- Page 1 SM-1641U MIXER WITH USB/SD/MP3 PLAYER AND BLUETOOTH RECEIVER INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DESCRIPTION - The model SM-1641UB is a mixer with 8 inputs , 4 stereo channels and 1 microphone. It is equipped with an MP3 player with connection port for USB storage devices and SD card reader. It shows ID3 tag information in MP3 files. - Page 5 13.- SD: SD memory card connection slot. 14.- USB storage device connection port. 15.- Information display. 16.- 12: start/pause playback. 17.- 3: stops playback. 18.- REPEAT: allows selection of repetition mode among SINGLE (repeat one track), FILE (repeat file) or ALL (repeat all). 19.- 7: a short press of this button allows rewinding to the previous track.
-
Page 6: Rear Panel
34.- Switches to select the channel assigned to each side of the crossfader. 35.- CROSSFADER: control which allows the balance to be made between the two channels assigned in the two switchers. 36.- CUE/PGM: control which allows the balance to be made between the headphones output (CUE) and the master output (PGM). -
Page 7: Bluetooth Receiver
BLUETOOTH RECEIVER - This model SM-1641UB allows MP3 files stored in your mobile telephone to be played if the device is paired with this mixer’s bluetooth receiver module. - In order to pair your mobile telephone with the bluetooth receiver, select the bluetooth option with the USB/SD/BT button. -
Page 8: Technical Specification
TECHNICAL SPECIFICATION SM-1641UB CHARACTERISTICS Mixer with 8 inputs, 4 stereo channels and 1 microphone. USB/SD/MP3 player and ID3 tag. Bluetooth receiver incorporated, plays music received from a mobile telephone. Echo and talkover. Assignable crossfader. INPUTS 2 lines/phono, 2 x RCA, 27,000 Ω 150 mV, 50,000 Ω 3 mV 5 lines, 2 x RCA, 27,000 Ω... -
Page 9: Warranty
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los... - Page 10 - 10 -...
- Page 11 - 11 -...
- Page 12 www.fonestar.com...
