-19 FLOATING BUFFER 2-38 AD,1-38 GAIN AMP...
Page 215 AD-157 AD-157 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher R_AD_(X) IC153 IC204 VA,2-38 1-38 18MHz BUFFER R11_AD_OUT BUFFER 2-31 MEM,2-31 R10_AD_OUT 2-32 MEM,2-32 R9_AD_OUT 2-33 MEM,2-33...
Page 216 MEM-98 MEM-98 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC100-104 IC105-109 IC190-194 AD, 2-42 AD-R0 in L1-R0 PR-248, 1-48 OCTAL OCTAL AD, 2-41 AD-R1 in L1-R1...
Page 217 DA-143 (1/2) DA-143 (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC300 R0[8:0] R01-R09 IC200 Q200-202 R01-R09 W SHADE-R(X) 1-53 VA-200,1-40 G0[8:0] LATCH G01-G09 54WS G01-G09...
Page 218 DA-143 (2/2) DA-143 (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC103 IC301(2/2) TDI1 27CLK 27CLK(X) 2-127 PR-248,1-127 525/625 X3/X1 IE36CLK CONVERTER PR-248,1-110 2-110 CONF-TMS 36CLK(X1)
Page 219 PR-248 (1/2) PR-248 (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher BOUNDARY IC11 IC110 IC303 BS-PR249-OUT DA-143,2-8 DA-143,2-6 TMS IN DA-143,2-5 TCK IN BUFF DA-143,2-9 TRST IN...
Page 220 PR-248 (2/2) PR-248 (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC401(ARC(R,G,B)) IC402,403,405,406 R-APC-OUT L1-R(0) 25%,50% R-CH CN-1787,4-44 TO 35 FILTER GEN FIFO L1-R(9) G-APC-OUT L1-G(0)
Page 221 PR-249 PR-249 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC101 IC205 IC301 IC401 IC403 IC804 TRST PR-248,2-9 TRST TRST TRST TRST TRST TRST TMS-2 PR-248,2-6 TCK-2...
Page 222 EN-141 EN-141 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC401 RV401 CCU Y RV402 Q402-Q406, IC403 Q400 IC400 IC404 CCU SYNC Q407, Q408 IC402 Q409 PR-248, 4-40...
Page 223 R2 PAL ONLY Q8, Q9 POWER SAVE (+5V D) VF, 101-6 CCIR/EIA OUT IN R1 NTSC ONLY +3.3V IN +7.5V +3.3V IN +3.3V IN Q20, Q21 +3.3V IN +3.3V +7.5V IC721 VA, 1-76 VBS_ON/OFF MONI_ON/OFF VA, 1-74 EN-141 6-19 6-19 BVP-9500WS/9500WSP MM...
Page 224 AT-128 AT-128 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher IC38 IC21 SW-1008, 1-A2 RE (X) IN C IC1 SCL DA, 1-81 BUFF SW-1008, 1-B2 RE (Y) IN...
Page 225 S. SH-69 ..............7-6 SW-936 ............... 7-82 SW-937 ............... 7-83 SW-1008 ............. 7-81 SW-1009 ............. 7-81 SW-1010 ............. 7-82 SW-1011 ............. 7-82 T. TG-194 ..............7-10 TG-203 ..............7-16 V. VA-189 ............... 7-4 VA-200 ............... 7-20 Frame Wiring ............. 7-82 BVP-9500WS/9500WSP MM...
Page 226 PA-226 PA-226 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 2SC4176-T1B35 TLC272CPW-E05 1OUT 120k 0.01uF 2OUT 0.01uF 2SC4176-T1B35 CLC505AJE-T 2SA1610-T1Y34 CLC505AJE-T 2SK620-TX ICX215AL-1 2SK508-T1K52 1SS302-TE85L 1SS300-TE85L 2SA1610-T1Y34 0.01uF...
Page 227 NR-65 NR-65 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher TC7SET08FU(TE85R) 100k 4.7uF TA-C CN1(13/20) X3_IN CLC505AJE-T 0.1uF 2SC4176-T1B35 2SA1610-T1Y34 TC7W53FU(TE12R) 3.9k 4.7uF 3.3k TA-C CN2 (1/6)
Page 228 VA-189 VA-189 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher TC7SET08FU(TE85R) CN7(10/12) PRE_BLKG_IN 100k TC7SET08FU(TE85R) *C25 0.068uF CN1 (4/14) OPT_CLP_H_IN CN9(14/20) OPT_CLP_H_OUT *R52 1SS302-TE85L 100k 2SC4176-T1B35 IC15...
Page 229 C136 C139 R310 R319 R323 R326 C122 R274 C123 100k 100pF 3.3k 100k 100pF R284 C126 1.5k R313 560pF 3.3k 0.1uF RN-C RN-C R269 R285 4.7k 2SC4176-T1B35 2SA1610-T1Y34 2SA1610-T1Y34 C138 0.1uF 2SA1610-T1Y34 VA-189 BOARD NO. 1-677-799-11, 12 BVP9500WS_VA-189_11B_1 BVP-9500WS/9500WSP MM...
Page 230 SH-69 SH-69 BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher IC3 (3/3) TC74HC4053AFT(EL) 0.0015uF 0.0015uF IC22 (3/3) 0.0015uF TC74HC4053AFT(EL) IC3 (1/3) IC3 (2/3) TC74HC4053AFT(EL) TC74HC4053AFT(EL) IC4 (1/3)
Page 231 CC_CONT1_OUT ND_CONT_2_IN (7/22) CC_CONT0_OUT ND_CONT_1_IN (10/22) ND_POSI_OUT ND_CONT_0_IN (9/22) FB10 CC_POSI_OUT CC_CONT_2_IN (12/22) CC_CONT_1_IN (11/22) CC_CONT_0_IN (14/22) 13 12 IC14 (4/4) IC16 (4/4) TL064CPW-E05 TL084CPWR SH-69 BOARD NO. 1-677-797-12 12 + 12 + BVP9500WS_SH-69_12A_1 7-7 (b) 7-7 (b) BVP-9500WS/9500WSP MM...
Page 232 SH-69 SH-69 BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 IC3 (3/3) TC74HC4053AFT(EL) 0.0015uF 0.0015uF IC22 (3/3) 0.1uF 0.0015uF TC74HC4053AFT(EL) IC3 (1/3) IC3 (2/3) TC74HC4053AFT(EL) TC74HC4053AFT(EL) SDATA IC4 (1/3) TC74HC4053AFT(EL) DA2LD IC22 IC22 IC22 0.001uF...
Page 233 CC_CONT2_OUT CC_CONT1_OUT ND_CONT_2_IN (7/22) CC_CONT0_OUT ND_CONT_1_IN (10/22) ND_POSI_OUT ND_CONT_0_IN (9/22) CC_POSI_OUT CC_CONT_2_IN (12/22) CC_CONT_1_IN (11/22) CC_CONT_0_IN (14/22) 13 12 IC14 (4/4) IC16 (4/4) TL064CPW-E05 TL084CPWR SH-69 BOARD NO. 1-677-797-11 12 + 12 + BVP9500WS_SH-69_011_1 7-7 (a) 7-7 (a) BVP-9500WS/9500WSP MM...
