  • Page 1 SmartHandle SmartIntego Manual 28.10.2020...

  • Page 2: Table Of Contents

    Contents SmartHandle SmartIntego (Manual) 2 / 160 Contents General safety instructions........................ 6 Product specific safety notices ...................... 9 Meaning of the text formatting ...................... 12 Intended use ............................... 13 General information .......................... 14 Designs ................................  16 Prerequisites.............................. 17 Mechanical Override (MO)......................... 21 Profiles.................................. 21 Fastening................................ 22 6.4.1 RRMO .............................. 23 6.4.2 RMO .............................. 24 Distances and door thicknesses...................... 25...
  • Page 3 Contents SmartHandle SmartIntego (Manual) 3 / 160 8.1.5 Snap-in WP............................ 41 8.1.6 Snap-in diagrams......................... 43 8.1.7 Restore storage mode for Snap-in.................. 44 Snap-in DoorMonitoring .......................... 45 8.2.1 Contents of packaging...................... 45 8.2.2 Tools required .......................... 45 8.2.3 Installation instructions SnapIn....................  45 8.2.4 Assembly Snap-In Door Monitoring ...................
  • Page 4 Contents SmartHandle SmartIntego (Manual) 4 / 160 8.8.5 Conventional fastening system, including Swiss Round MO WP...... 93 8.8.6 Diagrams for conventional fastening system.............. 96 8.8.7 Restore storage mode for SwissRound MO.............. 97 Scandinavian Oval ............................ 97 8.9.1 Contents of packaging....................... 97 8.9.2 Tools required .......................... 98 8.9.3 Installation instructions......................
  • Page 5 Contents SmartHandle SmartIntego (Manual) 5 / 160 16.7 Disassembling DoorMonitoring components ................ 154 16.8 Restore storage mode for RRMO...................... 155 16.9 Restore storage mode for RMO...................... 155 Accessories .............................. 156 17.1 Battery set .............................. 156 17.2 Sleeves................................ 156 17.3 Handles................................ 156 17.4 Covers ................................ 156 Technical specifications ........................

  • Page 6: General Safety Instructions

    Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in- correctly programmed components. SimonsVoss Technologies GmbH is not liable for the consequences of blocked access such as access to in- jured or endangered persons, material damage or other damage!
  • Page 7 This product communicates wirelessly. Metallic surfaces can greatly reduce the range of the product. Do not mount or place the product on or near metallic surfaces.  NOTE Intended use SimonsVoss-products are designed exclusively for opening and closing doors and similar objects. Do not use SimonsVoss products for any other purposes. ...
  • Page 8 Only trained personnel may install and commission the product.  Incorrect installation SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon- ents due to incorrect fitting or installation. Modifications or further technical developments cannot be excluded and may be implemented without notice.

  • Page 9: Product Specific Safety Notices

    Material damage through drilling error When you drill, you can cause damage to the door or the product if unsuitable tools are used. The SimonsVoss Technologies GmbH accepts no responsibility for material damage due to drilling errors. Observe safety instructions on drill.
  • Page 10 2. Product specific safety notices SmartHandle SmartIntego (Manual) 10 / 160 Loss of the precise guidance of the handle It may be difficult to install on mortise locks with a retaining nut. Do not mechanically alter the locking nut. The handle would then lose its precise guidance. ...
  • Page 11 2. Product specific safety notices SmartHandle SmartIntego (Manual) 11 / 160 Stiffness of the SmartHandle due to stiff mortice lock If the mortice lock is stiff, the SmartHandle will also be stiff. Check that the mortice lock is free-moving.  Fitting error or incorrect order If you make a mistake in measuring the door and order a SmartHandle, the SmartHandle will not fit.

  • Page 12: Meaning Of The Text Formatting

    3. Meaning of the text formatting SmartHandle SmartIntego (Manual) 12 / 160 3 Meaning of the text formatting This documentation uses text formatting and design elements to facilitate understanding. The table explains the meaning of possible text formatting: Example button Example checkbox Example...

  • Page 13: Intended Use

    SmartIntego interface. The integrator is usually a manufacturer of building management software (access control software, EMEA solution, fire alarm system, etc.), in which the SimonsVoss SmartIntego locking devices are also managed. It develops the interface to his system independently and is also responsible for the connected functions.

  • Page 14: General Information

    5. General information SmartHandle SmartIntego (Manual) 14 / 160 5 General information The SI:SmartHandle is an electronic fitting that can be used to open and close doors. Electronic fittings of the SI:SmartHandle series are available in the following models: Fastening Variants information Mounting on doors...
  • Page 15 5. General information SmartHandle SmartIntego (Manual) 15 / 160 Fastening Variants information Mounting on metal frame doors  Designed for a handle lock with Euro  profile or Swiss Round Without mechanical Metal frame mounting override The outer side can only be operated ...

  • Page 16: Designs

    6. Designs SmartHandle SmartIntego (Manual) 16 / 160 6 Designs The following section describes the available variants or options of the SI:SmartHandle in detail. NOTE Avoidance of incorrect orders through the order placement guide SmartIntego components offer a wide variety of combinations. Not every combination makes sense and is actually available.

  • Page 17: Prerequisites

    6. Designs SmartHandle SmartIntego (Manual) 17 / 160 6.1 Prerequisites These distances depend on the design of the door (door-specific).
  • Page 18 6. Designs SmartHandle SmartIntego (Manual) 18 / 160 Distance lock fol- lower face (out- side) to the outside Interior side Exterior side door leaf The SI:SmartHandle is suitable for the following distances, depending on the fastening: Door thick- Door thick- Door thick- Fastening ness S...
  • Page 19 6. Designs SmartHandle SmartIntego (Manual) 19 / 160 Door thick- Door thick- Door thick- Fastening ness S ness M ness L Conventional fixing for mortise locks with Scandinavian Oval cylinder (with/without min. 1 mm min. 1 mm min. 1 mm mechanical override) (see Fastening [  22] Distance lock fol-...
  • Page 20 6. Designs SmartHandle SmartIntego (Manual) 20 / 160 Door thick- Door thick- Door thick- Fastening ness S ness M ness L Conventional fastening with certification ac- cording to:  no minimum no minimum no minimum  thickness thickness thickness PAS24 ...

