- Page 1 C2 base/C2 pro/C2 marine English MAEN278, 2020-08...
- Page 2 Foreword Installation manual for C2 base/C2 pro/C2 marine Foreword All operator panels are developed to satisfy the demands of human-machine communication. Built-in functions such as displaying and controlling text, dynamic indication, time channels, alarm and recipe handling are included. The operator panel works primarily in an object-oriented way, making it easy to understand and use.
-
Page 3: Table Of Contents
21.5” .............. 18 7 Connectors .............. 19 Panel PC C2 base/C2 pro/C2 marine base full metal variant . 19 7.1.1 Input Power Connector ......... 19 7.1.2... -
Page 4: Safety Precautions
Safety Precautions Safety Precautions Both the installer and the owner and/or operator of the operator panel must read and understand this installation manual. General • Read the safety precautions carefully. • Check the delivery for transportation damage. If damage is found, notify the supplier as soon as possible. -
Page 5: Hazardous Materials
Safety Precautions Hazardous Materials Part Name Toxic or Hazardous Substances and Elements 部件名称 有 毒 有 害 物 质 或 元 素 汞 铅 镉 六价铬 多溴联苯 多溴二 苯醚 Mer- Lead Cad- Hex- Poly- cury mium avalent bromi- Poly- (Pb) Chrom- nated bromi-... -
Page 6: Disposal Requirements Under Weee Regulations
Safety Precautions of Beijer to customers. Certain components inside this product may have an EFUP which is lower than the EFUP on this product. Disposal Requirements Under WEEE Regulations For professional users in the European Union: If you wish to discard electrical and electronic equipment (EEE), please contact your dealer or supplier for further information. -
Page 7: During Installation
Safety Precautions Warning: Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire. LA BATTERIE PEUT EXPLOSER EN CAS DE MAUVAISE MANIPULATION. NE LA RECHARGEZ PAS, NE LA DÉMONTEZ PAS ET NE LA JETEZ PAS DANS LE FEU. •... -
Page 8: During Use
Safety Precautions During Use • Keep the operator panel clean. • Emergency stop and other safety functions may not be controlled from the operator panel. • Do not use excessive force or sharp objects when operating the touch screen. Service and Maintenance •... -
Page 9: Introduction
Introduction Introduction With C2 base/C2 pro/C2 marine HMI series, Beijer offers high mechanical flexibility with respect to the design. It can be used as a built-in solution. The front comes with standard IP65 protection. The built-in version is installed directly on the machine or in a command or control console. -
Page 10: Product Description
Product Description Product Description Product View Figure: Front view of built-in mount full metal. 1. Front plate. 2. TFTdisplay with projected capacitive touch. Beijer, MAEN278... - Page 11 Product Description 1. HDMI port 2. Display port 3. LAN ports 2x 4. USB 3.0 4x 5. Power LEDs 6. Power connector 7. Rear cover Beijer, MAEN278...
-
Page 12: Technical Data And Environmental Specification
Technical Data and Environmental Specification Technical Data and Environmental Specification Table: Technical Data C2 base/C2 pro/C2 marine Line Product C2 Base C2 Pro Front options Projected Capacitive Projected Capacitive Touch screen Touch screen Touch surface Glass Glass Mounting Processor Intel® 7th generation Intel®... - Page 13 RoHS compliant Cooling Fanless passive cooling Fanless passive cooling * Sizes dependend on availability** Optional, not standard (see Options on request) Table: Display Information Panel C2 base C2 base, C2 base, C2 base, C2 base, C2 pro C2 pro C2 pro...
-
Page 14: Order Information
Order Information Order Information Product Family Product Name Description C2 base C2 base 10 PPC 10,1" display, PCAP, Intel® Celeron® 3965U , 4GB Ram, 256GB SSD, Windows® 10 IoT Enterprise C2 base C2 base 12 PPC 12,1" display, PCAP, Intel® Celeron® 3965U , 4GB Ram, 256GB SSD, Windows®... - Page 15 Order Information C2 pro iX runtime C2 pro 12 iX 12,1" display, PCAP, Intel® i5-7300U , 4GB Ram, 256GB SSD, Windows® 10 IoT Enterprise, iX runtime C2 pro iX runtime C2 pro 15 iX 15,6" display, PCAP, Intel® i5-7300U , 4GB Ram, 256GB SSD, Windows®...
