Main Unit
(See page 5 for illustrations)
1
Main Unit (1x)
2
Rotating Mesh Basket (1x)
3
Rotating Rotisserie Fork with
Locking Screws (2x)
4
Shafts (of the rotating rotisserie fork
or rotating rotisserie skewers) (2x)
5
Rotisserie Removal Tool (1x)
6
Rack Wheels with Locking Screws (for
Rotating Rotisserie Skewers) (2x)
7
Rotating Rotisserie Skewers (10x)
8
Oil Drip Tray (1x)
9
Air Flow Racks (3x)
10 START/STOP Button (START/STOP Button for
Setting the Temperature & Time)
11 Interior Light (not shown)
12 Support for the Shaft & Rotating
Mesh Basket (right)
13 Rails
14 Removable inner glass assembly
15 Door
16 Cooking Space
17 Holder for the Shaft & Rotating
Mesh Basket (left)
18 Heating Element (not shown)
19 Control Panel
20 Air Inlet Slots
21 Air Outlet Openings
Control Panel
22 LED Display (alternating display of
temperature & remaining cooking time
during operation)
23 Operating Lamps (lighting up successively:
Airfryer Oven is in operation;
flashing: operation has been interrupted)
24 10 Programs
25
Switch the Light in the Airfryer Oven On/
Off
26
Switch Rotating Function
(for Rotating Mesh Basket, Rotating Rotisserie
Spit) On/Off
27
Set the Cooking Temperature : press briefly
and the temperature can be set with the
START/STOP Button
28
Set the Cooking Time: press briefly, then
set the cooking time with the START/STOP
Button
Intended Use
• This Airfryer Oven works with hot air and is
not a conventional Cooker that is filled with
oil or deep-frying fat. It is suitable for frying,
baking, grilling, dehydrating, keeping warm
or defrosting food. It generally works like a
convection fan oven.
• The Airfryer Oven is for personal domestic
use only and is not intended for commercial
applications.
• The Airfryer Oven should only be used as
described in these instructions. Any other
use is deemed to be improper. Incorrect
operation and incorrect handling may cause
faults with the Airfryer Oven and cause injury
to the user.
• The following are excluded from the warranty:
all defects caused by improper handling,
damage or unauthorised attempts at repair.
The same applies to normal wear and tear.
Before Initial Use
• Check the items supplied for completeness
(See page 5-6)and possible transport
damage. If you find any damage, do not use
the Airfryer Oven (!), but rather contact the
customer service department.
• Remove any possible films, stickers or
transport protection from the Airfryer Oven.
Never remove the rating plate and any
possible warnings!
• The Airfryer Oven should be used for the first
time without any food in it as it may produce
some smoke or odours due to coating
residues. Allow the Airfryer Oven to heat
up on the highest temperature setting for
approx. 15 minutes without any food in it (see
the "Using the Airfryer Oven" chapter).
• Thoroughly rinse all accessories. Follow the
instructions in the "Care and Cleaning"
chapter to do this.
7
