Svantek SV 200 User Manual

Noise monitoring station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
USER MANUAL
SV 200
NOISE MONITORING STATION
Copyright © 2017 SVANTEK. All rights reserved.
Warsaw, July 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Svantek SV 200

Summary of Contents for Svantek SV 200

  • Page 1 USER MANUAL SV 200 NOISE MONITORING STATION Copyright © 2017 SVANTEK. All rights reserved. Warsaw, July 2017...

  • Page 2: Table Of Contents

    SV 200 USER MANUAL CONTENTS Introduction ..........................6 Sound Level Meter & Analyser features ................6 General features of SV 200 ....................7 Accessories included ......................7 Optional accessories available .....................7 Assembling the instrument.......................8 Recommended order of assembly..................8 Delivered kit.........................8 Pre-assembling of the SV 200.................... 12 Pre-assembling of the meteorological beam (optional) ............
  • Page 3 SV 200 USER MANUAL Remote control principles ....................50 5.1.1 H24 Telit 3G Modem ...................... 50 5.1.2 Web server ........................52 5.1.3 SMS / E-mail alarming ....................53 5.1.4 SMS command exchange ....................53 5.1.5 Lantronix WiPort Modem ....................54 Instrument settings .........................
  • Page 4 SV 200 USER MANUAL 6.13 Calibration & System Check ....................71 6.13.1 Automatic calibration ....................71 6.13.2 Automatic system check ..................... 71 6.13.3 Logging ........................72 6.14 FTP data transfer ....................... 72 WEB interface .......................... 73 Live data page ........................73 7.1.1...
  • Page 5 SV 200 USER MANUAL 9.3.1 Control push-buttons on the front panel ................ 105 Swithing the control unit on and starting measurement ............. 107 Description of icons ......................107 Setting SV200 ......................... 108 9.6.1 Basis of SV200 control ....................108 9.6.2 Setting the SV200 function ...................

  • Page 6: Introduction

    SV 200 USER MANUAL INTRODUCTION The SV 200 is a unique Noise Monitoring Terminal (NMT) which includes in single portable housing: outdoor microphone, sound level meter and 1/1 & 1/3 octave analyzer, advanced logger integrating controller and communication systems. Using the most recent and State of the Art technological achievements, the design of high integration outdoor system became available.

  • Page 7: General Features Of Sv 200

    SV 200 USER MANUAL 1.2 General features of SV 200 • Noise monitoring terminal fitted in one portable instrument dedicated for unattended permanent and short period noise monitoring • Noise measurements meeting IEC 61672-1, type 1 standard • 1/1 & 1/3 octave real-time analysis •...

  • Page 8: Assembling The Instrument

    2. pre-assembling of the meteorological beam (see 2.4), 3. power supply installation (see 2.5), 4. assembling of the meteorological beam on the mast (see 2.6), 5. assembling of and start-up of the SV 200 device (see 2.7), 6. arrangement of the cabling (see 2.8). 2.2 Delivered kit The kit delivered to the client consists of the following elements: 1.
  • Page 9 • set of 4 dowels Φ 10 mm (with screws) for mounting the power unit into a wall • 2 band clips for mast mounting of the power supply 4. SC256 cable to communicate with SV 200 using USB interface...
  • Page 10 SV 200 USER MANUAL 5. Standard mounting kit consisting of: • mounting sleeve • base of the sleeve • two bolts M6x12 with washers • ” adapter M14/ wireless antenna mounting sleeve two bolts M6x12 washers ” adapter M14/ base of the sleeve...
  • Page 11 6. set of the elements of the meteorological beam (option), consisting of: • SV205B hygro-baro-thermometer module (optionally with rain detector mounted on it) • dedicated SC258 cable to connect the SV205B module to the SV 200 • ultrasonic wind-meter adapted to be connected to the SV205B device •...

  • Page 12: Pre-Assembling Of The Sv 200

    Install the microphone and the foam windscreen in the following order: 1. Check, if the SV 200 is switched off – LED indicators on the bottom panel of the instrument are not lighting. If the device is on, turn it off (see Chapter 3.1) 2.
  • Page 13 Notice: It is advised to calibrate the SV 200 at this point. For more information see Chapter 3.7. 5. Hold the outer cone with one hand, use the other hand to screw on the sleeve rotating it clockwise.
  • Page 14 SV 200 USER MANUAL 6. Align moving ring with the slot of the microphone protective sleeve so that the cable is not bent in any direction. Gently place the actuator located at the end of the cable in the dedicated socket.
  • Page 15 SV 200 USER MANUAL 8. Slide the foam windscreen onto the extension sleeve and push the foam until you see the lateral hole. push the foam windscreen until you see the lateral hole 9. Insert the 3 mm Allen key into the hole.
  • Page 16 SV 200 USER MANUAL 10. Holding the Allen key and the extension sleeve in one hand to keep them still, use the other hand to screw on the top cone with the anti-bird spikes, rotating it clockwise. Notice: It is important to keep the extension sleeve still, to protect actuator cable from damage.

