  • Page 2: Table Of Contents

    Precis Models Applicability Notice This manual contains specific information for the following Precis Standard Video & Stereo S-Video & Stereo Component Video & Stereo RGBHV/HD-15 & Stereo Contents ESD Warning ..............i Important Safety Information &...
  • Page 3 Contents Attaching Video Cables ............8 Standard Video .
  • Page 4 Chapter 6 – Control Panel Operations ......32 Key Functions ............. . 32 Executing a Test Switch .

  • Page 5: Esd Warning

    ESD Warning To avoid ESD (Electrostatic Discharge) damage to sensitive components, make sure you are properly grounded before touching any internal materials. When working with any equipment manufactured with electronic devices, proper ESD grounding procedures must be followed to ensure people, products, and tools are as free of static charges as possible.

  • Page 6: Important Safety Information & Instructions

    Important Safety Information & Instructions When using and installing your AutoPatch product, adhere to the following basic safety precautions. For more information about operating, installing, or servicing your AutoPatch product, see your product documentation. ä Read and understand all instructions before using and installing AutoPatch products. ä...

  • Page 7: Information Et Directives De Sécurité Importantes

    Information et directives de sécurité importantes Veuillez vous conformer aux directives de sécurité ci-dessous lorsque vous installez et utilisez votre appareil AutoPatch. Pour de plus amples renseignements au sujet de l’installation, du fonctionnement ou de la réparation de votre appareil AutoPatch, veuillez consulter la documentation accompagnant l’appareil.

  • Page 8: Notices

    Notices © AutoPatch 2006, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AutoPatch. Copyright protection claimed extends to AutoPatch hardware and software and includes all forms and matters copyrightable material and information now allowed by statutory or judicial law or herein after granted, including without limitation, material generated from the software programs which are displayed on the screen such as...
  • Page 9 Notices If necessary, the user should consult the Dealer or an experienced radio/television technician for additional suggestions. The user may find the booklet, How to Identify and Resolve Radio-TV Interference Problems, prepared by the Federal Communications Commission to be helpful.” This booklet is available from the U.S.

  • Page 10: Chapter 1 - Installing The Precis Lt

    Installing the Precis Welcome The Precis is a stand-alone routing system that fits in a broad range of audio/video environments. The Precis front control panel (optional on all standard models) or any control device that can send and receive ASCII characters through an RS-232 serial cable. Precis features include: A variety of audio and video connectors in a single enclosure...

  • Page 11: Front & Rear Views

    Front & Rear Views Front View The type and number of keys on the panels vary by model. For a description of Key functions, see pages 32 and 33. Figure 1: Front view of a Precis Rear View The number and type of input/output connectors depend on the model’s configuration.

  • Page 12: Unpacking

    Unpacking Before fully unpacking the Precis of damage, immediately notify the shipping agency and contact your AutoPatch Salesperson or Representative (see Service & Returns Policy, page 51). Once unpacking is complete, closely check the physical condition of the enclosure. Note: AutoPatch is not responsible for damage caused by insufficient packing during return shipment to the factory.

  • Page 13: Installation Recommendations

    Installation Recommendations Installation Recommendations When placing the enclosure, follow the recommendations and precautions in this section to reduce potential installation and operation hazards. The Precis four rubber feet and two rack ears. Depending on the installation, you may either surface mount the enclosure or mount it in a rack. Environmental Recommendations Choose a clean, dust free (preferably air-conditioned) location Avoid areas with direct sunlight, heat sources, or high levels of EMI...
  • Page 14 small amount of heat they produce under normal operating conditions; however, this design is defeated when high heat-producing equipment is placed directly above or below the enclosure(s). Caution: We recommend 3 inches (7.6 cm) of clearance around the enclosure openings. At a minimum, leave at least one empty rack unit above and below the enclosure.

  • Page 15: Installing The Precis Lt

    Installing the Precis Installing the Precis Items Needed for Installation: Enclosure Power cord Rubber feet (optional) A laptop computer or PC for serial control (optional) Surge protector (highly recommended) Additional items for rack mounting: Standard EIA 19 in. (48.26 cm) rack Rack ears and rack ear screws Screwdriver Screws that fit your rack...
  • Page 16 Or Rack installation – On the side of the Precis closest to the front panel (see Figure 3). Align the holes on one of the rack ears with the empty holes on the side of the Precis screws for the 1 RU; four screws for the 2 RU). Repeat for the other rack ear. Front Panel Figure 3: Attach rack ears to the sides of the Precis 4.

