To Upload The Recipes - Midea FlashChef G1 Quick Start Manual

21
Don't "Save As" the recipe directly into USB, simply save it on to the PC
22
and drag it into your USB to upload

To Upload the recipes:

1. Drag and Drop the saved recipe file (.db) to the USB Memory Device
2. Press the "Setting" icon (
3. Press "User Settings"
4. Input the password by pressing that area of the screen - the keyboard
will appear and type "flashtune" - then press the small "check" mark on
the keyboard to enter.
5. Press the USB window on the screen
23
6. Insert the USB into the port on the front right side of the oven.
(contact on the USB drive should be oriented towards the operator)
7. Wait for the area next to "Recipes Upload" "Recipes Download" and
"Firmware Update" to populate with "DISK_IMG".
7. Press "Recipes Upload"
8. Select the folder
9. If successful, folder will now show a circled "check mark" in the center.
10. Press the recipes icon and uploaded recipes will appear.
Save the recipes on to the pc
)
6
