- Page 1 IP Speaker User’s Manual Thank you for using our home IP speaker series. Please carefully read this manual first for better use. http://www.auxdio.com.cn...
- Page 2 Overview Dimensions This IP speaker is a stereo speaker specially designed for home IP music system, using the Big model dimensions: network as signal transmission carrier, integrated with decoder and power amplifier. 2×10W/4Ω and 2×20W/4Ω models are optional. The speaker is a stereo L-channel output type, with a extension interface at the rear for connection to an R-channel speaker.
-
Page 3: Specifications
The interface is connected to a R-channel speaker of a fixed-resistance type of 4Ω /10W or 4Ω/20W. Do not reverse polarity. Tip: A terminal consists of an L-channel speaker, which is the IP speaker, and an R-channel speaker, which is a fixed-resistance speaker of mating specifications. - Page 4 Installation Wiring Example R-channel speaker IP speaker 1. Installation diagram 4-6mm Ethernet switch SP EAKE R O UT L E FT 4 Ω NE T SPEA KER OU T L EFT 4 Ω Publi c Address System Pub lic Ad dr ess Syst em...
