- Page 1 2 WIRE SYSTEM FVQ-6020APP KIT & FVQ-6020 KIT VIDEO DOOR PHONE SYSTEM INSTALLER MANUAL FVQ-6016KP FVQ-6013/9013WIFI Please read the manual carefully before using the product. Please note that images and sketches in this manual may be different from the actual products...
-
Page 2: Table Of Contents
Contents Monitor Description ..............................3 Door Station Description ............................... 4 Addressing the monitors (When using more than one monitor): ................5 Impedance Switch ................................. 5 Viewing Multiple Door Stations On The Monitor ......................6 Wiring Diagrams ................................7 Lock Wiring .................................. 16 Summary Keypad door station codes ......................... -
Page 3: Monitor Description
Monitor Description Name Description Micro SD Socket for Micro SD Power Indicator White LED when power on Do Not Disturb Purple LED when function is enabled Message Indicator Green LED when you have missed calls Microphone Screen 7 Inch Digital TFT LCD Switch Bit 1- Bit 5 –... -
Page 4: Door Station Description
Door Station Description Name Status Indicator Camera Speaker Keypad LED’s (Sensor located in middle) Microphone Fixing screw Connection Port... -
Page 5: Addressing The Monitors (When Using More Than One Monitor)
Addressing the monitors (When using more than one monitor): This is controlled by dip switch 6 & 7 on the back of the monitor Type Dip Switch Setting Master Monitor Slave Monitor 1 Slave Monitor 2 Slave Monitor 3 Impedance Switch Only turn to the on position when the monitor is the end of line. -
Page 6: Viewing Multiple Door Stations On The Monitor
Viewing Multiple Door Stations On The Monitor When using multiple door station you need to activate the door station to view on the monitors. Using the settings menu on each individual monitor type in the following code depending how many door station you have. -
Page 7: Wiring Diagrams
Wiring Diagrams Notes: When using more than 1 door station you require a 4 branch Door station module FVQ-6012D When using more than 1 monitor in star configuration you require a 4 branch monitor module FVQ-6011M Door Station is addressed as number 1 by default... - Page 8 1 Door Station to 4 Monitors (Star Configuration)
- Page 10 1 Door Station to 3 Monitors (Series)
- Page 12 4 Door Station to 4 Monitors (Star Configuration)
- Page 14 4 Door Station to 3 Monitors (Series)
-
Page 16: Lock Wiring
Lock Wiring The system has 2 Locks • Lock 1 – 12 VDC (250mA) Output on exit or door release o Lock 1 is only power to unlock • Lock 2 – Dry Collector that can be toggled between Normally Open or Normally Closed The Exit button can be configured in 3 Modes (Default is Lock 1 &... - Page 17 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2...
- Page 18 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2 ...
- Page 19 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2 Normally Closed...
- Page 20 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2 ...
- Page 21 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2 Independent Exit button...
- Page 22 Power to Unlock Power to Lock Lock 1 Lock 2 Exit Button To Open Lock 1 Lock 2 Independent Exit button...
-
Page 23: Summary Keypad Door Station Codes
Summary Keypad door station codes Description CODE Example (1234 is the Master Code) Adding a User Lock 1 (16-25) Lock 1 – 1111 - 1234#16#1111#* Lock 2 (36-55) Lock 2 – 2222 - 1234#36#2222#* Lock 1 lock time 5 Seconds – 1234#04#10#* Lock 2 lock time 5 Seconds –... -
Page 24: Detailed Keypad Codes
Detailed Keypad Codes Adding a code: Input master code (1234 by default) and press #, then choose the lock group • Lock 1 (starts from 16 up to 25 ) Lock 2 (starts from 36 up to 55 ) • •... - Page 25 Door Station address setting: Input master code (1234 by default) and press #, 11#, type X#(where X goes from 1 to 4) Default is 1 E.G: For Keypad door station 1: 1234#, 11#, 1#, *. For Keypad door station 2: 1234#, 11#, 2#, *. For Keypad door station 3: 1234#, 11#, 3#, *.
- Page 26 Ring Volume: Input master code (1234 by default) and press #, 15#, type X(where X is: 0 = Door station ringtone ON; 1 = Door station ringtone OFF) Default mode is On E.G: On: 1234#, 15#, 0#, * Off: 1234#, 15#, 1#, * Keypad Lights: Input master code (1234 by default) and press #, 02#, type X(where X is: 0 = Keypad lights on;...
-
Page 27: Wi-Fi Configuration
Wi-Fi Configuration For latest up to date instructions please visit www.fermaxaus.com.au Please download the Fermvision Wifi Smart phone application... - Page 28 Notes Slots or openings in the back of the monitor are provided for ventilation and to ensure reliable operation of • the video monitor or equipment and to protect it from overheating. These openings must not be blocked or covered. All parts should be protected from violence vibration.