  • Page 21: Mechanical Override (Mo)

    6. Designs SmartHandle SmartIntego (Manual) 21 / 160 Door thick- Door thick- Door thick- Fastening ness S ness M ness L Escutcheon fastening (with/without  mechanical override) Metal frame fastening (with/without  max. 36 mm max. 56 mm max. 76 mm mechanical override) (see Fastening [  22]...
  • Page 22 6. Designs SmartHandle SmartIntego (Manual) 22 / 160 Euro profile cylinder Swiss Round Scandinavian Oval 6.4 Fastening You can use the following fastening variants: Fastening No additional drill holes are required Snap-in [  37]  on the door. You attach the Snap-in SI:SmartHandle through the square Snap-in DoorMonitoring [...
  • Page 23 6. Designs SmartHandle SmartIntego (Manual) 23 / 160 6.4.1 RRMO Use the RRMO version of the SmartHandle 3062 if you want to mount a SmartHandle 3062 on a metal frame door with a lock with a large distance Two adapter plates for mounting on metal frame doors (RR) are included. The recesses allow mechanical override (MO).
  • Page 24 6. Designs SmartHandle SmartIntego (Manual) 24 / 160 6.4.2 RMO Use the RMO (escutcheon mounting with mechanical override) version of the SmartHandles 3062 if: mechanical override (MO) with Euro profile (PC) or Swiss Round profile  (SR) is desired and four escutcheon holes for fixing the RMO version in the door (DIN 18251) ...

  • Page 25: Distances And Door Thicknesses

    6. Designs SmartHandle SmartIntego (Manual) 25 / 160 6.5 Distances and door thicknesses...

  • Page 26: Profile Cylinder (Pc)

    6. Designs SmartHandle SmartIntego (Manual) 26 / 160 6.5.1 Profile cylinder (PC) 6.5.1.1 SnapIn fastening MO and ES1/SKG/ Standard ES1/SKG/PAS24 PAS24 S: 39 - 60 mm Door M: 59 - 80 mm thickness L: 79–100 mm 70 mm  72 mm  Cannot be com- Cannot be com- Cannot be com- 75 mm...
  • Page 27 6. Designs SmartHandle SmartIntego (Manual) 27 / 160 6.5.1.3 Escutcheon installation MO and ES1/SKG/ Standard ES1/SKG/PAS24 PAS24 S: 40 - 53 mm S: Like standard Door M: 52 - 73 mm M: Like standard thickness L: 72 - 93 mm L: Like standard 72 mm ...

  • Page 28: Swiss Round (Sr)

    6. Designs SmartHandle SmartIntego (Manual) 28 / 160 6.5.2 Swiss round (SR) 6.5.2.1 SnapIn fastening MO and ES1/SKG/ Standard ES1/SKG/PAS24 PAS24 S: 39 - 60 mm Door M: 59 - 80 mm thickness Cannot be com- Cannot be com- Cannot be com- L: 79–100 mm bined with SnapIn bined with SnapIn...

  • Page 29: Scandinavian Oval (So)

    6. Designs SmartHandle SmartIntego (Manual) 29 / 160 6.5.2.4 Metal frame mounting MO and ES1/SKG/ Standard ES1/SKG/PAS24 PAS24 S: 40 - 53 mm S: Like standard Door M: 52 - 72 mm M: Like standard thickness L: 71 - 91 mm L: Like standard 70 mm ...

  • Page 30: Es1/Skg/Pas24

    6. Designs SmartHandle SmartIntego (Manual) 30 / 160 6.5.3.3 Escutcheon installation SI:SmartHandle are not available for mounting on Scandinavian Oval escutcheons. 6.5.3.4 Metal frame mounting SI:SmartHandle are not available for mounting on Scandinavian Oval metal frames. 6.6 ES1/SKG/PAS24 You can also get the SI:SmartHandle with the following certifications (see https://www.simons-voss.com/de/zertifikate.html SKG certification (SKG**) ...

  • Page 31: Spindle

    6. Designs SmartHandle SmartIntego (Manual) 31 / 160 6.8 Spindle You can use the following square sizes: Approval for fire-resist- Square size ant doors 7 mm in F8 design suitable for 8 mm fire protection doors with sleeve attached to 8 mm (not ...

  • Page 32: Backplate Width/Wide

    6. Designs SmartHandle SmartIntego (Manual) 32 / 160 6.9 Backplate width/wide You can choose between the following shield widths for the cover: Narrow backplate 41 mm Wide backplate 53 mm SmartHandle with one of the following options is slightly larger due to additional mounting plates: ...

  • Page 33: Handle Variants

    6. Designs SmartHandle SmartIntego (Manual) 33 / 160 Sensors within the DM-SI:SmartHandle monitor the opening status of the door. The following door statuses are logged: Door open/closed  Door unlocked/securely locked  Alarm  All changes are logged in the access list, including the transponder ID, date and time, which the locking system operator or a security officer can then upload and evaluate if necessary.

  • Page 34: Surface Finishes

    6. Designs SmartHandle SmartIntego (Manual) 34 / 160 L-shaped U-shape Round bended, anti- bacterial coated (like uncoated version) (like uncoated version) The SKG version is supplied with a thumb-turn on the inside. All handle variants are also available as accessories. 6.12 Surface finishes Select the upper surface for your SI:SmartHandle: Brushed stainless steel...

  • Page 35: Escape&Return Function

    6. Designs SmartHandle SmartIntego (Manual) 35 / 160 6.14.3 Escape&Return function SmartHandles with Escape&Return function allow opening without the need to press an identification medium again, shortly after the door was closed. The function is activated by selecting the corresponding check box and the specification of a time window in the integrator system.

  • Page 36: Storage

    7. Storage SmartHandle SmartIntego (Manual) 36 / 160 7 Storage IMPORTANT Freeze mode due to separate storage If you store the housing halves separately for a longer period of time (more than a week), SmartHandle may switch to freeze mode. Only separate the two halves of SmartHandle when installing it.

