Contents Digital Locking Cylinder 3061 (Manual) 2 / 54 Contents Intended use .............................. 5 General safety instructions........................ 6 Product specific safety notices ...................... 10 General ................................ 14 Product description............................ 14 Locking cylinder design .......................... 15 Half cylinder design............................ 15 Opening and locking from the outside .................... 16 Opening and locking from the inner side....................
Page 3
Contents Digital Locking Cylinder 3061 (Manual) 3 / 54 General instructions............................ 25 Programming the locking cylinder ...................... 25 Installation variants ............................ 25 6.3.1 Installation of double thumb-turn cylinders (except types .AP/.SKG/.VdS) .. 25 6.3.2 Fitting an anti-panic cylinder .................... 27 6.3.3 Installation of SKG/VdS cylinders .................. 30 6.3.4 Half Cylinder DK/MR........................ 31 6.3.5...
Page 4
Contents Digital Locking Cylinder 3061 (Manual) 4 / 54 Declaration of conformity ........................ 51 Help and other information ........................ 52...
(Manual) 5 / 54 1 Intended use Digital SimonsVoss Locking Cylinder 3061 are installed in designated door locks, such as DIN mortise locks, to integrate them into a digital locking system. The digital Locking Cylinder 3061 may only be used for its intended purpose in a designated door locking device.
Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in- correctly programmed components. SimonsVoss Technologies GmbH is not liable for the consequences of blocked access such as access to in- jured or endangered persons, material damage or other damage!
Page 7
Digital Locking Cylinder 3061 2. General safety instructions (Manual) 7 / 54 IMPORTANT Damage resulting from electrostatic discharge (ESD) This product contains electronic components that may be damaged by electrostatic discharges. 1. Use ESD-compliant working materials (e.g. Grounding strap). 2. Ground yourself before carrying out any work that could bring you into contact with the electronics.
Page 8
NOTE Intended use SimonsVoss-products are designed exclusively for opening and closing doors and similar objects. Do not use SimonsVoss products for any other purposes. NOTE Battery contact malfunction due to grease film When touching batteries, leave a thin film of skin grease on the batteries.
Page 9
Function error due to poor battery contact If the contact surface to the battery is too small, then the battery connec- tion may not create a stable connection to the battery. Only use batteries that are approved by SimonsVoss. NOTE Qualifications required The installation and commissioning requires specialized knowledge.
If you use the anti-panic cylinder in locks that are not approved, the escape door function can be disrupted and not released again. Contact SimonsVoss Technolo- gies GmbHfor further information.
Page 11
Digital Locking Cylinder 3061 3. Product specific safety notices (Manual) 11 / 54 CAUTION Hand injuries from carrier springing back A spring-loaded carrier is used in the anti-panic construction of the closing cylinder. This carrier can spring back when it is not installed, causing hand injuries.
Page 12
Digital Locking Cylinder 3061 3. Product specific safety notices (Manual) 12 / 54 NOTE Service interval of not less than one month for emergency exit locks The European standard EN 179 (attachment C) specifies that emergency exit locks must be serviced monthly. The anti-panic function must be in a satisfactory and operational condition.
Page 13
Digital Locking Cylinder 3061 3. Product specific safety notices (Manual) 13 / 54 NOTE Battery changes may only be carried out by trained personnel and only with the battery key provided (Z4.KEY)! NOTE Programming with obsolete LSM version New components can only be programmed with the current version of LSM.
14 / 54 4 General 4.1 Product description The SimonsVoss Digital Locking System 3060 is an electronic version of a mechanical locking system with the functions of a typical access control system. Digital Locking Cylinder 3061 and the digital half cylinder are a main...
Digital Locking Cylinder 3061 4. General (Manual) 15 / 54 Compact Reader 3078, can be connected as a wireless element. If the system is extended at a later stage, cylinders can be networked without wiring and managed in an online interconnected system. The locking cylinders are provided with two different firmware generations –...
Digital Locking Cylinder 3061 4. General (Manual) 16 / 54 4.4 Opening and locking from the outside With freely rotating locking cylinders (FD) The outer and inside thumb-turn rotate freely when not activated in the freely rotating Locking Cylinder 3061, meaning it is not possible to open or lock the door without a valid ID medium.
Digital Locking Cylinder 3061 5. Versions (Manual) 17 / 54 5 Versions Different versions of the digital Locking Cylinder 3061 are offered to cover the different needs of the market. The different versions are indicated by a code. The different versions can be combined: LOCKING CYLIN- ABBREVIATION DESIGNATION...
