SVAN 977A User Manual CONTENTS INDEX INTRODUCTION 1.1 SVAN 977A as Sound Level Meter & Analyser 1.2 SVAN 977A as Vibration Level Meter & Analyser 1.3 General features of SVAN 977A 1.4 Accessories included 1.5 Accessories available 1.6 Firmware options available MANUAL CONTROL OF THE INSTRUMENT 2.1 Control keys on the front panel...
Page 4 SVAN 977A User Manual 5.4.1 Setting logger general parameters – Logger Setup 5.4.2 Selecting logger results – Logger Results 5.4.3 Selecting additional summary results for saving – Summary Results 5.4.4 Triggering the logger results saving – Logger Trigger 5.4.5 Setting up markers – Marker Setup 5.4.6 Wave recording settings –...
Page 5 SVAN 977A User Manual 8.4. External power settings- External Power 8.5. Selecting IEPE current supply - IEPE Current 8.6. Programming keyboard – Keyboard Settings 8.7. Setting parameters of the I/O port - Multifunction I/O 8.8. Programming the instrument’s internal Real Time Clock – RTC 8.9.
Page 6 SVAN 977A User Manual 11.3.4 Changing spectrum type in Vibration modes - Spectrum Type 12 REVERBERATION TIME MEASUREMENTS - RT60 12.1 Selecting the RT 60 function 12.2 Settings of the RT60 analysis 12.3 Configuring RT60 views 12.4 Start RT60 measurements 12.5 Viewing of RT60 results...
Page 7 C.1.3 Effect of the SA 277 Outdoor Protection Unit C.2. Specification of SVAN 977A as a Vibration Level Meter C.3. Specification of SVAN 977A as 1/1 OCTAVE and 1/3 OCTAVE analyser C.4. Frequency characteristics of the implemented broadband digital filters C.5.
Page 8: Index
SVAN 977A User Manual INDEX 1/1 Octave · 32, 90 Data port · 84 1/3 Octave · 32, 90 Data protocol · 83 Day time limits · 43 Decay · 104 Decay method · 107 Decimal mark · 69, 96 Default settings ·...
Page 9 SVAN 977A User Manual Logger view · 65, 69 Logging · 47, 91, 99 Low range · 56 General settings · 41, 91, 98 GPRS · 82 GPS · 77 GPS view · 67 Gradient · 46 Main menu · 19 Gradient trigger ·...
Page 10 SVAN 977A User Manual Recording on trigger · 52 Spectrum view · 66, 94, 100, 102 Recording time · 53, 55, 105 Start delay · 41 Rectangle · 99 Start measurements · 23 Reference levels · 87 Start synchronisation · 41 Registration port ·...
Page 11: Introduction
(RT60) option and BA Assistant application for smartphones. A fast USB 1.1 interface (12 MHz) creates a real-time link for the PC "front-end" application of SVAN 977A. With the use of optional interfaces (RS 232) the instrument can be remotely controlled from the PC with the use of SvanPC++ software.
Page 12: Svan 977A As Sound Level Meter & Analyser
45 filters with centre frequencies 0.8 Hz ÷ 20 kHz, Class 1 IEC 61260-1: 2014. • Optional RPM measurement with the use of RPM probe, connected to the I/O socket of SVAN 977A. • Optional FFT analysis with the single Total overall value, performed with preselected frequency weighting filters and screens.
Page 13: Accessories Included
• SvanPC++ download and viewing software. 1.5 A CCESSORIES AVAILABLE • SA 277 microphone outdoor protection kit for the SVAN 977A microphone (microphone, desiccator and cable not included) • SA 270D desiccator for outdoor kit • SC 26 extension cable for SV 12L (TNC plug to TNC socket) •...
Page 14: Manual Control Of The Instrument
SVAN 977A User Manual MANUAL CONTROL OF THE INSTRUMENT Control of the instrument has been developed in a fully interactive manner. The user can operate the instrument by selecting the appropriate position from the selected Menu list. Thanks to that, the number of keys for control of the instrument has been reduced to nine for ease of use and convenience.
Page 15 SVAN 977A User Manual (<Menu>) This key (<Shift> + <ENTER>) opens the main Menu. Double press of the <Menu> key opens the list containing last opened positions. It gives faster access to the frequently used screens for easy navigation. [<Save>] This key (<Alt>...
Page 16 SVAN 977A User Manual The <Info> key (simultaneous pressing the ◄ and ► [Info] keys) opens the screen with the help information in the measurement display modes. Press <ESC> or <ENTER> to exit the Info screen. To enter the marker mode, press the <Shift> and <Alt> keys simultaneously <Shift>...
Page 17: Input And Output Sockets Of The Instrument
All sockets are described in detail in Appendix C for this manual. Note: The originally supplied Kingston Industrial memory card has been tested by SVANTEK and cards of this type are strongly recommended for use when the original card is going to be replaced.
Page 18: General Information
SVAN 977A User Manual GENERAL INFORMATION To start using the instrument the user should turn it on with the <Shift> and <Start/Stop> keys at the same time. Hold both keys down for 1 or 2 seconds and release to switch on.
Page 19 SVAN 977A User Manual Main menu The main Menu contains the headers of six sections (sub-menu), which group configuration settings by feature. The main Menu is opened after pressing the <Menu> (<Shift> + <ENTER>) key. The main Menu list contains the following...
Page 20 SVAN 977A User Manual Matrix of parameters When the list of parameters consists of more than one column you may change: • column with the ◄ / ► key • line in the same column with the ▲ / ▼ key •...
Page 21 SVAN 977A User Manual • You can change the character of the selected position using virtual keyboard with available ASCII characters. To make a keyboard active, press the ▲ / ▼ key. ▼ • To insert new character to the cursor...
Page 22: Power Of The Instrument
3.2 P OWER OF THE INSTRUMENT SVAN 977A can be powered by one of the following sources: • Four AA standard size internal batteries. In case of alkaline type, with a new fully charged set, the instrument can operate more than 12 h (6.0 V / 1.6 Ah). Instead of the ordinary alkaline cells, four AA rechargeable batteries can be used (a separate external charger is required for charging them).
Page 23: Getting Started
SVAN 977A User Manual 3.3 G ETTING STARTED Turning the instrument on To turn the instrument on, press the <Alt> and <Start/Stop> keys at the same time. The instrument goes through the self-test routine after turning on, displaying during this time: manufacturer logo, name of the instrument and the firmware version.
Page 24: Description Of Icons
SVAN 977A User Manual The logger and summary results will be automatically saved in the file with the name defined by the instrument and presented in the Logger Setup screen (Logger Name: Lxxxx). Other functions are switched off, like: - measurement trigger (Measurement Trigger: Off), - logger trigger (Logger Trigger: Off), - wave recording (Wave Rec.: Off),...
Page 25 SVAN 977A User Manual „USB” icon is displayed when there is a „logging” icon is presented when current successful USB connection with the PC. measurement results are logged into the logger file. „wave” icon is displayed when the wave “Level + trigger” icon is displayed when the “Level+”...
Page 26: Data Saving
The measurement files are stored by default in the predefined SVANTEK directory. The setup files are stored in the predefined directory SETUP. Other special files (logs, advanced alarms settings) are stored in the predefined SYSTEM directory. The predefined directories can be reassigned or renamed by the user.
Page 27 SVAN 977A User Manual Files are saved in the directory, which was assigned as a working directory. The working directory is displayed in the bottom line of the File Manager screen together with the memory icon. Directories are created manually with the use of <New Directory> position.
Page 28 SVAN 977A User Manual You can quickly jump to the directory where files were saved. To do this, make the field with file name active by means of ▲ / ▼ key and press <ENTER>. <ENT> If you press <Save> (<Alt>+<ENTER>) after the measurement, the instrument opens the Logger Setup screen (path: <Menu>...
Page 29 SVAN 977A User Manual Another option is to open the File Manager screen (path: <Menu> / File / File Manger), select New File and press <ENTER>. After edition of the automatically proposed name, press <ENTER> to confirm. <ENT> If Logger and Summary Results are both switched on in the Logger Setup list (path: <Menu>...
Page 30: Files Downloading And Uploading
SVAN 977A User Manual Saving setup files ( measurement configuration setup files can be stored in the SD Card memory with an extension .SVT manually either by means of <S/P> key or by creating the <New File> in the Setup Manager list.
Page 31 SVAN 977A User Manual Pressing simultaneously <Shift> and ◄ keys right after turning on the instrument allows to check and lock back early unlocked options. To select other options, press the <ENTER> key, which opens another page of the Active Functions list.
Page 32: Functions Of The Instrument - Function
SVAN 977A User Manual FUNCTIONS OF THE INSTRUMENT – Function In the Function section, you can select a measurement mode (Mode) which relates to the transducer type, a measurement function (Measurement Function) and perform the instrument check or calibration (Calibration).
Page 33: Instrument's Calibration - Calibration
SVAN 977A User Manual - SLM Sound Level Meter, - VLM Vibration Level Meter, - S:1/1 Sound 1/1 Octave, - V:1/1 Vibration 1/1 Octave, - S:1/3 Sound 1/3 Octave, - V:1/3 Vibration 1/3 Octave, - S:FFT Sound FFT, - V:FFT Vibration FFT.
Page 34: System Check
SVAN 977A User Manual 4.3.1 System Check ISO 8041-1:2017 standard advises users to perform in-situ checks of measuring instruments. Checking should be carried out immediately before and after the measurement. 1. Select System Check in the Calibration sub-list and press <ENTER>.
Page 35: Calibration By Sensitivity (Vibration Signal)
SVAN 977A User Manual For microphones with sensitivity higher than 35.0 mV/Pa the calibration factor will always be negative. For microphones with sensitivity lower than 35.0 mV/Pa the calibration factor will always be positive. The lowest available value of the sensitivity that can be introduced is equal to 35.0 µV/Pa (it conforms to the calibration factor equal to 60.0 dB) and the highest...
Page 36: Calibration By Measurement (Vibration Signal)
SVAN 977A User Manual 2. Set the reference calibration level (Cal. Level) – see Appendix C, Chapter C.1, par. Calibration. 3. Attach the acoustic calibrator SV 36 (or equivalent 114 dB@1000 Hz) carefully over the microphone of the instrument. Note: It is also possible to use an electro-mechanical pistonphone, which generates a signal (ca 124 dB) or different type of acoustic calibrator dedicated for ½”...
Page 37: History Of Performed Calibrations - Calibration History
SVAN 977A User Manual Attach the instrument’s accelerometer to the vibration calibrator using an appropriate or recommended fixing method. Switch on the calibrator and wait approximately 30 seconds before starting the calibration measurement. Start the calibration measurement by pressing the <Start/Stop> key.
Page 38: Erasing Calibration Records - Clear Calibr. History
