Bipolar LAP forceps (E) and bipolar LAP scissors (E)
Dismantling the product
d
d
Caution: Never pull the jaws apart
manually, as this would cause damage
to the instrument.
1 Pull out the connecting cable from the
handle (no illustration).
2 Press both unlocking buttons (d) on the
handle simultaneously and remove the shaft
tube from the handle.
Assembling the product
e
Caution: Never press the jaws together
manually, as this would cause damage to
the instrument.
1 To close the jaws, hold the insert by the
joint sleeve (e) and pull the rod (b).
d
4 Press the rear unlocking button on the
handle (d) and insert the shaft tube into the
handle until it snaps into place at the stop
position.
DISMANTLING AND ASSEMBLING
e
3 Screw the insert out of the shaft tube,
grasping it by the joint sleeve (e).
4 Withdraw the insert from the shaft tube.
c
b
2 Insert the insert (c) into the shaft tube (b).
The product must be cleaned and disinfected in disassembled condition with jaws opened.
5 To open the jaws, hold the insert by the
The three disassembled components:
a Handle, b Shaft tube and c Insert
b
3 Screw in the insert up to the stop position,
The complete instrument
e
joint sleeve (e) and push the rod (b) in the
direction of the jaws.
b
c
e
grasping it by the joint sleeve (e).
For the complete notes on use, refer to erbe-med.com
b
a
