Rosie Chair And Sofa's
Assembly lnstructions - Please keep for future reference
1 Seat
Dimensions
(one-seater)
Width - 81cm
Depth -78cm
Height -84cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 601 2895
2 Seat
Dimensions
(two-seater)
Width - 142cm
Depth -78cm
Height -84cm
3 Seat
Dimensions
(three seater)
Width - 202cm
Depth -78cm
Height -84cm
711/5596
717/3954
703/0671
703/3733
700/7446
719/8616
702/7354
702/5095
706/9707
723/6066
724/2531
698/0966
Issue 1- 08-05-17
Advertisement
Table of Contents
Related Manuals for Argos Home Rosie 711/5596
Summary of Contents for Argos Home Rosie 711/5596
- Page 1 Rosie Chair And Sofa's Assembly lnstructions - Please keep for future reference 711/5596 717/3954 703/0671 703/3733 700/7446 719/8616 702/7354 702/5095 706/9707 723/6066 724/2531 698/0966 2 Seat 1 Seat 3 Seat Dimensions Dimensions Dimensions (one-seater) (two-seater) (three seater) Width - 81cm Width - 142cm Width - 202cm Depth -78cm...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble the item as close We do not components and tools listed on to its final position (in the same recommend the pages 2.
- Page 3 Components - Parts lf you have damaged or missing components. call the Customer Helpline : 0345 601 2895 Chair / Sofa Body (Chair: 810 x 800 x 530mm) (Two seat sofa: 1420 x 800 x 530mm) (Three seat sofa: 2010 x 800 x 530mm) Back Cushion Leg x 4 (Chair: 600 x 420 x 140mm) x 1...
- Page 4 Assembly Instructions Attaching legs First, ensure the floor is protected to ensure no damage or marking to the chair / sofa. With help, carefully turn the chair or sofa body onto it's back as shown. Warning: The body is heavy. Lift with care. Locate plastic spacers onto the ends of legs Screw legs...
- Page 5 Assembly Instructions Placing back cushions Place back cushions into position as shown. Note: Ensure the back cushions are carefully located to ensure the velcro strips on the rear of the cushions, hold them in place. If you need help or have damaged or missing parts, call the Customer Helpline: 0345 601 2895 Home Retail Group.
