  • Page 1 RIRS 12005500 H EKO 3.0 MOUNTING AND INSTALLATION INSTRUCTION...

  • Page 2: Table Of Contents

    1. CONTENT 2. SYMBOLS AND MARKING 3. SAFETY INSTRUCTIONS AND PRECAUTIONS 4. INFORMATION ABOUT THE PRODUCT 4.1. DESCRIPTION 4.2. DIMENSIONS AND WEIGHT 4.3. TECHNICAL DATA 4.4. OPERATING CONDITIONS 4.5. STANDARD PACKAGE OF COMPONENTS 4.6. DESCRIPTION OF COMPONENTS 5. INSTALATION 5.1. RECEPTION OF GOODS 5.2.

  • Page 3: Symbols And Marking

    2. SYMBOLS AND MARKING Warning – pay attention Additional information Apply the auxiliary label on the unit (on an easily accessible location) or on the dashed location of the technical manual in order to keep the important information about the unit. Figure 2.1.

  • Page 4: Safety Instructions And Precautions

    3. SAFETY INSTRUCTIONS AND PRECAUTIONS Read these instructions very carefully before installing and using this equipment. Installation, connection and maintenance should be carried out Main safety rules Danger • of the device have stopped. • Make sure that the fans are not accessible through air ducts or branch openings. •...

  • Page 5: Information About The Product

    4. INFORMATION ABOUT THE PRODUCT 4.1. DESCRIPTION Not suitable for operation in pools, saunas and other similar premises. 4.2. DIMENSIONS AND WEIGHT Figure 4.2.1. RIRS 1200-1900 H EKO 3.0 1200 HEL 1200 HER 1200 HWL 1200 HWR 1900 HEL 1900 HER 1900 HWL 1900 HWR RIRS EKO 3.0...
  • Page 6 Figure 4.2.2. RIRS 2500-3500 H EKO 3.0 2500 HEL 2500 HER 2500 HWL 2500 HWR 3500 HEL 3500 HER 3500 HWL 3500 HWR RIRS EKO 3.0 [mm] 1608 1608 1608 1608 1900 1900 1900 1900 [mm] 1110 1110 1110 1110 1205 1205 1205...
  • Page 7 Figure 4.2.3. RIRS 5500 H EKO 3.0 5500 HEL 5500 HER 5500 HWL 5500 HWR RIRS EKO 3.0 [mm] 1910 1910 1910 1910 [mm] 1405 1405 1405 1405 [mm] 1485 1485 1485 1485 [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]...

  • Page 8: Technical Data

    4.3. TECHNICAL DATA RIRS EKO 3.0 1200 HE 1200 HW 1900 HE 1900 HW Exhaust air fan phase/voltage [50 Hz/VAC] 1/230 1/230 1/230 1/230 [kW/A] 0,38/2,5 0,38/2,5 0,47/2,04 0,47/2,04 speed [min 3370 3370 2530 2530 control input [VDC] 0-10 0-10 0-10 0-10 protection class...

  • Page 9: Operating Conditions

    RIRS EKO 3.0 5500 HE 5500 HW Exhaust air fan phase/voltage [50 Hz/VAC] 3/400 3/400 [kW/A] 1,85/2,9 1,85/2,9 speed [min 2180 2180 control input [VDC] 0-10 0-10 protection class IP54 IP54 Supply air fan phase/voltage [50 Hz/VAC] 3/400 3/400 [kW/A] 1,85/2,9 1,85/2,9 speed...

  • Page 10: Description Of Components

    4.6. DESCRIPTION OF COMPONENTS Figure 4.6.1. RIRS 1200-1900 HE EKO 3.0 construction (right side) Figure 4.6.2. RIRS 2500-3500 HE EKO 3.0 construction (right side) Figure 4.6.3. RIRS 5500 HE EKO 3.0 construction (right side) 1 - rotor heat exchanger; 2 - Supply fan; 3 - Exhaust fan; 4 - Electrical heater; 5 - Control board; 6 - Extract | EN RIRS 1200-5500 H EKO 3.0 v2021.1...

  • Page 11: Instalation

    5. INSTALATION 5.1. RECEPTION OF GOODS Each device is carefully checked before transportation. When receiving the goods, checking the devices for any damage made during transporta- tion is recommended. If any damage to the unit is observed, immediately contact the representatives of a transport company. Please inform the representative of the manufacturer, if any deviation of the device is noticed.

  • Page 12: Unpacking

    Figure 5.2.2. Lifting 5.3. UNPACKING Accessories may be packed together with the product. Prior to transporting the unit, the accessories should be unpacked • • • • • Before commencing the installation of the unit, please check if all ordered equipment have been delivered. Any variation from the ordered equip- ment list must be reported to the product supplier.

  • Page 13: Mounting

    Figure 5.4.2. RIRS 2500-5500 H EKO 3.0 * KE1 - only in electrical version; * KV1 - used in water version; ** Possible to control. THE LIST OF COMPONENTS Supply air fan Exhaust fan Exhaust air temperature sensor Supply air temperature sensor Extract air temperature and humidity sensor CO2 sensor Computer...

