2 - INTRODUCING THE PRODUCT

2.1 - Product description

2 1
1 Aluminium beam
2 Limit stop
3 Aluminium casing
4 Carriage
5 Adapter profile

2.2 - Overall dimensions

When deciding the beam installation height, always consider the highest point of the floor, to prevent jamming against the floor
during travel of the door leaves.
WIND LIGHT
142
H1
Automation installation height
H= H1 + HW + H2 + H3
(adjustment ± 6 mm)
HW
H2
H3
20
4
12
5
15
6 Belt traction bracket
7 Gear motor with encoder
8 Batteries
9 Control unit
10 Electric lock
CROSS-SECTIONS WITH COMMERCIAL PROFILES
A
10
6
14
11 Belt
12 Return pulley
13 Side cover panel
14 Floor guide
15 Travel stop
25 ±10
H1
HW
H2
H3
2
11 8
9
6
WIND
150
H= H1 + HW + H2 + H3
(adjustment ± 10 mm)
LEGEND:
H = Automation installation height
H1 = Height of Key Automation
top adapter profile
900PA020 = 24 mm
HW = Height of leaf
H2 = Height of Key Automation
bottom adapter profile
900PA021 = 30 mm
H3 = Ground clearance
3
7 13
