- Page 1 Dressing Table Green Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 06/03/20...
- Page 2 ● Regularly check and ensure that all bolts and fittings are tightend properly. ● This product is compliant EN 12521. Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales).
- Page 3 Fittings (Shown to scale) Bag 1 8 x 30 mm Dowel x 28 38 mm Screw x 10 15 mm Screw x 6 15 mm Screw x 2 Pipe Plug x 4 Metal Dowel x 14 12 mm Screw x 8 15 mm Locking Nut x 14 25 mm Screw x 4 28 mm Screw x 8...
- Page 4 Fittings (Shown to scale) Bag 3 22 mm Screw x 4 Handle Screw x 1 Handle x 2...
- Page 5 Hardware Metal Left Foot x 1 Metal Right Foot x 1 Metal Tube x 1 Metal Tube x 1 Metal Tube x 1 Drawer Runner x 2 Mirror x 1...
- Page 6 Tools required Ruler/tape Phillips screwdriver (small & medium) measure Phillips screwdriver Eye protection (small & medium) (when using a hammer or glue) Large hammer Power Drill Pencil Drill Heads...
- Page 7 Panels Bent Wood (1024 x 259 mm) Top Panel (1000 x 420 mm) Drawer Front Side (998 x 157 mm) Drawer Back Side (928 x 99 mm) Bottom Panel (970 x 420 mm) Drawer Right Side (300 x 99 mm) Right Side Panel (320 x 139 mm) Drawer Left Side...
- Page 8 8 x 30 mm Dowel x 28 38 mm Screw x 10 Metal Dowel x 6 15 mm Screw x 6 15 mm Screw x 2 Pipe Plug x 4 15 mm Locking Nut x 14 Metal Dowel x 14 12 mm Screw x 8 25 mm Screw x 4 28 mm Screw x 8...
- Page 9 8 x 30 mm Dowel x 4 Metal Dowel x 4 Drawer Runner x 2 15 mm Screw x 6 8 x 30 mm Dowel x 8...
-
Page 10: X 30 Mm Dowel X
8 x 30 mm Dowel x 6... -
Page 11: Mm Screw X
38 mm Screw x 2 15 mm Locking Nut x 4 Rotate Product... - Page 12 38 mm Screw x 2...
- Page 13 15 mm Locking Nut x 6 Rotate Product...
-
Page 14: Mm Screw X
Fasten the bolts using the alley key but do not fully tighten at this stage. 25 mm Screw x 2 Alley Key x 1 Fully tighten all bolts using alley key. 25 mm Screw x 2 Washer x 2 Alley Key x 1... - Page 15 12 mm Screw x 8 Metal Right Foot x 1 Alley Key x 1 Metal Tube x 1 Fasten the bolts using the alley key but do not fully tighten at this stage. Metal Left Foot x 1 Metal Tube x 1 28 mm Screw x 2 Alley Key x 1 Metal Tube x 1...
- Page 16 Pipe Plug x 4 Rotate Product Rotate Product...
- Page 17 28 mm Screw x 6 Alley Key x 1 Fully tighten all bolts using alley key. Rotate Product...
- Page 18 Metal Dowel x 4 8 x 30 mm Dowel x 1 8 x 30 mm Dowel x 1...
- Page 19 8 x 30 mm Dowel x 4 15 mm Locking Nut x 2...
- Page 20 15 mm Locking Nut x 2 38 mm Screw x 2...
- Page 21 38 mm Screw x 4 22 mm Screw x 4 Handle Screw x 1 Handle x 2 22 mm Screw x 4 Handle x 2...
- Page 22 15 mm Screw x 2...
- Page 23 Mirror x 1 Handle Screw x 1...
- Page 24 26 mm Screw x 1 Fischer Dubel 12 mm Screw x 1 25 x 150 mm Wall Strap 12 mm Screw x 1 25 x 150 mm Wall Strap 26 mm Screw x 1 Fischer Dubel...
- Page 25 WARNING!
- Page 26 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
