WINCH MOUNT KIT
FOR POLARIS ATV
P/N 25-3043
ASSEMBLY / OWNERS MANUAL
Application
WINCH KIT NO. 25-xxxx
Before You Begin, please read these instructions and check to be sure all parts and tools are
accounted for. The following instructions contain details required to install and service the contents
of this kit.
© 2020 Kolpin Outdoors Inc.
REV 05
Advertisement
Table of Contents
Related Manuals for Kolpin Outdoors 25-3043
Summary of Contents for Kolpin Outdoors 25-3043
- Page 1 Before you begin, please read these instructions and check to be sure all parts and tools are accounted for. The following instructions contain details required to install and service the contents of this kit. © 2020 Kolpin Outdoors Inc. REV 05...
- Page 2 Do not use your winch or winch mount for towing. Do not shock load the winch, cable or winch mount. Keep fingers, hands and loose clothing away from roller fairlead and winch cable drum when in use. © 2020 Kolpin Outdoors Inc. REV 05...
- Page 3 Note, winch mount kit includes hardware to fit many vehicle models and winch models. Not all hardware will be used for your specific application. For example, item #4 is only used for older style 1500lb winches. © 2020 Kolpin Outdoors Inc. REV 05...
- Page 4 Hex Bolt, Zinc Plated, M8-1.25 x 25mm LG Locknut, Zinc Plated, M8-1.25 Carriage Bolt, Zinc Plated, M8-1.25 x 25mm LG Flat Washer, Zinc Plated, M8 Hex Bolt, Zinc Plated, 1/4-20 x 1.0” LG Flat Washer, Zinc Plated, M6 © 2020 Kolpin Outdoors Inc. REV 05...
- Page 5 10. Using one M8 hex bolt (item #6) and one M8 carriage bolt (item #5), mount the winch to the winch mount plate (item Note, the winch motor will be on the right side of #1). the ATV once installed. © 2020 Kolpin Outdoors Inc. REV 05...
- Page 6 Restore any body panels removed. 20. With the vehicle key in the ON position, check winch for proper operation. 21. Retighten all hardware after 30 minutes of riding. © 2020 Kolpin Outdoors Inc. REV 05...
- Page 7 Most hardware is general in nature and is easily obtained locally. Be sure to replace with minimum metric class 8.8 specification. Kolpin Outdoors, Inc. Telephone: (763)-478-5800 Toll Free: (877)-956-5746 Fax Number: (800)-245-7569 www.kolpin.com Email: customerservice@kolpin.com © 2020 Kolpin Outdoors Inc. REV 05...
