Midea G3 Series Service Manual
  1. Manuals
  2. Brands
  3. Midea Manuals
  4. Oven
  5. G3 Series
  6. Service manual
Midea G3 Series Service Manual

Midea G3 Series Service Manual

Electric oven
Hide thumbs

Advertisement

Quick Links

Download this manual
Service Manual For Built-in Oven
Model list:
7NM: 7NM20M1, 7NM21M1, 7NM30M1
7NM30D0
7NM30Ex, 7NM30Tx
7NM30Fx
7NP: 7NP30Ex, 7NP30Tx
7NP30Fx
7NA:
7NA30Tx
Remarks: x=0, 1, 2.
Warnings:
 This service manual is not available to the general users, but only
applies to professional technicians with relevant qualifications. Any
incorrect maintenance may result in other dangers!
 The power (and gas) supply must be cut off before maintenance!
 A new power cord which meets the relevant technical requirements
must be used once possible hidden malfunctions are found with the
current power cord (refer to this Manual)!
 Please read carefully all safety warnings in this Manual before
maintenance!
 The product is prohibited from using until test is conducted as per
relevant regulations after maintenance!
 This service manual applies to many models, so the specific
operations please prevail in kind!
- -
(
G3 Series electric
oven)
V5.3
Nov, 2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the G3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midea G3 Series

Summary of Contents for Midea G3 Series

  • Page 1 Service Manual For Built-in Oven G3 Series electric oven) Model list: 7NM: 7NM20M1, 7NM21M1, 7NM30M1 7NM30D0 7NM30Ex, 7NM30Tx 7NM30Fx 7NP: 7NP30Ex, 7NP30Tx 7NP30Fx 7NA: 7NA30Tx Remarks: x=0, 1, 2. Warnings:  This service manual is not available to the general users, but only applies to professional technicians with relevant qualifications.

  • Page 2: Table Of Contents

    Contents Precaution ..............................1 Safety Precaution..........................1 Warning .............................. 1 Dimension ..............................1 Function ................................ 2 Mechanical oven (7NM**M1, 7NM30D0) ..................2 Electronic oven (7NM30Ex, 7NM30Tx, 7NP30Ex, 7NP30Tx) .............. 2 TFT oven(7NM30Fx, 7NP30Fx ) ......................3 Circuit diagram ............................. 4 7NM20M1 (with ECO function) ......................
  • Page 3 Disassembly of power board box ...................... 17 Disassembly of convection motor ..................... 18 Disassembly of top, bottom heating element .................. 19 6.10 Disassembly of cooling fan motor ..................... 20 6.11 Disassembly of lamp .......................... 21 Troubleshooting ............................22 Error codes ..............................23...

  • Page 4: Precaution

    1. Precaution 1.1 Safety Precaution 1. To prevent injury to the user or other people and property damage, the following instructions must be followed. 2. Incorrect operation due to ignoring instructions will cause harm or damage. 3. Before maintenance, please read carefully the following instructions at first. Warning .

  • Page 5: Function

    3. Function 3.1 Mechanical oven (7NM**M1, 7NM30D0) Rotate the knob to the related function position. Rotate the knob to the expected temperature position. Rotate the knob to the expected timer position. 3.2 Electronic oven (7NM30Ex, 7NM30Tx, 7NP30Ex, 7NP30Tx) Press the touching control buttons to adjust the function temperature and time, different touching control buttons are shown on below chart...

  • Page 6: Tft Oven(7Nm30Fx, 7Np30Fx )

    3.3 TFT oven(7NM30Fx, 7NP30Fx Press the touching control buttons and slide the screen to adjust the function temperature and time, different touching control buttons are shown on below chart...

  • Page 7: Circuit Diagram

    4. Circuit diagram 4.1 7NM20M1 (with ECO function) 4.2 7NM20M1 (without ECO function) 4.3 7NM21M1...

  • Page 8: 7Nm30M1

    4.4 7NM30M1 4.5 7NM30D0...

  • Page 9: 7Nm30Ex, 7Nm30Tx

    4.6 7NM30Ex, 7NM30Tx 4.7 7NM30Fx 4.8 7NP30Ex, 7NP30Tx...

  • Page 10: 7Np30Fx

    4.9 7NP30Fx 4.10 7NA30Tx...

  • Page 11: Installation

    5. Installation 5.1 Preparation before installation 1 Assembly shall be referred to the measurements in the following specification after the package is removed. (The packing material shall be handled properly.) 2 Please use the handle boxes on the sides if the oven is required to be lifted or moved. It is prohibited from using door handle directly to lift the oven.

  • Page 12: Disassembly

    6. Disassembly 6.1 Tools Most of the tools that you might need are shown below. Some are optional. ELECTRICAL PLIERS or STRIPPERS : For cutting and stripping small electrical wire. VOM (VOLT-OHM METER): For testing electrical circuits. If you do not have one, please get one. An inexpensive one will suffice, as long as it has both "AC Voltage"...