SVAN 977A User Manual 4.3.7 Erasing calibration records - Clear Calibr. History erase calibration records. this, choose Clear Calibr. History position in the Calibration list and press <ENTER> to perform this operation. The instrument will request the confirmation of this operation.
Page 39: Post Measurement Calibration - Post Calibration
SVAN 977A User Manual 4.3.9 Post measurement calibration – Post Calibration Sometimes it is required to perform so called post-calibration instrument. Post Calibration position allows to perform additional calibration after measurement session and add its results to the data file. The...
Page 40: Configuring Measurement Parameters - Measurement
SVAN 977A User Manual CONFIGURING MEASUREMENT PARAMETERS – Measurement The Measurement section groups items of menu related configuration measurement parameters. <ENT> The Measurement list contains the following positions: General Settings allowing to set up general measurement parameters; Measurement Trigger allowing to set up the measurement trigger;...
Page 41: Setting Up General Measurement Parameters - General Settings
SVAN 977A User Manual 5.1 S ETTING UP GENERAL MEASUREMENT PARAMETERS ENERAL ETTINGS The General Settings list allows you to set up general measurement parameters: measurement start delay (Start Delay), maximum delay period for the synchronization with RTC (Start Sync.), measurement period...
Page 42 SVAN 977A User Manual During the Integration Period, the instrument performs series of 1-second measurements/integrations, and every second averages 1-second results with the results averaged for n-1 seconds. These averaged results are displayed and renewed every second for the elapsed measurement time (n seconds). In the end of the Integration Period the averaged measurement results are saved in the logger file providing that such saving is enabled.
Page 43: Setting Up The Measurement Trigger - Measurement Trigger
SVAN 977A User Manual Selecting Lin is required for obtaining the true RMS value of the measured signal according to IEC 61672- 1:2013. When this option is selected the value of the Leq, SEL, LEPd and Lden results do not depend on the detector time constant: Fast, Slow or Impulse (the results are displayed without the indicator of the detectors selected in the profiles).
Page 44 SVAN 977A User Manual Trigger is switched on if one of its six available modes is selected in the Trigger position: Slope +, Slope –, Level +, Level –, Grad + or External. When the trigger is On, additional parameters can be defined: the measurement result that is checked for a trigger condition (Source), its threshold level (Level) and the speed of its changing (Gradient).
Page 45 SVAN 977A User Manual After 1-second integration, the instrument repeats the trigger condition checking every 0.5 ms and starts next 1-second integration if condition is met. Instrument does it as many times as many seconds are within the Integration Period stops measurement cycle.
Page 46: Setting Parameters For Profiles - Profiles
SVAN 977A User Manual Threshold level The threshold level for the measurement trigger (Level) can be set with 1 dB step in the range from 24 dB to 136 dB in sound modes and from 64dB (1.585mm/s ) to 176dB (631 m/s ) in vibration modes.
Page 47: Data Logging - Logging
SVAN 977A User Manual You can easily access the Profiles screen from the result view screen. Select some profile field (for example, P(1)) with the ▲ / ▼ or ◄ / ► key and press <ENTER>. <ENT> – L 5.4 D...
Page 48: Setting Logger General Parameters - Logger Setup
SVAN 977A User Manual The Logging list enables programming the logging functionality recording measurement results, markers and time- domain signal (wave). The Logging list consists of six positions: Logger Setup, Logger Results, Summary Results, Logger Trigger, Marker Setup Wave Recording.
Page 49: Selecting Logger Results - Logger Results
SVAN 977A User Manual The special warning is displayed in case a file with the edited name already exists in the memory. The instrument waits then for your reaction (any key should be pressed except <Shift> or <Alt>). <ENT> Logger file splitting The Split position allows you to split the logging data registration into separate files.
Page 50: Selecting Additional Summary Results For Saving - Summary Results
SVAN 977A User Manual Note: When Logger is disabled or no Logger results were selected, the logger plot cannot be activated in Display Modes and therefore doesn’t appear on the display. When Logger is enabled and results for logging selected, the logger plot will be available in measurement views.
Page 51: Setting Up Markers - Marker Setup
SVAN 977A User Manual The logging can be done only when the measurement running (the instrument performs a series of 1-second averages), from the measurement start till the measurement stop. This means, for example, when the Level measurement trigger is enabled, than when the...
Page 52: Wave Recording Settings - Wave Recording
SVAN 977A User Manual The Marker Setup allows to assign a specific name for each marker, select its type (normal or Point) and define markers for triggering wave recording (Trig column). <ENT> Name edition is performed in a special text editor screen after pressing the ►...
Page 53 SVAN 977A User Manual The Signal Gain parameter defines the gain of the recorded signal, when 16 bits per sample was selected: 0dB … 40dB. The File Name parameter defines the name of the wave file. You can edit this name in the editor screen, which is opened with the ◄...
Page 54 SVAN 977A User Manual The Slope - trigger starts recording under the condition: falling value of the RMS result (Source) averaged during 0,5 ms passes below the threshold level (Level). This is a mirrored trigger to Slope +. Note: When a wave recording is waiting for the slope trigger the “slope”...
Page 55: Setting Spectra - Spectrum
SVAN 977A User Manual Note: When a wave recording is waiting for the External, Integration Period or Integration Period Split trigger the “trigger” icon appears alternatively with the „wave” icon. Trigger source Only one measured result can be used as a trigger source (Source) for checking of the trigger condition in the Level Meter mode, namely the output signal from the RMS detector coming from the first profile which is denoted here as Leq(1) in the sound mode and RMS(1) in the vibration mode.
Page 56: Measurement Range Selection - Range
The Free Field and Diffuse Field filters are intended to compensate sound measurements in the free field conditions or in the diffuse field conditions. The microphone supplied with SVAN 977A (SV 7052E) is designed for sound measurements in the free field conditions. The Free Field option means that the correction filter for the diffuse field conditions is switched off.
Page 57: Rpm Measurement Settings - Rpm Measurement
SVAN 977A User Manual There are two ranges available: High and Low. detailed description measurement ranges parameters is given in Appendix C. The values of ranges in sound modes depend on the settings in the Compensation Filer screen (path: <Menu> / Measurement / ►...
Page 58: Setting Up The Exposure Time - Exposure Time
SVAN 977A User Manual Note: The RPM results are always registered in the logger file as logger results (with the logger step) and as summary results (with the integration period step). 5.9 S ETTING UP THE EXPOSURE TIME XPOSURE The Exposure Time parameter defines the workday exposure time that is used for the calculation of LEPd (cf.
Page 59: Example Of Timer Execution
SVAN 977A User Manual Time of measurement start The Start Hour position determines the time for the measurement to start. The required hour and minute can be selected in a special screen, which is opened with the ◄ / ► key.
Page 60: Advanced Alarm Function - Alarms
SVAN 977A User Manual It is recommended to set the Start Delay time to 0 seconds for the Timer function. 5.12 A DVANCED ALARM FUNCTION LARMS Alarms position appears Measurement list in the case the advanced alarms configuration file (ALARM.SVA) is...
Page 61: Configuring Data Viewing - Display
SVAN 977A User Manual CONFIGURING DATA VIEWING – Display The Display section contains elements for programming presentation of measurement result and display parameters. The content of the Display list depends on selected measurement function. <ENT> The Display section contains following items: Display Modes allowing to define active modes of a measurement results presentation;...
Page 62: Running Spl View
SVAN 977A User Manual 6.1.1 Running SPL view The Running SPL view is available in the Sound measurement modes. It shows in a large format one measured result – SPL for the selected profile (Leq with the weighting filter and detector constant defined in the Profiles screen for the last second).
Page 63: Combined Views
SVAN 977A User Manual Changing the field content The content of some fields can be changed with the ◄ / ► key together with <Alt>. <Alt/►> Changing active fields You can change the active field with the ◄ / ► key.
Page 64 SVAN 977A User Manual Note: Detector type for the displayed result depends on settings in General Settings and Profiles lists (path: <Menu> / Measurement). There is no displayed indication of the detector in case of Peak, P-P and Ovl results (see Appendix D).
Page 65: Logger View
SVAN 977A User Manual Changing the active fields You can change the active field with the ▲ / ▼ (vertically) or ◄ / ► (horizontally) key. ▼ 6.1.4 Logger view The Logger view depends on the settings made in the Logging list (path: <Menu> / Measurement / Logging).
Page 66: Spectrum View
SVAN 977A User Manual You may change the cursor position with the ◄ / ► key. ◄... 6.1.5 Spectrum view The Spectrum position is accessible only in the active 1/1 Octave, 1/3 Octave or FFT functions. The spectra views are described in Chapters and 11.
Page 67: Meter Table View
SVAN 977A User Manual The cursor position is changing with the ◄ / ► key if the field 3 is selected. The statistical level and appropriate value are presented in the line below the plot. Press the ◄ / ► key with <Shift> to go straight to the first or last Lnn position on the screen.
Page 68 SVAN 977A User Manual Scale of results presentation The Scale parameter defines results units: linear (Lin) or logarithmic (Log). For sound measurements the Scale position is not active. All results are always presented in dB. => In case of Log, the graphical presentation is...
Page 69: Adjusting The Logger View - Logger View
SVAN 977A User Manual Decimal Mark The Decimal Mark position allows to select which decimal mark (point or comma) will be used for data presentation in all presentation modes. 6.3 A DJUSTING THE LOGGER VIEW OGGER The Logger View screen allows to adjust the Logger view by choosing logged results to be displayed and colours of their curves.
Page 70 SVAN 977A User Manual Power saver delay The power saver delay defines the delay period from the last use of any key to the power saver mode. This delay period can be set for Dim screen on idle from 5 s to 60 s and for Screen off on idle from 1 m to 60 m. The <ENTER>...
Page 71: Managing Files - File