  • Page 17: Attaching Video Cables

    Attaching Video Cables Attaching Video Cables Important: Do not apply power to the Precis applying power to the system, power the Precis source and destination devices. Standard Video To connect video inputs and outputs, fasten the cable connectors onto the input and output BNC connectors (see Figure 5).

  • Page 18: Component Video (Bnc)

    To fasten a locking S-Video connector, either hold the connector at a slight angle to the right while pushing in, or pull back on the housing of the connector (see Figure 7) while pushing the connector in. To remove a locking S-Video connector, pull back on the housing of the connector. Housing Figure 7: Pull back the housing to fasten or unfasten a locking S-Video connector Caution: The connector or the Precis...

  • Page 19: Rgbhv Video

    RGBHV VIdeo RGBHV Video To connect HD-15 inputs and outputs, fasten the cables onto the input and output HD-15 connectors (see Figure 9). Figure 9: Fasten the cables onto the HD-15 connectors HD-15 Pinout For HD-15 board connector pinout information, see Figure 10. Figure 10: HD-15 board connector pinout Input (VESA DDC Compliant)

  • Page 20: Attaching Audio Wires

    Attaching Audio Wires Wiring Sources & Destinations Source and destination devices will require either balanced (differential) or unbalanced (single-ended) connections. Figures 11 and 12 illustrate the options for wiring between the sources and the input connectors and between the output connectors and the destinations.

  • Page 21: Stereo Audio 3-Term

    Stereo Audio 3-Term & 5-Term Stereo Audio 3-Term To attach stereo audio input and output wires: 1. Unscrew the clamps on the audio connector. 2. Insert the wires (see Figure 13 for wire placement for single-ended stereo) and firmly re-tighten the clamps to make secure connections. Figure 13: Insert the wires and re-tighten clamps Stereo Audio 5-Term To attach stereo audio input and output wires:...

  • Page 22: Attaching Video & Audio Rca Cables

    Attaching Video & Audio RCA Cables The example in Figure 15 shows RCA jacks attached for routing Y/Pb/Pr and stereo audio source signals as Input 1. Figure 15: Insert the RCA plugs into the RCA jacks Component Video (RCA) To attach RCA video cables, insert the RCA plugs into the RCA jacks according to the labels on the enclosure (see Figure 15).

  • Page 23: Attaching An External Controller

    The Precis Distribution Matrix can be controlled by attaching an external controller (computer, AMX, Crestron, etc.) to the Precis (DB-9 connector). An external controller is any device that can send and receive ASCII code via RS-232. The steps below are specifically for establishing external control using a personal computer (PC) and HyperTerminal software;...
  • Page 24 3. Open HyperTerminal. Check to be sure the Communication Port option is set for the port that the null modem cable is plugged into and that the settings match those in the Port Settings table below. 4. Apply power to the Precis The HyperTerminal splash screen displays information* for your Precis (see Figure 18).

  • Page 25: Applying Power

    Applying Power Applying Power Your Precis ships with a power cord that is compatible with your country’s power sources. The enclosure’s universal power receptacle accepts all major international standard power sources. Power consumption varies by model; maximum power specifications are located to the right of the power receptacle. For detailed power specifications, see page 3.

  • Page 26: Executing A Test Switch

    Executing a Test Switch The Precis ships from the factory with a default switch that routes the signal from Input 1 to all outputs on both levels. Before using the system for normal operations, the default switch should be disconnected and a test switch executed to verify that the system is working correctly.

  • Page 27: Chapter 2 - Standard Video & Stereo Models

    Standard Video & Stereo Models Applicability Notice This chapter contains specific information for the following Precis Standard Video & Stereo (5-Term) Front Control Panel P37-0404-115 P37-0408-115 P37-0804-115 P37-0808-115 * The Standard Video and Stereo Model comes in a variety of configurations. For information on model configurations not listed, contact your authorized AutoPatch Dealer.