  • Page 37: Installation (Manual)

    8. Installation (manual) SmartHandle SmartIntego (Manual) 37 / 160 8 Installation (manual) Some variants are supplied screwed into temporary spacer sleeves, so that the SmartHandles can be programmed in the packaging. This will ensure that the metal surfaces touch. Contact needs to be established in this way to programme SmartHandle.

  • Page 38: Snap-In

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. In the case of fire retardant doors, you must ensure that the supplied ...
  • Page 39 8. Installation (manual) SmartHandle SmartIntego (Manual) 39 / 160 4. Outer fitting 5. handle fastener piece 6. Door lock (not included in the scope of supply) 7. Snap-in mechanism 8. Inside fitting 9. Screw 10. Inside handle 11. Inside hexagon screw 12.
  • Page 40 8. Installation (manual) SmartHandle SmartIntego (Manual) 40 / 160 12. Push the inside fitting (8) until it is flush with the door. 13. Remove the cables from the snap-in mechanism (7), so that they hang freely out of the door and are not damaged (Diagram 7). 14.

  • Page 41: Snap-In Wp

    8. Installation (manual) SmartHandle SmartIntego (Manual) 41 / 160 31. Push the cover (2) onto the outer fitting (4), so that it is flush with the door. The cover is not symmetrical; look carefully at the marking to en- sure correct positioning (Diagram 10). 32.
  • Page 42 8. Installation (manual) SmartHandle SmartIntego (Manual) 42 / 160 14. Check that the outer handle (3) can turn easily; if it does not, there may be a problem with the mortise lock (6) or the handle may have been fit- ted incorrectly.

  • Page 43: Snap-In Diagrams

    8. Installation (manual) SmartHandle SmartIntego (Manual) 43 / 160 8.1.6 Snap-in diagrams Figure 2: Figure 3: Handle fastener piece Handle fastener piece open Figure 5: Figure 4: Fastener piece - correct position for Handle fastener piece closed the handle fastener piece when closed Figure 6: Figure 7:...

  • Page 44: Restore Storage Mode For Snap-In

    8. Installation (manual) SmartHandle SmartIntego (Manual) 44 / 160 Figure 8: Figure 9: Figure 10: Tab. 1: Diagrams showing installation 8.1.7 Restore storage mode for Snap-in 1. Disconnect the 3-pole cable from the inside fitting to the 3-pole cable from the outer fitting. If necessary, also disconnect the LockNode cable from the inside fitting.

  • Page 45: Snap-In Doormonitoring

    8. Installation (manual) SmartHandle SmartIntego (Manual) 45 / 160 8.2 Snap-in DoorMonitoring 8.2.1 Contents of packaging 2 x inlays  2 x covers  1 x outer fitting  1 x inside fitting  1 x outer handle (including lock ring) ...

  • Page 46: Assembly Snap-In Door Monitoring

    46 / 160 The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. In the case of fire retardant doors, you must ensure that the supplied ...
  • Page 47 8. Installation (manual) SmartHandle SmartIntego (Manual) 47 / 160 8.2.4.1 Components SmartHandle components (SnapIn) Inlay Outer cover Outside handle Outer fitting Handle fastener piece Lock (not included) Inside fitting Inside handle Headless screw for inside handle 10 Inside cover Inlay Door Monitoring components (SnapIn) Installation tool for cable Fastening screw sensor...
  • Page 48 8. Installation (manual) SmartHandle SmartIntego (Manual) 48 / 160 8.2.4.2 Step 1: Installing the fastening screw sensor NOTE The fastening screw sensor may not be in locked final position during in- stallation. The fastening screw sensor must be in the displayed "INSTALL- ATION"...
  • Page 49 8. Installation (manual) SmartHandle SmartIntego (Manual) 49 / 160 Follow the steps below to move the cone: 1. Ensure that the bolt sensor (C) is placed firmly on the installation tool (D). 2. Simply release the outer ring segment from point X (see image above) by turning in the direction of the arrow.
  • Page 50 8. Installation (manual) SmartHandle SmartIntego (Manual) 50 / 160 2. Push the bolt sensor into the profile cylinder opening via the installation tool (D) until it stops. The square opening in the bolt sensor must always point to the right towards the door hinges.
  • Page 51 8. Installation (manual) SmartHandle SmartIntego (Manual) 51 / 160 4. Position handle fastener piece (5) on the side which will later face the door, as in the diagram below, and fasten with a spanner in a clockwise direction (about 75º until you feel resistance). -45°...
  • Page 52 8. Installation (manual) SmartHandle SmartIntego (Manual) 52 / 160 5. Push plug out horizontally, directly beneath the snap-in mechanism, and to the inner side. The outer fitting must be joined together with the inside fitting at the same time by inserting the outer fitting bolt into the inner fitting's snap-in shaft.

  • Page 53: Conventional Fastening

    8. Installation (manual) SmartHandle SmartIntego (Manual) 53 / 160 8.2.4.7 Step 6: Fastening the covers Outer and inside covers are mounted in the same way: 1. Carefully press cover onto the door. Ensure that the cover is positioned flat against the door without a gap and no cables are outside the cover. 2.

  • Page 54: Conventional Fastening System

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. ...
  • Page 55 8. Installation (manual) SmartHandle SmartIntego (Manual) 55 / 160 4. Outer fitting 5. Lock ring 6. Door lock (not included in the scope of supply) 7. Spacing bolt 8. Inside fitting 9. Screws 10. Upper battery 11. Inside handle 12. Inside hexagon screw 13.
  • Page 56 8. Installation (manual) SmartHandle SmartIntego (Manual) 56 / 160 13. Hold the outside handle (3) and use the spanner to rotate the fastener piece (5) about 75° to the right until it fits into position (Figures 4 and 5). If you do not fit it correctly, the handle may come loose again. 14.