SVAN 977A User Manual MANAGING FILES – File The File section contains the elements that enable managing data (logger and wave) and setup files saved in the instrument’s memory (micro SD card). The memory structure and files saving methods are described in Chapter 3.5.
Page 72: Assigning Directory For Data Files Saving - Set As Working Dir
SVAN 977A User Manual In the File Manager screen, you can check the memory content, create new directories and files, select directory for automatic data files saving, rename and delete files and directories. All these operations can be done on the selected file or directory by means of the <ENT>...
Page 73: Deleting Files/Directories - Delete
SVAN 977A User Manual Opening the logger file means that the measurement results saved in this file will be loaded to the instrument's operation memory and may be reviewed on the screen. The results are loaded together with the Mode and...
Page 74: Renaming Files/Directories - Rename
SVAN 977A User Manual 7.1.5 Renaming files/directories – Rename You can rename files or directories. To do this, select the desired file or directory and press <ENTER>. Select the Rename position in the command list and press <ENTER>. The special screen with editor function will be opened.
Page 75 SVAN 977A User Manual Loading setup files Loading the setup file means that the settings saved in this file will be loaded to the instrument's flash memory. So, if you press the <Start/Stop> key the instrument will start the measurement with the newly loaded settings.
Page 76: Configuring Instrument Parameters - Instrument
SVAN 977A User Manual CONFIGURING INSTRUMENT PARAMETERS – Instrument The Instrument section is used for setting the various parameters which are primarily dedicated for controlling of the instrument hardware. <ENT> The Instrument list contains following positions: Auto Start allowing to start the measurement just after turning the instrument on;...
Page 77: Interface Parameters Settings - Communication Ports
SVAN 977A User Manual When the instrument is powered from a set of internal batteries you should select the correct battery type (Alkaline or Rechargeable). It is essential for the right detection of the capacity of the battery pack. 8.3. I...
Page 78: External Power Settings- External Power
SVAN 977A User Manual When Bluetooth is selected, the grey “Bluetooth” icon is displayed while there is no connection with another Bluetooth device. When devices are paired, the “Bluetooth” icon changes its colour to green. => 8.4. E XTERNAL POWER SETTINGS...
Page 79: Setting Parameters Of The I/Oport - Multifunction I/O
SVAN 977A User Manual <Start/Stop> key mode In the Start/Stop position, you can choose between Direct and With Shift. When the Direct option is selected, the instrument reacts on each of the <Start/Stop> keystroke, starting or stopping the measurement. When the With Shift option is selected the <Start/Stop> key will operate with the <Shift>...
Page 80 SVAN 977A User Manual Function of the Digital Out mode The Function position allows to select the function of the digital output of the I/O instrument’s socket. The socket can be used as a source of the trigger pulse (Trigger Pulse) which starts the measurement in another “slave instrument”...
Page 81: Programming The Instruments Internal Real Time Clock - Rtc
IRELESS RANSFER SVAN 977A instrument is not equipped with the modem and itself cannot assure data transfer via mobile network. However, it can control data transfer via the modem that supports GSM connection with the help of the Wireless Transfer functionality. The connection with the external modem is carried out via the USB port.
Page 82: Selecting Network Type - Network
SVAN 977A User Manual The Wireless Transfer position allows to select network type parameters of data transmission. <ENT> 8.9.1. Selecting network type – Network In the Network screen you can disable (Off) data transfer or enable it selecting GPRS. <ENT>...
Page 83: Configuring Connections - Modem Connection
SVAN 977A User Manual • Data Protocol – defines connection type for data exchange. Available types are TCP S (server mode), TCP C (client mode) and UDP. ► • Sim Auth Mode – defines the method of user verification by a SIM card type.
Page 84: Configuring Sms Service - Sms Options
SVAN 977A User Manual • Data Port – allows to enter up to 5 characters for the port number. This number denotes a port on which a communication socket will be configured for data exchange between the remote host and the station.
Page 85: Configuring E-Mail Service - E-Mail Settings
SVAN 977A User Manual 8.9.5. Configuring e-mail service - E-mail Settings The E-mail Settings position allows to configure the e-mail service used for alarm notification. If the SvanMail position is enabled, you should define only positions: Recipient e-mail, E-mail Subject and E-mail Message. The SvanMail option allows instruments, compatible with SvanNET, send e-mails without additional parameters, simplifying the process of configuring alarm notifications.
Page 86: Introducing The Instrument Name - Unit Name
▲ / ▼ key. <ENT> Note: The contents of the Unit Label screen should be always sent to the Svantek service department or official representative in case of any problems faced by the user during the instrument’s...
Page 87: Auxiliary Settings - Auxiliary Setup
SVAN 977A User Manual AUXILIARY SETTINGS – Auxiliary Setup Auxiliary Setup section provides additional functions that allow, for instance, customization of the device interface to a specific user requirement and are not directly related to the hardware components of the instrument.
Page 88: Selecting Units For Vibration Results - Vibration Units
SVAN 977A User Manual Reference levels for vibration measurements In the Acc position you can set the reference level of the acceleration signal in the range: 1 µms - 100 µms In the Vel position you can set the reference level of the velocity signal in the range: 1 nms - 100 nms In the Dil position you can set the reference level of the displacement signal in the range: 1 pm - 100 pm.
Page 89 SVAN 977A User Manual Confirmation of parameters changes If the Save Changes warning is enabled, the instrument asks to confirm whether you want to save changes or not in cases you changed some parameters in the list of parameters but exiting the screen with the <ESC>...
Page 90: 10 1/1-Octave And 1/3-Octave Analyser
SVAN 977A User Manual 10 1/1-OCTAVE AND 1/3-OCTAVE ANALYSER The instrument operates as the 1/1-octave or 1/3-octave analyser in a very similar way to the level meter. Moreover, 1/1-octave or 1/3-octave analysis is performed in parallel with the level meter measurements. All 1/1- octave (with 10/15 centre frequencies from 16 kHz down to 31.5 Hz/1.0 Hz;...
Page 91: Configuring 1/1 Or 1/3-Octave Analyser
SVAN 977A User Manual 10.2 C 1/3- ONFIGURING OCTAVE ANALYSER 10.2.1 General settings for 1/1 and 1/3-octave analysis – General Settings Execution of the 1/1-octave or 1/3-octave analysis depends on a certain set of parameters, configured in the Measurement section.
Page 92: Setting Parameters Of 1/1-Octave And 1/3-Octave Analysis - Spectrum
SVAN 977A User Manual 10.2.4 Setting parameters of 1/1-octave and 1/3-octave analysis - Spectrum active 1/1 Octave 1/3 Octave functions a context position (Spectrum) appears in the Measurement list (path: <Menu> / Measurement / Spectrum). In the Spectrum screen, you can select the band and the pre-weighting broadband frequency filter (only for sound measurements).
Page 93 SVAN 977A User Manual Ultra (1-31.5k) - 16 filters with centre frequencies from 1 Hz to 31.5 kHz => 1/3 Octave: Full (0.8-20k) - 45 filters with centre frequencies from 0.8 Hz to 20 kHz => Ultra (0.8-40k) - 48 filters with centre frequencies from 0.8 Hz to 20 kHz...
Page 94: Configuring 1/1 And 1/3 Octave Spectra Views
SVAN 977A User Manual You can easily get into the Spectrum screen from the spectrum view. It is necessary to enter the function field (for example 1/1) with the ▲ / ▼ key and press <ENTER>. <ENT> 10.3 C ONFIGURING...
Page 95: Adjusting Scales Of The Spectrum Plot - Display Scale
SVAN 977A User Manual You can shift the Y-axis in the spectrum view with the <Shift> and ▲ / ▼ keys pressed together. ▼ <Sh/ > You can change the cursor position with the ◄ / ► key. You can jump to the first or last...
Page 96: Selecting Spectra To Be Viewed - Spectrum View
SVAN 977A User Manual Scaling the vertical axis of the plot Dynamics parameter defines dynamic range of the Y-axis scale. => It is possible to select the range from the set: 10dB, 20dB, 40dB, 80dB, 100dB and 120dB. => Toggling the grid...
Page 97: Changing Spectrum Type In Vibration Modes - Spectrum Type
SVAN 977A User Manual When the Averaged or Instantaneous spectrum is selected, you can additionally enable presentation of the Max and/or Min values for each band by switching the Max or Min parameters on. The Max and Min spectrum is presented as a stepped line –...
Page 98: Fft Analyser
SVAN 977A User Manual 11 FFT ANALYSER The instrument operates as the FFT analyser in a very similar way to the Level Meter. Moreover, the FFT analysis is performed in parallel with the SLM or VLM measurements. Results of the FFT analysis (spectra) measured with preselected frequency weighting filter and window, are presented in the Spectrum view.
Page 99: Logging Of Fft Spectra - Logging
SVAN 977A User Manual Values of ranges in sound modes depend on the settings made in the Compensation Filer screen (path: <Menu> / Measurement / Compensation Filter). Note: The calibration factor is always added to the upper range level. For example, if the calibration factor is equal to 0.5 dB, the upper range will be changed automatically (the upper limit will be increased by 0.5).
Page 100: Configuring Fft Spectra View
SVAN 977A User Manual There are two averaging options (Averaging): Linear Exponential. case Exponential averaging, the Time Constant parameter appears in this screen. You can select: 100ms, 125ms, 200ms, 500ms, 1.0s, 2.0s, 5.0s or 10.0s. ► You can easily get into the FFT screen from the spectrum view.
Page 101: Setting Up The Scale Of Spectrum Plot - Display Scale
SVAN 977A User Manual You can shift the Y-axis in the spectrum view with the <Shift> and ▲ / ▼ keys pressed together. ▼ <Sh/ > You can change the cursor position with the ◄ / ► key. You can jump to the first or last spectrum line with <Shift>.and ◄...
Page 102: Selection Of Spectra To Be Viewed - Spectrum View
SVAN 977A User Manual Scaling the vertical axis Dynamics parameter defines dynamic range of the Y-axis scale. => It is possible to select the range from the set: 10dB, 20dB, 40dB, 80dB, 100dB and 120dB. => Toggling the grid The Grid position allows to toggle the horizontal grid lines of the logger or spectrum plot.
Page 103: Changing Spectrum Type In Vibration Modes - Spectrum Type
SVAN 977A User Manual You can easily get into the Spectrum View screen from the Spectrum view by entering the result field (Leq/RMS) with the ▲ / ▼ key and pressing <ENTER>. <ENT> 11.3.4 Changing spectrum type in Vibration modes - Spectrum Type...