  • Page 17: Pre-Assembling Of The Meteorological Beam (Optional)

    SV 200 USER MANUAL cover the hole cover the sleeve 13. Put the device horizontally to gain an easy access to the control panel. 14. Screw the wireless antenna. In version 1 of the device, insert the SIM card into the SIM card socket (according to Chapter 3.2).
  • Page 18 SV 200 USER MANUAL 1. Unscrew two sets of knobs (each containing of a nut and a screw) from the flattened end of the beam. 2. Put the beam on a flat surface so that the mounting socket of the wind-meter on the other side of the beam faces up 3.

  • Page 19: Power Supply Installation

    The meteorological beam should be installed on the mast, at least 2 m above the ground. The distance from the beam to the SV 200 device should be as great as possible, but it is limited to the length of the SC258 cable.

  • Page 20: Mounting The Sv 200

    6. Alternatively, loosen meteo beam fastening clamp and rotate the beam until the triangle- shaped mark indicates north. Remember to tighten the knobs afterwards! 2.7 Mounting the SV 200 Coaxial mounting of the device on the mast Φ 45 mm ended with a bolt M14 is recommended.
  • Page 21 9. Plug the power supply cable connector in to the DC IN socket on the control panel. 10. Plug the SC258 cable connector in to the Ext. I/O socket on the panel of the SV 200. 11. Press the <Power> button on the control panel to switch the device on.
  • Page 22 SV 200 USER MANUAL 14. Put the mounting sleeve on the bottom of the cup so that the cable slot in the bottom of the cup covers the cable slot in the cup. screw on slide the sleeve slot for cables press the pin 15.

  • Page 23: Finishing

    2.9 Important information The SA209 foam protects microphone from wind and rain. Notice: If SV 200 is used continuously for a long period of time it is recommended to replace SA209 foam at least once a year. During continuous usage the SA209 foam is exposed to different weather conditions with possibility of causing mechanical damage to the foam’s structure.
  • Page 24 SV 200 USER MANUAL unscrew the top cone hold the Allen key firmly in one hand 4. Take the Allen key out from the extension sleeve. 5. Take the foam windscreen off the extension sleeve. take the foam windscreen off...
  • Page 25 SV 200 USER MANUAL 6. Hold the microphone protective sleeve and the outer cone with one hand, use the other hand to unscrew the extension sleeve, rotating it counter-clockwise. Notice: It is important to keep the microphone protective sleeve still, to protect actuator cable from damage.
  • Page 26 SV 200 USER MANUAL 8. Take the outer cone with one hand, use the other hand to unscrew the microphone protective sleeve rotating it counter-clockwise. unscrew the sleeve hold firmly with one hand 9. Put the calibrator on the microphone calibrator 10.

  • Page 27: Replacement Of The Foam Windscreen

    SV 200 USER MANUAL 2.11 Replacement of the foam windscreen 1. Take the windscreen off according to steps 1 to 5 of Chapter 2.9. 2. Install new windscreen according to steps 8 to 12 of Chapter 2.3.

  • Page 28: Manual Control Of The Instrument

    SV 200 USER MANUAL MANUAL CONTROL OF THE INSTRUMENT 3G modem version Antenna socket battery indicator status indicator external interface socket DC IN socket POWER button SIM card slot LAN/WiFi version Antenna socket battery indicator status indicator external interface socket...

  • Page 29: Led Indicators And Power Button

    It is used for switching the instrument on and off and also starting/stopping the measurement manually. When the SV 200 is turned off a short press of the <Power> button turns it on. During the start-up process the STAT indicator turns orange.
  • Page 30 Meaning of the BAT LED states is described in the below table. green solid Battery charged red solid Charging battery Battery pack damaged or disconnected. Contact local SVANTEK red flashing dealership When instrument connected to the power supply – battery deeply no light discharged.