Page 235 DR-377 DR-377 BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher 6.5V 2SA1610-T1Y34 2SB1114-T1ZL CN1 (25/50) +6.5V_IN CN1 (45/50) BLM_B_IN BLM_B_OUT CN1 (23/50) +6.5V_IN X3_OUT 4.7uF CN1 (34/50)
Page 237 DR-377 DR-377 BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 6.5V 2SA1610-T1Y34 2SB1114-T1ZL CN1 (15/40) +6.5V_IN CN1 (35/40) BLM_B_IN BLM_B_OUT CN1 (13/40) +6.5V_IN X3_OUT 4.7uF CN1 (24/40) V-SUB_B_IN V-SUB_B_OUT TA-C 0.01uF SHUTTER_+_OUT 100uF SHUTTER_-_OUT 9.1k...
Page 238 TG-194 (1/3) TG-194 (1/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN4(4/16) TG-193,4-4 4:3/16:9 IN CN4(8/16) TG-193,4-8 5040/60 IN CN4(12/16) TG-193,4-12 SATOSE IN CN2(14/16) TG-193,2-14 SER CLK IN...
Page 239 AC15 AC13 AC14 IC30 AC14 IC29(2/4) TC7S08FU(TE85R) AC13 AC15 SN74HC02APW-E05 AB16 AC12 AC11 IC29(1/4) SN74HC02APW-E05 AC10 IC29(4/4) SN74HC02APW-E05 :TA-CD IC29(3/4) IC31 SN74HC02APW-E05 TC7S08FU(TE85R) ADRS SAVE IC33 TC7S02FU(TE85R) RESET PBLK START TG-194 (1/3) BOARD NO. 1-667-999-11 B-¥OHB750A-TG194-12@-M 7-11 7-11 BVP-9500WS/9500WSP MM...
Page 240 TG-194 (2/3) TG-194 (2/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher BM DATA ADRS AA14 FIELD CURS BM LD SER DATA SER CLK IC16 IC17 TC7S32FU(TE85R)
Page 241 8 6 7 :TA-C CN3(7/16) CN3(8/16) MA3J74200LSO CN3(9/16) 6.3V 3.3k CN3(10/16) :TA-C IC19 IC20 CN3(11/16) TC7S08FU(TE85R) SN74HC574APW-E05 CN3(14/16) IC23 CN3(15/16) IC15(2/2) IC41 IC40(1/4) TC74HC4053AFS-EL 2SA1611-T1M7 265PC812G2-E2 2SC4177-T1L5L6 TC74HC4053AFS-EL 2SA1611-T1M7 SN74HC32APW-E05 2SA1611-T1M7 2SA1611-T1M7 TG-194 (2/3) BOARD NO. 1-667-999-11 B-¥OHB750A-TG194-12@-M 7-13 7-13 BVP-9500WS/9500WSP MM...
Page 242 TG-194 (3/3) TG-194 (3/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 1µH TC7S00FU(TE85R) CN2(1/16) TG-193,2-1 +5V IN 1µH :RS-C CN3(3/16) TG-193,3-3 SHD GATE R OUT CN3(1/16)
Page 243 IC36 IC11 1SS302-TE85L TC7S00FU(TE85R) TC7S08FU(TE85R) 1.5k 1/16W 3.9k 2.2k 5.1k 6.3V 1µH IC13(4/4) IC13(3/4) IC14 IC15(1/2) IC13(2/4) IC13(1/4) TLC274CPW-E05 0 XP6534-TX XP6534-TX TLC274CPW-E05 0 TC4W53FU(TE12R) 265PC812G2-E2 TLC274CPW-E05 0 TLC274CPW-E05 0 TG-194 (3/3) BOARD NO. 1-667-999-11 B-¥OHB750A-TG194-12@-M 7-15 7-15 BVP-9500WS/9500WSP MM...
Page 244 TG-203 (1/2) TG-203 (1/2) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher +3.3V CN6 (7/7) +3.3V CN6 (6/7) CN6 (5/7) CN6 (4/7) ISPEN CN6 (3/7) CN6 (2/7) CN6 (1/7) +3.3V...
Page 245 B-SUB 100k V-SUB_B_OUT (34/50) RN-C VRG_R VREG_R_OUT (28/50) (-9.8V) VRG_G AO10 VREG_G_OUT (33/50) 2SK620-TX VRG_B AO11 VREG_B_OUT (48/50) 1SS300-TE85L AO12 3.3k C115 2.2uF -11V_OUT (11/50) TG-203 (1/2) INTEGR 002-C8 BOARD NO. 1-677-798-12, 13 BVP9500WS_TG-203_12X_1 7-17 (b) 7-17 (b) BVP-9500WS/9500WSP MM...
Page 247 TG-203 (2/2) TG-203 (2/2) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher +3.3V +3.3V R302 R303 +3.3V +3.3V IC56 (2/3) R302 R302 74LCX74MTCX R303 C107 R303 IC57...
Page 248 TG-203 TG-203 BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 +3.3V CN6 (7/7) +3.3V CN6 (6/7) CN6 (5/7) CN6 (4/7) ISPEN R222 R221 CN6 (3/7) CN6 (2/7) CN6 (1/7) 33pF +3.3V TEG1 CN3 (2/14)
Page 249 CN7 (37/40) R206 B-SUB V-SUB_B_OUT CN7 (24/40) H2_OUT CN7 (9/40) 100k R226 VRG_R VREG_R_OUT CN7 (18/40) VRG_G VREG_G_OUT CN7 (23/40) 2SK620-TX VRG_B C102 VREG_B_OUT CN7 (38/40) 10pF -11V_OUT CN7 (1/40) TG-203 BOARD NO. 1-677-798-11 BVP9500WS_TG-203_11B_1 7-17 (a) 7-17 (a) BVP-9500WS/9500WSP MM...
Page 250 VA-200 (1/2) VA-200 (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher NOTE SERIAL NO. 10001-10022(UC) 30001-30003(J) 40001-40032(CE) 002-I5 R_GAIN 18001-(UC) 38001-(J) 48001-(CE) 2SC4177-T1L5L6 2SA1611T1-M5M6 2SC4177-T1L5L6 IC2(2/2)
Page 251 TA-C TA-C TA-C TA-C TA-C C236 10uF TA-C RV203;B MOD BAL +3.5V L204 10uH +2.5V 002-I6 R_FLARE 002-I7 G_FLARE 002-I7 B_FLARE 002-I7 VA-200 (1/2) BOARD NO. 1-677-809-11 BVP9500WS_VA-200_011_1 SYN_GATE (14/41) R_CLAMP_DC_OUT (21/41) G_CLAMP_DC_OUT (20/41) B_CLAMP_DC_OUT (22/41) 7-21 7-21 BVP-9500WS/9500WSP MM...
Page 253 VA-200 (2/2) VA-200 (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN2 (19/40) OHB_H_CONT FAN_A_CONT CN1 (79/100) FAN_B_CONT CN1 (77/100) OHB_H_PULSE CN1 (68/100) FAN_CONT_ON/OFF CN1 (78/100)
Page 254 AD-157 AD-157 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher (2/2) CLC505AJE-T CLC505AJE-T 2SA1808-PT106 2SA1808-PT106 TC7W53FU(TE12R) 2SC4215Y-TE85L CLC505AJE-T TL062CPWR 0.1uF 10uF 2.2k RN-C 1.5k 3.3k 3.9k RN-C...
Page 255 6.3V TA-C RB205,RB206 R272 NM 18001-(UC) RB207,RB208 38001-(J) 48021-(CE) C262 C265 C266 R279 R287 RB209,RB210 C261 C269 120pF 120pF 0.1uF 10uF 0.1uF 1/4W RB211 RN-C TA-C IC261 (1/2) IC257 (2/4) TLC272CPW-E05 AD-157 BOARD NO. 1-677-800-11 BVP9500WS_AD-157_11A_1 7-25 7-25 BVP-9500WS/9500WSP MM...
