Cypress PSoC CY8CKIT-001 Quick Start Manual

Hide thumbs Also See for PSoC CY8CKIT-001:
1
2

Advertisement

Quick Links

Download this manual
1
Remove PSoC Development Board from Kit Packaging
3
After self test, read LCD screen for success message
5
For PSoC 1 Development:
• View the Kit User's Guide
• Install the PSoC 1 Software
®
PSoC
DEVELOPMENT KIT
QUICK START GUIDE
PSoC Development Board Self Test
2
Connect the AC Power Adapter
4
Select an Architecture:
• PSoC 1: Insert the "PSoC 1 Software" CD
• PSoC 3 / PSoC 5: Insert the "PSoC 3 / PSoC 5
Software" CD
6
For PSoC 3 / PSoC 5 Development:
• View the Kit User's Guide
• Install the PSoC 3 / PSoC 5 Software
