Understairs Storage Unit
Assembly Instructions
Dimensions
Width - 81cm
Depth - 23.6cm
Height - 91.2cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
- Please keep for future reference
875/3775
Version2 Date: 26/11/12
Advertisement
Related Manuals for Argos 875/3775
Summary of Contents for Argos 875/3775
- Page 1 Understairs Storage Unit 875/3775 Assembly Instructions - Please keep for future reference Dimensions Width - 81cm Depth - 23.6cm Height - 91.2cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand on the product, • We do not components and tools listed on this could cause damage. recommend the pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Top panel Large shelf panel (20.8 x 23.5cm) (79.5 x 23.5cm) Small side panel x 4 (23.4 x 20.8cm) Bottom panel (79.5 x 23.5cm)
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. in some cases mor may be supplied than are required. 39mm Locking pin x 4 50mm Screw x 18 30mm Dowel x 8 15mm Locking nut x 4 Wall plug x 1 Screw cover x 10 (This screw is...
- Page 5 Assembly Instructions Step 1 Attaching small shelf panel Use Locking pin Dowels onto the Top panel Note: Insert Locking pin as far as shown. Do not over tighten. the unit. Use a screwdriver to turn Locking nut clockwise to lock. Small shelf panel onto the Small side panel...
- Page 6 Assembly Instructions Step 3 Attaching large shelf panel Use Locking pin the Small side panel onto the Central panel Note: Insert Locking pin as far as shown. Do not over tighten. Use Locking nut Use a screwdriver to turn Locking nut clockwise to lock.
- Page 7 Assembly Instructions Step 4 - continued Use Locking nut Use a screwdriver to turn Locking nut clockwise to lock. Bottom panel onto the Small side panel Step 5 Attaching large side panel Large side panel onto the Top panel ,Small shelf panel ,Central panel...
- Page 8 Assembly Instructions Step 6 Fixing to wall It is recommended that the Note: Wall plugs supplied are wall for solid wall only. wall. be used for your wall, seek professional advice if in doubt strap onto the back of top panel. With help, move storage unit Top panel into position.
-
Page 9: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
