ATC MPC3 Installation, Operation & Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Applied Thermal Control Ltd
39 Hayhill Industrial Estate
Installation, Operation & Service Manual
Barrow-upon-Soar, Loughborough
LE12 8LD, United Kingdom
MPC3 / MPC10 / MPC18 / MPD3
+44 (0) 1530 839 998
Service@thermalexchange.co.uk
Support@app-therm.com
DOCUMENT DETAILS
Date 28/OCT/2020
Author(s) MJH
Page 1 / 5
Revision 4
Opening section MPC3, 10, 18 & MPD3
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPC3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATC MPC3

Summary of Contents for ATC MPC3

  • Page 1 Applied Thermal Control Ltd 39 Hayhill Industrial Estate Installation, Operation & Service Manual Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom MPC3 / MPC10 / MPC18 / MPD3 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 28/OCT/2020 Author(s) MJH Page 1 / 5 Revision 4 Opening section MPC3, 10, 18 &...

  • Page 2: Change Log

    Applied Thermal Control Ltd 39 Hayhill Industrial Estate Installation, Operation & Service Manual Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom MPC3 / MPC10 / MPC18 / MPD3 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 28/OCT/2020 Author(s) MJH Page 2 / 5...

  • Page 3: Product Specifications

    Applied Thermal Control Ltd 39 Hayhill Industrial Estate Installation, Operation & Service Manual Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom MPC3 / MPC10 / MPC18 / MPD3 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 28/OCT/2020 Author(s) MJH Page 3 / 5...

  • Page 4: Safety Notices

    For your safety, we draw your attention to the following warning and caution marks throughout the manual; the safe operation of an ATC chiller always remains the responsibility of the operator. This equipment is intended to be used as a liquid temperature conditioning device – it requires no external pump, nor any further manipulation of temperature.
  • Page 5 Applied Thermal Control Ltd 39 Hayhill Industrial Estate Installation, Operation & Service Manual Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom MPC3 / MPC10 / MPC18 / MPD3 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 28/OCT/2020 Author(s) MJH Page 5 / 5...

  • Page 6: Document Details

    ATC cannot be held responsible for any transit damage subsequently found. As the unit is >18kg, ATC must recommend that 2 persons are used to lift by hand, or a crane. Remove the unit from its original packaging and ensure that there is no packaging left around the cooling ducts. There is no internal product packaging that requires the chiller to be opened.

  • Page 7: Site & Environmental Requirements

    Caution; Always use ATC recommended fluids in your chiller – many other anti-freeze mixtures have the potential to corrode your application and to damage seals in the chiller.

  • Page 8: Installation

    Check all joints are tight and leak free. Where this product is incorporated into other equipment, it is the responsibility of the assembler to ensure safety. Caution; Do not replace detachable mains cords with inadequately rated cords. Contact ATC for appropriately rated products.

