Preset Battery Type of Charger and Task Parameters

Rated
Voltage
1.20V
NiCd/MH
2.00V
Pb
3.20V
LiFe
3.60V
Lilon
3.70V
LiPo
3.80V
LiHv
3.90V
ULiHv
How to Confirm Charging Current
Make sure to know the maximum charging current of the battery before charging, never use excessive current to charge to damage
your battery, which will result in over heat even explosion during the charging process.The charging and discharging capacity of battery
is usually marked with C value. Multiplying the charging C value and battery capacity equals to the maximum charging current supported
by the battery. For example, for a 1000mAh battery with a charging capacity of 5C, the maximum charging current would be 1000×5=
5000mA; therefore, the maximum charging current is 5A. For a lithium battery, if it is impossible to confirm the supported charging C
value, please set the charging current below 1C, for the sake of its (lithium battery) safety. The reference relation between C value and
charging time: charging time ≥60 minutes/ charging C value (e.g. it needs around 60~70 minutes to complete charging with 1C).
Due to differences in battery conversion efficiency, the time to complete the charging might be extended.

Operating the Charger

Power on K1 smart charger, connect the battery, and short press the middle button to enter the task setting menu as follows:
Task
Battery
Battery and cell count
Current
Full Charge Balance
Voltage Charge
1.40V
2.40V
3.65V
4.10V
4.20V
4.35V
4.45V
Charge
LiFe, LiIon, LiPo, LiHv, ULiHv, Pb, NiMh/Cd
LiFe, LiIon, LiPo, LiHv, ULiHv (1~6S); Pb (1~10S); NiMH/Cd (1~16S)
0.2~10.0A
Unbalanced Supported
Charge Cell Count
1~16S
1~10S
1~6S
1~6S
1~6S
1~6S
1~6S
Max. Charging
Current
10.0A
10.0A
10.0A
10.0A
10.0A
10.0A
10.0A
