FONESTAR CB-119 Manual

C -119
EN
MIXER WITH 3 MICROPHONES AND 1 AUXILIARY INPUT
DESCRIPTION
- Passive mixer with 3 microphones and 1 auxiliary input, for connecting the output to 1 mic. input.
CONTROLS AND FUNCTIONS
CONNECTION AND OPERATING
- Connect the microphones to the mixer inputs and if you want, an audio source to the auxiliary input.
- Connect the mic. level output to the microphone input on an amplifier or mixer.
- Regulate the volume for each mic. input and for the auxiliary input until you obtain the desired audio level.
TECHNICAL SPECIFICATIONS
CHARACTERISTICS
INPUTS
OUTPUTS
CONTROLS
DIMENSIONS
ACCESSORIES
This product has been tested and has passed the corresponding quality control prior to being put on the market.
FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute
the goods as expressed in the Spanish law 'La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified with no more than showing the proof of purchase. After
six months FONESTAR reserves the right to demand proof of the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts due to use, breakages, burns, spilt liquids or other
substances, excessive humidity, battery deterioration and internal manipulation of the device, the software or its components by unauthorized persons, and in
general any use that is unrelated to the nature and purpose of the product.
If any service is needed during the warranty period because of lack of conformity, please contact the business or distributor where the product was purchased in
no more than 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
This document adds information, and never decreases the consumers' rights, which in all cases are protected by the Spanish law 'La Ley General para la Defensa
de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre
FONESTAR is a member of ECOEMBALAJES ESPAÑA, S.A. "ECOEMBES", with number 03497 and all our products carry the symbol, backed by our membership and subscription
to the above mentioned organization with the recycling and subsequent management of our packaging.
FONESTAR is registered in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI (Registro de establecimientos Industriales), with the entry number
001851.
FONESTAR S.A. - NIF A28780443 - Poligono Trascueto - 39600 - Revilla de Camargo, Cantabria (Spain)
www.fonestar.com
1.- MIC 1-3: mic. inputs 1 to 3, 6.3 mm mono jack connectors.
2.- AUX: auxiliary input, 2 x RCA connectors.
3.- OUT: mic. level output, 6.3 mm mono jack connector.
4.- MIC 1-3 VOLUME: volume controls for the mic. 1 to 3 inputs.
5.- AUX VOLUME: volume control for the auxiliary input.
CB-119
Passive mixer with 3 microphones and 1 aux input.
Mic. output level for connecting to 1 microphone input.
3 unbalanced mics., 6.3 mm jack
1 aux, 2 x RCA
1 unbalanced mic., 6.3 mm jack
Volume through input
145 x 31 x 76 mm depth
1 audio cable, 6.3 mm mono plug to 6.3 mm mono plug, 1.8 m