Page 104: Reverberation Time Measurements - Rt60
(A, C and Z weighted). Whole measurement process and calculations implemented in SVAN 977A fulfil the ISO 3382 standard. The reverberation time of the room can be obtained with the use of SVAN 977A by two measurement methods: Impulse Response Method (Impulse) and Interrupted Noise Method (Decay). The selection of the method depends on the type of the used sound source.
Page 105 SVAN 977A User Manual The RT60 Settings list allows to select the method for RT60 calculations, define the name of the file, where the registered data will be collected, and other parameters for RT60 calculations. The Start Delay parameter defines the delay period from the moment the <Start/Stop>...
Page 106 SVAN 977A User Manual To make averaging of the new results with the results calculated earlier, select the field Averaging and press <ENTER>, select in the confirmation screen Yes and press <ENTER> again. In the field No.: x, the value x will be increased by one and the symbol ...
Page 107: Configuring Rt60 Views
SVAN 977A User Manual The Level position defines the threshold level of the sound source for triggering the RT60 measurement. If the measured sound is below the Level value, the RT60 measurement will not start. The parameter can be set in the range 24 ÷...
Page 108 SVAN 977A User Manual Place the sound power source in the measured room (for the sound power source location - see the reverberation time measurement ISO standard). Place the microphone in one of the selected measurement points (for the measurement points location see the reverberation time measurement ISO standard).
Page 109: Viewing Of Rt60 Results
SVAN 977A User Manual Start the measurement process with the <Start/Stop> key. The display indicates that the instrument is waiting for the trigger condition fulfilment. Fire the impulse sound power source. If the trigger condition is fulfilled the instrument starts to collect data.
Page 110 SVAN 977A User Manual Bar plot of RT60 results 1. Number of averaged results 2. RT 1/3 octave plot 3. Name of the RT result and its value 4. Used RT60 calculation method 5. Cursor position 6. RT results for Total values 7.
Page 111 SVAN 977A User Manual Changing the data type When the field 9 is active the type of data displayed (Raw, Smoothed or Integrated) can be changed with the ◄ / ► key pressed together with <Alt>. ► <Alt/ > Changing the band When the field 3 is active the central frequency of the band can be changed with the ◄...
Page 112: Remote Control Tools
This application allows you to control the instrument remotely via Bluetooth When SVAN 977A is a part of the SV 277 PRO/PRIM monitoring station it can be controlled via GSM connection. GSM connection opens wider possibilities for remote communication. There are few communication options via GSM connection, which depend on the Internet access, provided by GSM operators.
Page 113: Maintenance
• SA 17A external battery pack – operation time > 24 h (option) • USB interface – 500 mA HUB SVAN 977A is delivered with four AA alkaline batteries, but you may also use AA rechargeable batteries. The “battery” icon shows the condition of the internal batteries.
Page 114: Memory Card Extraction And Insertion
(e.g. pen) to push the card right in. 14.3 T RANSDUCERS SVAN 977A is equipped with the TNC connector as an input of the measured signal taken from the microphone preamplifier or the vibration transducer. Microphone The SVAN 977A set includes prepolarised ½”...
Page 115: Resetting The Instrument
(SV 80) with a coiled cable for accelerometer 2 m (SC 27) can be used. The SV 80 is an industry standard IEPE accelerometer offered for SVAN 977A. It is an ideal choice for walk-around measurement points in the rugged environments of industrial machinery monitoring, such as pumps, motors or fans.
Page 116: Firmware Upgrade
Clean the surface of the instrument with damp soft cloth. The instrument sockets should be cleaned with the use of compressed air. Note: In cases of larger dirt, such as oil or grease, contact your Local Authorized Distributor or Svantek Service Office.
Page 117: Troubleshooting
Chapter 14.4). • In case the reset does not help call your Local Authorized Distributor or Svantek Service Office. Should your SVANTEK professional measurement equipment need to be returned for repair or for calibration, please contact the service office at the following number or contact via the SVANTEK website.
Page 118: Glossary
SVAN 977A User Manual 15 GLOSSARY 15.1 M ODES AND EASUREMENT UNCTIONS Name Description Screen Reference Function menu section enabling selection Chapter measurement Mode, Measurement Function perform Calibration of the instrument. Mode Mode of the instrument operation defined by the...
Page 119: Calibration
SVAN 977A User Manual 1/3 Octave Measurement Function enabling calculation Chapter Level Meter results and 1/3-octave results for sound or 4.2, vibration measurements in accordance with Class 1 IEC 61260-1: 2014. 1/3-octave results are presented as a spectrum plot - a function of result vs central band frequency and can be saved as a time-history.
Page 120: Definitions Of Measured Results
SVAN 977A User Manual Calibration by Type of calibration based on the reference signal Chapter Measurement measurement with the use of a microphone or 4.3.4, 4.3.5 accelerometer calibrator. Calibration Level Level of the reference signal generated by used Chapter calibrator.
Page 121 SVAN 977A User Manual elapsed time exceeds 999 hours. Its maximum value is equal to the Integration Period and the elapsed time is zeroed when new measurement cycle starts. Percentage of the overloaded input signal, which Appendix D occurred within the elapsed measurement time.
Page 122 SVAN 977A User Manual LEPd Daily Personal Noise Exposure, the noise exposure level Appendix D for a nominal 8-hour working day, used for assessing the D.1.2 noise exposure of a worker during a working day. The LEPd result is calculated on the base of the Leq.
Page 123: Measurement Parameters
SVAN 977A User Manual P–P Peak-to-peak, the difference between highest and lowest Appendix D value of the signal within the elapsed measurement time. D.2.2 Root Mean Square result of the time-weighted vibration Appendix D (acceleration, velocity or displacement) level within the D.2.2...
Page 124 SVAN 977A User Manual Repetition Cycles Number of measurement/integration repetitions after the Chapter <Start> key pressure. This enables to make a series of measurements without pressing the <Start> key and save this series in the results file. RMS Integration Type of integration of RMS based results (RMS Chapter detector): Linear or Exponential.
Page 125 SVAN 977A User Manual Detector Exponential RMS detector time constant applied in the Chapter profile: - Impulse, Fast or Slow for sound results like Leq, Lmax, Appendix D Lmin, SEL, LEPd, Lden, Spl, Ltm3 and LTeq; D.1.2 - from 100ms to 10s for vibration results like RMS, MAX.
Page 126 SVAN 977A User Manual High High linear operating range for the sinusoidal signal. Chapter The calibration factor is always added to the upper range limit. Appendix C The range depends on the selected Compensation Filter. Measurement Screen that enables configuring...
Page 127 SVAN 977A User Manual Integration Period consists and stops the measurement cycle. Grad + Type of trigger that starts the 1-second measurement/ Chapter integration under the condition: value of the RMS result (Source) integrated during 0,5 ms is greater than the threshold level (Level) and the gradient of this Source is greater than the threshold level (Gradient).
Page 128 SVAN 977A User Manual Timer Screen that enables configuring automatic switching On Chapter the instrument and performing the measurement on the 5.11 programmed time with defined setup. Timer can be Single or repeatable (Multiple). After every timer cycle, the instrument automatically switches itself off.
Page 129 SVAN 977A User Manual Split Position in the Logger Setup screen that enables saving Chapter of the logger records in separate files according to 5.4.1 different rules: after the integration period, or every quarter / half an hour / hour, or on specific times of a day.
Page 130 SVAN 977A User Manual Post Period of additional logging after triggering condition Chapter fulfilment. 5.4.4 Wave Recording Recording of the waveform signal to a file with the Chapter extension WAV. Files WAV are created automatically. 5.4.6 Every time a wave recording starts the new WAV file is created and is closed when recording stops.
Page 131 SVAN 977A User Manual Trigger Parameter that enables switching Off or selecting the Chapter trigger type for triggering wave recording: Slope +, 5.4.6 Slope –, Level +, Level –, External, Integr. Period and Int. Period Split. If the instrument is waiting for the trigger condition, which...
Page 132 SVAN 977A User Manual Level Threshold level of the trigger condition. Chapter 5.4.6 Trigger Period Time interval of checking the triggering conditions. This Chapter parameter can be set as: Log. Step (same as 5.4.6 Logger Step value), 0.5ms, 100.0ms and 1s.
Page 133 SVAN 977A User Manual Filter Weighting filters for the 1/1 Octave and 1/3 Octave Chapter analysis: A, B, C, Z for sound analysis with Audio band, 10.2.4 HP for vibration analysis with Full band and HPE for sound and vibration analysis with Ultra band.
Page 134 SVAN 977A User Manual RT60 Settings Screen that enables setting the reverberation time Chapter measurement parameters: Start Delay, Method, Octave, 12.2 Freq. Range, Recording Time, Time Step, Averaging, Appendix E Noise Mar., Logger Name and Level. Start Delay Delay between pressing the <Start> key and the start of Chapter measurement integration.
Page 135 SVAN 977A User Manual Averaging Process of averaging of the reverberation time results Chapter from several measurements during RT60 calculations. 12.2 Appendix E Smoothing Process of smoothing of the raw reverberation time Chapter results. This is used for better visualization of the RT60 12.2...
Page 136: Display Parameters
SVAN 977A User Manual Event Event that generates alarm based on combination of Chapter Threshold and Time conditions. For each event, a 5.12 different type of Action can be set. Action Type of action in case of alarm: marker, audio, external Chapter I/O, SMS text message, or e-mail.
Page 137 SVAN 977A User Manual 1 Prof. & Logger Mode of presentation of one result in the upper part of Chapter view the screen and time history (logger) results in the lower 6.1.3 part of the screen. 3 Prof. & Logger...
Page 138 SVAN 977A User Manual Smoothed Data Presentation of smoothed decay curve of Leq results for Chapter view 1/1 or 1/3-octave bands. 12.5 Integrated Data Presentation of the integrated raw decay curve Chapter view (Schroeder curve). 12.5 Display Scale Screen that enables setting parameters of results...