  • Page 28: Product Specifications

    Standard Video & Stereo Product Specifications Figure 19: Front view of Precis Note: The number of input and output keys vary depending on the configuration. Figure 20: Rear view of Precis Product Specifications Applies to Precis Standard Video & Stereo Models (5-Term) Blank Panels 37-96 Front Control...
  • Page 29 Parameter Standard Video Level (max.) Input Impedance Return Loss Connector Type Standard Video Level (max.) Output Impedance Return Loss Connector Type Parameter Stereo Audio Frequency Response Throughput THD + Noise Crosstalk (adjacent channel) Signal to Noise Ratio (SNR) CMRR Stereo Audio Level (max.) Input Impedance...

  • Page 30: Chapter 3 - S-Video & Stereo Models

    S-Video & Stereo Models Applicability Notice This chapter contains specific information for the following Precis S-Video & Stereo (5-Term) Front Control Panel P37-0404-615 P37-0408-615 P37-0804-615 P37-0808-615 * The S-Video and Stereo Model comes in a variety of configurations. For information on model configurations not listed, contact your authorized AutoPatch Dealer.

  • Page 31: Product Specifications

    S-Video & Stereo Product Specifications Figure 21: Front view of Precis Note: The number of input and output keys vary depending on the configuration. Figure 22: Rear view of Precis Product Specifications For General and AC Power Specifications, see page 3. Applies to Precis Blank Panels 37-08...
  • Page 32 Parameter Level (max.) S- Video Input Impedance Return Loss Connector Type S- Video Level (max.) Output Impedance Return Loss Connector Type Parameter Stereo Audio Frequency Response Throughput THD + Noise Crosstalk (adjacent channel) Channel Separation Signal to Noise Ratio (SNR) CMRR Stereo Audio Level (max.)

  • Page 33: Chapter 4 - Component Video & Stereo Models

    Component Video & Stereo Models Applicability Notice This chapter contains specific information for the following Precis * The Component Video and Stereo Models come in a variety of configurations. For information on model configurations not listed, contact your authorized AutoPatch Dealer. Component Video &...

  • Page 34: Overview

    Component Video & Stereo Overview Overview Component Video and Stereo Models can route audio and video signals simultaneously or separately. For information on levels and control, see Control Panel Operations on page 32 or BCS Serial Control Protocol on page 40. The Precis Component Video and Stereo Models have two connector options.

  • Page 35: Product Specifications

    Figure 23: Front view of Precis Note: The number of input and output keys vary depending on the configuration. Figure 24: Rear view of Precis Figure 25: Rear view of Precis Product Specifications For General and AC Power Specifications, see page 3. Applies to Precis Component Video &...
  • Page 36 Component Video & Stereo Product Specifications Parameter Component Frequency Video Response Throughput Differential Gain* Differential Phase* Crosstalk (adjacent channel) Signal to Noise Ratio (SNR) * Differential gain and phase measurements are preformed with a standard 5-step modulated staircase test signal. Parameter Component Level (max.)
  • Page 37 Parameter Level (max.) Stereo Audio, Balanced & Impedance Unbalanced Input Gain Potentiometer Adjustment adjustment Range Type Connector Types Stereo Audio, Level (max.) Balanced & Impedance Unbalanced Output Type Connector Types AutoPatch reserves the right to modify its products and their specifications without notice. Component Video &...

  • Page 38: Chapter 5 - Rgbhv/Hd-15 & Stereo Models

    RGBHV/HD-15 & Stereo Models Applicability Notice This chapter contains specific information for the following Precis RGBHV/HD-15 & Stereo Models (3-Term) Front Control Panel P37-0404-844 P37-0408-844 P37-0804-844 P37-0808-844 * The RGBHV/HD-15 and Stereo Model comes in a variety of configurations. For information on model configurations not listed, contact your authorized AutoPatch Dealer.