  • Page 31: Sim Card Slot (3G Version Only)

    (i.e. temperature) are taken into account while charging to prevent any damage of the battery caused by charging in too high or too low temperature. Notice: The SV 200 is equipped with the mechanism which protects the internal Li-Ion batteries from damage caused by critical discharge. When the battery is running flat, the...

  • Page 32: External Communication Interface Socket

    Preparing for calibration 1. In order to access the microphone it is necessary to disassemble following parts of the SV 200 according to Chapter 2.10: •...
  • Page 33 SV 200 USER MANUAL Notice: It is also possible to use an electro-mechanical pistonphone, which generates the signal (ca 124 dB) or different type of acoustic calibrator dedicated for ½” microphones. In any case, before starting the calibration measurement, the user has to set the level of the signal generated by the given calibrator, which is stated in the calibration certificate of the unit.
  • Page 34 SV 200 USER MANUAL Using SvanPC++ with USB connection 1. Connect the SV 200 with PC using SC 256 cable and start SvanPC++. 2. When SV 200 instrument wizard appears on the screen, click Calibration. Calibration button 3. Set desired calibration parameters in the SV 200 Calibration window.

  • Page 35: Electrostatic Actuator

    (94 dB when using a calibrator that generates a level of 114 dB). 5. Confirm obtained calibration factor by clicking Yes button. 6. Assemble the SV 200 according to Chapter 2.3 of the manual. Using SV200CU User Control unit See Chapter 9.6.3.

  • Page 36: Basic Operations

    4.1 PC Software installation and activation To configure the SV 200 instrument for the first time the user needs to use PC running SVAN PC++ software. It allows you to easily control each function of the instrument and manage whole noise monitoring station systems consisting of more than one SV 200 device.

  • Page 37: Basic Configuration Of Wireless Connection

    In order to access SV 200 remotely to download measurement files, manage configuration, receive alarm emails etc. the instrument must be properly configured. SV 200 is equipped with either internal 3G modem or LAN/WiFi module. Before proceeding with configuration make sure, which version of the instrument is going to be configured.
  • Page 38 4. User is allowed to choose between two Registration modes: AS or DynDns. AS registration mode is provided by SVANTEK and requires no additional information. To use this mode contact your local SVANTEK distributor. DynDns mode requires the user to have active account on www.dyn.com.
  • Page 39 SV 200 USER MANUAL Notice: If the user wishes to use SV200’s web interface (Chapter 0), either DynDns registration mode should be chosen or SIM card with static IP address should be used for AS registration mode. 5. After entering all the required information SVAN PC++ will check connection settings. Wait until process is finished.
  • Page 40 SV 200 USER MANUAL LAN/WiFi version 1. After clicking the Add station button the Select system type… window will appear. Click Local Area Network button to continue configuration. 2. Choose suitable Connection mode. If the user plans to connect the instrument via wired connection Local Area Network connection mode should be chosen as well as the PC network interface that will be used for connection.
  • Page 41 SV 200 USER MANUAL 3. Depending on the connection mode the user needs to choose wireless network to connect to (in case WiFi – Infrastructure mode was chosen previously), choose network interface to reconfigure (in case WiFi – Ad hoc mode was chosen previously) or go straight to step 4.
  • Page 42 SV 200 USER MANUAL 6. After entering all the required information SVAN PC++ will check connection settings. Ensure that the PC is connected to the same network as the instrument for the connection test to succeed. Wait until process is finished. It may take a few minutes.

  • Page 43: Starting Measurement

    SV 200 USER MANUAL 4.2.2 Starting measurement SV 200 is able to monitor and log noise by enabling up to three different parameter configuration settings, also referred to as “ACOUSTIC PROFILE, each one with different filter (A, C and Z) and detector (SLOW, FAST and IMPULSE) settings.
  • Page 44 SV 200 USER MANUAL Using Web Interface 1. Open to the instruments’ Web Interface by entering IP address or domain name into your web browser address bar. 2. Once Web Interface is loaded navigate to Configuration tab. 3. In Configuration tab click Start measurements button.

  • Page 45: Changing The Working Directory

    SV 200 USER MANUAL 4.3 Changing the working directory Working directory is a folder on the SD card in which all the measurement data is stored. Changing the working directory can be conducted with SVAN PC++ software either locally via USB cable or remotely using RC module with SVAN Files feature.

