Product Specifications - ATC EcoMini EM Series Installation, Operation & Service Manual

Applied Thermal Control Ltd
39 Hayhill Industrial Estate
Barrow-upon-Soar, Loughborough
LE12 8LD, United Kingdom
+44 (0) 1530 839 998
Service@thermalexchange.co.uk
Support@app-therm.com
Date 28/AUG/2020
Attribute
Dimensions (W*D*H)
Weight
Heat transfer fluid volume
Cooling capacity
(T +20°C / +68°F)
ambient
(T +20°C / +68°F)
setpoint
Standard temp. range
Optional temp. range
Power supply requirement
Sound pressure level
Auto-diagnostic functions
Display
Fluid fittings (standard)
Fluid fittings (option)
Tool-less access
Undertemperature
protection
Overtemperature
protection
Compressor overload
protection
Overcurrent protection
Rated duty cycle
st
1 party approvals
rd
3 party approvals
Compatible heat transfer
fluids
Opening section EMPC3
Author(s) MJH
Unit Value
mm 180*435*380
inch 7.1*17.1*15
kg 20
lbs. 44.1
mL 650
USGal 0.172
W 500
BTU/h 1706
RT 0.142
°C +4 to +35
°C -10 to +65
VAC 100-240
Hz 50/60
1@240VAC
A
2@115VAC
dB 64
Undertemperature cutout
Overcurrent cutout
Refrigeration overpressure cutout
Process temperature
Compressor active/inactive
Pushfit 12mm
Valved QR
No
Via display setup
Hardware limited
Via PCB function
Fused, 2* T6.3A H250V
Continuous
CE
UL61010-1
CAN/CSA-C22.2
FCC CFR47 Part 15 Subpart B
IEC61000-6-4:2007 +A1:2011
IEC61000-6-2:2005
IEC61000-3-2:2014
IEC61000-3-3:2013
DI water
Propylene glycol Hexid A4, A6
Installation, Operation & Service Manual
EcoMini (EMxxn)
DOCUMENT DETAILS
Page 3 / 5 Revision 1

PRODUCT SPECIFICATIONS

Pending data collection
Power consumption curves
Cooling capacity curves
Pump performance curves
3
