5. Select the "SIP Conf." Link, and the phone will ask you to enter the user name and password. By
default the user name is "Polycom" and the password is "456".
6. Go to the "Server 1" section and set the LAN IP address of the Quadro board (SIP Proxy). This
should be set to "172.30.0.1" by default. Set the 5060 for "port" and change the expiration time
to 60 seconds.
7. Go to the "Local Settings" section of the same page and set "Digitmap" for example as
"xx.T#|*[0-6]|*[7-9]x". Set "Digit impossible map" to "1" (an exact digit map for this phone will
be provided later).
8. Press the "Submit" button in the same section. The phone will perform the configuration update.
Then it is necessary to reboot the phone. Press and hold the "-" "+" "Do Not Disturb" and "Hold"
buttons simultaneously for rebooting.

2.3 Configuration by the End User

The next step for the end user is to configure the SIP registration settings. That can be done by:
1. Go to the Polycom IP phone embedded web server and select the "Registration" link and then
the "Registration 1" page.
2. The user needs to set the "Address" (this is the SIP user name), "Auth Password" (the password
is the same as he/she configured on the Quadro board) and also the optional display name.
3. The user also can set here the address of the SIP proxy, but by default the proxy set in the "SIP
Conf" link will be selected (pre-configured to 172.30.0.1).
4. The user can change the SIP registration expire time, by default the expire time is set to 60
seconds on the "SIP Conf" page.
5. But if the LAN IP address of Quadro is changed, the user has to change the default SIP proxy
address, which is in the "Server 1" section on the "SIP Conf" page (see "Manual configuration of
Polycom SoundPoint IP300 using DHCP server" section of this document).

2.4 Some Additional Information

Distributors can also use the TFTP server, but there are the following drawbacks of this approach:
1. The factory default is FTP, so before booting for the 1
change that setting over the phone keypad
2. A download by TFTP protocol requires having not only the configuration on the TFTP server, but
also to the whole image
In contrary to this, the FTP client of the phone does not require the image, and in addition it
always checks if the configuration (or the image, if placed in the FTP folder) is newer and only
then will download it.
• Note: You should have the image version 1.3.1.
3. The Polycom documentation does not recommend using a TFTP server.
The user has to manually attach the extension to the SIP line and enter the SIP user name of the phone
and the password.
Copyright © 2004 Epygi Technologies, Ltd. All rights reserved.
*
(about 6 Mbytes) to be downloaded, otherwise the phone will not work.
Polycom SoundPoint IP 300 Phone Configuration
st
time, distributors have to manually
