American Dynamics MegaPower 3200 Installation Manual page 8

VOMs: A VOM, as directed by the keyboard, acts as
a secondary switch by selecting which of its four
video outputs (A, B, C, or D) connects to the video
input selected by the VIM of a camera group. A
VOM:
• Is installed in the bay for the highest camera
group.
• Comes in three types: VOM-1 supports four
camera groups, VOM-3 supports eight camera
groups, and VOM-4 supports 13 camera groups.
IMPORTANT! The highest camera group is
always received internally from the bay the VOM
resides. All other camera groups are received
externally from other bays via VOM cables. The
video path of a video input is shown in Figure 7.
• Provides text overlay to the video signal.
• Comes factory configured for the monitor levels it
will support. However, the installer must configure
the VOM (using jumpers) if they are replacing a
defective one or adding one to an existing system.
Standard vs. Condensed Bays
A switching bay can be an AD2010 standard bay or
AD2020 condensed bay.
Standard Bay
The standard bay (Figure 5) contains a video
switching bus along an internal backplane that has
16 lines.
Note: A standard bay is considered "mixed" when it
contains both VIMs and VOMs, or "dedicated" when
it contains only VIMs or VOMs. VOMs are installed in
only in the bay for the highest numbered camera
group.
Figure 5. AD2010 standard bay (rear view)
VOMs VIMs
AD2010N/P AND AD2020N/P MATRIX SWITCHING BAYS
INSTALLATION GUIDE
• A standard bay dedicated to video inputs can
• A mixed bay can support a mix of video inputs
• A bay dedicated to video outputs can support up
Figure 6. VIM and VOM combinations
241
256
Data
Buffer P/S
IN
T
E
DATA LINE
S
OUT
T
/
E
X
P
IN
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
6 of 64
support up to 256 video inputs or one camera
group. Up to 16 VIMs can plug into this bay. No
VOMs are used. See "A" in Figure 6.
and outputs. The number of VIMs allowed
depends on the number of VOMs required. See
Table 2 and "B–E" in Figure 6.
Table 2. Mixed bay input/output
combinations
Video Inputs Video Outputs
240 (15 VIMs) 4 (1 VOM)
224 (14 VIMs) 8 (2 VOMs)
208 (13 VIMs) 12 (3 VOMs)
192 (12 VIMs) 16 (4 VOMs)
to 64 video outputs. Up to 16 VOMs can plug into
this bay. No VIMs are used. See "F" in Figure 6.
1
A
IN
T
E DATA LINE
S
OUT
T
16 VIMs
/
E
X
P
(Dedicated Bay) IN
A
EXT. SYNC
N
S
I OUT
O
N
50/60 Hz
16
209 1
C
IN
T
E
DATA LINE
S
OUT
T
14 VIMs, 2 VOMs
/
E
X
P
(Mixed Bay) IN
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
224 16
177 1
E
IN
T
E
DATA LINE
S
T OUT
12 VIMs, 4 VOMs
/
E
X
P
IN
(Mixed Bay)
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
192 16
225 1
B
IN
T
E
DATA LINE
S
T OUT
15 VIMs, 1 VOM
/
E
X
P
IN
(Mixed Bay)
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
240 16
193 1
D
IN
T
E
DATA LINE
S
OUT
13 VIMs, 3 VOMs T
/
E
X
(Mixed Bay) P
IN
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
208 16
F
IN
T
E
DATA LINE
S
T OUT
16 VOMs
/
E
X
P
IN
(Dedicated Bay)
A
N EXT. SYNC
S
OUT
I
O
N
50/60 Hz
1 64
