SMA-912USB
PROFESSIONAL 12-CHANNEL
AUTOAMPLIFIED MIXER
N Instruction manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMA-912USB and is the answer not in the manual?

Questions and answers

Related Manuals for FONESTAR SMA-912USB

Summary of Contents for FONESTAR SMA-912USB

  • Page 1 SMA-912USB PROFESSIONAL 12-CHANNEL AUTOAMPLIFIED MIXER N Instruction manual...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.

  • Page 4: Controls And Functions Front Panel

    CONTROLS AND FUNCTIONS FRONT PANEL MONO input channels CH-1/CH-6: mono input channels for microphone signals and line level. 1.- SG/PK: channel input signal LED indicator. When there is an input signal connected the LED indicator lights up and stays green. If the input signal starts to get saturated, the LED indicator will turn orange and will turn red when the input signal is saturated.
  • Page 5 STEREO input channels CH-7/CH-12 : stereo input channels for microphone and line level signals. y de nivel de línea. 10.- BAL: balance adjustment of the input signals for channels 7-12. 11.- LINE IN and MIC/LEFT IN: 6.3 mm stereo and combo jack mic. and line signal input connectors.
  • Page 6 MULTI-EFFECTS PROCESSOR 21.- FUNCTION: display which shows the number of the chosen effect. 22.- PROGRAM (PUSH): button which allows you to select the desired effect for the input signals. Turn the control until the number of the desired effect appears in the display and then press the control to select it.

  • Page 7: Back Panel

    MAIN AND MONITOR EQUALIZERS 36.- MONITOR EQ and MAIN EQ: 7-band graphic equalizer with feedback locator in the main and monitor outputs. 37.- POWER: LED equalizer on indicator. 38.- LED feedback indicators: when one of the indicators lights up, it shows that there is feedback in the corresponding frequency.
  • Page 8 - Connect the microphones and the desired equipment to the CH1-12 channel inputs. - Switch the equipment on in order, starting with the peripheral systems and ending with the SMA-912USB. - While speaking through the microphone, adjust it with the LEVEL control of the corresponding channel, so that the LED SG/PEAK indicator of the output section level indicator lights up occasionally.
  • Page 9 The connection is made connecting one or various monitor speakers (where the output signal that is assigned to the bus monitor will come out) and one or various speakers to the 6.3 mm jack or speakon connectors on the back panel of the SMA-912USB. Note: respect the indications on the resulting speaker connection impedance.

  • Page 10: Bridge Mode

    BRIDGE MODE With the bridge mode the speaker or speakers that you connect to the speakon connector or 6.3 mm jack of the back panel will receive the sum of the power of both amplifiers. Note: respect the indications made about the resulting impedance of the speaker connections. - 10 -...

  • Page 11: Block Diagram

    BLOCK DIAGRAM - 11 -...

  • Page 12: Specifications

    SPECIFICATIONS SMA-912USB CHARACTERISTICS Professional 12-channel autoamplified mixer. USB/MP3 player. 24 bits DSP multieffects . Graphic equalizer with feedback locator. Output signal router to the amplifier for different operating modes, L/R, L+R/monitor and bridge mode. Limiter compressor. POWER 390 + 390 W RMS at 4 Ω...

  • Page 13: Declaration Of Conformity

    2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
