SECTION 3—ARMRESTS
S E C T I O N 3 — A R M R E S T S
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
Removing/Installing Swing Away Armrests
Removing/Installing Swing Aw ay Armrest
NOTE: For this procedure, refer to FIGURE 3.2.
Removing Swing Away Armrest
Unlock existing armrest assembly by operate the push pin
1.
2. Swing back on the existing armrest to remove from the front arm socket.
Remove armrest by operate the rear push pin
3.
4. Repeat STEPS 1 3 for opposite side of wheelchair, if necessary.
-
W A R N I N G
.
1 4
.