  • Page 39: Product Specifications

    RGBHV/HD-15 & Stereo Product Specifications Figure 26: Front view of Precis Note: The number of input and output keys vary depending on the configuration. Figure 27: Rear view of Precis Product Specifications For General and AC Power Specifications, see page 3. Applies to Precis RGBHV/HD-15 &...
  • Page 40 Parameter Video Level (RGB) (max.) Input Impedance (RGB) Level (HV) (max.) Impedance (HV) Return Loss Connector Type Video Level (RGB) (max.) Output Impedance (RGB) Level (HV) Impedance (HV) Connector Type Parameter Frequency Response Stereo Audio, Unbalanced THD + Noise Throughput Crosstalk (adjacent channel) Signal to Noise Ratio...

  • Page 41: Chapter 6 - Control Panel Operations

    Control Panel Operations Figure 28 features a typical Precis on your model may vary depending on the configuration. Level Keys Command Keys Rack Ears Figure 28: An 8x8 control panel on a Precis Key Functions Status Key: Places panel in Status Mode. Used to query the system for signal routing information and switch verification.

  • Page 42: Executing A Test Switch

    Executing a Test Switch Both Audio and Video Level Keys: When both keys are illuminated, both levels are selected, and audio and video signals are simultaneously routed. Input and Output Keys: Selects inputs or outputs. Used to enter the password while in Lock Mode.

  • Page 43: Executing & Disconnecting Switches

    3. Press the Take Key. All the illuminated keys turn off. Input 1 is disconnected from all the outputs on both levels. If all the illuminated keys on the panel do not turn off, or if the Cancel Key flashes, the command was not successful. Press the Cancel Key to clear. Regardless of the system response, execute the test switch.
  • Page 44 Executing Switches Executing Switches When executing a switch with one output, either the Input Key or the Output Key may be selected first. To route an input to multiple outputs, the Input Key must be selected before the Output Key. This example routes Input 2 to Output 1 on both levels.
  • Page 45 Select the outputs that you want to disconnect and then press the Take Key. Any output keys that remain illuminated are still connected. To disconnect a single switch: (Input 4 is routed to Output 1 on the Video Level) 1. Press the Video Level Key. The Video Level Key is the only key illuminated.

  • Page 46: Verifying Signal Status

    Verifying Signal Status Verifying Signal Status You can verify signal status to confirm that a switch has executed correctly, or that multiple outputs are correctly routed. An output can only receive a signal from one input; so verifying the status of an output will only illuminate the key of its one current input.

  • Page 47: Locking & Unlocking

    To verify the status of an output: (For the following example, Output 3 must be receiving a signal from Input 1 on the Video Level). 1. Press the Status Key. The Status Key illuminates, indicating the system is in Status Mode. 2.
  • Page 48 Locking & Unlocking For the following examples, the password is “ 1 3 1 2 2” using Input Keys. To lock the control panel 1. Press the Lock Key. The Lock Key flashes for 10 seconds. You must enter the password before the Lock Key stops flashing.

  • Page 49: Chapter 7 - Bcs Serial Control Protocol

    BCS Serial Control Protocol AutoPatch has developed a command language, BCS (Basic Control Structure), for operating the system through an external device and for diagnosing problems. The Precis uses a subset of this language for switching, disconnecting, and verifying status of commands. BCS command lines are entered into a terminal emulation program (e.g., Windows HyperTerminal) from an external control device which sends commands to the system.

  • Page 50: Bcs Command Table

    BCS Command Table BCS Command Table The table below shows BCS command characters (keys) used to generate control commands, their functions, and short function descriptions. Function Initiates a Change (Execute switch) command; this must precede the Change level, input, and output specification Initiates a Disconnect switch command;...

  • Page 51: Generating Commands (Execute, Disconnect, Status)

    Command lines begin with the applicable command character, followed by the characters and numbers indicating levels, inputs, and outputs. Command lines must always end with “T” (Take) command, which tells the system to execute the command. Example of a command line: CL1I2O3T (C)Change on(L1) Level 1,(I2)Input 2 to(O3) Output 3, (T) Take to execute the command.

  • Page 52: Disconnect Commands

    Generating Commands (Execute, Disconnect, Status) Example: CI2O3T Change on both levels, (I2O3) Input 2 to Output 3, (T) Take to execute the command. Disconnect Commands Disconnect command lines begin with “D” and specify an input or output, followed by the Take command. Example: DL2O3T (DL2) Disconnect on Level 2, (O3) Output 3, (T)Take to execute the command.