  • Page 9: Filling Procedure

    Revision 1 FILLING PROCEDURE The Mini chiller has a different fill procedure to ATC’s other products. Please read the entire passage before starting and familiarize yourself with the process. a) Connect the chiller to the electrical supply and switch on at the rear rocker switch.
  • Page 10 1. Process-start will start fridge and water circuit. 2. Pump priming button runs pump without process starting. 3. Access to settings menu. 4. Service pack refers to software version installed. 5. Serial number is added by ATC during production. Process View 1. Process stop. 9. Condensing temperature.
  • Page 11 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 2 / 9 Revision 1 Program Mode 1.
  • Page 12 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 3 / 9 Revision 1 Software Management (incl. logs and programs) 1.
  • Page 13 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 4 / 9 Revision 1 Maintenance Prompt View 1.
  • Page 14 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 5 / 9 Revision 1 Factory Settings (3) Scroll down from ‘Factory Settings’...
  • Page 15 4. Select start address. 5. Direction of data, select read-write, or read-only. 6. Data transmission rate. 7. Select odd or even. 8. Select half or full; standard ATC wiring is 3-wire half duplex. Annex E-1 200707 XTD controller XTD043RB-K620G&F (Mini at SW v39.4)
  • Page 16 5. Frequency issued to instruct the compressor to stop. Fan Settings Fan performance is closely linked to overall refrigeration system health. ATC caution users against making changes. 1. Return to ‘Factory Settings’ main menu. 2. To avoid stalling, the minimum duty default is 17%.
  • Page 17 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 8 / 9 Revision 1 Display Settings 1.
  • Page 18 Applied Thermal Control Ltd Operating Manual; Controller Operation 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex E-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 5/DEC/2019 Author(s) MJH Page 9 / 9 Revision 1 PID Cooling Settings (1) 1.
  • Page 19 Applied Thermal Control Ltd Operating Manual; Pressure & Flow Adjustment 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex F-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 29/NOV/2019 Compiled by MJH Revision 1 PRESSURE AND FLOW ADJUSTMENT IN MINI CHILLER WITH CENTRIFUGAL PUMP The Mini is available with a range of pump options.
  • Page 20 Fluid seen leaking from system Rapid changes in system temperature can cause some materials to change shape at a faster rate than others. Contact ATC to discuss alternative materials and parts in water circuit construction. Check for any error states on the compressor – the controller will indicate if an error has occurred –...
  • Page 21 Always clean with power supply isolated. Caution; Never blow out the condenser with compressed air. Caution; If the mains lead is lost or damaged, contact ATC who will be able to supply a replacement of the correct specification.
  • Page 22 Applied Thermal Control Ltd Operating Manual; Maintenance for Technicians 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex I-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 29/NOV/2019 Author(s) MJH Page 1 / 1 Revision 1 GENERIC MAINTENANCE FOR TECHNICIANS Warning;...
  • Page 23 Applied Thermal Control Ltd Operating Manual; Declarations & Approvals 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex J-1 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 6/JAN/2020 Author(s) MJH Page 1 / 1 Revision 3 EU DECLARATION OF CONFORMITY Document layout;...
  • Page 24 Applied Thermal Control (ATC) adheres to and embraces the ethical values that support our everyday activities. As an expression of these principles and ethical values, ATC adheres to the principle of responsible sourcing of components containing precious and non-precious metals and metal salts in compliance with applicable laws and regulations.
  • Page 25 Applied Thermal Control Ltd Operating Manual; Declarations & Approvals 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex J-7 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 15/JUL/2020 Author(s) MJH Page 1 / 1 Revision 1 WHAT IS THE REACH REGULATION 1907/2006? REACH is a regulation of the European Union, adopted to improve the protection of human health and the environment from the risks that can be posed by chemicals, while enhancing the competitiveness of the EU...
  • Page 26 Applied Thermal Control Ltd Operating Manual; Declarations & Approvals 39 Hayhill Industrial Estate Barrow-upon-Soar, Loughborough LE12 8LD, United Kingdom Annex J-8 +44 (0) 1530 839 998 Service@thermalexchange.co.uk Support@app-therm.com DOCUMENT DETAILS Date 27/AUG/2020 Author(s) MJH Page 1 / 1 Revision 1 WHAT IS THE POPs REGULATION 2019/1021? POPs stands for persistent organic pollutants.

  • Page 27: Warranty Terms

    ATC’s technical guidance on the web and in the product manual. On occasion, at the discretion of ATC, goods may be serviced on site FOC or a service loan unit may be supplied.
  • Page 28 Tel: +44 (0)1530 839998 OVERVIEW The ATC MINI Chiller uses the ModBUS® RTU communication protocol over RS485 networks All communication messages finish with a check sum type CRC (cyclic redundancy check). Every slave device in a network must have a different address.

  • Page 29: Physical Connection

    1 Physical Connection The ATC MINI Chiller is provided with an RS485 serial communication interface, insulated to 1kV so that any problem arising from ground potential is removed. While idle, the MINI Chiller is in a receive condition and only undertakes transmission after a message has been decoded that matches the configured address.

  • Page 30: Communication Protocol

    ATC Mini Chiller - ModBUS Communication Protocol 2 Communication Protocol The protocol adopted by the ATC MINI Chiller is a subset of the widely used MODBUS RTU (JBUS, AEG Schneider Automation, Inc. registered trademark) protocol, so that connections are easy for many commercial PLCs and supervisory programs.
  • Page 31 CRC-16 (LSB) CRC-16 (MSB) The slave reply means register 25 = 0AHex (10 decimal) and register 26 = 14H (20 decimal). Annex L-11M 190503 SA00011M RS485 ModBUS RTU for Mini ATC MINI Chiller Modbus Protocol v1 - 03 May 2019...
  • Page 32 Value to write (MSB) Written value (MSB) Value to write (LSB) Written value (LSB) CRC-16 (MSB) CRC-16 (MSB) CRC-16 (LSB) CRC-16 (LSB) Annex L-11M 190503 SA00011M RS485 ModBUS RTU for Mini ATC MINI Chiller Modbus Protocol v1 - 03 May 2019...
  • Page 33 Byte count CRC-16 (LSB) Value 1 (MSB) CRC-16 (MSB) Value 1 (LSB) Value 2 (MSB) Value 2 ((LSB) CRC-16 (LSB) CRC-16 (MSB) Annex L-11M 190503 SA00011M RS485 ModBUS RTU for Mini ATC MINI Chiller Modbus Protocol v1 - 03 May 2019...

  • Page 34: Register Map

    ATC Mini Chiller - ModBUS Communication Protocol 3 Register Map The ATC MINI Chiller slave address, register start address, write permission, baud rate, parity, duplex and enable are set in the ModBUS Parameter submenu accessible from the MINI Chiller user interface touch screen.
  • Page 35 Temperature values are sent according to the Temperature Units setting in the MINI Chiller Parameter Menu. Pressure values are sent according to the Pressure Units setting in the MINI Chiller Parameter Menu Annex L-11M 190503 SA00011M RS485 ModBUS RTU for Mini ATC MINI Chiller Modbus Protocol v1 - 03 May 2019...
  • Page 36 Page 1 / 1 Revision 1 RECOMMENDED SPARES FOR ATC MINI (M-SERIES) AND ECOMINI (EM-SERIES) CHILLERS Recommended spares include all rotating machinery (i.e. motors, fans), all sacrificial elements (i.e. fuses) and parts that users interact with (dials, fittings). Pricing is available from sales@app-therm.com.

