- Page 1 Swimming Pool Heat Pump USER MANUAL Read the instructions Illustrative photo...
- Page 2 Regulation (EU) n° 517/2014 of 16/04/14 on fluorinated greenhouse gases and repealing Regulation (EC) n° 842/2006 Leak checks 1. Operators of equipment that contains fluorinated greenhouses gases in quantities of 5 tons of CO2, equivalent or more and not contained in foams shall ensure that the equipment is checked for leaks. 2.
-
Page 3: Table Of Contents
0 °C, or else the Titanium exchanger will be damaged Thank you for using BRILIX swimming pool heat pump four your pool heating it will heat your pool water because of being frozen, in such case, your warranty will be lost. -
Page 4: Specifications
1.Specifications 1.1 Horizontal EU design, R32, HEATING AND COOLING Models XHPFDPLUS60 XHPFDPLUS100 XHPFDPLUS140 XHPFDPLUS160 * Heating Capacity at Air 28℃, Water 28℃,Humidity 80% Heating capacity Power consumption 0, 8 1,44 1,92 1,92 6,25 6,25 6,25 6,25 * Heating Capacity at Air 15℃, Water 26℃,Humidity 70%... - Page 5 EATING AND COOLING 1.2 Horizontal EU design, R410A ,HEATING AND COOLING HPFD100 Models XHPFD140 XHPFD160 XHPFD40 XHPFD60 XHPFD100 XHPFD140 XHPFD160 XHPFDPLUS 200 XHPFDPLUS 200 XHPFDPLUS 200 Tri XHPFDPLUS 200 Tri *Capacity at 25 °C/Water27 °C Heat Output (kW) 12,0 15,0 18,0 18,0 12,0...
-
Page 6: Installation
2.Installation 2.1 Installation illustration Water treatment Pump Filter Horizontal 800 mm min. By-pass Hot water to pool NOTE: The factory only provides the heat pump unit. The other items in the illustration are necessary spare parts for the water system which are provided by users or installers. ATTENTION: Please follow these steps when operating the first time 1. - Page 7 2.2 Installation (1) The heat pump unit must be installed by professional technicians. Otherwise unit may be damaged or body injured, even dead. (2) The unit designed for outdoor location with good ventilation. Recirculation of cold discharge air back into evaporator coil will greatly reduce heating capacity and efficiency of the unit, which will avoid the compessor warranty.
- Page 8 (9) Typically, the pool heat pump unit should be installed aside the pools, less than 7.5 meters distance. If it is installed farther away, the pipeline system will cause greater heat loss. The most of pipeline are installed under ground , although the pipeline. system has to do thermal insulation ,but tunnels and the soil around will still occur heat exchange , for example, each 30 meters ( 15 meters to and from the pump=30 meters total),unless the ground is wet or the water table is high.
- Page 9 2.3 The location of chemical’s instruction to your system is also critical to the heater’s life. If an automatic chlorinator or brominates is used, it must be located downstream of the heater. A trap must be installed between the chlorinator and the heater to prevent chlorine return into the heat pump. (See below pictures) Pressure-type Chlorinator or Brominator Check-valve...
-
Page 10: Initial Startup Of The Unit
DISCONNECT: A disconnect means (circuit breaker, fused or un-fesed switch) should be located within sight of and readily accessible from the unit. This is common practice on commercial and residential heat pumps. It prevents remotely-energizing unattended equipment and permits turning off power at the unit while the unit is being serviced. -
Page 11: Wiring Diagram
4.Wiring diagram Model: XHPFDPLUS60 & XHPFDPLUS100 COMPRESSOR Fan Motor R WHT C RED YLW/GRN YLW/GRN RUN/POW OUT1 Ambi e nt temperature OUT2 Heati n g pi p e temperature Water out temperature Water i n temperature Transformer OUT3 AC-N YLW/GRN... - Page 12 Model: XHPFDPLUS140 & XHPFDPLUS160 COMPRESSOR FAN MOTOR R WHT C RED YLW/GRN YLW/GRN OUT2 OUT1 RUN/POW OUT3 Ambient temperature Back temperature OUT4 Heating pipe temperature Water out temperature Water in temperature Transformer OUT5 AC-N YLW/GRN SWITCH (Water Pump) 220-240V ~ 50Hz * The dotted line part are only used in some models 3-XPDLT0022S Note: Electrical connection...