  • Page 46: Firmware Upgrade

    SV 200 USER MANUAL 4.4 Firmware upgrade The firmware which controls the SV 200 is possible for the user to upgrade. There are three separate programs loaded into the instrument’s memory: 1. User Program, 2. BOOTSTRAP, 3. HARDBOOT. The User Program controls all of the instrument’s functions i.e. measurements, communication, web server etc.
  • Page 47 SV 200 USER MANUAL To upgrade the instrument via Web interface 1. Open to the instruments’ Web Interface by entering IP address or domain name into your web browser address bar. 2. Once Web Interface is loaded navigate to Configuration tab.

  • Page 48: Web Interface Upgrade

    SV 200 USER MANUAL 4.4.2 Web interface upgrade Some major firmware version upgrades may require the user to upgrade Web Interface as well. This upgrade can be with SVAN PC++ software either locally via USB cable or remotely using RC module.

  • Page 49: Bootstrap Program Upgrade

    <Power> push-button shortly. If the STAT LED turned solid orange, the instrument entered into HARDBOOT mode. 4. Run batch file included in the upgrade package. Notice: Solid red STAT LED indicates error in booting process. Turn the SV 200 off and start the upgrade process from the beginning.

  • Page 50: Remote Configuration

    TCP Server is a mode of main communication channel in which the H24 Telit 3G Modem is configured to act as a server for incoming connections. For the use in SV 200, the modem is awaiting for the first connection to be established on a designated port (called Data Port; default 8001). Such connection can come from any application designed to act as an initiator of the TCP connection (such as SvanPC++) called remote peer.
  • Page 51 The DynDns is a service that allows a static name to be translated to an internet address. The controlling application uses the name to identify the SV 200 in the internet network as an address to connect to. The properly configured instrument provides means to validate its internet address to be recognized in internet network.

  • Page 52: Web Server

    Each SV 200 comes with its own set of default WWW files, ready to be used in such fashion, but the instrument allows the user's files to be used in its stead. The WWW files are stored in the root folder of the instrument’s SD card and can be updated using SvanPC++’s file upload function.

  • Page 53: Sms / E-Mail Alarming

    Z komentarzem [MB3]: Opisane w 6.11 – wystarczy? mail notification. Whenever a defined condition is met, the SV 200 can send an SMS to a defined number and/or an E-mail to a defined address to provide information, including the current value of the monitored result, the profile it is measured in and the value of the threshold it's being measured against.

  • Page 54: Lantronix Wiport Modem

    Access Point to which all Wi-Fi devices connect to. This requires the SV 200 to be configured to connect to such Access Point using its SSID (network name) and security settings. Similar to ad-hoc connections, the module will remain connected to the network once properly configured.
  • Page 55 This is solved by either configuring the Lantronix module to have a Static IP, recognized by the network or by deploying a DHCP protocol by whatever controller is governing the network (e.g. a router) and configuring it so that the SV 200 always receives the same address.

  • Page 56: Instrument Settings

    SV 200 USER MANUAL INSTRUMENT SETTINGS This chapter explains how to set up measurement, data logger and many more settings of the SV 200 with Remote Communication module of SVAN PC++ software. Instrument’s settings can be modified via SVAN PC++ software. SV 200 needs to be connected to the computer running SVAN PC++ either by USB cable or Internet/LAN connection.

  • Page 57: General Settings

    SV 200 USER MANUAL 6. Station configuration window will appear. It allows the user to modify general instrument settings, measurement setup, external I/O setup, internet services and system events settings. Remote communication setup is available only for USB connection. 6.2 General settings In general settings tab the user can enter the Name and Comment of the station.

  • Page 58: Measurement Setup

    SV 200 USER MANUAL 6.3 Measurement setup The Measurement setup tab consists of the following parameters: the measured function (Level meter, 1/1 octave or 1/3 octave), the delay of the start of measurements (Start delay), the integration period / measurement run time (Integration period), the RMS detector type (RMS integration), the number of repetitions of measurement cycles (Repetition cycles) and the frequency response of the microphone (Outdoor filter).

  • Page 59: Integration Period

    SV 200 USER MANUAL 6.3.3 Integration period The Integration Period setting defines the period during which the signal is being measured (integrated) and stored as the set of Summary Results (SR). The measurement will stop automatically after this period. When the Repetition cycle is greater than one the measurement will start again.

  • Page 60: Channels

    SV 200 USER MANUAL 6.4 Channels This tab enables the user to adjust filter and RMS detector settings for each acoustic profile individually, which effectively gives three separate results with different filter and detector setting. Frequency weighting filter for 1/1 & 1/3 octave analysis can also be set.

  • Page 61: Logger Settings

    SV 200 USER MANUAL 6.5 Logger settings This tab enables the user to set the logger functions: the recording of the measurement time history results, time history step and splitting. Splitting mode Logger on Logger step Logger results Logger meteo 6.5.1 Logger on...