  • Page 14: Unit Placing And Mounting Positioning Requirements

    5.5.1. UNIT PLACING AND MOUNTING POSITIONING REQUIREMENTS 1,5xL Min. distance to open the door - 1,5xL; Min. distance to open the control box door - H > 400 mm. 5.5.2. FLOOR MOUNTING • The installation should be performed having positioned the units in horizontal direction only. •...

  • Page 15: Connection Of The Unit To Electric Network

    • Air ducts are often mistakenly connected in inappropriate location. The ventilation units bear the labels indicating the correct air duct connection • 5.7. CONNECTION OF THE UNIT TO ELECTRIC NETWORK • • • • The unit must be earthed according to electrical equipment installation regulation. •...

  • Page 16: Maintenance

    6. MAINTENANCE 6.1. SAFETY INSTRUCTION Unplug the unit from the mains before opening the door (disconnect the power plug from the outlet or in case an automatic circuit breaker installed, disconnect it as well. Make sure that it cannot be turned on by third parties) and wait until the fans completely stop (for about 2 min.).

  • Page 17: Filters Maintenance

    Figure 6.3.3. RIRS 5500 H EKO 3.0 6.4. FILTERS MAINTENANCE direction. tion manual or on our website www.salda.lt 6.5. ROTOR MAINTENANCE • Maintenance of rotor heat exchanger must be performed on annual basis, once per year. • exchanger are tight.

  • Page 18: Fans Maintenance

    6.6. FANS MAINTENANCE • • The fan should be inspected and cleaned at least once per year. • • Proceed to maintenance and repair after any fan rotation is stopped. • • The motor features a heavy-duty ball bearing design. The motor is completely sealed and grease- free. •...
  • Page 19 RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...

  • Page 20: Control

    BMS over Modbus TCP/IP FLEX BMS over BACnet TCP/IP 7.2. DEVICE FUNCTIONS WEB application and SALDA AIR mobile application. Refer to the instruction manual of the existing control device for unit control instructions. | EN RIRS 1200-5500 H EKO 3.0 v2021.1...

  • Page 21: Accessories

    8. ACCESSORIES RIRS EKO 3.0 1200 HE 1200 HW 1900 HE 1900 HW Roof RIRS 1200/1900 H EKO 3.0 ACC000039 ACC000039 ACC000039 ACC000039 Roofs Roof CB 315 ACC004737 ACC004737 ACC004737 ACC004737 ABV 315 ACC000057 ACC000057 ACC000057 ACC000057 Outlet covers LSVF 315 FIT000308 FIT000308 FIT000308...
  • Page 22 Filter set RIRS 1200/1900 V/H EKO 3.0 Filter sets ACC004884 ACC004884 ACC004884 ACC004884 (ePM10-50+ePM1-70-2pcs.) ACC000269 ACC000269 ACC000269 ACC000269 Remote control panel FLEX ACC000270 ACC000270 ACC000270 ACC000270 Remote control panel ST-SA-Control ACC000271 ACC000271 ACC000271 ACC000271 Control Remote control panel Stouch ACC000272 ACC000272 ACC000272 ACC000272...
  • Page 23 AKS 500-12 FIT000447 FIT000447 FIT000447 FIT000447 AKS 500-9 FIT000281 FIT000281 FIT000281 FIT000281 Silencers SKS 70-40 FIT000302 FIT000302 FIT000302 FIT000302 CB 700x400 C2+DE ACC000223 ACC000223 ACC000223 ACC000223 CB 700x400 C4+DE ACC000224 ACC000224 ACC000224 ACC000224 CB 700x400 F2+DE ACC000225 ACC000225 ACC000225 ACC000225 CB 700x400 F4+DE ACC000226 ACC000226...
  • Page 24 Sensor CO duct S-KCO2 ACC000277 ACC000277 ACC000277 ACC000277 Sensor CO room S-RCO2-F2 ACC000278 ACC000278 ACC000278 ACC000278 External sen- sors Pressure transmitter S-1141 ACC004375 ACC004375 ACC004375 ACC004375 RIRS EKO 3.0 5500 HE 5500 HW Roof RIRS 5500 H EKO 3.0 ACC000042 ACC000042 Roofs Roof CB 800x500...

  • Page 25: Connection Of Accessories

    Filter sets Filter set RIRS 5500 H EKO 3.0 (ePM10-50-2pcs+ePM1-70-2pcs) ACC004896 ACC004896 Sensor CO duct S-KCO2 ACC000277 ACC000277 Sensor CO room S-RCO2-F2 ACC000278 ACC000278 External sen- sors Pressure transmitter S-1141 ACC004375 ACC004375 ACC000269 ACC000269 Remote control panel FLEX ACC000270 ACC000270 Remote control panel ST-SA-Control ACC000271 ACC000271...

  • Page 26: Room Co2 Transmitter Installation Recommendation

    Sensors connection: Figure 8.1.2.1. RIRS 1200-1900 H EKO 3.0 Figure 8.1.2.2. RIRS 2500-5500 H EKO 3.0 The CO2 transmitter is installed in the extract air duct or room. 8.1.3. ROOM CO2 TRANSMITTER INSTALLATION RECOMMENDATION 5 0 c m i n . min.