Page 139 SVAN 977A User Manual Spectrum View Screen that enables selecting of types of spectra for Chapter displaying: Averaged, Instantaneous, Max, Min, NR and 10.3.3, 11.3.3 Instantaneous Spectrum of instantaneous Leq results for the 1/1-octave Chapter or 1/3-octave bands. 10.3.3, 11.3.3...
Page 140: Instrument Parameters
SVAN 977A User Manual Velocity Velocity spectrum which is displayed if it has been Chapter selected in the Spectrum Type screen. 10.3.4, 11.3.4 Displacement Displacement spectrum which is displayed if it has been Chapter selected in the Spectrum Type screen.
Page 141 SVAN 977A User Manual Communication Screen that enables configuring instrument Chapter communication ports: GPS and Serial Port – RS232 or Ports Bluetooth. External Power Screen that enables configuring automatic instrument Chapter switching on or off in case the voltage of the external DC power exceeds or becomes lower than the threshold level.
Page 142 SVAN 977A User Manual Digital Out Mode of the I/O port when digital signal is used for Chapter triggering other “slave instrument(s)” (the instrument is acting in this case as a “master instrument”), or as a Appendix C source of alarm signal.
Page 143 SVAN 977A User Manual Send SMS Activation of alarm SMS sending via Wireless Transfer Chapter when Alarm Pulse is selected as a function of the Digital Out I/O mode. Send E-Mail Activation of alarm e-mail sending via Wireless Transfer Chapter when Alarm Pulse is selected as a function of the Digital Out I/O mode.
Page 144 SVAN 977A User Manual Send SMS Parameter of the Modem screen switching on the SMS Chapter alarm notification. 8.9.2 Send E-Mail Parameter of the Modem screen switching on the e-mail Chapter alarm notification. 8.9.2 Auto Reconnectio Parameter of the Modem screen switching on the device...
Page 145 SVAN 977A User Manual Registration Port Parameter of the Modem Connection screen defining the Chapter port number that denotes a port on which a 8.9.3 communication socket will be configured to transmit registration package (Register Mode: On) or exchange Http data (Register Mode: AS or SMT. AS).
Page 146 SVAN 977A User Manual SMS Option Screen that enables configuring SMS service used for Chapter alarm notification: Phone Number and Text Message. 8.9.4 Phone Number Parameter of the SMS Option screen defining the phone Chapter number where the text messages will be sent.
Page 147 SVAN 977A User Manual Sender e-mail Parameter of the E-mail Settings screen defining e-mail Chapter address from which the e-mail message will be sent. 8.9.5 Recipient e-mail Parameter of the E-mail Settings screen defining e-mail Chapter address to which the e-mail message will be sent.
Page 148: Auxiliary Parameters
SVAN 977A User Manual 15.7 A UXILIARY PARAMETERS Name Description Screen Reference Auxiliary Setup Section in the Main Menu that enables customizing the Chapter instrument interface to specific user requirements in the screens: Language, Factory Settings, Reference Levels, Vibration Units and Warnings.
Page 149: Appendix A. Remote Control
SVAN 977A User Manual - Appendixes APPENDIX A. REMOTE CONTROL The USB 1.1 interface is the serial one working with 12 MHz clock. Its speed is relatively high, and it ensures the common usage of USB in all produced nowadays Personal Computers.
Page 150: Function #2 - Read Out Of The Main Measurement Results
SVAN 977A User Manual - Appendixes The instrument outputs in this case a file containing all control settings given in Tab. A1 in the format: #1,Xccc,Xccc,(...),Xccc; Note: All bytes of that transmission are ASCII characters. #2 – R A.2. F...
Page 151 SVAN 977A User Manual - Appendixes The codes of results in the case of Sound Meter mode are defined as follows: number of measurement cycle; overload flag (c equals to 0 or 1); time of the measurement cycle (c – value in seconds);...
Page 152: Function #3 - Read Out Of The Measurement Results In 1/X Octave Or Fft Mode
SVAN 977A User Manual - Appendixes #3 – R A.3. F OCTAVE UNCTION EAD OUT OF THE MEASUREMENT RESULTS IN MODE #3 function enables one to read out the current measurement results in 1/x OCTAVE or FFT mode. #3 function format is defined as follows: –...
Page 153 SVAN 977A User Manual - Appendixes – battery state in [%]. – battery power, y = 0 – external supply power, y = -1 – USB power. y = -2 #7,BV; Get battery voltage. Response format: #7,BV,x.xx; where: – battery voltage in [V].
Page 154 SVAN 977A User Manual - Appendixes where: – Off, x = 0 – Free Field, x = 1 – Diffuse Field, x = 2 – Outdoor Environment, x = 3 – Outdoor Airport. x = 4 Response format: #7,MC; #7,WD;...
Page 155 SVAN 977A User Manual - Appendixes – exponential detector. x = 1 #7,SE,x; Set detector for statistical analysis. where: – linear detector, x = 0 – exponential detector. x = 1 Response format: #7,SE; #7,SL; Get statistical levels. Response format: #7,SL,x1,x2,x3,x4,x5,x6,x7,x8,x9,x10;...
Page 156 SVAN 977A User Manual - Appendixes #7,PI; Get internal microcontroller firmware version. Response format: #7,PI,x.xx; where: – internal microcontroller firmware version number. x.xx #7,VH; Get hardboot program version. Response format: #7,VH,x.xx; where: – hardboot program version number. x.xx #7,VB; Get bootstrap program version.
Page 157 SVAN 977A User Manual - Appendixes #7,RT,hh,mm; Set current real time clock settings without seconds; where: – time (seconds are reset), hh:mm Response format: #7,RT; #7,RT,hh,mm,ss; Set current real time clock settings with seconds; where: – time, hh:mm:ss Response format: #7,RT;...
Page 158 SVAN 977A User Manual - Appendixes #7,US,x; where: – subtype number. #7,CS; Clear current setup (factory settings). Response format: #7,CS; #7,WS; Get state of the ”Results Not Saved” warning. Response format: #7,WS,x; where: – warning disabled, x = 0 – warning enabled.
Page 159 SVAN 977A User Manual - Appendixes #7,WM,x; Set ”Min Free Space” value for the ”Ext. Disk Free Space” warning. where: – min. free space in [MB]. Response format: #7,WM; #7,LB; Get the name of the last logger filename. Response format: #7,LB,name;...
Page 160 SVAN 977A User Manual - Appendixes #7,CM,n,”<name>”,e,p; #7, CM,n,”<name>”,e,p; Set parameters of the n Logger Marker. Response format: #7,CM; where: – number of marker (1..4), <name> – name of marker (10 ASCII characters), – Event Trigger inactive on this marker, e = 0 –...
Page 161 SVAN 977A User Manual - Appendixes #7,EP; Get states of the External Power functionality. Response format: #7,EP,x,V ,y,V #7,EP,x,V ,y,V Set states of the External Power functionality. Response format: #7,EP; where: – Power Off functionality disabled, x = 0 – Power Off functionality enabled (the instrument will be switched-off after reaching...
Page 162: Function #D - Read / Write The Data Files From The External Memory (Sd-Card)
SVAN 977A User Manual - Appendixes #7,AC,x; Set state of the Auto Calibration functionality. Response format: #7,AC; where: – Auto Calibration disabled, x = 0 – Auto Calibration enabled. x = 1 #D – R A.5. F (SD- UNCTION RITE THE DATA FILES FROM THE EXTERNAL MEMORY CARD <disk>...
Page 163: Control Setting Codes
SVAN 977A User Manual - Appendixes A.6. C ONTROL SETTING CODES The control setting codes used in the SVAN 977A instrument are given in the table below. Table A.1. Control setting codes Group Group name Code description code U977 (read only)
Page 164 SVAN 977A User Manual - Appendixes Group Group name Code description code I0:n HP filter for profile n I1:n HP1 filter for profile n I2:n HP3 filter for profile n I3:n HP10 filter for profile n I4:n Vel11 filter for profile n...
Page 165 SVAN 977A User Manual - Appendixes Group Group name Code description code L0 - Linear Leq / RMS detector type L1 - Exponential A0 - Full A1 - Audio Spectrum Band A2 - Ultra f1 - Z filter Filter type in 1/x OCTAVE or FFT...
Page 166 SVAN 977A User Manual - Appendixes Group Group name Code description code w0 - Hanning w1 - Rectangle Screen in FFT analysis w2 - Flat Top w3 - Kaiser-Bessel y0 - 1600 y1 - FFT lines y2 - q0 -...
Page 167 SVAN 977A User Manual - Appendixes Group Group name Code description code Source of the measure triggering s0 - signal x = level in dB (24  136) lx - Measure Triggering level in SLM mode Measure Triggering gradient x = gradient in dB/ms (1  100)
Page 168 SVAN 977A User Manual - Appendixes Group Group name Code description code Xs0 - Leq(1) / RMS(1) Xs1 - Peak(1) External IO Source Xs2 - Max(1) Xs3 - Spl(1) / P–P(1) Xt0 - Current Extended IO Source Type Xt1 -...
Page 169 SVAN 977A User Manual - Appendixes Group Group name Code description code XJxxxxx - xxxxx up to 5 decimal characters Data Port (GPRS) (0  65535) XKxxxxx - xxxxx up to 5 decimal characters Registration Port (GPRS) (0  65535)
Page 170: Appendix B. Data File Structures (Firmware Revision 1.21)
SVAN 977A User Manual - Appendixes APPENDIX B. DATA FILE STRUCTURES (firmware revision 1.21) B.1. G SVAN 977 ENERAL STRUCTURE OF THE FILES Each file containing data from the SVAN 977 instrument consists of several groups of words. In case of SVAN 977, there are two different types of files containing: •...
Page 171 SVAN 977A User Manual - Appendixes Note: if any 16-bit result value is equal to -12288 (hex:d000) it means that the result is undefined. Below, all file structure groups are described separately in 0 – 0. The format used in the columns, named...
Page 172 SVAN 977A User Manual - Appendixes Table B.1.4 Calibration settings Word Name Comment number [47, nn=header’s length] 0xnn47 type of calibration performed prior to measurement: 0 - none 1 - BY MEASUREMENT PreCalibrType 2 - BY SENSITIVITY 3 - FACTORY CALIBRATION PreCalibrDate date of calibration performed prior to measurement (cf.
Page 173 SVAN 977A User Manual - Appendixes Word Name Comment number measurement range: 1 – LOW Range 2 – HIGH SLM mode: detector's type for statistical analysis: 0 – Linear, StatDet 1 – Exponential VLM mode: reserved repetition cycle: – infinity RepCycle nnnn –...
Page 174 SVAN 977A User Manual - Appendixes Word Name Comment number SLM mode: exposure time: 1..720 (in minutes) VLM mode: reserved SLM mode: rolling time(1) in seconds VLM mode: reference level for acceleration in 0.01 dB re 1.0 µm/s SLM mode:...
Page 175 SVAN 977A User Manual - Appendixes Word Name Comment number Logger files splitting time: -1 - off. SplitTime[2] 0:1439 - Time in minutes. Valid only if SplitMode is equal 1440. Logger files splitting time: -1 - off. SplitTime[3] 0:1439 - Time in minutes.
Page 176 SVAN 977A User Manual - Appendixes Table B.1.8 LOGGER TRIGGER parameters Word Name Comment number [2C, nn=block’s length] 0xnn2C trigger mode: 0 – Off, TriggerMode 3 – logging on trigger LEVEL+, 4 – logging on trigger LEVEL– source of the triggering signal: TriggerSource 0 –...
Page 177 SVAN 977A User Manual - Appendixes Word Name Comment number sampling frequency given in 10Hz TriggerSampling recording time of single data block: 0 - recording to the end of measurement TriggerRecTime 1..28800 (sec) filter type: 0 – HP, 1 – Z, TriggerFilter 2 –...
