Selecting the Input Power

All instruments leave the factory set for 120 VAC and with the line fuse re-
moved. The correct setting of the universal power entrance must be checked and
the appropriate fuse installed before the FlowSorb can be operated. The FlowSorb
is designed to operate with 100, 120, 220, or 240 VAC at 50 or 60 Hz. Voltage
selection and fusing are made at the power connector, which is located on the
rear panel of the unit.
The power cord should be disconnected from the FlowSorb before removing
the cover from the input power connector. Failure to disconnect the power
cord could result in electrical shock.
1. Make sure the power cord is disconnected from the FlowSorb.
2. Using a pointed object, remove the fuse block and cover assembly from the
power connector on the side panel of the FlowSorb.
3. Pull the voltage selector card straight out of the power connector housing.
Aug 00
Pointed Object
Selecting the Input Power
Voltage Selector
Card
2-3