  • Page 27: Connection Of Supply And Extract Air Dampers

    8.1.5. CONECTION OF AIR DAMPERS Spring-return actuators. Wiring diagram for RIRS 1200-1900 H EKO 3.0 M2, M3 – Open/Close damper actuators. Upon activation of outputs X16:17, X16:20 the dampers shall open, Upon activation of outputs X16:16, X16:19 the dampers shall close. Wiring diagram for RIRS 1200-1900 H EKO 3.0 M2 –...
  • Page 28 Figure 8.1.7.1. RIRS 1200-1900 H EKO 3.0 Figure 8.1.7.2. RIRS 2500-5500 H EKO 3.0 | EN RIRS 1200-5500 H EKO 3.0 v2021.1...

  • Page 29: Recommended Scheme For Connection Of Internal And External Components

    8.1.8. RECOMMENDED SCHEME FOR CONNECTION OF INTERNAL AND EXTERNAL COMPONENTS Figure 8.1.8.1. RIRS 1200 HE EKO 3.0 RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...
  • Page 30 Figure 8.1.8.2. RIRS 1900 HE EKO 3.0 | EN RIRS 1200-5500 H EKO 3.0 v2021.1...
  • Page 31 Figure 8.1.8.3. RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...
  • Page 32 Figure 8.1.8.4. RIRS 2500 HE EKO 3.0 | EN RIRS 1200-5500 H EKO 3.0 v2021.1...
  • Page 33 Figure 8.1.8.5. RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...
  • Page 34 Figure 8.1.8.6. RIRS 3500 HE EKO 3.0 | EN RIRS 1200-5500 H EKO 3.0 v2021.1...
  • Page 35 Figure 8.1.8.7. RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...
  • Page 36 Figure 8.1.8.8. RIRS 5500 HE EKO 3.0 | EN RIRS 1200-5500 H EKO 3.0 v2021.1...
  • Page 37 Figure 8.1.8.9. RIRS 1200-5500 H EKO 3.0 v2021.1 EN |...

  • Page 38: Possible Faults And Troubleshooting

    9. POSSIBLE FAULTS AND TROUBLESHOOTING FAILURE CAUSE EXPLANATION / CORRECTIVE ACTIONS No supply voltage Unit is not operating relay is active (if installed by the installer) tic protection fans are rotating Air supply heater or pre-heater is not opera- Possible heater or unit failure. MUST contact ting or malfunctioning (if installed) Manual protection is activated elimination.

  • Page 39: Ecodesign Data Table

    10. ECODESIGN DATA TABLE RIRS EKO 3.0 1200 HE 1200 HW 1900 HE 1900 HW Declared typology bidirectional bidirectional bidirectional bidirectional Type of drive Variable Variable Variable Variable Type of HRS recuperative recuperative recuperative recuperative 83,9 83,9 84,3 84,3 /s ] 0,33 0,33 0,42...
  • Page 40 RIRS EKO 3.0 5500 HE 5500 HW Declared typology bidirectional bidirectional Type of drive Variable Variable Type of HRS recuperative recuperative 76,4 76,4 /s ] 1,69 1,69 [ kW ] 3,58 3,58 SFPint [ W/(m /s) ] 1061 1061 Face velocity [ m/s ] 2,11 2,11...

  • Page 41: Declaration Of Confimity

    11. DECLARATION OF CONFIMITY Manufacturer SALDA, UAB LT-78109 Šiauliai, Lithuania Tel.: +370 41 540415 www.salda.lt RIRS * EKO 3.0 Machinery Directive 2006/42/EC EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU Ecodesign Directive 2009/125/EC RoHS 2 Directive 2011/65/EU Ecodesign requirements for ventilation units Nr. 1253/2014 Energy labeling of residential units Nr.

  • Page 42: Warranty

    12. WARRANTY date. such damage. damaged by installing the control system. 4.1. mechanical damage; 4.2. damage caused by entering outside objects, materials, liquids; lation and mounting regulations, deliberate or careless users or third-party behavior. days and deliver the equipment to manufacturer. Delivery costs should be covered by customer. Manufacturer reserves the right to change this technical passport any time without prior notice, if some typographic errors or inaccurate information is found, as well as after improving the apps and/or the devices.
  • Page 43 RIRS 1200-5500 H EKO 3.0 v2021.1...
  • Page 44 Once per year** Every 3-4 Filter replacement months** Look at the product label. ** - At least. NOTE. The customer shall be required to complete the Product Maintenance Table. MANUALS IN OTHER LANGUAGES https://select.salda.lt/file/ https://select.salda.lt/file/ https://select.salda.lt/file/ https://select.salda.lt/file/ https://select.salda.lt/file/ rirs1200-5500hekode rirs1200-5500hekodk rirs1200-5500hekofr rirs1200-5500hekolt rirs1200-5500hekopl https://select.salda.lt/file/...

This manual is also suitable for:
