Erbe LAP BiSect Dismantling And Assembling

Dismantling the product
c
a
1 Pull out the connecting cable
(no illustration).
2 Hold the handle (a) in such a way that the
moving handle is not obstructed. Press the
push-button and withdraw the shaft (c)
from the handle.
d
Assembling the product
b
1 Push the insulating tube (b) onto the shaft
(c).
a
4 Hold the handle (a) just like you would hold
a pen in such a way that the handles face
upwards and the moving handle is not ob-
structed, and press the push-button. Insert
the shaft into the handle (a) until it snaps
into place, without jamming it.
DISMANTLING AND ASSEMBLING
LAP BiSect scissors
b
3 Hold the electrode jaws (b) between your
thumb and index finger. Screw the electrode
out of the shaft by turning the rotary wheel
(e) (approx. 6 turns).
b
a Handle b Insulating tube c Shaft d Electrode
c
d
2 Insert the electrode (d) into the shaft up to
the stop position.
The product must be cleaned and disinfected in disassembled condition with jaws opened.
e
4 Withdraw the electrode (d) from the shaft.
5 Pull the insulating tube (b) off the shaft.
The four disassembled components:
3 Hold the electrode jaws (b) between your
The complete instrument
d
c
b
thumb and index finger. Screw the electrode
in, tightening it well, by turning the rotary
wheel (e) (approx. 6 turns); do not jam the
thread.
For the complete notes on use, refer to erbe-med.com