  • Page 57: Conventional Fastening System Wp

    8. Installation (manual) SmartHandle SmartIntego (Manual) 57 / 160 28.Check that the outer handle (3) can turn easily; if it does not, there may be a problem with the mortise lock (6) or the handle may have been fit- ted incorrectly. In case of doubt, disassemble components and start again from Step 10.
  • Page 58 8. Installation (manual) SmartHandle SmartIntego (Manual) 58 / 160 7. Mark the drill holes required on the door through the corresponding holes in the inside fitting (8). 8. Remove inside fitting (8) from the door. 9. Drill the 2 holes with a diameter of 8 mm through the door. 10.
  • Page 59 8. Installation (manual) SmartHandle SmartIntego (Manual) 59 / 160 23. Insert the supplied screws (9) through drill holes in the inside fitting (8) from inside the door and fasten to the spacing bolts (7) on the outer fit- ting by hand, using about 5-7 Nm. 24.Insert the upper battery (10) with the positive terminals facing away from the door into the brackets;...

  • Page 60: Diagrams For Conventional Fastening System

    8. Installation (manual) SmartHandle SmartIntego (Manual) 60 / 160 8.3.6 Diagrams for conventional fastening system Figure 2: Figure 3: Handle fastener piece Handle fastener piece open Figure 5: Figure 4: Fastener piece - correct position for Handle fastener piece closed the handle fastener piece when closed Figure 6:...

  • Page 61: Conventional Fastening System Wo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 61 / 160 Fitted to the door: NOTE General instructions: Depending on the handle model, it may not be pos- sible to remove the inlay immediately. In such a case, push the inlay through the opening in the cover and remove the cover. The inlay remains on the handle and cannot be removed until the handle is dismounted.
  • Page 62  The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. In ...

  • Page 63: Conventional Fastening System Wo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 63 / 160 8.4.4 Conventional fastening system WO Key: 1. Inlay 2. Inlay 3. Outside handle 4. Outer fitting 5. Lock ring 6. Door lock (not included in the scope of supply) 7. Spacing bolt 8.
  • Page 64 8. Installation (manual) SmartHandle SmartIntego (Manual) 64 / 160 3. The inlay cannot be fitted on some handles, such as offset handles, when they are already installed. Push the inlay onto the outer handle with the logo facing outwards in such cases. You can do this with most handles.
  • Page 65 8. Installation (manual) SmartHandle SmartIntego (Manual) 65 / 160 20.Insert the 3-pole cable through the cut-out in the lower end of the outer fitting. 21. Push the outer fitting (4) onto the door completely. In doing so, ensure that the inside fitting cable does not get caught or buckled. 22.

  • Page 66: Conventional Fastening System Mo Wp

    8. Installation (manual) SmartHandle SmartIntego (Manual) 66 / 160 36.Push the cover (13) over the inside handle (11). 37. Carefully push the inlay (14) through the opening in the inside cover (13). 38.Push the cover (13) onto the inside fitting (8), so that it is flush with the door.
  • Page 67 8. Installation (manual) SmartHandle SmartIntego (Manual) 67 / 160 4. Push the inside fitting spindle through the retainer slot in the door's mortise lock (6), so that the fitting is flush with the door. Ensure that you do not squash the 2-pole cable when doing so. 5.
  • Page 68 8. Installation (manual) SmartHandle SmartIntego (Manual) 68 / 160 20.Press the electronics module cover lid in the inside fitting carefully out of its bracket and fold back horizontally. Make sure that the electronics are not subject to mechanical load and are not damaged in any other way.

  • Page 69: Diagrams For Conventional Fastening System

    8. Installation (manual) SmartHandle SmartIntego (Manual) 69 / 160 37. Push the cover (2) onto the outer fitting (2), so that it is flush with the door. The cover is not symmetrical; look carefully at the marking to en- sure correct positioning (Diagram 7). 38.Click the inlay (1) carefully into the cover (2).

  • Page 70: Restore Storage Mode For Conventional Fastening System Mo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 70 / 160 8.4.7 Restore storage mode for conventional fastening system MO 1. Disconnect the 3-pole cable from the inside fitting with the 3-pole cable from the outer fitting. If necessary, also disconnect the LockNode cable from the inside fitting.

  • Page 71: Tools Required

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. ...

  • Page 72: Assembly Es1-/Skg-/Pas24 Smarthandle

    8. Installation (manual) SmartHandle SmartIntego (Manual) 72 / 160 8.5.4 Assembly ES1-/SKG-/PAS24 SmartHandle These installation instructions are designed for a standard door with a Euro Profile cylinder door lock already fitted. Old fittings must be fully removed before SI:SmartHandle SmartHandle is installed. NOTE To ensure full functionality, SmartHandle must always be used in combin- ation with an SLP lock.
  • Page 73 8. Installation (manual) SmartHandle SmartIntego (Manual) 73 / 160 Inside handle Headless screw for inside handle 10 Inside cover Inlay X1 Sleeves X2 Screws SKG components Adapter plate for inside fitting Installation key for outer fitting Adapter plate for outer fitting Spacer plate for outer fitting 8.5.4.2 Step 0: Preparing drill holes NOTE...
  • Page 74 8. Installation (manual) SmartHandle SmartIntego (Manual) 74 / 160 8. Re-fit door lock to door. 8.5.4.3 Step 1: Preparing to install the outer fitting 1. Place outer cover (2) loosely onto the outer fitting (4). Notice that the outer cover can only be placed onto the fitting in one direction. The outer cover is positioned flush on the outer fitting but without fastening it.
  • Page 75 8. Installation (manual) SmartHandle SmartIntego (Manual) 75 / 160 NOTE For easier installation, the cover can usually also be slid over the inlay later Step 6: Fastening the covers [  77] in chapter " ". 8.5.4.4 Step 2: Mount adapter plates to outer fitting 1.
  • Page 76 8. Installation (manual) SmartHandle SmartIntego (Manual) 76 / 160 2. Attach outer fitting onto the door from the outside and at the same time feed the end of the installation tool with the plug through the lock to the inside of the door. The three sleeves of the outer fitting construction are fit in the previously drilled holes and the cable of the installation tool protrudes outward from the inside of the door.