Page 178 SVAN 977A User Manual - Appendixes Word Name Comment number recording time of single data block: 0 - recording to the end of measurement TriggerRecTime 1..28800 (sec) filter type: 0 – HP, 1 – Z, TriggerFilter 2 – A, 3 – C, 5 –...
Page 179 SVAN 977A User Manual - Appendixes Word Name Comment number in case of DIGITAL OUT and ALARM PULSE: level (*10 dB) AlarmLevel in other cases: reserved in case of DIGITAL OUT and TRIG. PULSE: Polarisation: 0 – POSITIVE, 1 – NEGATIVE...
Page 180 SVAN 977A User Manual - Appendixes Word Name Comment number filter type in the 2 profile: 1 – Z, 2 – A, FilterP[2] 3 – C, 5 – B logger contents in the 2 profile defined as a sum of: 0 –...
Page 181 SVAN 977A User Manual - Appendixes Word Name Comment number detector type in the 1 profile: 0 - 100 ms, 1 - 125 ms, 2 - 200 ms, 3 - 500 ms, DetectorP[1] 4 - 1 s, 5 - 2 s, 6 - 5 s, 7 - 10 s...
Page 182 SVAN 977A User Manual - Appendixes Word Name Comment number flags in the 3 profile ProfileFlags[3] … … … Table B.1.14 RTF parameters Word Name Comment number [21 = id, nn = block’s length] 0xnn21 type of 1 user filter:...
Page 183 SVAN 977A User Manual - Appendixes Word Name Comment number Name of 2nd marker (10 characters length) 10..14 MarkerName[2] 2nd marker event: 0 – Off MarkerEvt[2] 1 – On 2nd marker point: 0 – Off MarkerPoint[2] 1 – On Name of 3rd marker (10 characters length) 17..21...
Page 184 SVAN 977A User Manual - Appendixes Table B.1.17 Header of the 1/x Octave analysis Word Name Comment number [4A = id, 00 = block’s length in the second word] 0x004A block length BlockLength [used_profile, profile’s mask] 0x0101 2 or 10 SystemBase 1 –...
Page 185 SVAN 977A User Manual - Appendixes Table B.1.19 Header of the FFT analysis Word Name Comment number [51 = id, 00 = block’s length in the second word] 0x0051 block length BlockLength [used_profile, profile’s mask] 0x0101 reserved zoom flag Zoom central frequency in [mHz] (in case of Zoom = 1) 5..6...
Page 186 SVAN 977A User Manual - Appendixes Table B.1.20 RT60 parameters Word Name Comment number [1A = id, nn = block’s length] 0xnn1A type of results in block 1B: RT60SaveMode 1 - results, 2 - averaged results calculation method: RT60Method_p 1 - DECAY,...
Page 187 SVAN 977A User Manual - Appendixes Table B.1.22 Contents of the logger file Word number Name Comment 0..(BuffLength/2-1) result#1, result#2, ... result#(BuffLength/2-1) Table B.1.23 Main results in SLM mode (saved in Summary Results Record) Word Name Comment number [07, nn=block’s length] 0xnn07 [used_profile, profile’s mask]...
Page 188 SVAN 977A User Manual - Appendixes Word Name Comment number Result[2][8] Ltm3 value in the 2 profile (*100 dB) Result[2][9] LTeq value in the 2 profile (*100 dB) Result[2][10] LR1 value in the 2 profile (*100 dB) Result[2][11] LR2 value in the 2...
Page 189 SVAN 977A User Manual - Appendixes Word Name Comment number Result[1][8] reserved Result[1][9] reserved reserved Result[1][10] reserved Result[1][11] reserved Result[1][12] UnderRes[1] under-range value in the 1 profile results flags: ResultsFlags[1] b1 - if set to 1: overload occurred [08, mm=sub-block’s length] 0xmm08 20..21...
Page 190 SVAN 977A User Manual - Appendixes Table B.1.25 Statistical levels (saved in Summary Results Record) Word Name Comment number [17, nn=block’s length] 0xnn17 [pp=used_profile, rr=profile’s mask] 0xpprr N_stat_level number of statistical levels = N number of the Lnn statistics; 3+i*(pp+1) nn[i] i=0..N-1...
Page 191 SVAN 977A User Manual - Appendixes ....0x020B [0B, prof_mask#2] SubblockLength 2 * number of classes in the second profile + 2 2..3 Histogram[2][1] the first counter in the second profile Histogram[2][2] 4..5 the second counter in the second profile ..
Page 192 SVAN 977A User Manual - Appendixes RPM Min[0] RpmMin[0] RPM Min[1] RpmMin [1] … … … Table B.1.31 METEO data (saved in Summary Results Record) Word number Name Comment [2A = id, 00 = block’s length in the second word]...
Page 193 SVAN 977A User Manual - Appendixes Table B.1.32 RT60 results Word Name Comment number [1B = id, 00 = block’s length in the second word] 0x001B BlockLength 7 + ((N2_rt60_freq-N1_rt60_freq+1)+N_max_total)*9) LowestFreq the lowest 1/3 OCTAVE frequency (*100 Hz) = 80...
Page 194: Structure Of The File Containing Results From Logger's File
SVAN 977A User Manual - Appendixes Word Name Comment number i=N1_rt60_freq÷N2_rt60_freq; 13+i cor_rt_20[i] i=N_tercje÷N_tercje+N_max_total-1 i=N1_rt60_freq÷N2_rt60_freq; 14+i cor_rt_30[i] i=N_tercje÷N_tercje+N_max_total-1 i=N1_rt60_freq÷N2_rt60_freq; 15+i cor_rt_user[i] i=N_tercje÷N_tercje+N_max_total-1 … … … Table B.1.34 SETUP file Word Name Comment number [20, 00=block’s length in the second word]...
Page 195: The Contents Of The Logger File
SVAN 977A User Manual - Appendixes RT60 results block (cf. Table B.1.32); RT60 averaged results block (cf. Table B.1.33). B.2.1. The contents of the logger file The records with the results and the records with the state of the markers as well as the records with the breaks in the results registration are saved in the files in the logger.
Page 196: Record With The State Of The Markers
SVAN 977A User Manual - Appendixes SLM mode: <result1> - Peak result, depending on the value of BufferP[3] (cf. Table B.1.12) <result2> - Max result, depending on the value of BufferP[3] (cf. Table B.1.12) <result3> - Min result, depending on the value of BufferP[3] (cf. Table B.1.12) <result4>...
Page 197: Record With The Breaks In The Results Registration
SVAN 977A User Manual - Appendixes b10 = state of #11 marker b1 = state of #2 marker b0 = state of #1 marker B.2.1.3. Record with the breaks in the results registration The record with the breaks in the results registration consists of four words: <0xB0ii>...
Page 198: Record With Meteo Data
SVAN 977A User Manual - Appendixes - The results of the statistical analysis in profiles (optional, cf. Table B.1.28) - The results of the statistical analysis performed in 1/x OCTAVE mode (optional, cf. Table B.1.29) - The RPM results (optional, cf. Table B.1.30) length of the block (field is optional and occurs only when b7..b0 in HS and HE headers are set to zero)
Page 199: Structure Of The Setup File
SVAN 977A User Manual - Appendixes starting header (1 word) The full name of the comment file (e.g. “REC62.WAV”). ending header (1 word), which differs from the HS only on b11 bit (thanks to it, it is possible to analyse the recorded file starting from its end)
Page 200: Appendix C. Technical Specifications
C.1.1 Specification of SVAN 977A as SLM in the standard configuration SVAN 977A working as the SLM with all listed below accessories meets requirements of the IEC 61672:2013 for the Class 1 instruments. The configuration of the complete SLM and its normal mode of operation SVAN 977A sound &...
Page 201 SVAN 977A User Manual - Appendixes Note: For the conformance tests with B&K4226 multifrequency calibrator, the Microphone Compensation must be set to “On”! (path: <Menu> / Measurement / Compensation Filter). Note: For the conformance of acoustical tests, the Microphone Compensation must be set to “Free Field”...
Page 202 SA22 is mounted on the microphone (see C.1.2) SVAN 977A diffuse field compensation filter Note: Using special filters might change the frequency response and measuring ranges of SVAN 977A. Please check the below given specification.
Page 203 SVAN 977A User Manual - Appendixes Linear operating ranges for LEQ measurements with Diffuse Filter Linear operating range for the “Diffuse” filter: “LOW” for the sinusoidal signal and microphone Table C.1.4. sensitivity 35 mV/Pa AS/F BS/F CS/F ZS/F AeqT BeqT...
Page 204 SVAN 977A User Manual - Appendixes Time weighting characteristics (Exponential averaging) “S“ according to IEC 61672 Class 1, Equivalent Time Constant 1000 ms Slow “F” according to IEC 61672 Class 1, Equivalent Time Constant 125 ms Fast “I” according to IEC 60804 Class 1, Equivalent Time Constant 35 ms, Hold Time 1500 s...
Page 205 SVAN 977A User Manual - Appendixes Typical Free Field frequency response of the microphone Table C.1.8. ACO 7052E free field response (0 deg incidence angle) - measured Frequency [Hz] Correction 31,5 factors 0.01 0.01 0.01 0.01 0.01 Frequency [Hz] [dB]...
Page 206 SVAN 977A User Manual - Appendixes Maximum peak voltage 30 V Peak-Peak (Maximum peak voltage of input sinusoidal signal, which can be lead to the SLM without destruction the meter) Warm-up time 1 min. (for 0.1 dB accuracy) Nominal delay less than 3 seconds (between operating of the "Reset- Button"...
Page 207 SVAN 977A User Manual - Appendixes Test conditions: SVAN 977A with microphone and preamplifier is mounted on the shaker. Ref 1. Vibration is applied in a direction perpendicular to the plane of the microphone diaphragm. Ref 2. Vibration is applied in a direction parallel to the plane of the microphone diaphragm.
Page 208 0,40 0,20 0,00 -0,20 -0,40 -0,60 -0,80 (dB) -1,00 100,00 1000,00 10000,00 100000,00 Frequency (Hz) Table C.1.11. SVAN 977A typical free field frequency response Frequency SVAN 977A Frequency SVAN 977A Frequency SVAN 977A [Hz} frequency [Hz} frequency [Hz} frequency response...
Page 209 19386,53 -0,36 1059,25 -0,01 4597,27 0,12 19952,62 -0,28 Case effect Effect of reflections and diffraction of the acoustic plane wave from the case of SVAN 977A (“case effect”). SVAN 977 case effect 1,00 0,50 (dB) 0,00 -0,50 100,00 1000,00 10000,00...
Page 210 SVAN 977A User Manual - Appendixes Table C.1.12. SVAN 977A “Case effect” Frequency Case effect Frequency Case effect Frequency Case effect [Hz} [Hz} [Hz} [dB] [dB] [dB] 251,19 0,00 1090,18 0,07 4731,51 0,15 258,52 0,00 1122,02 0,08 4869,68 -0,12 266,07...
Page 211 SVAN 977A User Manual - Appendixes Directional characteristics of SVAN 977A Directional response for SLM Class SVAN 977A with microphone ACO 7052E and preamplifier SV 12L for specified frequencies: The round charts show the directional characteristic and the charts below shows the errors for angles.
Page 212 SVAN 977A User Manual - Appendixes...
Page 213 SVAN 977A User Manual - Appendixes...
Page 214 SVAN 977A User Manual - Appendixes...
Page 215 SVAN 977A User Manual - Appendixes...
Page 216 SVAN 977A User Manual - Appendixes Table C.1.13. Directional response for SVAN 977A with microphone ACO 7052E Angle [ f [Hz] 0-10 10-20 20-30 30-40 40-50 50-60 60-70 70-80 80-90 90-100 0,01 0,01 0,01 -0,01 -0,01 -0,01 0,01 -0,02 -0,04...
Page 217 SVAN 977A User Manual - Appendixes 3150 -0,08 -0,22 -0,3 -0,3 -0,26 -0,33 -0,53 -0,66 -0,9 3550 0,03 0,03 -0,22 -0,56 -0,61 -0,54 -0,7 4000 -0,06 -0,25 -0,37 -0,37 -0,4 -0,9 -0,91 -1,08 -1,51 4500 -0,03 -0,04 0,08 -0,39 -0,58...
Page 218 SVAN 977A User Manual - Appendixes 1000 -0,09 -0,13 -0,17 -0,19 -0,19 -0,17 -0,13 -0,07 -0,03 -0,03 1250 -0,2 -0,27 -0,33 -0,34 -0,33 -0,27 -0,16 -0,07 -0,12 -0,15 1600 -0,19 -0,3 -0,35 -0,36 -0,35 -0,28 -0,18 -0,11 -0,13 -0,12 2000...
Page 219: Effect Of The Sa 22 Windscreen
-1,00 -1,20 [Hz] SA22 free fiield response Windscreen compensation filter Compensated Windscree Effect Windscreen SA22 free field response and compensated effect Table C.1.14. SVAN 977A effect of the SA 22 windscreen SA 22 SA 22 Frequency SA 22 Compen- Frequency...