Digital Locking Cylinder 3061 5. Versions (Manual) 18 / 54 Standard Euro profile cylinder as per DIN 18252/EN1303 Scandinavian Oval British oval Swiss Round Locking Cylinder 3061s are also offered in mortise and rim cylinder models for American door profiles. 5.1 FD version (Standard) Locking Cylinder 3061 freely rotating on both sides.
Digital Locking Cylinder 3061 5. Versions (Manual) 19 / 54 5.5 version for steel and fire retardant doors Design is similar to standard version but for doors with sturdy metal sections, such as fire doors, or doors with highly protective shielding. This version is recommended in areas with high interference fields, such as server rooms, and for all metal doors.
Digital Locking Cylinder 3061 5. Versions (Manual) 20 / 54 NOTE The profile cylinder must be protected with a VdS-approved burglar-resist- ant class B or C door label. Such door plates conform to DIN 18257, Class ES 2 or ES 3. The cylinder may not protrude more than 3 mm above the door plate.
Loss of magnetization and cylinder authorization If you use flip-flop mode or time switching on an AP2 cylinder, magnetiza- tion may be lost and the cylinder must be reauthorized. SimonsVoss there- fore generally recommends not using these functions with an AP2 cylinder.
Digital Locking Cylinder 3061 5. Versions (Manual) 22 / 54 5.12 CO version In the comfort cylinder (CO), the inside knob is permanently interconnected with the locking cam, so that doors can be opened and locked from the inside without needing to use a transponder. 5.13 WP Version (FD) The protection rating is increased from IP54 to IP66 in the WP version (weatherproof) of the Locking Cylinder 3061.
Digital Locking Cylinder 3061 5. Versions (Manual) 23 / 54 5.18 WN version (HZ) The WN version is fitted with a network flap (LockNode Inside). This network cap enables the lock to be networked directly (networked connection between lock and the LSM). This version is available for all models.
Page 24
Digital Locking Cylinder 3061 5. Versions (Manual) 24 / 54 *Comply with EN 179 and EN 1125 requirements and the lock manufacturer's data sheets. The different versions can be combined as you wish. Exceptions are indicated in the individual model descriptions.
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 25 / 54 6 Installation instructions 6.1 General instructions When installing the digital Locking Cylinder 3061, ensure that there are no sources of low-frequency radio interference in the surrounding area. The profile cylinder housing should be fitted flush in outside areas; it should project a maximum of 3 mm and a profile cylinder escutcheon or security fitting should be installed if necessary.
Page 26
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 26 / 54 5. Battery replacement key 6. Locking disc with opening (identical on outside) 7. Outer thumb-turn 6.3.1.1 Removing the outer thumb-turn Place the installation key on the outer thumb-turn in such a way that its two teeth engage into the outer thumb-turn;...
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 27 / 54 1. Bayonet disc 2. Thumb-turn 3. Bayonet disc closed 4. Bayonet disc open Place the installation key on the outer thumb-turn in such a way that its two teeth engage into the outer thumb-turn (if necessary, turn the thumb- turn until both teeth lock into the locking disc).
Page 28
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 28 / 54 The locking cam is always in a pre-defined position in the AP cylinder when disengaged. This prevents accidental blocking. Unlike other cylinder versions, the AP cylinder is installed the other way round (inserted into the lock from the inside to the outside).
Page 29
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 29 / 54 U section: No restore force on the cam R section: Restore force section towards U section Top dead point in deadbolt throw - no restore force on O section: the cam Top threshold section Lower threshold section...
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 30 / 54 6.3.3 Installation of SKG/VdS cylinders Loosen the outside knob's threaded pin using an Allen key. Do not unscrew completely. Hold the inside knob firmly and then turn the outside knob anti-clockwise.
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 31 / 54 2. Then screw the core extraction protection adapter into position on the cylinder and lock into place using the threaded pins. 3. Install the non-electronic knob on the core extraction protection ad- apter.
Page 32
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 32 / 54 8. While applying pressure, pull the thumb-turn (including inside tube) from the profile cylinder (see Step D in the diagram). NOTE You must not strike the thumb-turn during installation. Do not allow the cylinder to come into contact with oil, paint or acids.
Digital Locking Cylinder 3061 6. Installation instructions (Manual) 33 / 54 This generally also applies when installing the cylinder in a key switch, for example. 6.3.5 Installing Swiss Round Both cylinders and a fitting need to be removed from doors when installing a Swiss round cylinder.
cylinder does not en- zone. None gage. Activated alarm system while using the SimonsVoss Block Lock. Battery Warning Level 1: Replace batteries in the 8 short audible signals Batteries are low. cylinder. before engaging. Battery Warning Level 2:...
