Installing a Heating Mantle

Installing a Heating Mantle
A heating mantle is used on a sample tube to assist in maintaining a specified
temperature. Heating mantles should be used only on samples being degassed (in
the Degas position).
1. Slide the heating mantle upward around the sample tube.
2. Holding the mantle in place with one hand, gently push the clamp horizon-
tally to the left (or right as shown here) about the mantle at two or three cen-
timeters (approximately one inch) below the upper edge.
Sample Tube
Heating Mantle
Clamp
3. Plug the heating mantle power cord and the thermocouple plug into their ap-
propriate connectors. The indicator immediately above the register alternates
on and off, indicating power is being applied as needed to attain and hold
the set temperature. Internal electronic circuitry limits the maximum tempera-
ture attainable to 400
ing display if Temp is depressed.
2-10
o
C. Attempts to exceed this limit will result in a flash-
FlowSorb III
Heating Mantle
Power Cord
Thermocouple
