  • Page 1 SM-303SC COMPACT 3-CHANNEL MIXER N Instruction manual...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
  • Page 4: Controls And Functions Front Panel

    DESCRIPTION - Compact 3-channel mixer. - USB audio input/output for connecting to PC. CONTROLS AND FUNCTIONS FRONT PANEL MIC/LINE 1 IN: balanced line/microphone input for channel 1, combo connector(XLR and 6.3 mm stereo jack). LINE 2/3 IN: line input for channels 2 and 3, 2 x RCA connectors. CD/TAPE IN: line input, 2 x RCA connectors.
  • Page 5: Back Panel

    - Connect the desired equipment to the channel inputs. A dynamic or condenser microphone can be connected to the corresponding input. - Connect the devices to the power supply. - Switch the devices on in this order: firstly, the players, then the mixer SM-303SC and lastly, the power amp or amplifier. - 5 -...
  • Page 6: Block Diagram

    BLOCK DIAGRAM - 6 -...
  • Page 7: Specifications

    SPECIFICATIONS SM-303SC CHARACTERISTICS Compact 3-channel mixer. Audio USB input/output for connection to PC. INPUTS 1 balanced mic./line, combo (XLR and 6.3 mm jack) 1 line, 2 x RCA 1 stereo CD/tape in, 2 x RCA 1 audio USB CONTROLS Channel 1: gain, bass (±15 dB, 80 Hz), treble (±15 dB, 12 000 Hz), pan and volume control Channel 2/3: Bass (±15 dB, 80 Hz), treble (±15 dB, 12 000 Hz), balance,...
  • Page 8: Declaration Of Conformity

    This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