  • Page 53: Command Line Responses

    Command Line Responses Command characters and numbers appear on the screen when the system accepts them. A command line has successfully executed when the entered “T” command appears. If a command or number is not accepted, a different character appears and the command is not executed.
  • Page 54 Executing a Test Switch All command characters appear when accepted by the system. When a command is successfully executed, all of the characters appear as entered. If a command character or a number is not accepted, a different character appears indicating that the command did not execute.

  • Page 55: Appendix A - Troubleshooting & Technical Support

    Troubleshooting & Technical Support Troubleshooting a Test Switch If the test switch did not execute correctly: Start with . . . Check the power indicator on the front of the enclosure. If it is not illuminated, check the power switches and the power cords on the enclosure and on the source and destination devices.

  • Page 56: Technical Support

    Technical Support Follow up with . . . Check all input and output cable connections on the rear of the enclosure and on the devices to ensure all connections are correct and secure. Attempt the switch again. Isolate source and destination equipment and cable problems by patching around the switcher using barrel connectors to check the overall signal path.

  • Page 57: Autopatch Statement Of Warranty

    AutoPatch Statement of Warranty Warranty. AutoPatch, a division of X Washington, warrants that its products will be free of defects in materials and manufacture at the time of sale and will remain in good working order for a period of five (5) years following the date of the original sales invoice from AutoPatch.
  • Page 58 AutoPatch Statement of Warranty Disclaimer of Other Warranties. The warranties contained in Section 1 are the exclusive warranties given by AutoPatch and supersede any prior, contrary or additional representations, whether oral or written. AUTOPATCH DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES – WHETHER EXPRESS, IMPLIED, OR STATUTORY –...
  • Page 59 No Modifications. This warranty may not be modified except in writing by an authorized AutoPatch officer. Severability. If any provision of this warranty is found to be invalid or unenforceable, then the remainder shall have full force and effect, and the invalid provision shall be partially enforced to the maximum extent permitted by law to effectuate the purpose of the agreement.

  • Page 60: Autopatch Service & Returns Policy

    AutoPatch Service & Returns Policy Service AutoPatch products are to be serviced only by AutoPatch authorized service agents. Return Authorizations Except for warranty claims, merchandise will not be accepted for return or exchange after the first thirty (30) days following the invoice date. Returned items must be shipped prepaid and insured in their original packing containers (if possible).

  • Page 61: Replacement Policies And Procedures

    AutoPatch Service & Returns Policy the carrier is complete. Therefore, claims for damages and shortages must be filed with the transporting company by the receiving company in accordance with the transporting company’s procedures. Visible damage and shortages must be noted on the freight bill;...

  • Page 62: Special Notice

    3. Repaired or replaced part(s) will be warranted for the remainder of the original system warranty, or we will extend the original warranty period by the period of verifiable downtime, whichever provides the greatest benefit. Following warranty expiration: 1. Call your AutoPatch Dealer, area representative, or the AutoPatch customer service department with a description of the problem.

  • Page 63: Index

    Index AC line conditioner 5 airflow restriction 4 applicability notices Component Video & Stereo Models 24 RGBHV/HD-15 & Stereo Models 29 Standard Video & Stereo Models 18 S-Video & Stereo Models applying power Caution 5 circuit overloading 5 grounding/earthing 5 sequence 6 to the Precis ASCII 1, 40...
  • Page 64 Index disconnecting switches HD-15 pinout 10 BCS commands 43 humidity 3 control panel 35-36 HyperTerminal 15, 40 ears, rack 7 icon legend 1 earthing/grounding 5 installation, enclosure email, technical support 47 enclosure Caution 4 clearance 5 environmental recommendations 4 front view 7 rack installation 7 key functions specifications 3...
  • Page 65 RMA (Return Materials surge protector 5 Authorization) 51 S-Video & Stereo Models RS-232 serial port 14 rubber feet 6 safety information ii S-Video connector, Caution 9 serial number 47 switch(es) serial port settings 15 Service & Returns Policy 51 shipping boxes 3 damage 3 damage claims 51...
