Optional 4K input boards

HDMI/DP board
1)
Input Signal
Standard
Input resolution
2) 4 × DVI input board
Input signal
Standard
Input resolution
3) 4 × SDI input board
Input signal
Video source format
Input resolution
Transmission distance
The 4 input boards of Z6 Pro can be combined in any combination of above 3 input boards.
1 × HDMI2.0+LOOP, 1
only one of them will be working at the same time
HDMI: EIA/CEA-861 standard, HDMI-2.0 compliant, HDCP2.2 compliant
DP: DP-1.2 standard and HDCP1.3 compliant
3840×2160@60Hz
1920×1080@60Hz
4096×2160@60Hz
4 x DVI inputs
VESA standard, support HDCP, compatible with HDCP1.4
1920×1080@60Hz
8bit: support RGB444, YCbCr444, YCbCr422, YCbCr420
4 3G-SDI
×
Compatible with 3G-SDI, HD-SDI, SD-SDI
1080p, 1080i, 720p, 480i, 576i
1080p≤100 meters
× DP1.2
8bit: support RGB444,
YCbCr420
10bit: supports YCbCr422, YCbCr420
8/10bit: support RGB444, YCbCr444, YCbCr422,
YCbCr420
8bit: support RGB444,
YCbCr420
6
YCbCr444, YCbCr422,
YCbCr444, YCbCr422,