  • Page 77: Conventional Fastening System For Doormonitoring

    8. Installation (manual) SmartHandle SmartIntego (Manual) 77 / 160 8.5.4.7 Step 5: Installing the inside handle 1. Position the internal cover (10) on the internal fitting without fastening it. Notice that the cover can only be placed onto the fitting in one direc- tion.

  • Page 78: Tools Required

    You must not strike parts of SI:SmartHandle during installation.  The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool.

  • Page 79: Installation Conventional Fastening Door Monitoring

    8. Installation (manual) SmartHandle SmartIntego (Manual) 79 / 160 No water or moisture must penetrate the door or reach the inner side.  Always use the WP version for moisture. Programme SI:SmartHandle before installing.  SI:SmartHandle may be difficult to fit in mortise locks with a retaining ...
  • Page 80 8. Installation (manual) SmartHandle SmartIntego (Manual) 80 / 160 8.6.4.1 Components SmartHandle components Inlay Outer cover Outer handle, including lock ring Outer fitting Handle fastener piece Lock (not included) Inside fitting Inside handle, including hexagon socket screw Headless screw for inside handle 10 Inside cover Inlay X1 Sleeves...
  • Page 81 8. Installation (manual) SmartHandle SmartIntego (Manual) 81 / 160 Bolt sensor Installation tool for bolt sensor anti-twist mechanism 8.6.4.2 Step 0: Preparing drill holes NOTE Please remove the lock from the door before drilling to prevent it from be- coming damaged! The lock can be reinstalled in the door once you have completed drilling.
  • Page 82 8. Installation (manual) SmartHandle SmartIntego (Manual) 82 / 160 3. Insert fastening screw sensor into the sensor screw hole until it will go no further. A spring mechanism holds the fastening screw sensor in place in the door lock. 8.6.4.4 Step 2: Bolt sensor installation Preparation of the bolt sensor For preparation, the bolt sensor (C) has to be mounted onto the installation tool according to the following illustration:...
  • Page 83 8. Installation (manual) SmartHandle SmartIntego (Manual) 83 / 160 2. Simply release the outer ring segment from point X (see illustration above) by turning in the direction of the arrow. 3. Move the cone parallel to the axial direction to release it. 4.
  • Page 84 8. Installation (manual) SmartHandle SmartIntego (Manual) 84 / 160 Fix anti-twist mechanism in the door lock Introduce the anti-twist mechanism (E) in the rectangular opening of  the bolt sensor until you hear it snap into position. If necessary, the anti- twist mechanism can be slightly pressed together so that it fits through the lock better.
  • Page 85 8. Installation (manual) SmartHandle SmartIntego (Manual) 85 / 160 NOTE For easier installation, the cover can also be pushed over the inlay later in Step 6: Fastening the covers [  86] chapter " ". 8.6.4.6 Step 4: Installation of fittings 1.

  • Page 86: Disassembling Doormonitoring Components

    8. Installation (manual) SmartHandle SmartIntego (Manual) 86 / 160 3. Insert inside handle horizontally into the outer fitting in the desired direc- tion (DIN left or DIN right). The internal handle is placed in the internal fitting without being fastened. 4.

  • Page 87: Additional Info: Doormonitoring Sensor Lock

    1. Download the latest pin assignment configuration for connecting the selected sensor lock. You will find it online in the SimonsVoss Value Ad- ded Resellers Area for registered users. Contact your reseller to down- load the current pin assignment if necessary.
  • Page 88 88 / 160 You can use a multimeter to identify or verify that the sensor lock is connected correctly. However, SimonsVoss Technologies GmbH accepts no liability for damage caused or malfunctions caused as a result The different switching statuses between cables in different door ...

  • Page 89: Swiss Round Mo

    You must not strike parts of the SI:SmartHandle during installation.  The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool.

  • Page 90: Conventional Fastening System, Including Swiss Round Mo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 90 / 160 No water or moisture must penetrate the door or reach the inner side. In  case of moisture, always use the WP version. Programme the SI:SmartHandle before installation!  The SI:SmartHandle may be difficult to fit in mortise locks with a ...
  • Page 91 8. Installation (manual) SmartHandle SmartIntego (Manual) 91 / 160 4. Outer fitting 5. Lock ring 6. Door lock (not included in the scope of supply) 7. Spacing bolt 8. Inside fitting 9. Screws 10. Upper battery 11. Inside handle, including hexagon socket screw 12.
  • Page 92 8. Installation (manual) SmartHandle SmartIntego (Manual) 92 / 160 12. Place handle fastener piece (5) into position (see Figures 2 and 3). 13. Hold the outside handle (3) and use the spanner to rotate the handle fastener piece (5) about 75° to the right until it fits into position (Figures 4 and 5).

  • Page 93: Conventional Fastening System, Including Swiss Round Mo Wp

    8. Installation (manual) SmartHandle SmartIntego (Manual) 93 / 160 28.Insert the upper battery (10) with the positive terminals facing away from the door into the brackets; in doing so, insert the batteries under the black retaining collar first. Use clean gloves free of fat or grease to handle batteries.
  • Page 94 8. Installation (manual) SmartHandle SmartIntego (Manual) 94 / 160 1. Optional: handles, escutcheons, fittings and other door furniture fitted to the door are to be removed. 2. SmartHandle is partly assembled when supplied; see "Disassembly". 3. Optional: In a lock with an 8.5 mm or 10 mm spindle, push the corres- ponding sleeve (8 mm -->...
  • Page 95 8. Installation (manual) SmartHandle SmartIntego (Manual) 95 / 160 18. Connect the 2-pole cable from the outer fitting to the 3-pole cable from the inside fitting. This cable can only be inserted in one direction. Do not pull on the cables while doing so; just carefully secure the plug-in con- nection into position.

  • Page 96: Diagrams For Conventional Fastening System

    8. Installation (manual) SmartHandle SmartIntego (Manual) 96 / 160 33. Carefully push the inlay (14) through the opening in the inside cover (13). 34.Push cover (13) onto the inside fitting (8), so that it is flush with the door. The cover is not symmetrical; look carefully at the marking to en- sure correct positioning (Diagram 7).