  • Page 62: Logger Meteo

    SV 200 USER MANUAL 6.5.3 Logger meteo The Logger meteo check-box controls saving results from SV205B weather station (sold separately). The results are saved according to Logger step setting, unless it is smaller than 1s. In such case weather data will be stored in the result file each second.

  • Page 63: Event Recording

    In Wave recording mode recordings will take form of separate PCM (*.wav) files stored on the SD Card of the SV 200 alongside logger files. In Event recording mode the recordings will be stored inside logger files. Audio recording in logger file is indicated by the Audio marker.

  • Page 64: Trigger Type

    SV 200 USER MANUAL 6.6.3 Trigger type The Trigger type list enables the user to set the parameters for the recording trigger. Triggering is switched on if one of its seven available modes is selected: Continuous, Slope +, Slope –, Level +, Level –, Gradient + or Integration period.

  • Page 65: Csv Export

    P3, 1, 68.9, 64.0, 56.9, 64.0, 61.9, 61.9, 66.9, 64.0, 64.0, 63.9, 63.6, 63.3, 63.0, 62.0, 61.6, 61.3, 61.0, 60.5, 60.0, 0 … … Notice: CSV files can take up a lot of storage space and therefore bandwidth during data download. Be careful using this feature especially with 3G modem version of SV 200.

  • Page 66: Advanced

    SV 200 USER MANUAL 6.8 Advanced The Advanced settings tab enables the user to define ten statistical levels, named from N1 to N10, to be calculated and saved in the measurement files. Z komentarzem [MB5]: Statistic cycles ? Statistics selector All values have to be in the integer range of 1 to 99.

  • Page 67: External I/O

    SV 200 USER MANUAL 6.9 External I/O The External I/O tab allows the user to select the device connected to the SV 200 via the Ext. I/O socket. External device selector Device settings 6.9.1 External device The External device selector list contains devices possible to connect via Ext.

  • Page 68: Internet Services

    6.10.1 WWW Server The WWW Server enables the user to control the SV 200 using web browser on any device. For more information on WWW Server see Chapter 7. In this section the user can enable or disable the WWW server feature by checking or unchecking Enabled box.

  • Page 69: System Events

    SV 200 USER MANUAL 6.11 System events The SV 200 can automatically report certain system events by email or text message. List of reported events can be found in System events section. Events selector Battery and memory thresholds Text message format and recipient and email account settings are configured in Alarm settings section.

  • Page 70: Time Synchronization

    SV 200 USER MANUAL 6.12 Time synchronization The SV 200 offers sophisticated time synchronization features, including automatic and manual daylight saving time adjustments. Time zone settings Time synchronization settings Custom daylight saving time setting 1. To enable the time synchronization feature in Time synchronization settings section choose suitable time synchronization protocol.

  • Page 71: Calibration & System Check

    SV 200 USER MANUAL 6.13 Calibration & System Check The SV 200 is fitted with an Automatic calibration and Automatic system check features. This section enables the user to configure details of those features. Automatic calibration settings Automatic system check settings 6.13.1 Automatic calibration...

  • Page 72: Logging

    Automatic calibration settings section. 6.14 FTP data transfer The FTP data transfer is used to transfer measurement data and setup files between the SV 200 and any FTP server. For more information on FTP data transfer concept see Chapter 8.2.

  • Page 73: Web Interface

    SV 200 USER MANUAL WEB INTERFACE When enabled, and the instrument is properly configured (both in 3G and Wi-Fi versions), SV 200 offers the user easy means of accessing the instrument’s settings, results and status information via a Web browser.

  • Page 74: Summary Results Section

    SV 200 USER MANUAL Notice: The flashing LED is visible on all four tabs of the Web Interface, to conveniently provide information on measurement status at all times. 7.1.2 Summary Results section The Summary Results section gives the user the overview of selected measurement function results from current and previous integration period.

  • Page 75: Time History Results Section

    SV 200 USER MANUAL 7.1.3 Time History Results section The Time history section enables the user to view time history of the functions selected in function selector. There are four functions (L and L ) available to select for each measurement peak, profile.

  • Page 76: Spectrum Section

    SV 200 USER MANUAL 7.1.4 Spectrum section The Spectrum section displays spectrum from current integration period. The spectral information is based on the analysis type currently set in the instrument and the user can browse it both in chart or table form.

  • Page 77: File Storage Page

    File storage is a listing of the files recorded in the instrument’s SD card storage. The listing includes only the files from a single folder and it initially shows the content of the SV 200’s currently set working directory. By clicking on the folders or using the “folder up” button, the user can navigate through the folder structure.

  • Page 78: Configuration Page

    SV 200 USER MANUAL 7.3 Configuration page Configuration page contains several sections, each allowing to view and adjust part of the instrument’s settings. In order to toggle a section on click corresponding button. stop/start measurements button section buttons apply settings button A the bottom of the page are two buttons: “Start/stop measurement”...

  • Page 79: Filters & Detectors Section

    SV 200 USER MANUAL 7.3.1 Filters & detectors section In Filters & detectors, the user can adjust frequency weighting filter and RMS detector settings for each profile and frequency weighting filter for spectrum analysis. integration type setting profile filter settings...

  • Page 80: Storage Section

    SV 200 USER MANUAL Detector The following RMS detectors are available in the instrument: Impulse, Fast and Slow. This setting corresponds to RMS Detector in SvanPC++ RC Station Configuration (see Chapter 6.4.2). 7.3.2 Storage section In the Storage section the user can select which results will be recorded in time history file and determine intervals in which both time history results and summary results will be recorded.
  • Page 81 SV 200 USER MANUAL Summary results interval The summary results interval setting defines the period during which the signal is being measured (integrated) and stored as the set of Summary Results (SR). The measurement will stop automatically after this period. When the Repetition cycle is greater than one the measurement will start again.

  • Page 82: Real Time Clock

    SV 200 USER MANUAL 7.3.3 Real Time Clock Displays the current time in the instrument as compared to the local time of the PC. The “Update RTC” button allows the user to update the instrument’s time to the PC’s current time.

  • Page 83: Calibration And System Check

    SV 200 USER MANUAL 7.3.4 Calibration and System Check This tab enables the user to configure automatic calibration and system check as well as perform manual checks. Current calibration factor Automatic calibration settings Automatic system check settings Last check result...
  • Page 84 Manual actuator control Enable actuator button enables and disables electrostatic actuator of the SV 200. After activating the actuator the wave icon will appear next to the status LED in the top left corner of the WEB interface page indicating activity of the actuator.

  • Page 85: Ftp Data Transfer

    SV 200 USER MANUAL 7.3.5 FTP Data Transfer The FTP data transfer is used to transfer measurement data and setup files between the SV 200 and any FTP server. For more information on FTP data transfer concept see Chapter 8.2.

  • Page 86: Auxiliary Settings

    Restart instrument button Browse button Upload button Load firmware button Complete update process is described in detail in Chapter 4.4. Before upgrade it is essential that the proper firmware file is downloaded from SVANTEK website and the internet connectivity is stable.

  • Page 87: Status Page

    SV 200 USER MANUAL 7.4 Status page Status page is used to display status information about the instrument. The default contents of the status page are as follows: • serial number • firmware version • web server version • measurement state •...

  • Page 88: Data Collecting

    SV 200 USER MANUAL DATA COLLECTING This chapter describes how to obtain data stored in the SV 200 instrument using Internet connection. Three possible communication modes are presented SVAN PC++ with Remote Communication module, FTP Client - direct upload to an FTP Server and data download using built-in WEB Interface.
  • Page 89 SV 200 USER MANUAL 4. Choose the instrument you wish to manage in Stations list. To select multiple instruments use Ctrl+Click combination. connection type box stations list 5. Click the button starting the desired data collecting mode. data collecting modes...

  • Page 90: Remote Communication Service

    SV 200 USER MANUAL 8.1.2 Remote Communication Service Automatic Files Download (AFD), Continuous Logger Download (CLD) and Live Results Preview run within Remote Communication Service. It is a program operating in background regardless of whether SvanPC++ is running or not. The user doesn’t even have to be logged in his Windows user profile. All data collecting features of SvanPC++ are active once set up.

  • Page 91: Svan Files

    Source selector enables the user to change source of files to display in the instrument navigation pane. In case of SV 200 there are two sources available: SD disk and Internal RAM. No measurement data can be stored in the Internal RAM memory of the instrument.
  • Page 92 SV 200 USER MANUAL Downloading files 1. In the instrument pane navigate to the directory where necessary measurement files are stored. By default SVAN Files display current working directory of the instrument. 2. Select the Download type. By default binary SVL files are downloaded, however CSV files are also available.
  • Page 93 Delete button Updating RTC SVAN Files enables the user to set the real time clock (RTC) of the SV 200. Current PC time can be set as well as manually selected value. To synchronize SV 200 time with the current PC time click Set RTC button. To enter other value click Customize RTC button.

