  • Page 1 X-862 MIXER/PRE MPLIFIER INSTRUCTION MANUAL...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.

  • Page 4: Controls And Functions Front Panel

    DESCRIPTION - Mixer/preamplifier. - Priority paging. Chimes. - 4 mic./line inputs with direct output and 4 line inputs. - General purpose output activated by prioirty. - Mono/stereo mode. CONTROLS AND FUNCTIONS FRONT PANEL VOL: volume control of the corresponding input channel. SIGNAL/PEAK: LED power indicator of the corresponding input channel.

  • Page 5: Rear Panel

    REAR PANEL Power supply input 230/115 V AC. TONE: closes the contacts among one of the preset tone terminals (1-4) and the COM terminal in order to play the corresponding tone. VCA: remote volume control per channel. Connect an external potentiometer between the terminals R and COM for the right channel and between the L and COM channels for the left channel in order to remotely control the volume of both the output channels.

  • Page 6: Mono/Stereo Mode

    PRIORITY AND CHIMES It is possible to select the priority of input channels 1 to 4, as well as its level. Similarly, it is possible to select whether the chimes are played or not in the input channels 1 to 4. In order to access the jumper and the potentiometer it is necessary to unscrew the upper cover of the device.

  • Page 7: Installation And Connection

    - Check that the direct input and output volume controls are at their minimum. - Power the mixer/preamplifier mod. MX-862 using the AC mains socket. - Once the connections have been made according to your needs, connect the devices to the mains supply and switch them on.

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS MX-862 CHARACTERISTICS Mixer/preamplifier. Phantom power supply. Priority paging. Chimes. 4 mic./line inputs with direct output. General purpose output activated by priority. Stereo/mono mode. Remote volume control of the master output. INPUTS 4 balanced mics./lines, switchable XLR 5 mV and 700 mV...
  • Page 9 - 9 -...
  • Page 10 - 10 -...

  • Page 11: Warranty

    2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