Page 35
Digital Locking Cylinder 3061 7. Audible signals (Manual) 35 / 54 The locking cylinder batteries feature a redundant system. If one of the batteries fails or its capacity falls below a certain level, the system emits a battery warning. The battery warning levels between G1 and G2 differ after Battery Warning Level 2 if the battery capacity falls under the emergency battery warning threshold values.
Page 36
Digital Locking Cylinder 3061 7. Audible signals (Manual) 36 / 54 Emergency battery – Freeze mode (G2 cylinders): In freeze mode, an audible signal will sound if an attempt is made to open using an authorised transponder, but the cylinder will not engage. The G2 cylinder can now only be opened using a battery replacement transponder or programming device.
Digital Locking Cylinder 3061 7. Audible signals (Manual) 37 / 54 Battery replace- Up to 15,000 ac- Up to 50 access ment: activate cess events or up events or up to 30 with battery re- to 9 months on days placement standby transponder...
Fingerprints on batteries may reduce battery life considerably. Only use batteries which have been approved by SimonsVoss. NOTE You may cause damage to the Locking Cylinder 3061 if you reverse the po- larity.
Digital Locking Cylinder 3061 8. System 3060 battery replacement (Manual) 39 / 54 8.3 Emergency battery procedure As stated above, a locking cylinder changes to storage mode (G1) or freeze mode (G2) if Battery Warning Level 2 is ignored. A different procedure is used each for G1 and G2 to eliminate this mode.
Digital Locking Cylinder 3061 8. System 3060 battery replacement (Manual) 40 / 54 NOTE Only use the G2 battery replacement transponder to deactivate freeze mode and then immediately replace the cylinder batteries. Misuse may lead to complete battery discharge and, consequently, a complete failure of the cylinder.
Digital Locking Cylinder 3061 8. System 3060 battery replacement (Manual) 41 / 54 10. Replace the thumb-turn (align the triangle mark as in the diagram), hold the recessed grip ring firmly and fasten the inside thumb-turn by turning in a clockwise direction (about 10°). (Diagram may differ slightly from the purchased product) 11.
Page 42
Digital Locking Cylinder 3061 8. System 3060 battery replacement (Manual) 42 / 54 NOTE You must place the ribbon cable loop crossways directly under the thumb- turn lid. 5. Reattach lid to the outer thumb-turn and press gently. The lid is now flush against the outer thumb-turn. 6.
HZ.SL: It is recommended to grease the latching edge on the electrical en- closure lever handle. Empty batteries always must be replaced by new ones approved for use by SimonsVoss. Dispose of old batteries in the proper manner. Carry out a new functional test after changing the batteries in anti-panic cylinders.
Digital Locking Cylinder 3061 10. Areas of use (Manual) 44 / 54 10 Areas of use 10.1 General The digital locking cylinder is compatible with locks for Euro profile cylinder as per DIN 18252 and EN1303. 10.2 Fire doors As a general rule, this cylinder can be fitted into fire doors. However, you must check that it is actually approved for use in fire doors.
Digital Locking Cylinder 3061 11. Accessories (Manual) 45 / 54 11 Accessories 11.1 Thumb-turns The following special thumb-turns are available as accessories: Outer thumb-turn in a TN4 design Outer thumb-turn, 42 mm in diameter with recessed grips Inside thumb-turn, 36 mm in diameter for a .TS cylinder ...
You can use this tool to install or remove outer thumb-turns and replace batteries. 11.6 Battery set A new set of batteries can be ordered, which contains ten CR2450 batteries. Only ever use batteries approved by SimonsVoss.
Digital Locking Cylinder 3061 13. Declaration of conformity (Manual) 51 / 54 13 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article TN4-Zylinder complies with the following guidelines: 2014/53/EU "Radio equipment" 2014/30/EU "EMC" 2011/65/EU "RoHS"...
Take the packaging to an environmentally responsible recycling point. Hotline If you have any questions, the SimonsVoss Service Hotline will be happy to help you on +49 (0)89 99 228 333 (German fixed network; call charges vary depending on the operator).
Page 53
Digital Locking Cylinder 3061 14. Help and other information (Manual) 53 / 54 SimonsVoss Technologies GmbH Feringastrasse 4 85774 Unterföhring Germany...
Page 54
Unterföhring, near Munich, and its production site in Osterfeld, eastern Germany, the company employs around 300 staff in eight countries. SimonsVoss is a company in the ALLEGION Group, a globally active network in the security sector. Allegion is represented in around 130 countries worldwide (www.allegion.com).