  • Page 94: Automatic Files Download

    8.1.5 Automatic Files Download AFD (Automatic Files Download) is most commonly used data collecting method. In this mode SvanPC++ automatically downloads data from any number of SV 200 monitoring stations and stores it in selected local or remote directory. Besides downloading files AFD performs other tasks such as: •...
  • Page 95 . If 3G modem is used make sure that SIM card data plan covers large transfers. Downloading period setting determines how often data from the SV 200 will be downloaded to the PC. Five different periods can be chosen: hourly, daily (at specified hour), weekly (at specified weekday, at specified hour), monthly (at specified day of month, at specified hour) and custom (specified time interval between downloads).
  • Page 96 File Conf. button next to each individual station in the Station list. To start Automatic Files Download session and download files from the SV 200 immediately click Download now button. Stopping session To finish Automatic Files Download session after downloading all measurement files click Stop AFD button.

  • Page 97: Continuous Logger Download

    CLD (Continuous Logger Download) mode is used for continuous downloading of measurement data from SV 200. Measurement results can be presented in real time while saving in selected local or remote directory. In this mode only logger (SVL) files are downloaded.
  • Page 98 & summary Download step setting determines how often data from the SV 200 will be downloaded to the PC. File saving settings section enables the user to configure basic settings for files download such as download path, file naming rules and writing session log.
  • Page 99 SV 200 USER MANUAL It is also possible to override global file saving settings of CLD session by clicking File Conf. button next to each individual station in the Station list. Stopping session To finish Continuous Logger Download session after downloading all measurement files click Stop button.

  • Page 100: Live Results

    SV 200 USER MANUAL 8.1.7 Live Results Live Results mode is used to easily view current SV 200 results without necessity to save the measurement files on the computer. This mode is capable of publishing HTML results on the WEB server and also uploading measurement files from the instrument directly on the FTP server.
  • Page 101 SV 200 USER MANUAL To start Live Results session click Start button. The LR session will start immediately. Measurement status control While the Live Results session is active Start/stop measurement button enables the user to start or stop measurement manually.

  • Page 102: Alarms

    SV 200 USER MANUAL 8.1.8 Alarms SvanPC++ Remote Communication Alarms window enables the user to configure customized email notifications for certain events. Email server Alarms settings settings Message settings With Alarms user can be informed about following events: • System events, such as disconnecting and reconnecting to the network, losses of external power, exceeding maximum temperature inside the station etc.

  • Page 103: Ftp Client

    The SV 200 is fitted with an inbuilt FTP client. This feature allows automatic uploads of measurement data (*.svl and *.csv files) as well as audio (*.wav files) on an FTP server. Also the SV 200 can download setup files from FTP server and change its configuration. The possibility of instrument reconfiguration in...

  • Page 104: Sv 200Cu User Control Unit

    SV 200 USER MANUAL SV 200CU USER CONTROL UNIT The SV200CU control unit is an optional accessory, that enables the user to access most essential functions and settings of the SV200 manually. The control unit enchances SV200 functions and enables to perform settings and conduct the measurements manually, when the operator is in the close position to the SV200.

  • Page 105: Manual Control Of Sv200

    SV 200 USER MANUAL 9.3 Manual control of SV200 Control of SV200 via the control unit has been developed in a fully interactive manner. The user can operate SV200 by selecting the appropriate position from the selected Menu list of the control unit. Thanks to that, the number of push-buttons for control of SV200 has been reduced to nine for ease of use and convenience.
  • Page 106 SV 200 USER MANUAL This can prevent accidentally starting or stopping a measurement at the wrong time by just brushing against the Start/Stop button on its own. <ENTER> This push-button enables the user to enter the selected position shown on the screen Menu list or to confirm selected settings.

  • Page 107: Swithing The Control Unit On And Starting Measurement

    SV 200 USER MANUAL (<>, <>) The <>, <> push-buttons pressed in conjunction (or in sequence) with <Shift> enable the user specifically to: • shift the cursor from the first to the last position and back on the menu list;...

  • Page 108: Setting Sv200

    SV 200 USER MANUAL “arrow up” “curve” icon is presented when the current icon is displayed when overload appears. measurement results are logged into thes logger file. “arrow down” icon is displayed when “plug” icon displayed when instrument is powered from the external under range appears.
  • Page 109 SV 200 USER MANUAL Position selection The desired position in menu list is selecting using the <> or <> push-buttons. <> Entering position After selection of the desired position in the menu list, the user has to press the <ENTER> push-button in order to enter it.