Page 256 MEM-98 (1/5) MEM-98 (1/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN2(60pin):AD-IF CN1(200pin):MB(DA)-IF +3.3V-2 CN1(200/200) 200 CN1(199/200) 199 +3.3V out for AD-FF CN1(198/200) 198 +3.3V out for AD-FF CN1(197/200) 197 +3.3V out for AD-FF...
Page 257 MEM-98 (2/5) MEM-98 (2/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher AD-RGB AD-RGB LINE1-OUT IC190 LINE-1 001-L1,003-B1,004-B1 74LCX574MTCX +3.3V +3.3V +3.3V +3.3V C100 IC100 C105 IC105...
Page 258 MEM-98 (3/5) MEM-98 (3/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher AD-RGB AD-RGB 001-L1,002-B1,004-B1 LINE2-OUT +3.3V +3.3V +3.3V +3.3V +2.5V LINE-2 OUT C200 IC200 C205 IC205...
Page 259 MEM-98 (4/5) MEM-98 (4/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher AD-RGB AD-RGB 001-L1,002-B1,003-B1 LINE3-OUT +3.3V +3.3V +3.3V +3.3V LINE-3 OUT 74LCX574MTCX C300 IC300 C305 IC305...
Page 260 MEM-98 (5/5) MEM-98 (5/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher B-Scan 001-G8 B-Scan CONT-3B CONT-3B 004-G9 CONT-3A CONT-3A 004-B9 +3.3V L501 2.2uH C501 C502 C503...
Page 261 DA-143 (1/5) DA-143 (1/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher Line1-Video Line2-Video Line3-Video CN1 (1/200) (49/240) CN1 (2/200) CN1 (3/200) L1-B11 L1-B11 (13/240) CN1 (139/200)
Page 262 DA-143 (2/5) DA-143 (2/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +5.0V L101 IC105 47uH (1/2) +3.3V +5.0V TLC272CPW-E05 D100 R130 C112 MA3J74200LSO +3.3V 100k 10uF...
Page 263 DA-143 (3/5) DA-143 (3/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +5.0V L201 10uH R208 R207 L200 C200 IC202 (3/4) 10uH 0.1uF TLC274CPW-E05 R220 IC202 (2/4)
Page 264 DA-143 (4/5) DA-143 (4/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher JTAG 005-M1 JTAG WS-IF 005-M2 WS-IF 54WS +3.3V 54WS 003-C5 TO DA L302 C306 C307...
Page 265 DA-143 (5/5) DA-143 (5/5) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +3.3V IC314 NC7SZ08P5 JTAG JTAG 004-C1 WS-IF WS-IF 004-C2 +5.0V +3.3V CN2:to/from 248,249 C300 C301 (9/240) 0.1uF...
Page 266 PR-248 (1/6) PR-248 (1/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher 002-H1,003-C9 +2.5V 100k IC12 +2.5V NC7SZ86P5 IC11 (2/9) IC11 (3/9) 74LCX541MTCX IC11 (4/9) IC11 (5/9)
Page 267 L1-G(11) (25/240) 10uF (24/240) L1-B(0) (23/240) L1-B(1) (22/240) L1-B(2) (21/240) L1-B(3) (20/240) L1-B(4) L1-B(5) (19/240) L1-B(6) (18/240) (17/240) L1-B(7) (16/240) L1-B(8) (15/240) L1-B(9) (14/240) L1-B(10) (13/240) L1-B(11) PR-248 (1/6) BOARD NO. 1-677-806-12, 13 BVP9500WS_PR-248_12A_1 7-37 (b) 7-37 (b) BVP-9500WS/9500WSP MM...
Page 268 PR-248 (2/6) PR-248 (2/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher IE-OUT-18MHzCLK 001-E6 001-E7,003-M5,004-B10,006-L6 BOUNDARY 001-D1,003-C9 001-E8 HD/VD-SH-OUT B-OUT-SH 001-E9 001-E8 R-OUT-SH 001-E9 G-OUT-SH +5.0V C139 0.1uF...
Page 269 C138 C115 0.1uF 0.1uF HD/VD_OUT_IE 003-M4 003-M4 003-M3 DTL-OUT-IE 003-M2 B_OUT_IE 003-M2 G_OUT_IE 003-M1 003-M1 R_OUT_IE to ARC DTL_IE_OUT_ARC 004-M2 36MHzCLK(X) 003-M2 36MHzCLK(X)-DA 005-O6 SC-CONT-OUT H-CNT(ST-ALONE) (106/240) PR-248 (2/6) BOARD NO. 1-677-806-12, 13 BVP9500WS_PR-248_12A_2 7-39 (b) 7-39 (b) BVP-9500WS/9500WSP MM...
Page 271 PR-248 (3/6) PR-248 (3/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher from IE 002-AB9 R_OUT_IE G_OUT_IE 002-AB8 002-AB8 B_OUT_IE 001-S2,002-H9 PowerOnReset +2.5V 36MHzCLK(X) 002-AB9 002-AB8 L302...
Page 272 PR-248 (4/6) PR-248 (4/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher BZS-IN 003-G9 BZS-IN 003-C5 R-CH 003-C3 G-CH +3.3V 002-M8 36MHzCLK(X)-ARC 003-C6 B-CH +2.5V +3.3V L408 L406 0.1uF...
Page 273 (42/45) VD-PR-OUT VF_DTL-VIDEO(X) VF-DTL(X) (43/45) VF_DTL-VIDEO(G) ARC-SKIN-G VF-DTL(G) (44/45) BLANKING (45/45) IC411 TC7WH74FU(TE12R) R430 GND-A page-2 ARC-Analog-out Analog-OUT1 ARC-Analog-OUT 002-AB3 002-AB4 Analog-OUT1 from DA VIDEO(X) 005-Y6 VIDEO(X)/(G) PR-248 (4/6) BOARD NO. 1-677-806-12, 13 BVP9500WS_PR-248_12A_4 7-43 (b) 7-43 (b) BVP-9500WS/9500WSP MM...
Page 274 PR-248 (5/6) PR-248 (5/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher IC505 R559 R561 L-NORMAL NC7SZ04P5 100k H-PowerSave 002-G7 DA-OUT-ON/OFF R560 100k R-ARC-OUT Q500 Q505 004-I8...
Page 275 0.1uF VIDEO-GAIN 002-I5 VIDEO-GAIN 002-AB9 36MHzCLK(X)-DA +3.3V C525 C515 0.1uF 0.1uF IC510 NC7SZ86P5 IC504 CXD2315Q IC508 NC7SZ66P5X L502 +5V-2 L501 -3.0V C512 C508 0.1uF 33uF GND-A PR-248 (5/6) L500 BOARD NO. 1-677-806-12, 13 BVP9500WS_PR-248_12A_5 7-45 (b) 7-45 (b) BVP-9500WS/9500WSP MM...
Page 276 PR-248 (6/6) PR-248 (6/6) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher PR-248 PR-248 PR-249 PR-248 PR248-249(2) PR-249 +2.5V PR248-249(1) L600 IIC-SPM 10uH 002-C7 IIC-SPM (221/240) +2.5V...
