Product features

The MultiRheo Filter is a stationary filtration unit used for the full-flow and
bypass filtration of low-viscosity fluids. The MRF is used for the separation of
particles 100 µm to 1 µm (absolute) in size.

Filter housing components

The filter housing has the following components:
Item
10
20
30
40
100
110
1 1 1
140
150
MRF1 x
MoWa MRF1 3550863b en-us 2016-06-13.docx
MRF1 E
Description
Filter housing
Filter head
Body seal ring
Coupling nut
Drain plug
Socket
Sealing ring
Screw plug / Clogging indicator
Filter element