  • Page 13: Disassembly Of Oven Door

    Step 2: Remove the bake rack and bake tray from the oven. Step 3: Remove the fixed screws that located inside the front frame on both sides of the oven. (See the following figure). Step 4: Pull the oven out of the cabinet toward you, using the gripping points and the handle boxes on the sides.
  • Page 14 Step 2: Hold the oven door and lift up (open the door 30° angle)，then slowly and obliquely drag the door backward. Warning: The door body is prohibited from dragging forcibly and shall be prevented glass smashing during the disassembly process.

  • Page 15: Disassembly Of Flat Door

    6.3.2 Disassembly of flat door (Type: 2 layers of glass) Step 1: Remove the door from oven (please refer to Point 6.3.1), and put it horizontally on the table. Step 2: Press on the right and left side of the cover and remove the cover. (See No.1, No.2 indicated in Fig), take the inner glass out (See No.3 indicated in Fig).

  • Page 16: Disassembly Of Control Panel

    Step 4: Use a screwdriver to remove the screws fixed the hinges, and disassemble the hinges. 6.4 Disassembly of control panel 6.4.1 Remove the control panel from oven WARNING: 1 Turn off the electrical power supply to the appliance prior to servicing it. Failure to disconnect the power supply during service may result in an electrical shock or fire hazard.

  • Page 17: Disassembly Parts Of Control Panel

    Step 2: Move the control panel to the top and pull it out gradually , be careful with the limitation of the length of the wirings. 6.4.2 Disassembly parts of Control panel Step 1: Remove the control panel from oven (please refer to Point 6.4.1). Step 2: Pull the knobs out of the control panel assembly by hands.
  • Page 18 First take out the four connectors carefully, and take out the three screws, then you can take out the PCB board .if there need change the TFT screen ,you need take another four screws(7NM30Fx-E1xxx00). Use a screwdriver and electrician to disassemble the parts holder , if the holders get broken by accident , it’s reasonable to get them changed also(7NM20M1-E21xy**).

  • Page 19: Disassembly Of Top Cover

    6.5 Disassembly of top cover WARNING: Turn off the electrical power supply to the appliance prior to servicing it. Failure to disconnect the power supply during service may result in an electrical shock or fire hazard. Step : Use a screwdriver to disassemble the screws on top cover like the picture below...

  • Page 20: Disassembly Of

    6.6 Disassembly of back cover WARNING: Turn off the electrical power supply to the appliance prior to servicing it. Failure to disconnect the power supply during service may result in an electrical shock or fire hazard. Step 1:Remove the top cover from oven (please refer to Point 6.5), and put it horizontally on the table.

  • Page 21: Disassembly Of Convection Motor

    6.8 Disassembly of convection motor WARNING: Turn off the electrical power supply to the appliance prior to servicing it. Failure to disconnect the power supply during service may result in an electrical shock or fire hazard. Step 1: Remove the door from oven (please refer to Point 6.3.1), and put it horizontally on the table.

  • Page 22: Disassembly Of Top, Bottom Heating Element

    Step 5: Disconnect the wires on the convection motor. For the sake of reassembly convenience, please mark the connection positions before moving the wires. Remove the screw fixed the convection motor and rotate the motor anti-clockwise to take it out. 6.9 Disassembly of top, bottom heating element Step 1: Remove the door from oven (please refer to Point 6.3.1), and put it horizontally on the table.

  • Page 23: Disassembly Of Cooling Fan Motor

    Step 6： back heating element. Disconnect the wires on the For the sake of reassembly convenience, please mark the connection positions before moving the wires. Remove the screws from the cavity，and then pull the back heater out from the cavity . 6.10 Disassembly of cooling fan motor WARNING: 1 Turn off the electrical power supply to the appliance prior to servicing it.

  • Page 24: Disassembly Of Lamp

    6.11 Disassembly of lamp Step1: Open the door to the maximum angle. Remove the bulb by screwing the lamp cover off the cavity only if the bulb is required to be replaced. Step2: Remove the wire rack first, then disassembly the right lateral outer case, disconnect the wire line.

  • Page 25: Troubleshooting

    Troubleshooting OPERATIONAL DIFFICULTIES AND POSSIBLE CAUSES Symptom Cause / Source Troubleshooting Checks Solution User Actions / Solutions Oven will Not open heating element Check elements at harness Replace elements or replace Call for service. heat. connection point. harness if needed. Oven lamp will Light bulb was burned out.

  • Page 26: Error Codes

    8. Error codes (Model：Electronic type, Touch type.) Displayed Description Solution Error code 1. Press the Power button to see if the error code is displayed Temperature sensor open circuit (or again? If also shown, go to step 2. short circuit) is detected at any time, the 2.
  • Page 27 loads (Lamp, Heating elements, Convection motor) are closed except cooling fan motor. The other buttons are invalid except the Power button. 1. Press the Power button to check whether the oven door has been locked or unlocked successfully after 10 seconds, and (Only for Pyrolytic models.