- Page 13 5.3 Schéma zapojení bazénového tepelného čerpadla Model: XHPFDPLUS 200 XHP 200, XHPFD200 YLW/GRN FAN MOTORR FAN MOTORR COMPRESSOR R WHT C RED YLW/GRN YLW/GRN OUT2 OUT1 RUN/POW OUT3 Cooling pipe temperature Ambient temperature Back temperature OUT4 Heating pipe temperature Water out temperature Transformer Water in temperature OUT5...
- Page 14 5.4 Schéma zapojení bazénového tepelného čerpadla Model: XHPFDPLUS 200 Tri XHP 200 Tri ,XHPFD200 Tri 3-XPDLT0052 Phase sequence protection High voltage switch Low voltage switch Flow switch failure Remote controller 1 3 4 Current checking Current checking * The dotted line part are only used in some models...
-
Page 15: Operation
SWITCH (Water Pump) 220-240V ~ 50Hz * The dotted line part are only used in some models 3-XPDLT0022S Note: Electrical connection 5.4 Schéma zapojení bazénového tepelného čerpadla The power supply for the heat pump must come, preferably, from an exclusive circuit with regulatory XHP 200 Tri ,XHPFD200 Tri protection components (30mA differential protection) and a magneto-thermal switch. - Page 16 - The tolerance of acceptable voltage variation is +/- 10% during operation. The connections must be dimensioned according to the power of the device and the state of installation. - The cables must be properly installed to prevent interference. 5.Operation - The pump is intended for connection to a general power supply with earth connection.
- Page 17 Parameter 0 Parameter 1 Parameter 2 To set the entering water temp. To set the entering water temp. Total working time of compressor under cooling mode (15-35 °C, under heating mode (15-40 °C, after frosting (30-90 min,default default setting: 28 °C) default setting:28 °C) setting : 40 min) Parameter 3...
- Page 18 Parameter 9 Parameter A Manual adjustment steps of Manual adjustment steps Cooling target for superheat of electronic expansion electronic expansion valve valve(18-94), default (-15 °C -15 °C),default setting: 70(*5) setting -2 °C HEATING MODE COOLING MODE 5. 3 How to know the current status? Inlet water temp.
- Page 19 Actual steps of electronic expansion valve. (1) Press to check water-in/water-out/heating and cooling Condenser /back gas/ambient temperature/actual steps of electronic expansion valve. (2) When the unit is switched off, current time is displayed. 5.4 Water temperature setting: Under current mode, press to modify the water setting temperature even if it is ON/OFF status.
- Page 20 5.9 RUNNING DATA SETTINGS ATTENTION: •HP running parameters must be checked after installation and before first used. •When the LED on, it will display water inlet temperature. •When the LED off, it will display the actual time •When the LED on, the water temp could be changed. Parameter Meaning Range Defaul...
-
Page 21: Maintenance
REMARKS: (1) When HP stop running in 60 seconds, water pump will shut off automatically. (2) LED wire controller can operate the water pump after connected additional cable to the pump device in the position of “PUMP” terminal accurately. (3) It is necessary to put an extra 3-phase transfer device for 3 phases water pump. 6.Maintenance You should check the water supply system regularly to avoid the air entering the system and occurrence of low water flow, because it would reduce the performance. - Page 22 Warranty terms and conditions The warranty conditions are governed by your supplier’s trade and warranty terms and conditions. Safe disposal of the product after its service life After its service life is over, have the product disposed of ecologically by a specialized company. Claims and servicing Claims are governed by applicable consumer protection legislation.
- Page 23 A0124MBX3203...
