Front Panel Controls

RESET BUTTON -
1
detected during a test, the red failure lamp within the button will light. To reset the system for the next test, press
and release this button. This button may also be used to abort a test in progress.
TEST BUTTON -
2
This is a momentary contact switch used to start a test. Press the green button to turn on the
high voltage output when in test mode. The indicator lamp within the button will light when there is continuity
between Cont. Check and Return ports..
LCD DISPLAY -
The Liquid Crystal Display is the main readout for the operator and programmer of the test
3
settings and test results.
HIGH VOLTAGE OUTPUT JACK -
4
the adapter box high voltage connector.
POWER SWITCH -
5
ROTARY KNOB -
Use this knob to advance forward/backward through the setup menus and to setup system
6
and test parameters.
RETURN JACK -
Provides the return connection for the leakage current.
7
CONT CHECK -
Provides the connection for checking ground continuity.
8
HIGH VOLTAGE LED INDICATOR -
9
the high voltage output terminal.
hipot.com
1 2
5
This is a momentary contact switch used to reset the tester. If an out-of-range reading is
Use this jack for the connection of the detachable high voltage test lead or
Rocker-style switch with international ON ( | ) and OFF (0) markings.
This indicator flashes to warn the operator that high voltage is present at
3
6 7
4
8 9