Page 278 PR-248 (1/6) PR-248 (1/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 002-H1,003-C9 +2.5V 100k IC12 +2.5V NC7SZ86P5 IC11 (2/9) IC11 (3/9) 74LCX541MTCX IC11 (4/9) IC11 (5/9) IC11 (6/9) 74LCX541MTCX 74LCX541MTCX 74LCX541MTCX 74LCX541MTCX BS-PR249-OUT...
Page 279 L1-G(10) (25/240) L1-G(11) 10uF (24/240) L1-B(0) (23/240) L1-B(1) (22/240) L1-B(2) L1-B(3) (21/240) L1-B(4) (20/240) (19/240) L1-B(5) (18/240) L1-B(6) (17/240) L1-B(7) (16/240) L1-B(8) L1-B(9) (15/240) L1-B(10) (14/240) (13/240) L1-B(11) PR-248 (1/6) BOARD NO. 1-677-806-11 BVP9500WS_PR-248_11A_1 7-37 (a) 7-37 (a) BVP-9500WS/9500WSP MM...
Page 280 PR-248 (2/6) PR-248 (2/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 IE-OUT-18MHzCLK 001-E6 001-E7,003-M5,004-B10,006-L6 BOUNDARY 001-D1,003-C9 001-E8 HD/VD-SH-OUT 001-E9 B-OUT-SH 001-E8 R-OUT-SH 001-E9 G-OUT-SH +5.0V C139 0.1uF IC120 (1/3) L105 C100 IC113 (2/2)
Page 281 PR C115 C138 0.1uF 0.1uF 003-M4 HD/VD_OUT_IE 003-M4 003-M3 DTL-OUT-IE 003-M2 B_OUT_IE 003-M2 003-M1 G_OUT_IE 003-M1 R_OUT_IE to ARC DTL_IE_OUT_ARC 004-M2 003-M2 36MHzCLK(X) 36MHzCLK(X)-DA 005-O6 SC-CONT-OUT (106/240) H-CNT(ST-ALONE) PR-248 (2/6) BOARD NO. 1-677-806-11 BVP9500WS_PR-248_11A_2 7-39 (a) 7-39 (a) BVP-9500WS/9500WSP MM...
Page 283 PR-248 (3/6) PR-248 (3/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 from IE R_OUT_IE 002-AB9 002-AB8 G_OUT_IE B_OUT_IE 002-AB8 001-S2,002-H9 PowerOnReset +2.5V 36MHzCLK(X) 002-AB9 002-AB8 L302 DTL-OUT-IE L303 002-AB7 002-AB5 C306 C311 0.1uF 0.1uF...
Page 284 PR-248 (4/6) PR-248 (4/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 BZS-IN 003-G9 BZS-IN R400 0 HD-PR-OUT VD-PR-OUT R401 003-C5 R-CH 003-C3 G-CH +3.3V 002-M8 36MHzCLK(X)-ARC 003-C6 B-CH +2.5V +3.3V L408 L406 0.1uF...
Page 285 NC7SZ125P5 VD-PR-OUT (42/45) VF_DTL-VIDEO(X) (43/45) VF-DTL(X) VF_DTL-VIDEO(G) ARC-SKIN-G (44/45) VF-DTL(G) (45/45) BLANKING IC411 TC7WH74FU(TE12R) R430 GND-A page-2 ARC-Analog-out Analog-OUT1 ARC-Analog-OUT 002-AB3 002-AB4 Analog-OUT1 from DA VIDEO(X) 005-Y6 VIDEO(X)/(G) PR-248 (4/6) BOARD NO. 1-677-806-11 BVP9500WS_PR-248_11A_4 7-43 (a) 7-43 (a) BVP-9500WS/9500WSP MM...
Page 286 PR-248 (5/6) PR-248 (5/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 IC505 R559 L-NORMAL R561 NC7SZ04P5 100k H-PowerSave 002-G7 DA-OUT-ON/OFF R560 100k R-ARC-OUT 004-I8 R-ARC-OUT C526 C501 C527 R530 C516 C506 R506 Q505 33uF 6.8k...
Page 287 VIDEO-GAIN 002-I5 VIDEO-GAIN 002-AB9 36MHzCLK(X)-DA +3.3V C525 Q504 C515 0.1uF 0.1uF 2SA1688-4-SONY-TL IC510 NC7SZ86P5 IC504 CXD2315Q IC508 NC7SZ66P5X L502 +5V-2 L501 -3.0V C512 C508 0.1uF 33uF GND-A L500 PR-248 (5/6) BOARD NO. 1-677-806-11 BVP9500WS_PR-248_11A_5 7-45 (a) 7-45 (a) BVP-9500WS/9500WSP MM...
Page 288 PR-248 (6/6) PR-248 (6/6) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 PR-248 PR-248 PR-249 PR-248 PR248-249(2) PR-249 +2.5V PR248-249(1) L600 IIC-SPM 002-C7 IIC-SPM (221/240) +2.5V (215/240) (136/160) (67/160) (222/240) (135/160) +2.5V L601 (216/240)
Page 289 PR-249 (1/8) PR-249 (1/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher L2-(IC_clock_18) 002-C1 Power-ON-Reset 002-C7,003-C1,004-V1,005-K1,006-C8,007-C1,008-X2 +2.5V-L2 line2_IIC line2_IIC L101 002-C5,003-C8,004-W3,006-C7 JC103 C107 0.1uF C106 0.1uF JC102...
Page 290 PR-249 (2/8) PR-249 (2/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +2.5V-L2 IC204 C207 NC7SZ04P5 0.1uF R205 001-K1 L2-(IC_clock_18) +2.5V-L2 JC202 from SH L201 JC204 JC203...
Page 291 PR-249 (3/8) PR-249 (3/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 002-I8,004-C1 L2-36MHzCLK(X) Power-ON-Reset 001-K1,002-C7,004-V1,005-K1,006-C8,007-C1,008-X2 L2-(IE_video) L2-(IE_video) 002-C6 +2.5V-L2 L2-DTL L2-DTL 002-L7 L301 L302 C305 C308 0.1uF...
Page 292 PR-249 (4/8) PR-249 (4/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +2.5V-L2 SPARE-VIDEO-IN 008-C2 002-I8,003-C1 L2-36MHzCLK(X) +2.5V-L2 C405 C406 C407 C409 0.1uF 0.1uF 0.1uF 0.1uF R428 IC407 +2.5V-L2...
Page 293 Line2-8 L2-8 (67/160) Line2-9 74LCX16374MTDX L2-9 C420 0.1uF (52/160) (51/160) C419 0.1uF R417 VF-CHR VF-CHARACTOR C426 (4/160) 47pF (3/160) (2/160) (1/160) L2-signal L2-SIGNAL R429 L2-SIGNAL 008-W9 PR-249 (4/8) BOUNDARY_SCAN BOARD NO. 1-677-807-11, 12 BOUNDARY_SCAN 001-I9,002-C3,003-L6,005-J9,006-D3,007-L6,008-W4 BVP9500WS_PR-249_11A_4 7-51 7-51 BVP-9500WS/9500WSP MM...
Page 294 PR-249 (5/8) PR-249 (5/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher L3-(IC_clock_18) 006-D1 Power-ON-Reset 001-K1,002-C7,003-C1,004-V1,006-C8,007-C1,008-X2 +2.5V-L3 line3_IIC line3_IIC 006-C5,007-C8,008-X3 L501 JC503 C507 0.1uF C506 0.1uF JC502...