  • Page 110: Setting The Sv200 Function

    SV 200 USER MANUAL Help information In most windows the last line or several lines at the bottom of the screen contain help information. It informs the user how to select or modify the parameter’s value, change the character in the text line etc.
  • Page 111 SV 200 USER MANUAL The Calibration sub-list consists of two positions: Auto Calibration Calibr. by Measurement, which are used to perform the actual calibration. <ENT> Notice: The calibration factor is always added to the results in the Level Meter, 1/1 Octave, 1/3 Octave modes.

  • Page 112: Setting The Measurement Parameters - Measurement

    SV 200 USER MANUAL Notice: It is also possible to use an electro-mechanical pistonphone, which generates a signal (ca 124 dB) or different type of acoustic calibrator dedicated for ½” microphones. In any case, before starting the calibration measurement, the user has to set the level of the signal generated by the given calibrator (Cal.

  • Page 113: Selection Of Measurement Parameters - General Settings

    SV 200 USER MANUAL General Settings enables the user to set various general measurement parameters; Compensation Filter enables the user to switch on required microphone compensation filter; Profiles enables the user to program the profile parameters; Logging enables the user to program the logging function;...

  • Page 114: Selection Of The Microphone Compensation Filters - Compensation Filter

    SV 200 USER MANUAL Day time limits selection The Day Time Limits position enables the user to select the definition of the day and night periods required by the local standards. These limits are used for the calculation of the Lden function (cf. App. D for the definition).Two options are available: 6H–18H and 7H–19H.
  • Page 115 SV 200 USER MANUAL Notice: If Logger is swithed off, files are not created and measurement results of the time history changes are not saved! The Logger position switches on and off the functionality, which enables the user to save selected results from the three user profiles with the defined period selected in Logger Step.

  • Page 116: Selection Of The 1/1 Octave And 1/3 Octave Spectrum Parameters - Spectrum

    SV 200 USER MANUAL 9.7.5 Selection of the 1/1 Octave and 1/3 Octave spectrum parameters – Spectrum The Spectrum position appears in the Measurement list when the 1/1 Octave 1/3 Octave function selected Measurement Function list (path: <Menu> Function Measurement Function / 1/1 Octave or 1/3 Octave).
  • Page 117 SV 200 USER MANUAL Field description of the One Profile vi ew 1. Profile number. 2. The value of the measured result. 3. The name of the implemented filter: Z, A, C. 4. Detector time constant: Imp., Fast, Slow when...

  • Page 118: Spectrum Scale And Grid Setting - Display Scale

    SV 200 USER MANUAL The user may shift the Y-axis during the spectrum presentation after pressing the <Shift> and <> (or <Shift> and <>) push-buttons. <Sh/> The user may change the cursor position by means of the <>, <> push-buttons. The frequency and the appropriate value are presented in the line below the plot.

  • Page 119: Setting The Parameters Of The Spectrum Presentation - Spectrum View

    SV 200 USER MANUAL 9.8.3 Setting the parameters of the spectrum presentation - Spectrum View The Spectrum View position enables the user to change the type of the spectrum (Type) and to activate the presentation on the display of the Max and Min values for every displayed spectrum band.

  • Page 120: Managing The Instrument Files - File

    SV 200 USER MANUAL Setting the power saver delay The power saver delay defines the delay period from last use of any push- button to the power saver mode. This delay period can be set for Dim screen on idle from 5 s to 60 s and for Screen off on idle from 1 m to 60 m.

  • Page 121: Setting Of The Instrument Parameters - Instrument

    SV 200 USER MANUAL 9.10 Setting of the instrument parameters – Instrument The Instrument list is used for setting the various parameters which are primarily dedicated to control of SV200 hardware and contains the following items: <ENT> Battery enables the user to get information about current power source;...

  • Page 122: Setting The Parameters Of The Serial Interface - Serial Port

    The displayed text is scrolled on the display after pressing <> and <>. Notice: The contents of the Unit Label window should be always sent to Svantek’s service department or official representative in case of any problems faced by the user during the instrument’s normal operation in the field.

  • Page 123: Setting The Language Of The User Interface - Language

    SV 200 USER MANUAL 9.15.1 Setting the language of the user interface – Language The Language sub-list enables the user to select the language of the user interface. For activation of the Russian version of the user interface, the special code has to be entered.

Table of Contents