Page 220 -0,43 0,07 19386,53 -1,00 -0,80 2175,20 0,50 -0,43 0,07 19952,62 -1,06 0,18 -0,88 2238,72 0,50 -0,43 0,07 Note: When using windscreen SA22 the “Windscreen” compensation filter must be “On” to ensure good tolerances margin of the SVAN 977A frequency response.
Page 221: Effect Of The Sa 277 Outdoor Protection Unit
& vibration analyser SV 80 10mV/m/s2, IEPE accelerometer (see C.6 for details) SC 27 coiled cable for accelerometer 2 m Accessories included in SVAN 977A instrument set SC 16 USB 1.1 cable Accessories available SV 55 RS 232 interface for SVAN 95x instrument series...
Page 222 SVAN 977A User Manual - Appendixes Table C.2.1 Linear operating ranges with the Wh filter Linear operating ranges (RMS) Range (RMS) With the SV80 (10 mV/ms ) accelerometer sensitivity @ 79.58 Hz Measured at the reference environmental conditions from 3.16 mms...
Page 223 SVAN 977A User Manual - Appendixes Table C.2.5 Linear operating ranges with the Vel10 filter Linear operating ranges (RMS) Range (RMS) With the SV80 (10 mV/ms ) accelerometer sensitivity @ 79.58 Hz Measured at the reference environmental conditions from 1 mms to 1.59 ms...
Page 224 (137 dB related to 1 µV Range HIGH Maximum input voltage SVAN 977A is the instrument with the II security class according to the international standard IEC 348. The input voltage should be within the 30 V Peak – Peak RMS detector (Linear averaging) •...
Page 225 SVAN 977A User Manual - Appendixes Antialiasing filter Built-in antialiasing filter (eighth-order elliptic type) ensuring correct sampling of the measured signal. Pass band(-1 dB) 22.200 kHz or 44.4 kHz Pass band(-3 dB) 23.520 kHz or 47.0 kHz Stop band 26.256 kHz or 52.53 kHz Attenuation in the stop band >...
Page 226 SVAN 977A User Manual - Appendixes Environmental, electrostatic and radio frequency criteria Note: In the measurement conditions with the strong electromagnetic disturbances (e.g. near the high-voltage transmission lines) the lower measurement limit can be drastically shifted as the result of the external field influence on the measurement cables. In such cases, the careful shielding of the measurement cables is strongly recommended.
Page 227: Specification Of Svan 977A As 1/1 Octave And 1/3 Octave Analyser
1/3 OCTAVE PECIFICATION OF ANALYSER SVAN 977A can operate as 1/1-octave or 1/3-octave analyser conforming to the international IEC 61260- 1:2014 standard for the pass band filters. Note: Simultaneously to the frequency analysis SVAN 977A operates as Sound Level Meter! See Chapters C.1 for specification.
Page 228 SVAN 977A User Manual - Appendixes Note: For the signals with the crest factor n >1.41 upper measuring range of the RMS is reduced. The valid upper limit can be calculated according to the below given formula: − , where A is the upper limit for the sinusoidal signal...
Page 229 SVAN 977A User Manual - Appendixes Effect of magnetic field < 15 dB (A) or < 25 dB (Z) (for 80 A/m and 50 Hz) Effect of Vibration < 0.1 dB (from 20 Hz to 1000 Hz at 1 m/s Antialiasing filter Built-in antialiasing filter.
Page 230 SVAN 977A User Manual - Appendixes 1/1 Octave filters 16 filters with centre frequencies from 1 Hz to 31.5 kHz (base 10), meeting IEC 61260-1:2014 standard for Class 1 31.5 kHz 1/1 octave filter 16.0 kHz 1/1 octave filter (Ultra band)
Page 231 SVAN 977A User Manual - Appendixes 8.0 kHz 1/1 octave filter 4.0 kHz 1/1 octave filter 2.0 kHz 1/1 octave filter...
Page 232 SVAN 977A User Manual - Appendixes 1.0 kHz 1/1 octave filter 500 Hz 1/1 octave filter 250 Hz 1/1 octave filter...
Page 233 SVAN 977A User Manual - Appendixes 125 Hz 1/1 octave filter 63.0 Hz 1/1 octave filter 31.5 Hz 1/1 octave filter...
Page 234 SVAN 977A User Manual - Appendixes 16.0 Hz 1/1 octave filter 8.00 Hz 1/1 octave filter 4.00 Hz 1/1 octave filter...
Page 235 SVAN 977A User Manual - Appendixes 2.00 Hz 1/1 octave filter 1.00 Hz 1/1 octave filter Summary curve of the Ultra Band...
Page 236 SVAN 977A User Manual - Appendixes Summary curve of the Audio/Full Band 1/3 Octave filters 48 filters with centre frequencies from 0.8 Hz to 40 kHz (base 10), meeting IEC 61260-1:2014 standard for Class 1 1/3 octave filters for 31.5 kHz 1/1 octave filter...
Page 237 SVAN 977A User Manual - Appendixes 1/3 octave filters for 16.0 kHz 1/1 octave filter (Audio/Full band) 1/3 octave filters for 8.0 kHz 1/1 octave filter 1/3 octave filters for 4.0 kHz 1/1 octave filter...
Page 238 SVAN 977A User Manual - Appendixes 1/3 octave filters for 2.0 kHz 1/1 octave filter 1/3 octave filters for 1.00 kHz 1/1 octave filter 1/3 octave filters for 500 Hz 1/1 octave filter...
Page 239 SVAN 977A User Manual - Appendixes 1/3 octave filters for 250 Hz 1/1 octave filter 1/3 octave filters for 125 Hz 1/1 octave filter 1/3 octave filters for 63.0 Hz 1/1 octave filter...
Page 240 SVAN 977A User Manual - Appendixes 1/3 octave filters for 31.5 Hz 1/1 octave filter 1/3 octave filters for 16.0 Hz 1/1 octave filter 1/3 octave filters for 8.00 Hz 1/1 octave filter...
Page 241 SVAN 977A User Manual - Appendixes 1/3 octave filters for 4.00 Hz 1/1 octave filter 1/3 octave filters for 2.00 Hz 1/1 octave filter 1/3 octave filters for 1.00 Hz 1/1 octave filter...
Page 242 SVAN 977A User Manual - Appendixes Summary curve of the Ultra Band Summary curve of the Audio/Full Band...
Page 243: Frequency Characteristics Of The Implemented Broadband Digital Filters
SVAN 977A User Manual - Appendixes C.4. F REQUENCY CHARACTERISTICS OF THE IMPLEMENTED BROADBAND DIGITAL FILTERS “A” filter Class 1 according to IEC 651 and IEC 61672-1:2013 “A” filter characteristics “C” filter Class 1 according to IEC 651 and IEC 61672-1:2013 “C”...
Page 244 SVAN 977A User Manual - Appendixes “B” filter Class 1 according to IEC 651 “B” filter characteristics “U” filter Class 1 according to IEC 61012:1990 “U” filter characteristics “AU” filter Class 1 according to IEC 61012:1990 “AU” filter characteristics...
Page 245 SVAN 977A User Manual - Appendixes “LF” filter according to EPA-93-F105-02-104 Low Frequency Noise Control Regulations “LF” filter characteristic “HP1” filter is used for the acceleration measurements (the vibration signal) in the frequency range from 1 Hz to 20 kHz.
Page 246 SVAN 977A User Manual - Appendixes “HP10” filter is used for the acceleration measurements (the vibration signal) in the frequency range from 10 Hz to 20 kHz “HP10” filter characteristics “Vel1” filter is used for the velocity measurements (the vibration signal) in the frequency range from 1 Hz to 20 kHz “Vel1”...
Page 247 SVAN 977A User Manual - Appendixes “Vel10” filter is used for the velocity measurements in the frequency range from 1 Hz to 20 kHz “Vel10” filter characteristics “VelMF” filter is used for the evaluation of the state of the machines. This filter is used for the measurements in the frequency range from 10 Hz to 1000 Hz and conforms ISO 10816 “VelMF”...
Page 248 SVAN 977A User Manual - Appendixes “Dil3” filter is used for the displacement measurements in the frequency range [1 Hz to 20 kHz] “Dil3” filter characteristics “Dil10” filter is used for the displacement measurements in the frequency range [1 Hz to 20 kHz] “Dil10”...
Page 249 SVAN 977A User Manual - Appendixes “HP” filter is a High-Pass filter “HP” filter characteristics “HPE” filter is a High-Pass filter for the Ultra frequency band “HPE” filter characteristics...
Page 250: Miscellaneous Specification Of Svan 977A
Typical Micro SD or Micro SDHC cards can be used. Supported for up to 128 GB (provided that card was formatted as FAT32). Note: The originally supplied Kingston Industrial memory card has been tested by SVANTEK and cards of this type are strongly recommended for use when the original card is going to be replaced.
Page 251 Power consumption from the 6V source is approx. 130 mA (at + 20C) So, typical operating time from 4 x AA alkaline batteries will be about 12 hours. SVAN 977A can be also powered from the AA Type rechargeable batteries. ...
Page 252 RS 232 interface (optional) The RS 232 interface option for SVAN 977A is provided by means of the SV 55 interface. It conforms to the EIA Standard RS 232C. It enables the user to program remotely all instrument functions and the transmissions to and from the meter with the speed from 1200 bit/s to 115200 bit/s.
Page 253 SVAN 977A User Manual - Appendixes I/O – User programmable Analogue Outputs, Digital Input / Output connector 3.5 mm Mini Stereo Jack type (cable plug and instrument socket are shown) Table C.5.7. Pin out of the 3.5 mm Mini Stereo Jack...
Page 254 >30m line-of-sight and depending on local RF conditions. ® “The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SVANTEK is under license. Other trademarks and trade names are those of their respective owners.
Page 255 SVAN 977A User Manual - Appendixes FCC and IC ® This product contains an FCC and Industry Canada certified Bluetooth Low energy wireless transmission module: • FCC ID: QOQWT12 • Industry Canada ID: 5123A-BGTWT12A • Producer: Silicon Laboratories • Model: WT12 Bluetooth Module...
Page 256: Specification Of Sv 80 Accelerometer
SVAN 977A User Manual - Appendixes C.6. S SV 80 PECIFICATION OF ACCELEROMETER Performance Number of axis ...................1 Sensitivity (± 5 %) ................10 mV/(ms ) ~ 100 mV/g RMS ÷ 500 ms Measurement range ................0.01 ms Peak Frequency response (by design guideline, ± 3 dB) ......0.5 Hz ÷ 14 000 Hz Linearity ....................±...
Page 257: Using Of The Sa 277 Outdoor Microphone Protection Unit
The wave incidence angle is oriented to the microphone membrane surface. 0 deg means direction orthogonal to the membrane surface. 90 deg means direction parallel to the membrane surface. Frequency response of SVAN 977A with SA 277 outdoor protection unit is compensated by means of two digital filters: •...
Page 258 SVAN 977A User Manual - Appendixes Linear Operating Ranges with the Environmental filter Table C.7.1 Self-generated noise for different weighting filters Electrical *) Acoustical compensated Weighting filter Range < 15 dB < 15 dB < 20 dB < 16 dB <...
Page 259 SVAN 977A User Manual - Appendixes Microphone response for 90 deg incidence angle Table C.7.4 ACO 7052E free field correction (90 deg incidence angle) ACO 7052E ACO 7052E ACO 7052E Actuator to Free Field Typical electrostatic Free Field response f [Hz]...
Page 260 SVAN 977A User Manual - Appendixes ACO 7052E ACO 7052E ACO 7052E Actuator to Free Field Typical electrostatic Free Field response f [Hz] correction for 90 deg actuator response for 90 deg incidence incidence angle angle 473.15 0.05 0.00 0.06 486.97...
Page 261 SVAN 977A User Manual - Appendixes ACO 7052E ACO 7052E ACO 7052E Actuator to Free Field Typical electrostatic Free Field response f [Hz] correction for 90 deg actuator response for 90 deg incidence incidence angle angle 1830.21 0.00 -0.29 -0.29 1883.65...
Page 262 SVAN 977A User Manual - Appendixes ACO 7052E ACO 7052E ACO 7052E Actuator to Free Field Typical electrostatic Free Field response f [Hz] correction for 90 deg actuator response for 90 deg incidence incidence angle angle 7079.46 0.15 -2.66 -2.51 7286.18...
