Notes:
1. 1 1/4" diameter conduit access hole.
2. 5/8" plywood floor (must support 142 lbs.).
Important: Because of continuing product improvements, Maytag reserves the right to change specifications without
notice. Dimensional specifications are provided for planning purposes only. For complete details see installation
instructions that accompany each product before selecting cabinetry, making cutouts or beginning installation.
C
I
G
Inches
A
30 minimum
B
24 minimum
C
27 7/8
D
E
28 1/2
F
28 1/4
F
G
29 3/4
H
4 to 33 above floor 10.2 to 83.8 above floor
I
24 7/16
Dimensions
Centimeters
76.2 minimum
61.0 minimum
24
70.8
61
72.4
71.8
75.6
62.1
