Triton t150z Installation And Operating Instructions Manual

Pumped thermostatic electric shower
Hide thumbs
Table of Contents

Advertisement

Quick Links

t150z
pumped
thermostatic
electric shower
! IMPORTANT !
Under *NO circumstances must
this shower be connected directly
to a mains water supply.
It is designed for GRAVITY FED
COLD WATER systems ONLY !
*
Failure to comply may invalidate product warranty
Installation and
operating
instructions
I
nstallers please note these InstructIons are to be left wIth the user
2180759D
September 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the t150z and is the answer not in the manual?

Questions and answers

Related Manuals for Triton t150z

Summary of Contents for Triton t150z

  • Page 1 ! IMPORTANT ! Under *NO circumstances must this shower be connected directly to a mains water supply. It is designed for GRAVITY FED COLD WATER systems ONLY ! Failure to comply may invalidate product warranty...

  • Page 2: Table Of Contents

    Fault finding ................25 - 26 BEAB CARE requirements ............27 - 31 Guarantee, etc................. rear cover To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone: 0844 980 0730...

  • Page 3: Important Safety Information

    PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and  maintained in good working order in accordance with our instructions and recommendations. WARNING: DO NOT operate shower if frozen, or suspected of being frozen. It must thaw out ...

  • Page 4: Introduction

    INTRODUCTION ADVICE TO USERS This book contains all the necessary fitting and Important: When first installed the unit operating instructions for your electric shower. will be empty. It is essential the unit should Take time to read this book thoroughly and familiar-...

  • Page 5: Main Components

    MAIN COMPONENTS Fig. Note: Wires have not been shown for reasons of clarity. Inside unit (fig.) 8. Temperature Control 4. Shower outlet . Top cable/pipe entry 9. Terminal block 5. Filter . Wall screw fixings 0.

  • Page 6: Main Components

    MAIN COMPONENTS (continued) Fig. Inside Cover (fig.) 0. Stop/start switch - Inside . Control printed circuit board - Inside . Front cover - T150Z pumped Other items Instructions, guarantee, etc.

  • Page 7: Electrical Requirements

    ELECTRICAL REQUIREMENTS Shepperton Park, WARNING! W-006-A Triton Road, Nuneaton, THIS APPLIANCE MUST BE EARTHED Warwickshire, CV11 4NR The installation, supply cable and circuit protection must conform with BS 7671 (IEE wiring regulations) and be sufficient for the amperage required.
  • Page 8 5.1 A 30mA residual current device (RCD) must without the use of a plug or socket outlet. be installed in all UK electric and pumped t150z pumped thermostatic electric shower shower circuits. This may be part of the 6.2 The switch must be accessible and clearly consumer unit or a separate unit.

  • Page 9: Water Requirements

    WATER REQUIREMENTS The installation must be in accordance with Water Regulations/Bylaws. Supply Source ..........Gravity fed cold water only Minimum Head .......... 8cm Maximum static pressure ......100 kPa (1 bar) or (10m Head) Maximum inlet temperature ...... 28°C Minimum inlet temperature .......

  • Page 10: Siting Of The Shower

    SITING OF THE SHOWER WARNING! For ease of servicing, the unit must always be The shower must not be mounted on the surface of tiled walls. never positioned where it will be subjected tile up to the unit.

  • Page 11: Fitting The Shower To The Wall

    FITTING THE SHOWER TO THE WALL Fig.7 Note: The control knobs are an integral part of the cover – DO NOT attempt to remove them. Unscrew the two top and bottom two retaining screws (fig.7) and lift the cover from the backplate.

  • Page 12: Plumbing Connections

    PLUMBING CONNECTIONS Fig.0 Plumbing to be carried out before wiring DO NOT use jointing compounds on any pipe fittings for the installation. DO NOT solder fittings near the shower unit as heat can travel along pipework and damage components.
  • Page 13 The Inlet fitting is designed to rotate through Fig. to allow for either Top or Bottom/Rear entry fitting (fig.). Note: The inlet fitting is designed to enter a compression fitting only. DO NOT use push fit connectors as full engagement cannot be guaranteed.

  • Page 14: Electrical Connections

    ELECTRICAL CONNECTIONS Fig. Switch off the electricity supply at the mains. Fig. shows a schematic wiring diagram. The cable entry points are shown in fig.. The cable can be surface clipped, hidden or via 20 mm conduit.

