T R A N C E
2nd generation
electric shower
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
R E TAIL VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
THIS OFFER IS NOT VALID OUTSIDE THE UK
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The shower installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
IMPORTANT SAFETY ADVICE
The shower unit MUST BE switched off at the
isolating switch when not in use. This is a
safety procedure recommended for all
electrical appliances.
The shower head and hose supplied with this
product are a safety critical part of your shower.
Failure to use genuine Triton parts may cause
injury and invalidate your guarantee.
2180629O - August 2024
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Triton TRANCE
Summary of Contents for Triton TRANCE
- Page 1 The shower head and hose supplied with this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321 INSTALLATION AND OPERATING INSTRUCTIONS Please read this book thoroughly and familiarise yourself with all instructions before commencing installation and keep it for future reference.
-
Page 2: Important Safety Information And Guidance Notes
Trance 2nd generation electric shower INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. - Page 3 IMPORTANT - PLEASE READ THESE Trance 2nd generation electric shower GENERAL GUIDANCE NOTES BEFORE PROCEEDING GENERAL 2.3 DO NOT solder pipes or ttings within 300mm of the shower unit, as heat can transfer along Isolate the electrical and water supplies before the pipework and damage components.
-
Page 4: Specifications
Trance 2nd generation electric shower ADVICE TO USERS This book contains all the necessary fitting and operating instructions for your Triton electric shower. Please read them carefully. IMPORTANT: When rst installed the unit The shower installation must be carried out by a will be empty. -
Page 5: Table Of Contents
Load Profile Energy Efficiency Class Energy Efficiency (%) Annual Electricity Consumption (kwh) Sound Power Level (db) To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Telephone: 024 7637 2222 Email:... -
Page 6: Main Components
Trance 2nd generation electric shower MAIN COMPONENTS Fig.1 Inside unit (fig.1) 1. Top cable entry 2. Bottom pipe entry 3. Rear pipe entry area 4. Side pipe entry area 5. Rear cable entry area 6. Wall screw fixing 7. Terminal block 8. -
Page 7: Electrical Requirements
Trance 2nd generation electric shower Electrical requirements Electrical requirements ELECTRICAL REQUIREMENTS Fig.3 - Illustrative purposes only WARNING! W-006-A Triton Showers, THIS APPLIANCE MUST BE EARTHED Triton Road, Nuneaton, Warwickshire, CV11 4NR The installation, supply cable and circuit xxxx protection must conform with BS 7671 (IEE wiring regulations) and be suf cient for the amperage required. - Page 8 Trance 2nd generation electric shower A 45 amp double pole isolating switch with 9.3 In any event, it is essential that individual a minimum contact gap of 3mm in both site conditions are assessed by a competent poles must be incorporated in the circuit.
-
Page 9: Water Requirements
Trance 2nd generation electric shower WATER REQUIREMENTS The installation must be in accordance with Water Regulations/Bylaws. Supply Source ............Mains pressure cold water *Minimum running pressure and flow to 100kPa (1.0 bar) at 8 litres per minute the inlet of the shower for full performance for 8.5Kw - 9.5Kw... -
Page 10: Siting Of The Shower
Trance 2nd generation electric shower SITING OF THE SHOWER WARNING! IMPORTANT: If installing onto a tiled wall The shower must not be positioned W-008-A always mount the unit on the surface of the where it will be subjected to freezing tiles. -
Page 11: Fitting The Shower To The Wall
Trance 2nd generation electric shower FITTING THE SHOWER TO THE WALL Fig.7 WARNING! Check there are no hidden cables or pipes before drilling holes for wall W-005-A plugs. Use great care when using power tools near water. The use of a residual current device (RCD) is recommended. - Page 12 Trance 2nd generation electric shower Screw the top fixing and bottom screws into position leaving the base of the screw heads Fig.10 protruding 6mm out from the wall. Hook the backplate over the top and bottom screws and fit the centre fixing screw into position.
-
Page 13: Plumbing Connections
Trance 2nd generation electric shower PLUMBING CONNECTIONS WARNING! Plumbing to be carried out before wiring The outlet of the shower acts as a W-004-A DO NOT use jointing compounds on any pipe vent and MUST NOT be connected to fittings for the installation. -
Page 14: Electrical Connections
Trance 2nd generation electric shower ELECTRICAL CONNENCTIONS Fig.12 SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAINS. Fig.12 shows a schematic wiring diagram. The cable entry points are shown in fig.1. The cable can be surface clipped, hidden or via 20mm conduit. -
Page 15: Replacing The Cover
Trance 2nd generation electric shower REPLACING THE COVER Fig.14 Refit the trimplate. Turn the POWER selector spindle clockwise to the position shown in Power selector fig.14. spindle Position at Turn the stabiliser valve spindle fully clockwise face on right until resistance is felt (fig.15). -
Page 16: Commissioning
Trance 2nd generation electric shower WARNING Fig.18 Before normal operation of the shower, it Start/Stop switch is essential the following commissioning assembly procedure is completed correctly. COMMISSIONING The first operation of the shower is intended to flush out any remaining unit debris and to make sure the heater unit contains water before the elements are switched on. -
Page 17: Operating The Shower
Trance 2nd generation electric shower OPERATING THE SHOWER Fig.21 Make sure the commissioning procedure has been carried out. To start the shower Press the Start/Stop button and water will flow. High To stop the shower Power Press the Start/Stop button and water will cease selector to flow. - Page 18 Trance 2nd generation electric shower Note: The preferred number on ECONOMY will WARNING! give a different temperature to the same number After any servicing of mains water position on HIGH. supply, always flush out the pipework W-002-A To decrease the shower temperature to remove any debris.
-
Page 19: Operating Functions And Cleaning
Before cleaning, turn off the unit at the isolation switch to avoid the shower being accidentally switched on. Triton recommends that all products are cleaned using warm, soapy water. DO NOT use abrasive or aggressive chemical cleaning products as this may affect the product... -
Page 20: Instructions For Installers And Service Engineers Only
Trance 2nd generation electric shower INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY CLEANING THE INLET FILTER Cleaning the inlet filter Fig.26 It is recommended that the lter is periodically cleaned in order to maintain the performance of the shower. It is essential that this operation is carried out by an installer or service engineer. -
Page 21: Fault Finding
Trance 2nd generation electric shower FAULT FINDING IMPORTANT: Switch OFF the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem Cause Action 1 Shower 1.1 Interrupted power 1.1.1 Blown fuse or circuit breaker. Check inoperable, no supply. - Page 22 Trance 2nd generation electric shower FAULT FINDING Problem Cause Action 4 Water too cool 4.2.5 Fit a pump to give minimum pressure; or cold - cont. contact Customer Experience for advice. 4.3 Reduction in ambient 4.3.1 Adjust flow rate via temperature control.
-
Page 23: Spare Parts
Please have your model name available. WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and compliance with the WEEE directive. - Page 24 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: CXsupport@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2024...