Page 295 PR-249 (6/8) PR-249 (6/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +2.5V-L3 IC605 NC7SZ04P5 C607 0.1uF R611 005-K1 L3-(IC_clock_18) +2.5V-L3 JC602 JC603 L601 from SH JC604...
Page 297 PR-249 (7/8) PR-249 (7/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 006-J8,008-C1 L3-36MHzCLK(X) Power-ON-Reset 001-K1,002-C7,003-C1,004-V1,005-K1,006-C8,008-X2 L3-(IE_video) L3-(IE_video) 006-C8 +2.5V-L3 L3-DTL L3-DTL 006-L7 L701 L702 C705 C708 0.1uF...
Page 298 PR-249 (8/8) PR-249 (8/8) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher L3-36MHzCLK(X) +2.5V-L3 006-J8,007-C1 L801 L802 C805 C807 C808 C809 C811 33uF 0.1uF 0.1uF 0.1uF 0.1uF...
Page 299 0.1uF L2-6 L2[6]-OUT L2-5 C820 L2[5]-OUT 0.1uF R808 L2-4 L2[4]-OUT SPARE L2-3 L2[3]-OUT SPARE-VIDEO C826 L2-2 47pF L2[2]-OUT L2-1 L2[1]-OUT L2-0 L2[0]-OUT L3signal HD/VD-IN 001-L8,004-M7,005-J8 L3-SIGNAL PR-249 (8/8) BOARD NO. 1-677-807-11, 12 L2-SIGNAL 004-X8 BVP9500WS_PR-249_11A_8 L2-SIGNAL 7-57 7-57 BVP-9500WS/9500WSP MM...
Page 300 EN-141 (1/3) EN-141 (1/3) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher CN1(12/100) VBS_ON/OFF CNT-R Q101 Q102(2/2) IC100 Q105 Q106 2SK1332-3-TL XP6435-TX 2SA1808-PT106 2SA1808-PT106 AD8005ART-REEL7 002-C6 +7.5V...
Page 301 IC502 (4/4) IC502 (3/4) R552 TL064CPW-E05 TL064CPW-E05 R543 C520 C525 R554 R557 C528 R563 C531 C529 2.2uF 0.01uF 4.7uF 10pF C526 EN-141 (1/3) EXT_SC_OUT (30/100) IC503 (2/3) IC508 TC74HC4053AFT(EL) TC4W53FU(TE12R) BOARD NO. 1-677-803-12 BVP9500WS_EN-141_12A_1 7-59 (b) 7-59 (b) BVP-9500WS/9500WSP MM...
Page 302 EN-141 (2/3) EN-141 (2/3) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher CN1 (7/100) MONI_ON/OFF CNT-R IC721 TC7ST32FU(TE85R) Power.Save(+5V_D)-RB Power.Save(+5V)-RB Power.Save(-3V)-RB 001-Z3, Y/R/G/B 003-E3 001-C1, +5V_D 003-E4...
Page 303 R770 R771 R772 C655 2.2k R699 R768 18pF C661 R783 0.1uF CR 13 R781 C662 R782 0.1uF R780 R779 C664 C656 10uF C663 R784 C665 0.1uF 0.1uF 10uF EN-141 (2/3) BOARD NO. 1-677-803-12 BVP9500WS_EN-141_12A_2 7-61 (b) 7-61 (b) BVP-9500WS/9500WSP MM...
Page 304 EN-141 (3/3) EN-141 (3/3) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher 001-C5 VF_SELECT2 IC801 001-C5 VF_SELECT1 TC4W53FU(TE12R) Power.Save(+5V)-R IC800(3/3) Power.Save(+5V)-RB Q806 R809 R818 Q807 TC74HC4052AFT(EL) 6.8k 2SC4215Y-TE85L 6.8k...
Page 305 R916 C905 R920 R924 R925 R933 C910 R937 R941 R942 2.7k 0.1uF 2.7k 0.1uF Y_OUT_VF (62/100) GND_VF (61/100) C903 R915 R921 R926 C908 R932 R938 R943 10uF 2.2uF EN-141 (3/3) BOARD NO. 1-677-803-12 BVP9500WS_EN-141_12A_3 7-63 (b) 7-63 (b) BVP-9500WS/9500WSP MM...
Page 306 EN-141 (1/3) EN-141 (1/3) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 CN1(12/100) VBS_ON/OFF CNT-R Q105 Q101 Q102(2/2) 2SA1808-PT106 Q106 IC100 2SK1332-3-TL XP6435-TX 2SA1808-PT106 AD8005ART-REEL7 002-C6 +7.5V C105 002-C2, R120 003-E1 R125 R103 6.8k 2.2k...
Page 307 IC502 (4/4) IC502 (3/4) R552 TL064CPW-E05 TL064CPW-E05 R543 C520 C525 R554 R557 C528 R563 C531 C529 2.2uF 0.01uF 4.7uF 10pF C526 EXT_SC_OUT (30/100) IC503 (2/3) EN-141 (1/3) IC508 TC74HC4053AFT(EL) TC4W53FU(TE12R) BOARD NO. 1-677-803-11 BVP9500WS_EN-141_12A_1 7-59 (a) 7-59 (a) BVP-9500WS/9500WSP MM...
Page 308 EN-141 (2/3) EN-141 (2/3) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 CN1 (7/100) MONI_ON/OFF CNT-R IC721 TC7ST32FU(TE85R) Power.Save(+5V_D)-RB Power.Save(+5V)-RB Power.Save(-3V)-RB 001-Z3, Y/R/G/B 003-E3 001-C1, +5V_D 003-E4 L600 001-C1, 003-E1 Digital_(+5V)_RB 001-C4 CLAMP R797...
Page 309 R786 R789 R780 0.1uF R779 IC604 TL062CPWR (2/2) IC602 (1/3) IC604 (1/2) C664 TC74VHC123AFT(EL) C656 TL062CPWR 10uF C663 R784 C665 IC602 (2/3) 0.1uF 0.1uF 10uF TC74VHC123AFT(EL) RV609:INT SC EN-141 (2/3) BOARD NO. 1-677-803-11 BVP9500WS_EN-141_12A_2 7-61 (a) 7-61 (a) BVP-9500WS/9500WSP MM...
Page 310 EN-141 (3/3) EN-141 (3/3) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 001-C5 VF_SELECT2 IC801 001-C5 VF_SELECT1 TC4W53FU(TE12R) Power.Save(+5V)-R Power.Save(+5V)-RB IC800(3/3) R809 Q806 R818 Q807 TC74HC4052AFT(EL) 6.8k 6.8k 2SC4215Y-TE85L XP6534-TX R804 R805 R806 R807 240(UC) 3.3k...
Page 311 R916 C905 R920 R924 R925 R933 C910 R937 R941 R942 2.7k 0.1uF 2.7k 0.1uF Y_OUT_VF (62/100) GND_VF (61/100) C903 R915 R921 R926 C908 R932 R938 R943 10uF 2.2uF EN-141 (3/3) BOARD NO. 1-677-803-11 BVP9500WS_EN-141_12A_3 7-63 (a) 7-63 (a) BVP-9500WS/9500WSP MM...
Page 312 AT-128 (1/3) AT-128 (1/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher REC_TALLY0 CN1(58/100) REC_TALLY_IN TAPE_REM0 CN1(72/100) TAPE_REMAIN_IN AUDIO_LEVEL0 CN1(73/100) AUDIO_LEVEL_IN IRIS_POSI0 CN1(74/100) IRIS_POSI_IN EX.P._POSI0 CN1(76/100) EX.P._POSI...