  • Page 15: Shower Drain Pumps (Not Supplied)

    C. Solenoid Valve D. Trimplate DANGER! Rotating Parts Pump wire terminal block Control wire to connect the shower to the pump transformer module. Pumps are not supplied with any products manufactured by Triton Showers (see page 14 for compatible pumps).
  • Page 16 For Whale Pump warranty information please visit: www.whalepumps.com no endorsements are offered by Triton Showers regarding any third party products listed within this fitting book. ** To be used in conjunction with supplied flow sensor on the water inlet (NOT to be connected to Safeguard PCB).

  • Page 17: Commissioning

    Secure the cover with a couple of the retaining screws. IMPORTANT: When the T150Z being comissioned is to be used in the capacity of a BEAB Care shower, please refer to pages 28 - 29 and make sure that the appropriate sections are completed.
  • Page 18 • The following operation must be Fig.7 carried out with the flexible hose screwed to the outlet but without the showerhead attached. Make sure the outlet of the flexible hose is directed to waste. Turn the Temperature control to number ‘1’...

  • Page 19: Pcb Dip Switch Settings

    DIP SWITCH SETTINGS Fig.9 A four way DIP switch block is mounted on the control PCB that allows the user to configure the shower to perform different functions (fig.9). 1 2 3 4 Dip Switch No.

  • Page 20: Replacing The Cover

    REPLACING THE COVER Fig.0 Attached to the display PCB, inside the cover, is a 10-way ribbon cable. The ribbon cable connector must be plugged into the socket located at the right of the power PCB situated inside the unit (fig.0).

  • Page 21: Operating The Shower/Operating Functions

    OPERATING THE SHOWER When the electricity supply to the shower is switched on at the isolating switch, the “power on” indicator will light. Start/Stop button to start the shower Press the start/stop button and water will flow.
  • Page 22 Fig. The water temperature is altered by changing the amount of Hot water from the heater can that is mixed with Cold water from the inlet. This is done by moving the temperature control knob (fig.).
  • Page 23 OPERATING FUNCTIONS (fig.) Fig. Power on indicator (green) When the electricity supply to the shower is Power On indicator switched on at the isolating switch, the power indicator will light up. Low flow indicator (red)

  • Page 24: Instructions For Installers And Service Engineers Only

    INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLEANING THE FILTER Fig.4 It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower.

  • Page 25: Spare Parts

    SPARE PARTS Ref. Description Part No. Top and bottom pipe entry trim ......... 83313430 Thermal safety cut-out ..........22012020 Power printed circuit board ........7073709 Can and element assembly 8.5Kw ......P19520700 9.5Kw ......P19520703 Flow switch assembly ..........

  • Page 26: Spare Parts

    Solenoid outlet elbow assembly (not shown) ..P23410803 Heater can wire set (not shown) ......83313440 Triac and wires (not shown) ........P19520903 Thermister (not shown) ...........22012030 6. Front cover PCB ............7073708 7. T150Z Pumped Front cover assembly .....S23410600 (includes PCB and start/stop switch)

  • Page 27: Fault Finding

    FAULT FINDING FAULT FINDING Important: Switch off the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem/Symptom Cause Action/Cure Problem/Symptom Cause Action/Cure  Shower inoperable, no . Interrupted power...

  • Page 28: Fault Finding

    FAULT FINDING FAULT FINDING Problem/Symptom Problem/Symptom Cause Cause Action/Cure Action/Cure 6 Low flow LED 6. Low flow condition 6.. Insufficient water flow available. permanently on when 1. Check showerhead is not blocked start/stop bar pressed.
  • Page 29 BEAB CARE requirements In-service Testing (T50Z pumped) Designation Code: -IW-S Shower...
  • Page 30 BEAB CARE requirements...
  • Page 31 BEAB CARE requirements...

  • Page 32: Beab Care Requirements

    BEAB CARE requirements Notes for commissioning and in-service testing . Measuring the Shower Outlet Water 4. Measurement of Supply Voltage at Temperature Appliance Terminals With the shower running, position the Switch off the electricity at the mains supply showerhead horizontally and place a funnel and remove the circuit fuse.
  • Page 33 BEAB CARE requirements Frequency of in-service testing Table  Conditions for In-service test next in-service test 6 to 8 weeks after First in-service test. commissioning. If no significant change in water outlet temperature 12 months after (greater than ±1°C) between commissioning and first test.
  • Page 34 shower...
  • Page 35 shower...
  • Page 36 Triton is a division of Norcros Group (Holdings) Limited E-mail: serviceenquiries@tritonshowers.co.uk Extended Warranty AVAILABLE NOW. Call 0844 980 0740 for more details. 29-5-2009 TRITON reserve the right to change product specification without prior notice. E&OA. © TRITON SHOWERS 2009...
  • Page 37 Pdf Supplied By http://www.plumbworld.co.uk/...
