FlowSorb III
Electrical and electronic components include: (1) an on/off power switch, univer-
sal power entrance, and fuse block; (2) a power supply; (3) a thermal conductiv-
ity sensor and amplifier circuit; (4) a conductivity cell output linearization circuit;
(5) a heating mantle temperature setting and feedback control system; (6) an indi-
cator with appropriate selection switches for displaying the measured surface area
by the single-point technique and the adsorbed gas volume for multipoint testing,
the sample degassing temperature, and the thermally detected signal; (7) adjust-
ments for initial calibration; and (8) on the FlowSorb III 2310 only, start and re-
set controls.
Mar 2012
Basic Construction
1-9