  • Page 37: Section 2: Hazards Identification

    SAFETY DATA SHEET according to Regulation (EU) 2015/830 Page Harp® 134a Revision Revision date 2017-06-21 SECTION 1: Identification of the substance/mixture and of the company/undertaking 1.1. Product identifier Product name Harp® 134a REACH Registration Number 01-2119459374-33 CAS No. 811-97-2 EC No. 212-377-0 1.2.

  • Page 38: Section 3: Composition/Information On Ingredients

    Page Harp® 134a Revision Revision date 2017-06-21 2.2. Label elements Signal Word Warning Hazard Statement Compressed gas: H280 - Contains gas under pressure; may explode if heated. Precautionary Statement: P410+P403 - Protect from sunlight. Store in a well-ventilated place. Storage 2.3.

  • Page 39: Section 6: Accidental Release Measures

    Page Harp® 134a Revision Revision date 2017-06-21 5.3. Advice for firefighters exposed containers. SECTION 6: Accidental release measures 6.1. Personal precautions, protective equipment and emergency procedures Ensure adequate ventilation of the working area. Avoid contact with skin and eyes. Evacuate personnel to a safe area.
  • Page 40 Page Harp® 134a Revision Revision date 2017-06-21 8.2. Exposure controls 8.2.1. Appropriate engineering Ensure adequate ventilation of the working area. controls 8.2.2. Individual protection Wear protective clothing. measures Eye / face protection Approved safety goggles. Skin protection - Wear suitable gloves. Handprotection Skin protection - Other Wear suitable protective clothing.
  • Page 41 Page Harp® 134a Revision Revision date 2017-06-21 9.2. Other information VOC (Volatile organic Not relevant compounds) Conductivity No data available Surface tension No data available Gas group No data available Benzene Content No data available Lead content No data available SECTION 10: Stability and reactivity 10.1.

  • Page 42: Section 13: Disposal Considerations

    Page Harp® 134a Revision Revision date 2017-06-21 12.1. Toxicity No data available 12.2. Persistence and degradability Not readily biodegradable. 12.3. Bioaccumulative potential Does not bioaccumulate. Partition coefficient Harp® 134a No data available 12.4. Mobility in soil No data is available on this product. 12.5.
  • Page 43 Page Harp® 134a Revision Revision date 2017-06-21 14.5. Environmental hazards Environmental hazards Marine pollutant 14.6. Special precautions for user No data is available on this product. 14.7. Transport in bulk according to Annex II of MARPOL 73/78 and the IBC Code No data is available on this product.
  • Page 44 Issue 6.3, January 2020 Page 1 of 4 SAFETY DATA SHEET HEXID A4 HEAT TRANSFER FLUID Conforming to Directive 1907/2006/EC SECTION 1: IDENTIFICATION OF THE SUBSTANCE/MIXTURE AND OF THE COMPANY/UNDERTAKING 1.1. Product Name Hexid A4 1.2. Supplier Applied Thermal Control Limited 39 Hayhill Industrial Estate, Barrow upon Soar, Leicestershire, LE12 8LD.

  • Page 45: Personal Precautions

    Issue 6.3, January 2020 Page 2 of 4 SAFETY DATA SHEET HEXID A4 HEAT TRANSFER FLUID Conforming to Directive 1907/2006/EC SECTION 6: ACCIDENTAL RELEASE MEASURES 6.1. Personal precautions Use personal protective equipment. Avoid contact with skin and eyes. Keep unnecessary and unprotected personnel from entering the area.

  • Page 46: Section 10: Stability And Reactivity

    Issue 6.3, January 2020 Page 3 of 4 SAFETY DATA SHEET HEXID A4 HEAT TRANSFER FLUID Conforming to Directive 1907/2006/EC SECTION 10: STABILITY AND REACTIVITY 10.1. Reactivity Stable under recommended storage conditions. No dangerous reaction known under conditions of normal use.
  • Page 47 Issue 6.3, January 2020 Page 4 of 4 SAFETY DATA SHEET HEXID A4 HEAT TRANSFER FLUID Conforming to Directive 1907/2006/EC SECTION 12: ECOLOGICAL INFORMATION 12.1. Acute toxicity Fish - LC50 : 40613 mg/l (Oncorhynchus mykiss; 96 h) (static test) Daphnia and other aquatic invertebrates - LC50 : 18340 mg/l (Ceriodaphnia Dubia (water flea); 48 h) (static test) Algae - ErC50 : 19000 mg/l (Pseudokirchneriella subcapitata (green algae);...