  • Page 97: Restore Storage Mode For Swissround Mo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 97 / 160 Figure 6: Figure 7: Tab. 4: Diagrams showing installation 8.8.7 Restore storage mode for SwissRound MO 1. Disconnect the 3-pole cable from the inside fitting to the 3-pole cable from the outer fitting. If necessary also disconnect the cable of the LockNode from the inside fitting.

  • Page 98: Tools Required

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. ...

  • Page 99: Conventional Fastening System Scandinavian Oval

    8. Installation (manual) SmartHandle SmartIntego (Manual) 99 / 160 Conventional fastening system: When fitting the handle into position on  the door with the two screws, make sure that the electronics are not subject to mechanical load and are not damaged in any other way. 8.9.4 Conventional fastening system Scandinavian Oval Keys: 1.
  • Page 100 8. Installation (manual) SmartHandle SmartIntego (Manual) 100 / 160 16. Inlay 17. Inlay Installation: 1. Optional: handles, escutcheons, fittings and other door furniture fitted to the door are to be removed. 2. The SI:SmartHandle is partly assembled when supplied; see Disas- sembly.
  • Page 101 8. Installation (manual) SmartHandle SmartIntego (Manual) 101 / 160 13. Push the outer fitting (4) onto the door, making sure that the cable does not get caught or damaged in any other way. 14. Hold the outer fitting (4) firmly and then press the adapter plate (9) against the door from the inside.
  • Page 102 8. Installation (manual) SmartHandle SmartIntego (Manual) 102 / 160 27. Check that the outer handle (3) can turn easily; if it does not, there may be a problem with the mortise lock (8) or the handle may have been fit- ted incorrectly.

  • Page 103: Conventional Fastening System For Scandinavian Oval Dp

    8. Installation (manual) SmartHandle SmartIntego (Manual) 103 / 160 8.9.5 Conventional fastening system for Scandinavian Oval DP Key: 1. Inlay 2. Inlay 3. Outside handle 4. Outer fitting 5. Handle fastener piece 6. Drilling protection plate 7. Adapter plate for outer side 8.
  • Page 104 8. Installation (manual) SmartHandle SmartIntego (Manual) 104 / 160 Installation: 1. Optional: handles, escutcheons, fittings and other door furniture fitted to the door are to be removed. 2. SI:SmartHandle is partly assembled when supplied; see "Disassembly". 3. Push inlay (1) onto the outer handle (3). Depending on the handle model, it may not be possible to fit it once the handle is installed.
  • Page 105 8. Installation (manual) SmartHandle SmartIntego (Manual) 105 / 160 15. Hold the outer fitting (4) firmly and then press the inner side adapter plate (10) against the door from the inside. 16. Use the four screws (11) to join the inner side adapter plate (10) with the outer fitting (4) from the inside, ensuring that the fitting can still move freely.

  • Page 106: Conventional Fastening System For Scandinavian Oval Mo

    8. Installation (manual) SmartHandle SmartIntego (Manual) 106 / 160 28.Check that the outer handle can turn easily; if it does not, there may be a problem with the mortise lock (9) or the handle may have been fitted incorrectly. In case of doubt, disassemble components and start again from Step 4.

  • Page 107: Diagrams For Scandinavian Oval

    8. Installation (manual) SmartHandle SmartIntego (Manual) 107 / 160 8.9.7 Diagrams for Scandinavian Oval Figure 2: Figure 3: Handle fastener piece Handle fastener piece open Figure 5: Figure 4: Fastener piece - correct position for Handle fastener piece closed the handle fastener piece when closed Figure 6: Figure 7:...

  • Page 108: Steel Frame With/Without Mo (Rrmo)

    8. Installation (manual) SmartHandle SmartIntego (Manual) 108 / 160 Conventional fastening [  53]  Conventional fastening system WO [  61]  Swiss Round MO [  89]  Scandinavian Oval [  97]  8.11 Steel frame with/without MO (RRMO) The cable connector is located on the inside for all variants. 8.11.1 Contents of packaging 2 x inlays ...

  • Page 109: Tools Required

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. In ...

  • Page 110: Installation

    8. Installation (manual) SmartHandle SmartIntego (Manual) 110 / 160 When installing SmartHandle, you must ensure that the cable does not  get caught or fitted too tightly to the door. Conventional fastening system, including MO: When fitting the handle  into position on the door with the two screws, make sure that the electronics are not subject to mechanical load and are not damaged in any other way.
  • Page 111 8. Installation (manual) SmartHandle SmartIntego (Manual) 111 / 160 3. Turn the drilling template 180 degrees and align the drilling template again. 4. Pierce the middle hole in the door with a pointed object (pin). 5. Remove the door lock. 6.
  • Page 112 8. Installation (manual) SmartHandle SmartIntego (Manual) 112 / 160 Prepare the cable 1. Use the opening tool to push the foam insert to the side. 2. Guide the cable past the foam insert and down out of the fitting without kinking it.
  • Page 113 8. Installation (manual) SmartHandle SmartIntego (Manual) 113 / 160 8.11.4.3 Step 2: Mounting the outside handle Attach the outside handle 1. Make sure that the slide of the cover is in the position shown. 2. Clip the cover into the inlay. 3.
  • Page 114 8. Installation (manual) SmartHandle SmartIntego (Manual) 114 / 160 Secure the outside handle 1. Put the retaining ring on the inside of the outside handle. 2. Turn the retaining ring clockwise by about 75°. The outside handle is secured. 8.11.4.4 Step 3: Mounting the outside fitting adapter plate 1.
  • Page 115 8. Installation (manual) SmartHandle SmartIntego (Manual) 115 / 160 4. Screw the sleeve nuts onto the adapter plate. Outside fitting adapter plate is mounted. 8.11.4.5 Step 4: Mounting the outside fitting Insert the prepared outer fitting with the adapter plate into the prepared ...
  • Page 116 8. Installation (manual) SmartHandle SmartIntego (Manual) 116 / 160 Outer fitting is mounted. 8.11.4.6 Step 5: Mounting the inside fitting 1. Screw the inserted external fitting from the inside of the door to the in- ternal fitting adapter plate. 2. Connect the extension cables (only for M and L version). 3.
  • Page 117 8. Installation (manual) SmartHandle SmartIntego (Manual) 117 / 160 6. Screw on the blank cylinder. The inside fitting is mounted. 8.11.4.7 Step 6: Screw on the inside fitting 1. Open the battery compartment.
  • Page 118 8. Installation (manual) SmartHandle SmartIntego (Manual) 118 / 160 2. Remove the uppermost battery. 3. Screw on the inside fitting.
  • Page 119 8. Installation (manual) SmartHandle SmartIntego (Manual) 119 / 160 4. Insert the battery back into the compartment. 5. Close the battery compartment again. The inside fitting is screwed on.
  • Page 120 8. Installation (manual) SmartHandle SmartIntego (Manual) 120 / 160 8.11.4.8 Step 7: Mounting the inside handle Attach the inside handle 1. Make sure that the slide of the cover is in the position shown. 2. Clip the cover into the inlay. 3.

