Kinetrol (large)
5.14
Order no.: 304535
Technical data
5.14.1
Device-specific data
Operating pressure
Air connection
Ambient conditions
Operating temperature
Mechanical data
Housing specification
Weight
Dimensions
Accessories
Designation
Angle brackets, large, DN 3" and DN 80
Threaded union QSML 1/8" 6 mm
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Measuring system MAK TIGER 3003
Max. 7 bar
IG 1/8"
-20 ... +80 °C
Epoxy resin, powder-coated
1.24 kg
136 x 112 x 93
Order no.
304816
202418
37
