Charge
Balancing port is strongly recommended when charging lipo battery, which can make sure to monitor voltage on each cell battery and
balance it when charging. Warning beeper will yell before start charging lipo if in non-balance mode(no connecting with balance port).
Current setting range: 0.2~10.0A

Charging Screen

Press the direction button to switch the information displayed in the lower half of the screen, as cell voltage, cell internal resistance,
working parameter. The cell voltage and internal resistance only on display in balancing charging mode.

Advanced Settings

Under the standby interface,
long press the left and right channel selection buttons at the same time to enter the advanced settings menu.
Dual task
Select this setting,the charger will charge to the two channel batteries with the same parameters at the same time.
Connect the charger with the power supply and power on, select this setting on the advanced setting menu to set the task parameters.
DC power (CH1)
The charger CH1 is equivalent to a DC power supply when
selecting this function, with output voltage adjustable from
5~24V, and current adjustable from 0.2~5.0A.
Paralled task
Select this setting, it could output Max Power to one battery.
Find a power splitter or 1/2 power cord, one end connect
with the battery, and the other two ends connect with
the battery output port. The battery balance port could
connect with any of the charger's balance port. Connect
the charger with the power supply and power on, and connect
your battery as required, select this setting on the advanced
Paralled charge
setting menu to set the task parameters.