Page 313 MA3J74200LSO RN-C RN-C RN-C RN-C RN-C RN-C RN-C RN-C RN-C TA-C RN-C RN-C GND-2 GND-2 MA3J74200LSO MA3J74200LSO MA3J74200LSO MA3J74200LSO MA3J74200LSO MA3J74200LSO MA3J74200LSO GND-2 0.1uF EX.P._POSI 003-D4 IRIS_POSI 003-D5 FOCUS_POSI 003-D5 AT-128 (1/3) BOARD NO. 1-677-801-11 BVP9500WS_AT-128_011_1 7-65 7-65 BVP-9500WS/9500WSP MM...
Page 314 AT-128 (2/3) AT-128 (2/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher 1SS301-TE85L +3.3V R123 R124 R125 100k 100k 1SS301-TE85L 0.39uH PC15 1SS301-TE85L STK12C68-S45 PC02 2.2k 1SS301-TE85L...
Page 315 IC38 (5/9) 74LCX244MTCX 74LCX244MTCX C107 IC11 (5/9) AT-128 (2/3) 10uF 10uF 10uF 10uF 10uF 0.1uF IC11 (4/9) 74LCX244MTCX 74LCX244MTCX C110 TA-C TA-C TA-C TA-C TA-C 0.001uF IC11 (7/9) 74LCX244MTCX BOARD NO. 1-677-801-11 IC12 (1/3) BVP9500WS_AT-128_011_2 TC7W00FU(TE12R) 7-67 7-67 BVP-9500WS/9500WSP MM...
Page 316 AT-128 (3/3) AT-128 (3/3) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher +3.3V +3.3V-2 0.39uH 0.39uH IC21 0.1uF HD6417032VF12 0.1uF 0.1uF GND-2 PA15/IRQ3/DREQ1 PA14/IRQ2/DACK1 PA13/IRQ1/DREQ0/TCLKB PA12/IRQ0/DACK0/TCLKA SCL-IC1...
Page 317 GND-2 SOCK SER_CLK_OUT (57/100) 23 (23/100)CN1 LD_V_BLKG SDA1 SER_DATA_1_OUT 24 (24/100)CN1 R140 220 R141 220 IC31 TC7W74FU(TE12R) C101 C129 150pF 150pF 150pF 150pF 150pF R112 CCD_RXD_OUT (35/100) R113 CCD_TXD_IN (36/100) AT-128 (3/3) BOARD NO. 1-677-801-11 BVP9500WS_AT-128_011_3 7-69 7-69 BVP-9500WS/9500WSP MM...
Page 318 PS-553 (1/2) PS-553 (1/2) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher 002-L6 +9.3V_ITH 002-L4 +2.5V_ITH 002-L6 -5.5V_ITH (3/4) (1/4) (2/4) (4/4) TLC27L4CPW-E05 TLC27L4CPW-E05 DTA144EUA-T106 1SS301-TE85L TLC27L4CPW-E05...
Page 319 PS-553 (2/2) PS-553 (2/2) BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher IC151 (2/2) IC151 (1/2) Q153 IC152 TC7S04FU(TE85R) TC7S04FU(TE85R) LTC1625CGN-E2 SI4410DY-T1-REVA (13/101) IC101 Q102 +5.5V L100...
Page 320 PS-553 (1/2) PS-553 (1/2) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 002-L6 +9.3V_ITH 002-L4 +2.5V_ITH 002-L6 -5.5V_ITH (3/4) (4/4) (1/4) (2/4) DTA144EUA-T106 1SS301-TE85L TLC27L4CPW-E05 TLC27L4CPW-E05 TLC27L4CPW-E05 TLC27L4CPW-E05 002-B4 100k 3.3M kaishuu 100k 150k...
Page 321 PS-553 (2/2) PS-553 (2/2) BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 IC151 (2/2) IC151 (1/2) Q153 IC152 TC7S04FU(TE85R) TC7S04FU(TE85R) LTC1625CGN-E2 SI4410DY-T1-REVA (13/101) CN1 IC101 Q102 Q101 D101 +5.5V L100 DTC144EUA-T106 LTC1625CGN-E2 SI4410DY-T1-REVA 10uH...
Page 323 PS-554 PS-554 BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher Q3 (1/2) IC51 DTC144EUA-T106 LTC1625CGN-E2 SI9945AEY-T1 DTC144EUA-T106 LTC1625CGN-E2 10uH CN1(2/20) UNREG_IN CN1(12/20) UNREG_IN IC101 (3/4) CN1(3/20) GND_UNREG...
Page 325 PS-554 PS-554 BVP-9500WS (UC) : S/N 10001 throuth 10010 BVP-9500WSP (CE) : S/N 40001 throuth 40007 Q3 (1/2) IC51 DTC144EUA-T106 LTC1625CGN-E2 SI9945AEY-T1 DTC144EUA-T106 LTC1625CGN-E2 10uH CN1(2/20) UNREG_IN CN1(12/20) 12 UNREG_IN IC101 (3/4) CN1(3/20) GND_UNREG TC7W04FU(TE12R) CN1(13/20) 13 GND_UNREG 0.1uF 0.1uF 1A-1.8A...
Page 326 MB-830 (1/2) MB-830 (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher OHB1 CHB_DIAG_IN OHB3 CC_POSI_IN BTB14 IIC_OHB_SDA OHB7 SW-TOP CN12 CCD_TXD_IN BTB17 LD_OHB BTB19 SER_CLK_OUT OHB2...
Page 327 (8/200) (7/200) GND_D GND_D L1-B6 L1-B7 L1_B8 L1_B9 (6/200) (5/200) GND_D GND_D L1-B8 L1-B9 L1_B10 L1_B11 (4/200) (3/200) GND_D GND_D L1-B10 L1-B11 (2/200) (1/200) GND_D GND_D GND_D GND_D MB-830 (1/2) BOARD NO. 1-677-804-11 IIC_CONT_SW BVP9500WS_MB-830_11A_101 CONTROL_A 7-75 7-75 BVP-9500WS/9500WSP MM...
Page 328 MB-830 (2/2) MB-830 (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher POWER POWER INTERFACE FAN_CONT UNREG_IN GND_UNREG GND_A GND_A CN4(100/100) CN4(99/100) 99 GND_A GND_A CN5(100/100) CN5(99/100)
Page 329 10uH C601uF 0.1uF VF_GND (3/70) CN7 (4/70) CN7 PB_REFERENCE_IN C611uF F_B_+ +3.3V/+2.5V (1/70) CN7 (2/70) CN7 VTR_SYNC_CA_OUT 6.8uF C621uF 0.1uF TA-C C631uF C64 0.22uF F_B_- 10uH 0.01uF CN20 CN13 CN18 MB-830 (2/2) BOARD NO. 1-677-804-11 BVP9500WS_MB-830_11A_102 7-77 7-77 BVP-9500WS/9500WSP MM...
Page 330 CN-1787 (1/2) CN-1787 (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher LINE-23 SN74LVC827APWR 0.1uF SPARE-OUT L309 L3[9]-OUT L308 L3[8]-OUT FL56 L307 L3[7]-OUT CLK27 L306 LINE3_OUT L3[6]-OUT...
Page 331 CN-1787 (2/2) CN-1787 (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN1_BUS_A CN1_BUS_A 001-B9 001-B9 SKIN_GATE FL150 FL149 +3.3V FL148 VTR_SYNC_CA_IN VF_GND VF_GND FL147 PB_REFERENCE_OUT VF_GND...
