- Page 1 PoE255 User Manual Thanks for using DSPPA Public Address System. Please read the manual carefully for better use of the equipment. G u a n g z h o u D S P PA A u d i o C o . , L t d...
- Page 2 This page is left blank for uses’ notes.
- Page 3 About this User Manual This User Manual is available and effective upon completion of development of the PoE255 Network Outdoor Waterproof Column Speaker. The User Manual includes system description, matters needing attentions in use, instructions on system connection, instructions on use of product and technical specifications of the terminal. Please read this User Manual carefully before connection, installation and use and operate in accordance with corresponding instructions in the Manual.
- Page 4 Matters needing attention Please read the following before operating the product. Warning The following basic requirements must be strictly observed, to avoid potential personal injury and equipment or property damages to you or any person nearby. The basic requirements include without limitation to the following: Power source/power cable When abnormal conditions are realized...
-
Page 5: Table Of Contents
1.2 Features................................ 1 II. Appearance Description............................2 2.1 Rear Panel............................... 2 III. Connection Diagram............................... 3 3.1 Connection Diagram of PoE255 Network Outdoor Waterproof Column Speaker in the System....3 IV. Setting Operation of the Terminal...........................4 4.1 IP Address Setting............................4 4.2 Sound Adjustment............................5 V. -
Page 6: Product Description
PoE255 Network Outdoor Waterproof Column Speaker 1.1 About PoE255 Network Outdoor Waterproof Column Speaker is a network play terminal with audio data streaming based on the TCP/IP transmission protocol, which can be mounted to any place accessible to network. It has built-in two woofers and a tweeter, with sound adjustment function. -
Page 7: Appearance Description
Active Speaker II. Appearance Description 2.1 Rear Panel +48V PoE Network interface Connected to +48V PoE switch. -
Page 8: Connection Diagram
For the connection of the entire system, please refer to the user manual of the network PA system. ② The connection of PoE255 network outdoor waterproof column speaker in the system must be connected to the + 48V 100M PoE switch, and set the corresponding address to communicate with the host. -
Page 9: Setting Operation Of The Terminal
Active Speaker IV. Setting Operation of the Terminal 4.1 IP Address Setting The speaker can be customized to modify the network parameters. If you want to modify the IP address, please read this section carefully for alteration methods: Method 1: The IP address alteration of the host / computer requires the IP address of the host / computer and that of the terminal on the same network segment. -
Page 10: Sound Adjustment
Active Speaker (Pic. 2) Method 2: 1. Enter the network host software “Settings” -> “System Maintenance” -> “Device Maintenance”. 2. Find the IP address of the terminal on the label, select and click “Modify IP”. 3. As shown in Pic. 3, modify the parameters and click OK to display success. (Pic. -
Page 11: Setting Instructions On The Host
(Pic. 5) The host system will automatically search the terminal equipment of the PoE255 network speaker, or you can manually search for the equipment. Click “Classification Display”, as shown below. Enter the device name, device number, and device IP for precise filtering. - Page 12 Active Speaker (Pic. 6) After finding the terminal, select the device in the interface as shown in Pic. 5, and then click the “Edit” button to enter the interface as shown below. You can view the basic information of the terminal, set the data transmission mode, the transit server and volume control;...
-
Page 13: Installation
Active Speaker VI. Installation Bracket 1 Screw Bracket 2 Bracket 3 Bracket Accessories 1) Divide the mounting bracket into three parts: 1, 2, and 3. Install two hex screws into the mounting slot on the rear of the speaker. (Place the column speaker horizontally to facilitate the installation) Note: When placing the speaker horizontally, please be careful not to touch or press the front mesh of the speaker with the hard surface, otherwise the front mesh will be deformed. - Page 14 Active Speaker Max. elevation angle adjustment Safety distance 140mm Adjustable Screw height Bracket 1 Max. depression angle adjustment Safety distance 160mm 3) After cutting the mounting holes on the wall according to the installation plan, fix the bracket 3 on the wall.
- Page 15 Active Speaker Adjustable 0~80° left or right Tighten the screws after adjusting the angle Adjustable 0~20° up or down...
- Page 16 Active Speaker Safety Precautions 1． Safety Precautions Please do NOT connect this device to the power source, before the system is correctly wired. It is important to ensure that input voltage to the device is the same as required voltage of the device, ...
-
Page 17: Packing List
User manual 1 copy Certificate 1 copy Warranty card 1 copy PoE255 column speaker 1 piece Whole machine fixing screw M6*50 Black stainless steel 201 material 2 pieces Φ6.5 stainless steel flat gasket 2 pieces M6*16(3.7mm) whole machine fixing screw stainless steel 201 material... - Page 18 ● This is connected to power source via the plug and any failure or danger occurs, the user can disconnect the device from power source by pulling out the plug out from the socket, therefore, it is required that the power socket should be located somewhere with easy access. Guangzhou DSPPA Audio Co., Ltd.
