Quick Installation Guide

Portable 3G/4G Wireless N Router
TL-MR3020
MODEL NO.
2

Hardware Connection

3G/4G Router Mode (Default)
In this mode, the TL-MR3020 is connected to a 3G/4G USB modem
and wirelessly share the 3G/4G mobile connection to multiple users.
Mode Switch
NOTE: 1. TL-MR3020 can be powered by Power Adapter or laptop/PC through the USB cable.
2. TL-MR3020 will restart automatically after you turn the Mode Switch.
3

Connect to Network

Here we take Wireless Network Connection as example, please make sure your device is wirelessly enabled.
For Windows XP
1
Click the icon at the bottom of your desktop.
2 Click Refresh network list, and then select the SSID
(wireless network name) of TL-MR3020. Click Connect.
NOTE: 1. The default SSID of the network is TP-LINK_POCKET_3020_xxxxxx (The xxxxxx is the last six characters of the Router's MAC address.)
2. The pre-encryption of TL-MR3020 is written on the product label, please refer to it when you connect to the wireless network.
4
Router Con gurations
1
Open a web browser, type 192.168.0.254 in the address eld, and press Enter. At the prompt,
enter the default User Name and Password: admin. Click OK to enter the Router's management
page.
NOTE:
For your convenience, TL-MR3020 will keep the following two items when you switch the working mode:
1. WAN information (Internet information), such as the User name and Password of 3G/4G ISP and PPPoE, the Dynamic IP address setting, etc.
2. Wireless settings, such as SSID (Wireless Network Name), Key Type and Password.

Package Contents

Portable 3G/4G Wireless N Router
TL-MR3020
TL-MR3020 QIG
Power Adapter USB Cable
Resource CD Ethernet Cable
System Requirement
The following operating systems are supported:
• Windows XP • Windows Vista • Windows 7
• Windows 98 • Windows 2000 • Windows 2003
• Windows Me • Mac • Linux
The following browsers are supported:
• Internet Explorer • FireFox
• Safari • Chrome
WISP Client Router Mode
In this mode, the TL-MR3020 is wirelessly connected to the WISP
(Wireless Internet Service Provider) and share the Internet with
multiple users.
3G/4G
For Windows 7
1
Click the icon
2
Click refresh button
Connect.
1

Physical Description

Mode Switch
Power
Internet
WLAN
RJ45 Ethernet
WPS/RESET
SSID: 123
Mode Switch
at the bottom of your desktop.
and then select the target network. Click
2
After a successful login, please con gure the Router according to the working mode you
choose.
3G/4G USB Port This port is used to plug a 3G/4G modem/card into.
Mini USB Port
This port is used to connect the provided power adapter.
This port can be LAN or WAN port depending on the
RJ45 Ethernet Port
working mode.
3G/4G USB Port
This button is used to switch the working mode of the
Mode Switch
Router.
Mini USB Port
To use WPS function, please push the button for less
RJ45 Ethernet Port than 5 seconds, and then the WPS LED will flash; to
WPS/RESET
reset the Router, please push the button for at least 10
seconds.
Solid The Router is on.
Power
O The Router is o .
The Router is connected to the Internet, but
Solid
there is no data being transferred.
150Mbps TL-MR3020
Internet
Flashing The Router is transferring data.
O The Router is not connected to the Internet.
Solid Wi-Fi is enabled.
There is data being transferred through
Flashing
WLAN
Wi-Fi.
O Wi-Fi is disabled.
The Ethernet port is connected, but there is
Solid
no data being transferred.
RJ45 Ethernet
Flashing The Ethernet port is transferring data.
O The Ethernet port is not connected.
Standard AP Mode
In this mode, the TL-MR3020 is connected to a wired network
and transforms the wired Internet access into wireless so that
multiple users can share the Internet.
Wired Network
Mode Switch
For MAC OS
1
Click the icon at the right top of your desktop.
2
Make sure the status of Airport is On, and then select the
SSID (network name) of TL-MR3020 and click it.
(To be continued)
