FONESTAR MD-802 Instruction Manual

6-channel mixer/splitter
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
MD-802
6-CHANNEL MIXER/SPLITTER
N Instruction manual

Advertisement

Table of Contents
loading

Related Manuals for FONESTAR MD-802

Summary of Contents for FONESTAR MD-802

  • Page 1 MD-802 6-CHANNEL MIXER/SPLITTER N Instruction manual...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.

  • Page 4: Controls And Functions Front Panel

    DESCRIPTION - Audio mixer/splitter. - 1 main input channel, 1 main output channel and 6 canals that can be set as inputs or outputs. CONTROLS AND FUNCTIONS FRONT PANEL INPUT LEVEL: LED main input signal level indicators. SPLITTER MAIN INPUT LEVEL: main input volume control when operating as splitter. MAIN LINK: button for guiding the MAIN IN input to the MAIN OUT output.
  • Page 5 CONNECTION OPERATING AS MIXER - Connect the desired audio sources to the channel CH 1 to CH 6 inputs. - Move the SPLITTER/MIXER selectors on the front panel to the MIXER position. - Connect an amplifier to the MAIN OUT output on the device. OPERATING AS SPLITTER - Connect an audio source to the MAIN IN input on the device.

  • Page 6: Block Diagram

    OPERATING AS MIXER/SPLITTER - It is possible to set the device as a mixer and a splitter simultaneously. To do this, some inputs can be used as mixer inputs with the MAIN OUT output and some outputs can be used as splitter outputs with the MAIN IN input.

  • Page 7: Specifications

    SPECIFICATIONS MD-802 6-channel mixer/splitter. CHARACTERISTICS INPUTS 4 balanced lines, XLR, 50,000 Ω 150 mV at 2 V 2 balanced lines, 6.3 mm jack, 50,000 Ω 150 mV at 2 V 1 main in, 2 x XLR, 50,000 Ω 150 mV at 2 V OUTPUTS 4 balanced lines, XLR, 600 Ω...
  • Page 8 This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