Page 332 CN-1927, CN-1928, CN-1929 CN-1927, CN-1928, CN-1929 BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher...
Page 333 CN-1930, CN-2045, SW-1008, SW-1009 CN-1930, CN-2045, SW-1008, SW-1009 BVP-9500WS (UC) : S/N 10011 and Higher BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40008 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher (1-580-535-11;12Pin)
Page 334 Frame Wiring (1/2) Frame Wiring (1/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher CN101 CN101 (FEMALE) (FEMALE) -EXTERNAL SIDE- -EXTERNAL SIDE- 13 14 15 16 17...
Page 335 CHU_DATA_OUT L3_9_OUT MIC1 (XLR) L1_R1 HARNESS MIC 1 IN IIC_CA_IN/OUT 27MHZ_CLOCK_IN CONNECTOR (MIC) L1_R0 CN103 ELCO IIC_DATA_ST 18MHZ_X_OUT MIC(X)_OUT MIX_X_IN MIC(X)_IN MIC(Y)_OUT MIC_Y_IN MIC(Y)_IN GND(MIC) GND_MIC GND(MIC) UNREG_+12V_IN CN-1787 GND(A) UNREG_+12V_OUT CN-1927 GND_A Frame Wiring (1/2) 7-83 7-83 BVP-9500WS/9500WSP MM...
Page 336 Frame Wiring (2/2) Frame Wiring (2/2) BVP-9500WS (UC) : S/N 10001 and Higher BVP-9500WS (J) : S/N 30001 and Higher BVP-9500WSP (CE) : S/N 40001 and Higher HN103 HN101 HN105 HARNESS HARNESS HARNESS (PA) (PA) (FD) +5V_OUT +5V_IN +5V_IN +5V_OUT...
Page 337 PS-554 ..............8-29 S. SH-69 ..............8-31 SW-936 ............... 8-33 SW-937 ............... 8-33 SW-1008 ............. 8-33 SW-1009 ............. 8-33 SW-1010 ............. 8-33 SW-1011 ............. 8-33 T. TG-194 ..............8-35 TG-203 ..............8-37 V. VA-189 ............... 8-39 VA-200 ............... 8-41 BVP-9500WS/9500WSP MM...
Page 339 R160 RB150 C177 C178 IC257 R161 RB151 IC261 * B2 C179 R162 RB152 IC262 R163 RB153 C180 C181 IC264 * C2 R164 RB154 C182 IC266 R165 RB155 R166 RB156 C183 JC152 R167 RB157 C184 C185 JC153 R168 RB158 BVP-9500WS/9500WSP MM...
Page 341 * B4 R126 * D3 * H4 IC23 R128 IC24 R129 * H4 IC25 R130 * H4 * D2 * H4 IC26 R131 IC27 * H3 R132 * D7 IC28 * G4 R133 * E7 IC29 R134 * D7 BVP-9500WS/9500WSP MM...
Page 343 FL46 * A3 FL49 FL56 FL105 * A3 FL106 * A3 FL107 * A3 FL108 * A3 *:B SIDE FL109 * A3 FL110 * A3 FL111 * A3 FL112 * A3 FL113 * A3 FL114 * A3 FL118 BVP-9500WS/9500WSP MM...
Page 344 * B1 FL35 SUFFIX: -11 SUFFIX: -11 * B1 FL36 * B1 FL37 FL38 FL39 * B2 FL40 FL41 * B2 FL45 FL46 FL49 FL56 FL105 FL106 FL107 FL108 *:B SIDE FL109 FL110 FL111 FL112 FL113 FL114 FL118 BVP-9500WS/9500WSP MM...
Page 345 -B SIDE- SUFFIX: -11 SUFFIX: -11 CN-2045 -A SIDE- SUFFIX: -11 FL11 FL13 CN-2045 -B SIDE- SUFFIX: -11 CN-1929 CN-1929 -A SIDE- -B SIDE- CN-2095 CN-2095 SUFFIX: -11 SUFFIX: -11 -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 BVP-9500WS/9500WSP MM...
Page 347 R234 C332 C333 L100 * B3 R235 *:B SIDE C334 L101 R236 L102 R237 C335 C336 L103 * D1 R238 C337 L200 R239 L201 R240 C338 L202 * A1 R241 C339 C340 L203 * A2 R242 8-11 8-11 BVP-9500WS/9500WSP MM...
Page 348 R234 C332 C333 L100 * B3 R235 *:B SIDE C334 L101 R236 L102 R237 C335 C336 L103 * D1 R238 C337 L200 R239 L201 R240 C338 L202 * A1 R241 C339 C340 L203 * A2 R242 8-12 8-12 BVP-9500WS/9500WSP MM...
Page 349 * B3 * A3 *:B SIDE * B3 * B3 * A3 * A1 R74 R75 IC11 * B2 * B2 * B2 * B2 * A3 DR-377 DR-377 -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 8-13 8-13 BVP-9500WS/9500WSP MM...
Page 351 * H5 * E6 * H6 C511 C708 IC302 C709 * E6 IC303 * H6 C512 C710 * E8 IC304 * H6 C513 C514 C711 * E7 IC400 * H5 (Continued to next page.) 8-15 (b) 8-15 (b) BVP-9500WS/9500WSP MM...
Page 352 R616 * G4 R726 R820 * D2 R939 Q624 * H6 R250 R500 R617 * F2 R727 R821 * D2 R940 Q625 * H6 R251 R501 R618 * G2 R728 R822 * D3 R941 8-16 (b) 8-16 (b) BVP-9500WS/9500WSP MM...
Page 353 * H6 * E6 * H6 C511 C708 IC304 C709 * E6 IC400 * H5 C512 C710 * E8 IC401 * H7 C513 C514 C711 * E7 IC402 * H8 (Continued to next page.) 8-15 (a) 8-15 (a) BVP-9500WS/9500WSP MM...
Page 354 R618 * G2 R728 R822 * D3 R941 Q626 * J6 R300 R502 R619 * H2 R729 R823 * C3 R942 Q700 * J5 R301 R503 * B1 R620 * H2 R730 R824 R943 8-16 (a) 8-16 (a) BVP-9500WS/9500WSP MM...
Page 355 * C5 CN17 * B2 * A4 CN18 CN20 * A3 * D1 * B1 * E1 * A1 * A1 * B1 * B1 MB-830 * D1 -B SIDE- * D1 * C1 SUFFIX: -11 8-17 8-17 BVP-9500WS/9500WSP MM...
Page 357 * B3 IC305 JC10 R536 * B3 RB252 C112 C170 C252 C310 C370 IC191 * B3 IC306 JC11 R553 * B3 RB253 * B3 * C3 C113 C171 C253 C311 C371 IC192 IC307 JC12 R554 RB10 RB254 8-19 8-19 BVP-9500WS/9500WSP MM...
Page 359 IC10 * C2 IC11 * D2 * C1 * C1 PA-226 PA-226 -A SIDE- -B SIDE- * B2 SUFFIX: -11 SUFFIX: -11 * A1 * C1 * C2 * C1 * C2 *:B SIDE * B2 8-21 8-21 BVP-9500WS/9500WSP MM...
Page 361 * A2 * B3 C307 C538 IC401 R429 R610 C539 * A2 IC402 R430 C308 C540 * A2 IC403 * B4 R431 * F2 C309 C310 C541 * A3 IC404 * B3 R432 * F2 8-23 (b) 8-23 (b) BVP-9500WS/9500WSP MM...