Page 263 SVAN 977A User Manual - Appendixes Free Field Frequency response of SVAN 977A with SA 277 (90 deg incidence angle) Table C.7.6 SVAN 977A with SA 277 frequency response for 90 deg incidence angle f [Hz] Typical non-compensated Compensation Typical compensated frequency...
Page 264 SVAN 977A User Manual - Appendixes f [Hz] Typical non-compensated Compensation Typical compensated frequency frequency response of filter response of SVAN 977W with SVAN 977A with SA 277 for SA 277 for 90 deg incidence “Environmental” 90 deg incidence angle angle (Environmental) 0.03...
Page 265 SVAN 977A User Manual - Appendixes f [Hz] Typical non-compensated Compensation Typical compensated frequency frequency response of filter response of SVAN 977W with SVAN 977A with SA 277 for SA 277 for 90 deg incidence “Environmental” 90 deg incidence angle angle (Environmental) 0.33...
Page 266 SVAN 977A User Manual - Appendixes f [Hz] Typical non-compensated Compensation Typical compensated frequency frequency response of filter response of SVAN 977W with SVAN 977A with SA 277 for SA 277 for 90 deg incidence “Environmental” 90 deg incidence angle angle (Environmental) -1.98...
Page 267 SVAN 977A User Manual - Appendixes Case effect of SA 277 (90 deg incidence angle) Table C.7.5 ACO 7052E frequency response and SA 277 case effect (90 deg incidence angle) Case effect of Compensation filter Compensated case SA 277 for 90 deg effect for 90 deg “Environmental”...
Page 268 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case SA 277 for 90 deg effect for 90 deg “Environmental” f [Hz] incidence angle incidence angle (Environmental) 421.70 0.06 -0.09 -0.03 434.01 0.08 -0.09 -0.01 446.68 0.07 -0.10...
Page 269 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case SA 277 for 90 deg effect for 90 deg “Environmental” f [Hz] incidence angle incidence angle (Environmental) 1631.17 0.31 -0.36 -0.05 1678.80 0.30 -0.34 -0.04 1727.83 0.29 -0.31...
Page 270 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case SA 277 for 90 deg effect for 90 deg “Environmental” f [Hz] incidence angle incidence angle (Environmental) 6309.57 0.15 2.15 2.30 6493.82 0.30 2.16 2.46 6683.44 0.46 2.15...
Page 271 SVAN 977A User Manual - Appendixes Linear Operating Ranges with the Airport filter Table C.7.7 Self-generated noise for different weighting filters Electrical *) Acoustical compensated Weighting filter Range < 15 dB < 14 dB < 20 dB < 16 dB <...
Page 272 SVAN 977A User Manual - Appendixes Free Field Frequency response of SVAN 977A with SA 277 (0 deg incidence angle) Table C.7.11 SVAN 977A with SA 277 frequency response (0 deg incidence angle) Typical non-compensated Typical compensated Compensation frequency response of...
Page 273 SVAN 977A User Manual - Appendixes Typical non-compensated Typical compensated Compensation frequency response of frequency response of f [Hz] filter SVAN 977A with SA 277 for SVAN 977A with SA 277 for “Airport” 0 deg incidence angle 0 deg incidence angle (Airport) 459.73...
Page 274 SVAN 977A User Manual - Appendixes Typical non-compensated Typical compensated Compensation frequency response of frequency response of f [Hz] filter SVAN 977A with SA 277 for SVAN 977A with SA 277 for “Airport” 0 deg incidence angle 0 deg incidence angle (Airport) 1778.28...
Page 275 SVAN 977A User Manual - Appendixes Typical non-compensated Typical compensated Compensation frequency response of frequency response of f [Hz] filter SVAN 977A with SA 277 for SVAN 977A with SA 277 for “Airport” 0 deg incidence angle 0 deg incidence angle (Airport) 6878.60...
Page 276 SVAN 977A User Manual - Appendixes Case effect of SA 277 (0 deg incidence angle) Table C.7.10 SA 277 case effect (0 deg incidence angle) Case effect of Compensation filter Compensated case effect of f [Hz] SA 277 for 0 deg SA 277 for 0 deg incidence “Airport”...
Page 277 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case effect of f [Hz] SA 277 for 0 deg SA 277 for 0 deg incidence “Airport” incidence angle angle (Airport) 446.68 -0.05 -0.06 -0.11 459.73 -0.04 -0.06 -0.10...
Page 278 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case effect of f [Hz] SA 277 for 0 deg SA 277 for 0 deg incidence “Airport” incidence angle angle (Airport) 1678.80 0.41 -0.50 -0.09 1727.83 0.40 -0.51 -0.11...
Page 279 SVAN 977A User Manual - Appendixes Case effect of Compensation filter Compensated case effect of f [Hz] SA 277 for 0 deg SA 277 for 0 deg incidence “Airport” incidence angle angle (Airport) 6309.57 -1.18 1.32 0.14 6493.82 -1.03 1.22 0.19...
Page 280 SVAN 977A User Manual - Appendixes Free Field Directional characteristics of SVAN 977A with SA 277 Directional response for SLM Class SVAN 977A with microphone ACO 7052E, preamplifier SV 12L and outdoor microphone kit SA 277 for specified frequencies: Total directional characteristics The round charts show the directional characteristic and the charts below shows the errors for particular angles.
Page 281 SVAN 977A User Manual - Appendixes...
Page 282 SVAN 977A User Manual - Appendixes...
Page 283 SVAN 977A User Manual - Appendixes...
Page 284 SVAN 977A User Manual - Appendixes...
Page 285 SVAN 977A User Manual - Appendixes Table C.7.12 Directional response for SVAN 977A with microphone ACO 7052E, preamplifier SV 12L and outdoor protection unit SA 277 f [Hz] 0-10 10-20 20-30 30-40 40-50 50-60 60-70 70-80 80-90 90-100 0,03 0,06...
Page 286 SVAN 977A User Manual - Appendixes 3150 0,03 -0,13 -0,35 -0,77 -1,14 -1,4 -1,61 -1,83 -1,82 -1,85 3550 -0,13 -0,39 -0,89 -1,38 -1,62 -1,94 -2,07 -2,29 -2,29 -1,98 4000 -0,14 -0,49 -1,1 -1,42 -1,67 -1,76 -1,79 -1,92 -1,78 -1,67 4500...
Page 287 SVAN 977A User Manual - Appendixes 1000 0,26 0,15 0,05 -0,01 -0,08 -0,16 -0,21 -0,21 -0,19 1250 -0,08 -0,22 -0,23 -0,22 -0,2 -0,28 -0,3 -0,3 -0,27 -0,27 1600 -0,22 -0,22 -0,18 -0,15 -0,2 -0,17 -0,05 -0,22 -0,28 -0,27 2000 -0,85...
Page 288: Declaration Of Conformity
SVAN 977A User Manual - Appendixes C.8. D ECLARATION OF ONFORMITY...
Page 289 SVAN 977A User Manual - Appendixes...
Page 290: Appendix D. Definitions And Formulae Of Measured Values
SVAN 977A User Manual - Appendixes APPENDIX D. DEFINITIONS AND FORMULAE OF MEASURED VALUES D.1. S OUND EVEL ETER D.1.1 Basic terms and definitions (SLM mode) current time period of the measurement in seconds. the last second of the measurement.
Page 291: Definitions And Formulas Of Slm Results
SVAN 977A User Manual - Appendixes D.1.2 Definitions and formulas of SLM results The instrument calculates the sound measurement results for three profiles. The calculation flow diagram for one profile is presented below: max, min, Spl, tm3, τ = Slow p(t) wτ...
Page 292 SVAN 977A User Manual - Appendixes   m-minutes running Leq is the rolling (sliding)    Leq screen for the last m minutes of      − measurement (m x 60 seconds) moving with 1 second step Note: if the current time period of the measurement is less then m minutes then LRm result is undefined.
Page 293 SVAN 977A User Manual - Appendixes ≠ 0, T   Le is calculated for: T = 0, T = 0.        ≠ 0.   Ln is calculated for: T = 0, T = 0, T ...
Page 294: Vibration Level Meter
SVAN 977A User Manual - Appendixes D.2. V IBRATION EVEL ETER D.2.1 Basic terms and definitions (VLM mode) current time period of the measurement in seconds.  exponential time constant in seconds for the giving time-weighting. The following time constants are available: 100 ms, 125 ms, 200 ms, 500 ms, 1.0 s, 2.0 s, 5.0 s, 10.0 s.
Page 295: Statistical Levels - Lnn Definition
SVAN 977A User Manual - Appendixes Percentage of the overloaded input signal, which occurred during the current time period of the measurement (T) Peak Maximum absolute value of the signal Peak calculated for the given T − − P–P Peak-to-peak (P-P) result is the difference...
Page 296 SVAN 977A User Manual - Appendixes Example: Let us assume that L35 is equal to 76.8 dB. It means that during the measurements the noise level 76.8 dB was exceeded in not more than 35% of the observation period. The cumulative density function for the exemplary data is presented in Figure on the right side.
Page 297: Appendix E. Reverberation Time Calculations
SVAN 977A User Manual - Appendixes APPENDIX E. REVERBERATION TIME CALCULATIONS E.1. I NTRODUCTION If an impulsive sound is generated in a room with reflecting boundaries, repeated reflections at the boundaries result in the rapid establishment of a more or less uniform sound field. This field then decays as the sound energy is absorbed by the bounding materials.
Page 298: Definitions And Calculation Of The Rt 60 Reverberation Time
SVAN 977A User Manual - Appendixes reverberation time (RT 60) is obtained using the slope coefficient of the decay curve. The type of the definition from which slope coefficient is calculated (EDT, RT 20, RT 30 or user defined) depends on the...
Page 299 SVAN 977A User Manual - Appendixes It is recommended by the ISO-3382 standard to set 10 dB value for noise margin. In case of the impulse method, the sound pressure level values between points t and t are approximated with the straight line (y = a · x + b) by the linear regression. The RT 20 value is calculated using the slope coefficient ‘a’...
Page 300: Description Of The Decay Curve Recording In Different Measurement Methods
SVAN 977A User Manual - Appendixes linear approximation 5 dB [dB] 30 dB noise margin t [s] Fig 4. The RT 30 evaluation E.3. D ESCRIPTION OF THE DECAY CURVE RECORDING IN DIFFERENT MEASUREMENT METHODS ➢ DECAY method This RT 60 measurement method requires omnidirectional sound source which emits pink noise in appropriate frequency band.
Page 301 SVAN 977A User Manual - Appendixes • The time between markers t and t in which the omnidirectional sound source emits acoustic power and the SVAN xxx analyser measures the actual sound pressure level. • The time between markers t...
Page 302 SVAN 977A User Manual - Appendixes [dB] 10 dB t [s] trig registration time Fig 7. Data recording in the impulse method of the reverberation time evaluation The measurement time in this method consists of: • The time before marker t...

Svantek SVAN 977A User Manual

Index

1 Introduction

2 Manual Control of the Instrument

3 General Information

4 FUNCTIONS of the INSTRUMENT - Function

5 CONFIGURING MEASUREMENT PARAMETERS - Measurement

6 CONFIGURING DATA VIEWING - Display

7 MANAGING FILES - File

8 CONFIGURING INSTRUMENT PARAMETERS - Instrument

9 AUXILIARY SETTINGS - Auxiliary Setup

10 1/1-Octave and 1/3-Octave Analyser

11 Fft Analyser

12 Reverberation Time Measurements - Rt60

13 Remote Control Tools

14 Maintenance

15 Glossary

Appendix A. Remote Control

APPENDIX B. DATA FILE STRUCTURES (Firmware Revision 1.21)

Appendix C. Technical Specifications

Appendix D. Definitions and Formulae of Measured Values

Appendix E. Reverberation Time Calculations

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Svantek SVAN 977A

Summary of Contents for Svantek SVAN 977A

Table of Contents