  • Page 121: Escutcheon Fixing With/Without Mo (Rmo)

    8. Installation (manual) SmartHandle SmartIntego (Manual) 121 / 160 Secure the inside handle Screw in the set screw of the inside handle.  The inside handle is secured. SmartHandle is mounted. 8.12 Escutcheon fixing with/without MO (RMO) The cable connector is located on the inside for all variants.

  • Page 122: Contents Of Packaging

    8. Installation (manual) SmartHandle SmartIntego (Manual) 122 / 160 8.12.1 Contents of packaging 2 x inlays  2x cover (shield)  1 x outer fitting  1 x outer fitting adapter plate  4x special sleeve nut with square head for adapter plate external fitting ...

  • Page 123: Tools Required

     The two inlays in the cover are locked into position with a clip  mechanism. These may only be removed using the SimonsVoss installation tool. No water or moisture must penetrate the door or reach the inner side. In ...

  • Page 124: Installation

    8. Installation (manual) SmartHandle SmartIntego (Manual) 124 / 160 8.12.4 Installation NOTE Cable through lock cylinder opening If the locking cylinder opening is very small, the cables are more difficult to install. In this case, slightly enlarge the locking cylinder opening. ...
  • Page 125 8. Installation (manual) SmartHandle SmartIntego (Manual) 125 / 160 ü SmartHandle programmed. 1. Loosen the screw connection that connects the inside and outer fittings. 2. Dispose of the screw and the plastic sleeve.
  • Page 126 8. Installation (manual) SmartHandle SmartIntego (Manual) 126 / 160 3. Disconnect the three-pin cable that connects the inside fitting and the outer fitting. 4. If necessary, also disconnect the cable of the LockNode of the inside fit- ting. Halves are separated. Attaching damper foams Glue the damper foams to the fittings as shown.
  • Page 127 8. Installation (manual) SmartHandle SmartIntego (Manual) 127 / 160 8.12.4.2 Step 2: Mounting the outside handle Attach the outside handle 1. Make sure that the slide of the cover is in the position shown. 2. Push the cover (shield) together with the cover onto the fitting. 3.
  • Page 128 8. Installation (manual) SmartHandle SmartIntego (Manual) 128 / 160 Secure the outside handle 1. Put the retaining ring on the inside of the outside handle. 2. Turn the retaining ring clockwise by about 75°. The outside handle is secured.
  • Page 129 8. Installation (manual) SmartHandle SmartIntego (Manual) 129 / 160 8.12.4.3 Step 3: Mounting the outside fitting adapter plate 1. Insert the special sleeve nut through the adapter plate. 2. Turn the adapter plate over.
  • Page 130 8. Installation (manual) SmartHandle SmartIntego (Manual) 130 / 160 3. Screw the adapter plate onto the outer fitting so that the special sleeve nuts cannot fall out. 4. Screw the sleeve nuts onto the adapter plate. 5. If necessary, connect the extension cables (M and L version). Outside fitting adapter plate is mounted.
  • Page 131 8. Installation (manual) SmartHandle SmartIntego (Manual) 131 / 160...
  • Page 132 8. Installation (manual) SmartHandle SmartIntego (Manual) 132 / 160 Outer fitting is mounted.
  • Page 133 8. Installation (manual) SmartHandle SmartIntego (Manual) 133 / 160 8.12.4.5 Step 5: Mounting the inside fitting 1. If necessary, insert your locking cylinder without bending the cables.
  • Page 134 8. Installation (manual) SmartHandle SmartIntego (Manual) 134 / 160 2. Screw the inserted external fitting from the inside of the door to the in- ternal fitting adapter plate. 3. Lead the cables of the outside fitting to the inside.
  • Page 135 8. Installation (manual) SmartHandle SmartIntego (Manual) 135 / 160 4. Place the inside fitting on the plate. The inside fitting is in place. 8.12.4.6 Step 6: Screw on the inside fitting 1. Open the battery compartment.
  • Page 136 8. Installation (manual) SmartHandle SmartIntego (Manual) 136 / 160 2. Remove the uppermost battery.
  • Page 137 8. Installation (manual) SmartHandle SmartIntego (Manual) 137 / 160 3. Screw on the inside fitting.
  • Page 138 8. Installation (manual) SmartHandle SmartIntego (Manual) 138 / 160 4. Reinsert the battery and screw the cylinder tight. 5. Close the battery compartment again.
  • Page 139 8. Installation (manual) SmartHandle SmartIntego (Manual) 139 / 160 6. Connect all cables. The inside fitting is screwed on. 8.12.4.7 Step 7: Mounting the inside handle Attach the inside handle 1. Make sure that the slide of the cover is in the position shown.
  • Page 140 8. Installation (manual) SmartHandle SmartIntego (Manual) 140 / 160 2. Push the cover (shield) together with the cover onto the fitting.
  • Page 141 8. Installation (manual) SmartHandle SmartIntego (Manual) 141 / 160 3. Press the inside of the cover firmly.
  • Page 142 8. Installation (manual) SmartHandle SmartIntego (Manual) 142 / 160 4. Press the cover on the outside firmly. 5. Attach the handle. Inside handle is attached.
  • Page 143 8. Installation (manual) SmartHandle SmartIntego (Manual) 143 / 160 Secure the inside handle 1. Screw in the set screw of the inside handle. The inside handle is secured. 2. If you have a Swiss Round version, clip the plastic cover onto the MO cut-out.

