Chapter 1
1 2

Physical Description

1 2 1

The Exterior

LED Explanation
LED
(Wi-Fi)
(Internet)
(Battery)
Blinking Green
Note:
The LEDs will turn off automatically after idling for 30 seconds. To check the LED status, press the Power
button to turn them on again.
Item Explanation
Item
Power Button
Micro USB Port
Micro USB Port
Status
On Wi-Fi is enabled.
Off Wi-Fi is disabled.
On Internet service is available.
Off Internet service is unavailable.
On Power is on.
Off Power is off.
Blinking Red The battery level is lower than 10%.
The Mobile Wi-Fi is charging.
• Press and hold to power on/off the Mobile Wi-Fi.
• Press to turn on LEDs if they are off after idling.
Plug in the USB cable to this port to charge your Mobile Wi-Fi.
Get to Know About Your Mobile Wi-Fi
LEDs
Power Button
Indication
Description
5
