Concentric thermostatic mini mixer shower

OPERATING THE SHOWER

(fig.16)
Fig.16
To start the shower, turn the On/Off flow control
clockwise until it hits the stop for maximum flow.
To stop the shower, turn the On/Off flow control
anti-clockwise until it hits the stop.
Temperature
control
To adjust the showering temperature rotate the
temperature control clockwise for cooler and
anti-clockwise for hotter.
CAUTION: Exposed metal surfaces may
become hot during use.
Hotter Cooler
Flow control
On Off
14
