Specifications

Operational
Bandwidth............................................................. 17MHz
Frequency response ............................. ±0.5dB to 12MHz
S/N ratio................................ 65dB (Vp-p vs. Vrms noise)
Crosstalk
Adjacent channels ........................–55dB (at 3.58MHz)
Input-to-input .................................–70dB (at 3.58MHz)
Differential delay ...................................................... ±1.0˚
Differential phase......................................... 1.5˚ or better
Differential gain.......................................... 1.0% or better
Tilt.............................................................. 0.5% or better
Gain ..............................................................Unity (±1dB)
Return loss (input/output) ...................................... ≥40dB
DC level (video signal)................................................. 0V
Switching .......................................Complete switching of
cross-point matrix. EIA RS-170
Switching speed....................................... <20ms (typical)
Keyboard/Receiver control time................. 20ms (typical)
Phase adjustment .............................180˚ vertical interval
Non-volatile memory.............................Setup information
On-Screen Text ......................................Date/time, video
Character Set ............................................Alpha numeric
Electrical
Power ........................................40W nominal, 60W max.
AD2010N, AD2020N ............ 120Vac (±10%), 50-60Hz
AD2010P, AD2020P ......... 100-240Vac (auto-sensing)
Max Operational Limit ......................90-264V, 47-63Hz
AD2010N/P AND AD2020N/P MATRIX SWITCHING BAYS
INSTALLATION GUIDE
and NTSC, CCIR and PAL
adjustment for switching bay
saved in permanent
flash memory
input number,
video input title,
site number,
site title monitor status,
user/keyboard number
(with 16 modules)
Connections
Video inputs .......................0.5–2.0Vp-p, composite BNC
Video outputs ...............................1Vp-p, composite BNC
AD data line in/out ......................... Two BNC connectors
External sync in/out........................ Two BNC connectors
Mechanical
Mounting ....................... Designed for EIA-310-D and
Dimensions (H x W x D)...................267 x 483 x 470 mm
Weight..................................... 28kg (60 lbs), fully loaded
Environmental
Operating temperature .............. 0˚ to 40˚C (32˚ to 104˚F)
Storage temperature ........... –40˚ to 70˚C (–40˚ to 155˚F)
Humidity .......................... 0 to 95% RH (non-condensing)
25 of 64
IEC 60297-1 standard 482.6mm
(19in) electronic racks
(10.5 x 19 x 18.5in)
bay (with 16 modules)