Page 363 * A2 * B3 C307 C538 IC401 R429 R610 C539 * A2 IC402 R430 C308 C540 * A2 IC403 * B4 R431 * F2 C309 C310 C541 * A3 IC404 * B3 R432 * F2 8-23 (a) 8-23 (a) BVP-9500WS/9500WSP MM...
Page 364 * B2 IC400 R428 R609 * A2 C307 C538 IC401 R429 R610 C539 * A2 IC402 R430 C308 C540 * A2 IC403 R431 * F2 C309 C310 C541 * A3 IC404 R432 * F2 8-24 (a) 8-24 (a) BVP-9500WS/9500WSP MM...
Page 365 R415 IC404 * A2 C502 R416 IC405 * B2 R417 C503 C504 IC406 * C3 R418 IC407 * D3 C505 R419 IC408 * C4 R420 C506 IC409 * A2 R421 C507 C508 IC410 * A2 R422 8-25 8-25 BVP-9500WS/9500WSP MM...
Page 366 C503 C504 IC406 * C3 R418 * B1 IC407 * D3 * A1 C505 R419 IC408 * C4 R420 * B2 C506 IC409 * A2 R421 * B2 C507 C508 IC410 * A2 R422 * B2 8-26 8-26 BVP-9500WS/9500WSP MM...
Page 367 FB303 R319 C304 FB304 R320 C305 C306 FB351 * D1 R321 FB352 * D2 C307 R322 FB353 R323 C308 C309 FB354 R324 C310 FB355 R325 FB356 R351 C311 R352 C312 C313 * B3 R353 8-27 (b) 8-27 (b) BVP-9500WS/9500WSP MM...
Page 369 FB303 R319 C304 FB304 R320 C305 C306 FB351 * D1 R321 FB352 * D2 C307 R322 FB353 R323 C308 C309 FB354 R324 C310 FB355 R325 FB356 R351 C311 R352 C312 C313 * B3 R353 8-27 (a) 8-27 (a) BVP-9500WS/9500WSP MM...
Page 370 FB353 R356 FB354 * B2 R357 C308 C309 FB355 * A2 R358 * C3 C310 FB356 R359 * C3 R360 C311 * B3 * C3 R361 C312 C313 IC21 * B3 * C3 R362 8-28 (a) 8-28 (a) BVP-9500WS/9500WSP MM...
Page 371 D151 R102 * A3 D152 D201 R103 * A3 * A3 D202 R104 R105 * A3 D203 D204 R106 * A2 * A2 D205 R107 R108 * A2 R109 * A3 R110 * A3 8-29 (b) 8-29 (b) BVP-9500WS/9500WSP MM...
Page 373 D151 R102 * A3 D152 D201 R103 * A2 * A3 D202 R104 R105 * A3 D203 D204 R106 * A2 * A2 D205 R107 R108 * A2 R109 * A3 R110 * A2 8-29 (a) 8-29 (a) BVP-9500WS/9500WSP MM...
Page 374 R106 R107 * A2 D203 R108 * A2 D204 R109 * A3 * A2 R110 R111 * A2 R112 * A2 * A2 R113 R151 * A2 R152 * A2 FB51 R153 * A1 8-30 (a) 8-30 (a) BVP-9500WS/9500WSP MM...
Page 375 FB10 IC10 IC11 IC12 IC13 IC14 IC15 * C2 * C1 IC16 * C2 IC17 * C2 IC18 IC19 IC20 * C2 IC21 IC22 * C2 * B2 IC23 * C2 IC25 * C2 * B2 8-31 8-31 BVP-9500WS/9500WSP MM...
Page 376 * C2 IC21 IC22 * C2 * B2 IC23 * C2 IC25 * C2 * B2 * B1 * B1 * B1 * A6 * A6 * A6 * B1 * B2 * B1 * A4 8-32 8-32 BVP-9500WS/9500WSP MM...
Page 377 -B SIDE- SUFFIX: -11 SUFFIX: -11 SW-937 SW-937 -A SIDE- -B SIDE- SUFFIX: -12 SUFFIX: -12 SW-1008 SW-1008 SW-1011 SW-1011 -A SIDE- -B SIDE- -A SIDE- -B SIDE- SUFFIX: -11 SUFFIX: -11 SUFFIX: -11 SUFFIX: -11 8-33 8-33 BVP-9500WS/9500WSP MM...
Page 379 * F2 TG-194 TG-194 -A SIDE- -B SIDE- RB10 SUFFIX: -11 SUFFIX: -11 RB11 RB12 RB13 RB14 * G4 * J3 * J4 * F1 * J2 * G1 * B1 * B2 * C1 *:B SIDE 8-35 8-35 BVP-9500WS/9500WSP MM...
Page 381 R112 R238 IC54 R113 R239 * A3 IC55 R114 R240 IC56 * A4 R115 R241 IC57 * A4 R116 R242 R118 R243 * A5 R119 R244 * C5 R121 R245 C100 C101 R122 R301 8-37 (b) 8-37 (b) BVP-9500WS/9500WSP MM...
Page 383 * B2 R218 IC21 * B2 R219 * B3 IC22 R224 IC24 * B5 R225 IC25 R226 * A1 IC39 R227 IC40 * A2 R228 IC41 * A3 R229 C100 C101 IC44 * A5 R230 8-37 (a) 8-37 (a) BVP-9500WS/9500WSP MM...
Page 384 * B1 R111 R215 * B3 R112 R216 * B3 R113 R217 R114 R218 * B3 R115 R219 R116 R220 R117 R221 R118 R222 R119 R223 C100 R120 R224 C101 C102 * C5 R121 R225 8-38 (a) 8-38 (a) BVP-9500WS/9500WSP MM...
Page 385 R288 C102 IC50 R166 R291 IC51 R167 R292 C103 R168 R293 C104 C105 R169 R294 C106 R170 R295 R171 R296 C107 C108 R172 R297 C109 R173 R298 R174 R299 C110 R175 R300 C111 C112 R176 R301 8-39 8-39 BVP-9500WS/9500WSP MM...
Page 386 R310 C108 C109 R181 R311 C110 R182 R312 R183 R313 C111 C112 * C5 R184 R314 * C3 C113 R185 R315 * C2 R186 R316 C114 * C5 R187 R317 C115 C116 * C3 R188 R318 8-40 8-40 BVP-9500WS/9500WSP MM...
Page 387 * C1 C138 C613 C614 * B2 C139 C140 C615 * C2 * C1 C141 C700 C701 * C2 * C1 C142 C702 * C2 * C1 C143 C144 C703 Q100 * C1 (Continued to next page.) 8-41 8-41 BVP-9500WS/9500WSP MM...
Page 388 R636 * A1 R158 R271 R637 R159 R272 * A1 R638 R160 R273 * A1 R639 * A1 R161 R274 R640 R162 R275 * A1 R641 R163 R276 * A1 R642 R164 R277 * A1 R701 8-42 8-42 BVP-9500WS/9500WSP MM...
Page 390 BVP-9500WS (J, UC) Printed in Japan Sony Corporation BVP-9500WSP (CE) J, E 2002. 9 08 B&P Company 9-968-580-02 ©2001...

This manual is also suitable for:

Bvp-9500wsp

Sony BVP-9500WS Maintenance Manual

Quick Links

Related Manuals for Sony BVP-9500WS

Summary of Contents for Sony BVP-9500WS

This manual is also suitable for:

Table of Contents