-
Page 16: Mechanical Specification
Mechanical specification Mechanical specification 10.1“ 12.1“ Beijer, MAEN278... - Page 17 Mechanical specification 15.6” 18.5” Beijer, MAEN278...
- Page 18 Mechanical specification 21.5” Beijer, MAEN278...
-
Page 19: Connectors
Connectors Connectors Panel PC C2 base/C2 pro/C2 marine base full metal variant Figure: Interfaces for Panel PC C2 base/C2 pro/C2 marine base variant 1. HDMI port 2. Display port 3. LAN ports 2x 4. USB 3.30 4x 5. Power LEDs 6. -
Page 20: Power-Switch And Leds
Connectors 7.1.2 Power-Switch and LEDs Figure: Power switch and LEDs. 1. LED power 2. Power on 3. LED drive activity Table: Power LED Signal No Power Green Active Green blinking Standby Table: Drive Activity Signal No Power Green Active 7.1.3 USB3.0 Type-A Connector Table: Pinout USB 3.0 Signal Name... -
Page 21: Led Diagram Of Lan Connectors
Connectors Signal Signal Name Name TX1+ TX3- TX1- TX2- TX2+ TX4+ TX3+ TX4- 7.1.5 LED Diagram of LAN Connectors Table: Status of LEDs from GbE RJ-45 Connector Left LED: Right LED: activ- activ- ity/link ity/link No LAN con- 10 Mbit nectivity Yellow Link... -
Page 22: Display Port
Connectors Signal Name +5 V Power Hot Plug Detect 7.1.7 Display Port Table: Pinout Display Port Connector Signal Name Signal TX0+ TX3- TX0- TX1+ AUX+ TX1- TX2+ AUX- TX2- TX3+ 7.1.8 COM2 RS-232/422/485 (via internal cable connection to CN16, Option) Table: Pinout RS-232/422/485 Connector Half Full... -
Page 23: Installation And Start
Installation and Start Installation and Start Mounting Instructions (built-in-variant only) 1. Use Philips head Screwdriver to mount. Mounting set with screws and clamping brackets Lens head Screw Philips M4x12 DIN 7985 - ISO 7045 Beijer, MAEN278... - Page 24 Installation and Start 2. Pre-assembly: Insert the screw into clamping bracket. Note: Note the right direction. 3. Insert the clamping bracket into your system. 4. Fix the bracket with the screw to the housing. Beijer, MAEN278...
-
Page 25: Startup Procedure
5. Repeat step 4 for all positions of clamping bracket. Startup Procedure To activate your C2 base/C2 pro/C2 marine Panel PC connect the power supply to power connector on the C2 base/C2 pro/C2 marine back side. The LED “PWR” gives a green light now. -
Page 26: Exchange Of Ssd
Exchange of SSD Exchange of SSD 1. Undo the screws for the SSD cover. Undo all screws. 2. Open the cover with the SSD attached. Beijer, MAEN278... - Page 27 Exchange of SSD 3. Undo the screws holding the SSD and remove it. Insert the new SSD in to the cover after the old has been removed. Beijer, MAEN278...
- Page 28 Exchange of SSD 4. Mount the four countersunk screws to the sides of the SSD. 5. Reattach the cover.. Beijer, MAEN278...
-
Page 29: Exchange Of Battery
Exchange of battery Exchange of battery 1. Undo the screws for the cover. 2. Put the cover aside. Beijer, MAEN278... - Page 30 Exchange of battery 3. Put a small screwdriver underneath the battery. 4. Carefully pry it upwards so it becomes loose. Be careful not to drop the battery inside! Beijer, MAEN278...
- Page 31 Exchange of battery 5. Insert the new battery at an angel in the correct position. Be careful not to drop the battery inside! Push it in all the way so both sides of the holder makes a good clamp. Beijer, MAEN278...
- Page 32 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