  • Page 144: Smartintego Programming

    9. SmartIntego programming SmartHandle SmartIntego (Manual) 144 / 160 9 SmartIntego programming Wireless Online WO: The SI:SmartHandle do not have to be removed from the packaging for programming, but can be programmed while still in the box. Position the packaging so that the outer labelling is legible. SmartIntego Virtual Card Network SVCN: The SI:SmartHandle do not have to be removed from the packaging for programming.

  • Page 145: Configuration

    10. Configuration SmartHandle SmartIntego (Manual) 145 / 160 10 Configuration See TechGuide WO/SVCN.

  • Page 146: Status Messages

    11. Status messages SmartHandle SmartIntego (Manual) 146 / 160 11 Status messages See TechGuide WO/SVCN.

  • Page 147: Signal

    12. Signal SmartHandle SmartIntego (Manual) 147 / 160 12 Signal See TechGuide WO/SVCN.

  • Page 148: Battery Warning In Smartintego

    SI:SmartHandle automatically switches to freeze mode. Once at this warning level, SmartHandle can now only be activated using a SimonsVoss programming device. Locking devices in wireless online systems do not signal their battery status. The battery status is displayed directly in the integrator system.

  • Page 149: Battery Replacement In Smartintego

    14. Battery replacement in SmartIntego SmartHandle SmartIntego (Manual) 149 / 160 14 Battery replacement in SmartIntego 1. Slide the battery change tool from below into the cover of the inner fit- ting. 2. Unlock the cover. 3. Gently slide the cover towards the handle. 4.
  • Page 150 14. Battery replacement in SmartIntego SmartHandle SmartIntego (Manual) 150 / 160 14. Hold a battery replacement card in front of the lock. A battery measurement is performed to detect the new batteries. No further (false) battery warnings are sent to the integrator system.

  • Page 151: Maintenance, Cleaning And Disinfection

    15. Maintenance, cleaning and disinfec- tion SmartHandle SmartIntego (Manual) 151 / 160 15 Maintenance, cleaning and disinfection If necessary, clean the SI.SmartHandle AX with a soft and, if necessary,  damp cloth. When disinfecting the SI.SmartHandle AX, only use agents that are ...

  • Page 152: Disassembly

    16. Disassembly SmartHandle SmartIntego (Manual) 152 / 160 16 Disassembly 16.1 Restore storage mode for Snap-in 1. Disconnect the 3-pole cable from the inside fitting to the 3-pole cable from the outer fitting. If necessary, also disconnect the LockNode cable from the inside fitting.

  • Page 153: Restore Storage Mode For Conventional Fastening System Mo

    16. Disassembly SmartHandle SmartIntego (Manual) 153 / 160 16.3 Restore storage mode for conventional fastening system MO 1. Disconnect the 3-pole cable from the inside fitting with the 3-pole cable from the outer fitting. If necessary, also disconnect the LockNode cable from the inside fitting.

  • Page 154: Restore Storage Mode For Scandinavianoval Dp

    16. Disassembly SmartHandle SmartIntego (Manual) 154 / 160 2. Hold the inside and outer fittings firmly while pulling them away from one another horizontally. 3. If necessary, loosen the hexagon screw in the inside door handle, but ensure that you only unscrew a little, so that the screw remains in the handle.

  • Page 155: Restore Storage Mode For Rrmo

    16. Disassembly SmartHandle SmartIntego (Manual) 155 / 160 16.8 Restore storage mode for RRMO 1. Disconnect the internal fitting 3-pole cable from the outer fitting 3-pole cable. If necessary, also disconnect the LockNode cable from the inner side fitting. 2. Hold the internal and outer fittings firmly while pulling them away from one another horizontally.

  • Page 156: Accessories

    17. Accessories SmartHandle SmartIntego (Manual) 156 / 160 17 Accessories 17.1 Battery set A set of batteries with replacement batteries is available for SmartHandle SO, which contains ten CR2450 batteries. 17.2 Sleeves You can also use the SI:SmartHandle for mortise locks with the square dimensions 8.5 mm or 10 mm.

  • Page 157: Technical Specifications

    18. Technical specifications SmartHandle SmartIntego (Manual) 157 / 160 18 Technical specifications Dimensions, narrow (WxHxD) 41 x 224 x 14 mm Dimensions, wide (WxHxD) 53 x 224 x 14 mm 80,000 locking cycles, 5 years on Battery life (online network WO): standby Battery life (offline networking or 50,000 locking cycles, 6 years on...

  • Page 158: Declaration Of Conformity

    19. Declaration of conformity SmartHandle SmartIntego (Manual) 158 / 160 19 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article SI.SH.*, SH.* complies with the following guidelines: 2014/53/EU "Radio equipment"  2014/30/EU "EMC"  2011/65/EU "RoHS" ...

  • Page 159: Help And Other Information

    Take the packaging to an environmentally responsible recycling point.  Hotline If you have any questions, the SimonsVoss Service Hotline will be happy to help you on +49 (0)89 99 228 333 (German fixed network; call charges vary depending on the operator).
  • Page 160 Unterföhring, near Munich, and its production site in Osterfeld, eastern Germany, the company employs around 300 staff in eight countries. SimonsVoss is a company in the ALLEGION Group, a globally active network in the security sector. Allegion is represented in around 130 countries worldwide (www.allegion.com).

This manual is also suitable for:

Si:smarthandle seriesSmartintego smarthandle 3062

Table of Contents
